CGUIEditableText Class Reference

Specialization of CGUIText that allows for modification and selection of text. More...

#include <GUIEditableText.h>

Inheritance diagram for CGUIEditableText:

Classes
struct	BidiTurningPoint_t
struct	CursorPos_t
	Holds a cursor position. More...

Public Member Functions
	CGUIEditableText (const CGUIObject *const pkParentObject, const eC_String &kText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Value &vTextWidth=eC_FromInt(0), eC_Bool bWordWrap=false)
	CGUIEditableText (const CGUIObject *const pkParentObject, const eC_String *const pkText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Value &vTextWidth=eC_FromInt(0), eC_Bool bWordWrap=false)
	CGUIEditableText (const CGUIObject *const pkParentObject, const TextResource_t &eTextID, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Value &vTextWidth=eC_FromInt(0), eC_Bool bWordWrap=false)
	CGUIEditableText (const CGUIEditableText &rkSource)
	~CGUIEditableText ()
virtual CGUIEditableText *	Clone () const
void	Delete (eC_UInt uiCursorPosAtStartLine, eC_UInt uiCursorPosAtEndLine, eC_UInt uiStartLine=0, eC_UInt uiEndLine=0)
void	DeleteSelection ()
void	ExtendSelection (eC_UInt uiCharIndex, eC_UInt uiLineIndex=0)
CursorPos_t	GetBestCursorPosition (const eC_Value &vRelXPos, const eC_Value &vRelYPos)
CGUIRect	GetCursorAbsRect ()
CursorPos_t	GetCursorPosByCharIndex (eC_UInt uiCharIndex)
CursorPos_t	GetCursorPosition ()
eC_Value	GetCursorWidth () const
CursorPos_t	GetLastCursorPos ()
eC_Value	GetLineHeight ()
eC_Bool	GetLTRpivotField (eC_UInt currentIndex, LeftEmbedding &ltrPivotPair)
eC_UInt	GetLtrTurnPnt (eC_UInt currentIndex)
virtual const eC_String *const	GetPassword ()
eC_Bool	GetRectOfIndex (eC_UInt uiIndex, CGUIRect &rect)
eC_UInt	GetRtlTurnPnt (eC_UInt currentIndex)
eC_String	GetSelectedText ()
eC_UInt	GetSelectionColor () const
CursorPos_t	GetSelectionEnd ()
CursorPos_t	GetSelectionStart ()
eC_String	GetStrOfLine (eC_UInt uiCurrentLine) const
eC_Bool	HasSelection ()
void	Insert (const eC_String &kInsChars)
eC_Bool	IsCursorVisible () const
eC_Bool	IsInLtRField (eC_UInt currentIndex)
eC_Bool	IsLeftToRightEmbedding ()
CGUIEditableText &	operator= (const CGUIEditableText &rkSource)
virtual void	PrintText ()
void	ReadFromStream ()
void	ResetSelection ()
void	ResetTurningPoints ()
void	SelectAll ()
void	SetCursorPosition (eC_UInt uiCursorPosAtLine, eC_UInt uiCurrentLine=0)
void	SetCursorVisible (eC_Bool bVisible)
void	SetCursorWidth (eC_Value vWidth)
void	SetEmbeddingDirection (const eC_Bool bRightToLeft)
virtual void	SetFont (const FontResource_t &eFontID)
void	SetPasswordCharacter (eC_String &kPwdStr)
void	SetPasswordMode (eC_Bool bPasswordMode)
void	SetSelectionColor (const eC_UInt &uiSelectionColor)
void	SetSelectionColor (const GlobalProperty_t &uiSelectionColor)
virtual void	SetTextString (const eC_String &rkTextString)
void	SetWordWrap (eC_Bool bWordWrap, const eC_Value &vWidth=eC_FromInt(0))
void	ToggleCursor ()
virtual void	WriteToStream (const eC_Bool bWriteTextType=false)
Public Member Functions inherited from CGUIText
	CGUIText (const CGUIObject *const pkParentObject, const eC_String &kText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)
	CGUIText (const CGUIObject *const pkParentObject, const eC_String *const pkText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)
	CGUIText (const CGUIObject *const pkParentObject, const TextResource_t &eTextID, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)
	CGUIText (const CGUIText &kTextToBeCopied)
virtual	~CGUIText ()
	Destructor.
void	FitHeightToContainedText ()
void	GetAdjustment (eC_Value &vXAdjustment, eC_Value &vYAdjustment) const
eC_Bool	GetAutoSize () const
const CGUIObject *	GetContainingObject () const
FontResource_t	GetFont () const
eC_Int	GetFontSize () const
eC_Float	GetFontSpacing () const
HorAligned_t	GetHorAlign () const
virtual eC_Value	GetLineSpacing () const
eC_UInt	GetNumberOfLines ()
virtual eC_Value	GetRelXPos () const
virtual eC_Value	GetRelYPos () const
virtual void	GetRequiredOrgTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)
virtual eC_Value	GetRequiredTextHeightForWidth (eC_Value vAvailableWidth=0)
virtual void	GetRequiredTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)
CGUICommonEnums::Rotation_t	GetRotation () const
const CGUIRect &	GetSpecificClipRect () const
const eC_String *	GetText () const
void	GetTextColor (eC_UInt &uiTextColorStandard, eC_UInt &uiTextColorHighlighted, eC_UInt &uiTextColorGrayedOut, eC_UInt &uiTextColorPressed) const
void	GetTextColor (GlobalProperty_t &eTextColorStandard, GlobalProperty_t &eTextColorHighlighted, GlobalProperty_t &eTextColorGrayedOut, GlobalProperty_t &eTextColorPressed) const
eC_UInt	GetTextColorGrayedOut () const
eC_UInt	GetTextColorHighlighted () const
eC_UInt	GetTextColorPressed () const
eC_UInt	GetTextColorStandard () const
virtual eC_Value	GetTextHeight () const
TextResource_t	GetTextID () const
virtual eC_Value	GetTextWidth () const
VerAligned_t	GetVerAlign () const
void	InvalidateArea ()
eC_Bool	IsBidi () const
eC_Bool	IsTextCut ()
eC_Bool	IsTextID () const
eC_Bool	IsTextSingleLine () const
CGUIText &	operator= (const CGUIText &kSource)
void	SetAdjustment (const eC_Value &vXAdjustment, const eC_Value &vYAdjustment)
void	SetAligned (const VerAligned_t &eVerAligned=V_TOP, const HorAligned_t &eHorAligned=H_LEFT)
void	SetAlignedHorizontal (const HorAligned_t &eHorAligned=H_LEFT)
void	SetAlignedVertical (const VerAligned_t &eVerAligned=V_TOP)
void	SetAutoSize (const eC_Bool &bAutoSize)
void	SetContainingObject (const CGUIObject *const pkParent)
void	SetFontSpacing (const eC_Float &fFontSpacing)
virtual void	SetLineSpacing (const eC_Value vLineSpacing)
void	SetRelRect (const CGUIRect &kRect)
virtual void	SetRelXPos (const eC_Value &vRelXPos)
virtual void	SetRelYPos (const eC_Value &vRelYPos)
void	SetRotation (const CGUICommonEnums::Rotation_t eRotation)
void	SetSpecificClipRect (const CGUIRect &kRect)
void	SetTextAlignmentProperty (const GlobalProperty_t &eTextAlignmentProperty)
virtual void	SetTextColor (const eC_UInt &uiTextColorStandard, const eC_UInt &uiTextColorHighlighted, const eC_UInt &uiTextColorGrayedOut, const eC_UInt &uiTextColorPressed)
virtual void	SetTextColor (const GlobalProperty_t &eTextColorStandard, const GlobalProperty_t &eTextColorHighlighted, const GlobalProperty_t &eTextColorGrayedOut, const GlobalProperty_t &eTextColorPressed)
void	SetTextColorGrayedOut (const eC_UInt &uiTextColorGrayedOut)
void	SetTextColorGrayedOut (const GlobalProperty_t &eTextColorPropertyGrayedOut)
void	SetTextColorHighlighted (const eC_UInt &uiTextColorHighlighted)
void	SetTextColorHighlighted (const GlobalProperty_t &eTextColorPropertyHighlighted)
void	SetTextColorPressed (const eC_UInt &uiTextColorPressed)
void	SetTextColorPressed (const GlobalProperty_t &eTextColorPropertyPressed)
void	SetTextColorStandard (const eC_UInt &uiTextColorStandard)
void	SetTextColorStandard (const GlobalProperty_t &eTextColorPropertyStandard)
virtual void	SetTextHeight (const eC_Value &vTextHeight)
virtual void	SetTextID (const TextResource_t &eTextID)
void	SetTextString (const eC_String *pkTextString)
virtual void	SetTextWidth (const eC_Value &vTextWidth)
Public Member Functions inherited from CGUIColorPropertyObserver
	CGUIColorPropertyObserver ()
	default-constructor
	~CGUIColorPropertyObserver ()
	destructor
eC_UInt	AddColorProperty (const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)
void	AddColorProperty (const eC_UInt &uiIndex, const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)
ColorValue_t	GetColorProperty (const eC_UInt &uiIndex) const
eC_UInt	GetColorValue (const eC_UInt &uiIndex) const
virtual void	OnColorPropertyChange ()
void	RemoveColorProperty (const eC_UInt &uiIndex)
void	SetColorProperty (const eC_UInt &uiIndex, const eC_UInt &uiColorValue)
void	SetColorProperty (const eC_UInt &uiIndex, const GlobalProperty_t &eColorProperty)
void	SetColorProperty (const eC_UInt &uiIndex, const ColorValue_t &kColorValue)
Public Member Functions inherited from CGUIObserver
	CGUIObserver ()
	Default constructor.
virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.
const eC_TListDoubleLinked < CGUISubject * > &	GetSubjectList () const
virtual void	OnNotification (const eC_String &kMessage)
virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)
virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)
void	SetAutoDelete (const eC_Bool bAutoDelete)
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
void	SetXMLTag (const eC_String &kXMLTag)

Public Attributes
BidiTurningPoint_t	m_kBidiTurnPoints
	turning-points

Additional Inherited Members
Public Types inherited from CGUIText
enum	HorAligned_t { H_LEFT, H_CENTERED, H_RIGHT, H_PROPERTY }
	Possible horizontal alignments. More...
enum	TextColorTypeFlags_t { TEXT_COLOR_STANDARD_IS_PROPERTY = 1, TEXT_COLOR_HIGHLIGHTED_IS_PROPERTY = 2, TEXT_COLOR_GRAYED_OUT_IS_PROPERTY = 4, TEXT_COLOR_PRESSED_IS_PROPERTY = 8 }
	Enumeration indicating if a property or a color value is used for each text color.
enum	VerAligned_t { V_TOP, V_CENTERED, V_BOTTOM }
	Possible vertical alignments. More...
Static Public Member Functions inherited from CGUIText
static eC_String	GetEllipsisString ()
static eC_String	GetHyphenString ()
static void	SetEllipsisString (const eC_String &kEllipsis)
static void	SetHyphenString (const eC_String &kHyphen)
Static Public Attributes inherited from CGUIText
static const eC_Char	XMLTAG_TEXT_COLOR_GRAYEDOUT [] = "TextColorGrayedOut"
	xml-tag for grayedout-color
static const eC_Char	XMLTAG_TEXT_COLOR_HIGHLIGHTED [] = "TextColorHighlighted"
	xml-tag for highlighted-color
static const eC_Char	XMLTAG_TEXT_COLOR_PRESSED [] = "TextColorPressed"
	xml-tag for pressed-color
static const eC_Char	XMLTAG_TEXT_COLOR_PROPERTY_FLAGS [] = "ColorPropertyFlags"
	XML tag to be used when writing text colors into a stream. More...
static const eC_Char	XMLTAG_TEXT_COLOR_STANDARD [] = "TextColorStandard"
	xml-tag for standard-color
static const eC_Char	XMLTAG_TEXTID [] = "TextID"
	XML tag to be used when writing a text ID into a stream.
static const eC_Char	XMLTAG_TEXTTYPEID [] = "TextTypeID"
	XML tag to be used when writing a text type ID into a stream.
Protected Types inherited from CGUIText
typedef eC_TListDoubleLinked < ExtendedString_t >	ExtendedStringList_t
	The extended string list is a double-linked list of extended strings.
typedef eC_TListDoubleLinked < eC_UInt >	UIntList
	Double linked List of unsigned integers.
Protected Member Functions inherited from CGUIText
virtual void	AdaptText ()
eC_Bool	ContainsHyphenationMarks (const eC_String &kStr) const
void	CreateLocalTextCopy ()
virtual void	FitString (ExtendedString_t &rkResultStrData, const eC_String &rkStrToAnalyse, eC_String &rkRestStr, eC_UInt &uiOffset)
virtual eC_Value	GetHorStartAbsXPos ()
virtual eC_Value	GetPrintLineAbsXPos (const eC_Value &vWidth, const eC_Value &vHeight)
virtual eC_Value	GetPrintLineAbsXPos (const eC_UInt uiLine)
virtual eC_Value	GetPrintLineAbsXPos ()
virtual eC_Value	GetPrintLineAbsYPos (const eC_Value &vWidth, const eC_Value &vHeight)
virtual eC_Value	GetPrintLineAbsYPos (const eC_UInt uiLine)
virtual eC_Value	GetPrintLineAbsYPos ()
eC_Value	GetRequiredTextHeight () const
eC_Value	GetRequiredTextWidth () const
virtual eC_Value	GetVerStartAbsYPos ()
virtual void	OnNotification ()
eC_Bool	PrepareClipRect ()
virtual void	PreparePrint ()
void	ReadFontColors (const eC_UInt uiVersion)
void	SetRequiredTextHeight (eC_Value vRequiredTextHeight)
void	SetRequiredTextWidth (eC_Value vRequiredTextWidth)
void	SetTextCut (const eC_Bool bIsCut)
void	WriteFontColors ()
	Helper function for WriteStream().
Protected Attributes inherited from CGUIText
eC_Bool	m_bAdaptText
eC_Bool	m_bSingleLine
	Indicates whether this text is single- or multi-line.
eC_Bool	m_bTextCut
	Indicates whether the text is cut and has an appended ellipsis.
eC_Bool	m_bTextIDLocalCopy
eC_Bool	m_bTextIsBiDi
	Indicates whether the text is a BiDi-text.
eC_Bool	m_bUseEllipsis
	use ellipsis if text is too long
FontResource_t	m_eFont
	Font ID for this text object.
HorAligned_t	m_eHorAligned
	Horizontal alignment.
CGUICommonEnums::Rotation_t	m_eRotation
	rotation for the text
GlobalProperty_t	m_eTextAlignmentProperty
	Property used for the text color for alignment. By default, this value is DUMMY_PROPERTY, i.e. a fixed alignment is used.
TextResource_t	m_eTextID
VerAligned_t	m_eVerAligned
	Vertical alignment.
eC_Float	m_fFontSpacing
	Font spacing for the text object.
UIntList	m_kHyphens
	List of hyphen positions in the original text.
ExtendedStringList_t	m_kListStringsExtended
	List of strings to be printed, and their cached width and height.
const CGUIObject *	m_pkParentObject
	The object containing (and printing) this text.
eC_String *	m_pkText
eC_Value	m_vLineHeight
	The height of one text line with this text's font.
eC_Value	m_vLineSpacing
	The line spacing factor.
eC_Value	m_vRelXPos
	X position of this text's printing area relative to the parent object.
eC_Value	m_vRelYPos
	Y position of this text's printing area relative to the parent object.
eC_Value	m_vRequiredOrgTextHeight
eC_Value	m_vRequiredOrgTextWidth
eC_Value	m_vTextHeight
	Height of this text's printing area.
eC_Value	m_vTextWidth
	Width of this text's printing area.
eC_Value	m_vXAdjustment
	Printing adjustment for m_vRelXPos.
eC_Value	m_vYAdjustment
	Printing adjustment for m_vRelYPos.
Static Protected Attributes inherited from CGUIText
static const ExtendedString_t	ms_ckEmptyExtendedString
	An empty Extended String.
static const eC_String	ms_ckEmptyString
	An empty string.
static const eC_String	ms_ckSingleSpace
	A single space character for text size calculations.

Detailed Description

Specialization of CGUIText that allows for modification and selection of text.

This text maintains a cursor position and a selection, which can be thought of as two cursor positions. A cursor position is defined as a point (described by CursorPos_t) denoting the position of a character. Cursor position (W, Y) indicates that the cursor is to the left of the W-th character in Line Y. The default cursor position after constructing an instance of this class is at the end of the text.

The cursor position can be visualized by drawing a cursor whose width and visibility can be influenced. The cursor is represented by a vertical line that has the same height as one text line and a configurable width (default is 1 pixel).

The color of the base class (CGUIText) standard text is used. Note that since this text is no CGUIObject it does not perform a blinking animation for the cursor, it rather draws the cursor or not. See CGUIEdit or CGUIMultiLineEdit for controls that use this text to display a blinking cursor.

A continuous portion of the text can be selected. The selection range is described by two cursor positions, a 'start' and an 'end' position relative to the cursor position. If these two values are the same, no text is selected. If they differ, the text from 'start' to 'end' is selected and is marked visually by a different background color, which is also configurable, see SetSelectionColor(). There are various methods to influence the selection from outside and to obtain information about the current selection.

It is possible to insert a string into the text at current cursor position or delete string from the text by giving start and end cursor positions.

The word wrap functionality is enabled at construction time. It can also be configured with SetWordWrap().

The password mode enables the editable text to obfuscate the input using a specified character that is displayed instead of the actual user input.

Note that only left-aligned text is allowed within GUIEditableText.

Constructor & Destructor Documentation

CGUIEditableText::CGUIEditableText	(	const CGUIObject *const	pkParentObject,
		const eC_String &	kText,
		const eC_Value &	vXPos = eC_FromInt(0),
		const eC_Value &	vYPos = eC_FromInt(0),
		const eC_Value &	vTextWidth = eC_FromInt(0),
		eC_Bool	bWordWrap = false
	)

Constructor. With word wrap is enabled, the default width is set to be given width. If word wrap is disabled, the default width is set to be the required width of the given text string.

Parameters

pkParentObject	Pointer to object containing the text.
kText	Reference of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
vTextWidth	The width of the text.
bWordWrap	false: text is always displayed in a single line, true: lines can be wrapped.

CGUIEditableText::CGUIEditableText	(	const CGUIObject *const	pkParentObject,
		const eC_String *const	pkText,
		const eC_Value &	vXPos = eC_FromInt(0),
		const eC_Value &	vYPos = eC_FromInt(0),
		const eC_Value &	vTextWidth = eC_FromInt(0),
		eC_Bool	bWordWrap = false
	)

Constructor. With word wrap is enabled, the default width is set to be given width. If word wrap is disabled, the default width is set to be the required width of the given text string.

Parameters

pkParentObject	Pointer to object containing the text.
pkText	Pointer of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
vTextWidth	The width of the text.
bWordWrap	false: text is always displayed in a single line, true: lines can be wrapped.

CGUIEditableText::CGUIEditableText	(	const CGUIObject *const	pkParentObject,
		const TextResource_t &	eTextID,
		const eC_Value &	vXPos = eC_FromInt(0),
		const eC_Value &	vYPos = eC_FromInt(0),
		const eC_Value &	vTextWidth = eC_FromInt(0),
		eC_Bool	bWordWrap = false
	)

Constructor. With word wrap is enabled, the default width is set to be given width. If word wrap is disabled, the default width is set to be the required width of the given text string.

Parameters

pkParentObject	Pointer to object containing the text.
eTextID	TextID
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
vTextWidth	The width of the text.
bWordWrap	false: text is always displayed in a single line, true: lines can be wrapped.

CGUIEditableText::CGUIEditableText

(

const CGUIEditableText &

rkSource)

Copy constructor.

Parameters

rkSource

The text instance to be copied.

CGUIEditableText::~CGUIEditableText

(

)

Destructor.

Member Function Documentation

CGUIEditableText * CGUIEditableText::Clone ( ) const

virtual

Clones the instance of the GUIEditableText object.

Returns

Pointer to the cloned GUIEditableText object.

Reimplemented from CGUIText.

void CGUIEditableText::Delete	(	eC_UInt	uiCursorPosAtStartLine,
		eC_UInt	uiCursorPosAtEndLine,
		eC_UInt	uiStartLine = 0,
		eC_UInt	uiEndLine = 0
	)

Delete strings from the start cursor position of given start line and column to the end cursor position of given end line and column.

Parameters

uiCursorPosAtStartLine	The cursor position index of the line where the deletion starts.
uiCursorPosAtEndLine	The cursor position index of the line where the deletion finishes.
uiStartLine	Line where the deletion starts.
uiEndLine	Line where the deletion finishes.

void CGUIEditableText::DeleteSelection

(

)

Deletes the current selection. Results in a call to Delete() with the current selection start/end indices.

void CGUIEditableText::ExtendSelection	(	eC_UInt	uiCharIndex,
		eC_UInt	uiLineIndex = 0
	)

Extends the current selection up to a specific position. The selection area is from the current cursor to the specific position, and the current cursor position becomes the specific position.

Parameters

uiCharIndex	The character index up to which the selection is extended.
uiLineIndex	The line up to which the selection is extended.

CGUIEditableText::CursorPos_t CGUIEditableText::GetBestCursorPosition	(	const eC_Value &	vRelXPos,
		const eC_Value &	vRelYPos
	)

Finds the closest cursor position to an arbitrary pixel position, for instance a mouse position.

Parameters

vRelXPos	X position relative to this text's containing CGUIObject.
vRelYPos	Y position relative to this text's containing CGUIObject.

Returns

The cursor position to be obtained.

See Also

CursorPos_t

CGUIRect CGUIEditableText::GetCursorAbsRect

(

)

Get the absolute rectangle of the cursor.

Returns

The absolute rectangle of the cursor.

CGUIEditableText::CursorPos_t CGUIEditableText::GetCursorPosByCharIndex

(

eC_UInt

uiCharIndex)

Get the cursor position by the char index of the current text string.

Parameters

uiCharIndex

The char index of the current text. Note: The char index starts from 1.

Returns

The cursor position to be found.

See Also

CursorPos_t

CGUIEditableText::CursorPos_t CGUIEditableText::GetCursorPosition

(

)

Get the cursor position index and the line where the cursor locates.

Returns

The cursor position and current line stored in CursorPos_t structure.

See Also

CursorPos_t

eC_Value CGUIEditableText::GetCursorWidth

(

)

const

Returns the width of the cursor.

Returns

the width of the vertical cursor line.

CGUIEditableText::CursorPos_t CGUIEditableText::GetLastCursorPos

(

)

Determines the last valid cursor position of this text (position after the last character).

Returns

The last cursor position.

See Also

CursorPos_t

eC_Value CGUIEditableText::GetLineHeight ( )

inline

Returns the height of one line of text. Not to be confused with GetTextHeight().

Returns

line-height

eC_Bool CGUIEditableText::GetLTRpivotField	(	eC_UInt	currentIndex,
		LeftEmbedding &	ltrPivotPair
	)

Get left-to-right turning-points

Parameters

currentIndex
ltrPivotPair

Returns

true if ...

eC_UInt CGUIEditableText::GetLtrTurnPnt

(

eC_UInt

currentIndex)

Get left-to-right turning-points

Parameters

currentIndex

Returns

turning-point

const eC_String *const CGUIEditableText::GetPassword ( )

virtual

Retrieves the password. If the text is currently not in password mode, the visible text is returned.

Returns

A pointer to the password or visible text.

eC_Bool CGUIEditableText::GetRectOfIndex	(	eC_UInt	uiIndex,
		CGUIRect &	rect
	)

Return the region for an index

Parameters

uiIndex	index
rect	rect for the index

Returns

true if index was valid

eC_UInt CGUIEditableText::GetRtlTurnPnt

(

eC_UInt

currentIndex)

Get right-to-left turning-points

Parameters

currentIndex

Returns

turning-point

eC_String CGUIEditableText::GetSelectedText

(

)

Returns the currently selected text.

Returns

The selected text if there is selection, otherwise an empty string.

eC_UInt CGUIEditableText::GetSelectionColor

(

)

const

Returns the background color of selected text.

Returns

the background color of selected text.

CGUIEditableText::CursorPos_t CGUIEditableText::GetSelectionEnd

(

)

Get the selected end cursor position and the end line. Note: The cursor index starts at 0.

Returns

The cursor position and end line stored in CursorPos_t structure.

See Also

CursorPos_t

CGUIEditableText::CursorPos_t CGUIEditableText::GetSelectionStart

(

)

Get the selected start cursor position and the start line.

Returns

The cursor position and start line stored in CursorPos_t structure.

See Also

CursorPos_t

eC_String CGUIEditableText::GetStrOfLine

(

eC_UInt

uiCurrentLine)

const

Get the string of the given line.

Parameters

uiCurrentLine

The line number

Returns

The string of the given line.

eC_Bool CGUIEditableText::HasSelection

(

)

Determines whether this text currently has a selection.

Returns

True if there is a selection, otherwise False.

void CGUIEditableText::Insert

(

const eC_String &

kInsChars)

Inserts characters at the current cursor position. After this call returns, the cursor is positioned at the end of the inserted text.

Parameters

kInsChars

The character string to be inserted.

eC_Bool CGUIEditableText::IsCursorVisible

(

)

const

Determines the current visibility of the cursor.

Returns

True if the cursor is currently visible, otherwise False.

eC_Bool CGUIEditableText::IsInLtRField

(

eC_UInt

currentIndex)

Return if index is in ltr-field

Parameters

currentIndex

Returns

true if in ltr-field

eC_Bool CGUIEditableText::IsLeftToRightEmbedding

(

)

Return if text is containing LTR-embedding

Returns

true if contains embedding

CGUIEditableText & CGUIEditableText::operator=

(

const CGUIEditableText &

rkSource)

Assignment operator.

Parameters

rkSource

Text instance, which is the source of the assignment.

Returns

The assignment destination

void CGUIEditableText::PrintText ( )

virtual

Draws the text and everything that belongs to it. This includes drawing the selection if there is one, calling the base class implementation to print the text and drawing the cursor if it is set to be visible.

See Also

SetSelectionColor()

SetCursorVisible()

CGUIText::PrintText()

Reimplemented from CGUIText.

void CGUIEditableText::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See Also

CGUIObject::ReadFromStream()

Reimplemented from CGUIText.

void CGUIEditableText::ResetSelection

(

)

Deselects all characters so that there is no selection.

Note

Internally, this method sets the selection 'start' and 'end' positions equal to the current cursor position. This way, a subsequent call to ExtendSelection() starts the 'new' selection at this position.

void CGUIEditableText::ResetTurningPoints

(

)

Reset all turning points

void CGUIEditableText::SelectAll

(

)

Selects all characters and positions the cursor at the end of the text.

void CGUIEditableText::SetCursorPosition	(	eC_UInt	uiCursorPosAtLine,
		eC_UInt	uiCurrentLine = 0
	)

Set the cursor position of given line. Note: The cursor position starts at 0.

Parameters

uiCursorPosAtLine	The cursor position.
uiCurrentLine	The line where the cursor locates.

void CGUIEditableText::SetCursorVisible

(

eC_Bool

bVisible)

Sets the cursor visibility. If the cursor is set to visible, it is drawn in the next call of PrintText().

Parameters

bVisible

The visibility of the cursor.

void CGUIEditableText::SetCursorWidth

(

eC_Value

vWidth)

Sets the width of the cursor.

Parameters

vWidth

The width of the vertical cursor line.

void CGUIEditableText::SetEmbeddingDirection

(

const eC_Bool

bRightToLeft)

Set the embedding direction

Parameters

bRightToLeft

void CGUIEditableText::SetFont ( const FontResource_t &  eFontID)

virtual

Calls the base class implementation and updates the character widths.

Parameters

eFontID

The new font for the text.

Reimplemented from CGUIText.

void CGUIEditableText::SetPasswordCharacter

(

eC_String &

kPwdStr)

Activate the password mode to obfuscate the input using a specified character that is displayed instead.

Parameters

kPwdStr

The character that shall be displayed. Pass an empty string to disable the password mode and display readable text.

void CGUIEditableText::SetPasswordMode

(

eC_Bool

bPasswordMode)

Set the password-mode or clear it

Parameters

bPasswordMode

state of password-mode

void CGUIEditableText::SetSelectionColor

(

const eC_UInt &

uiSelectionColor)

Sets the color used for drawing the background of selected text.

Parameters

uiSelectionColor

The background color of selected text.

void CGUIEditableText::SetSelectionColor

(

const GlobalProperty_t &

uiSelectionColor)

Sets the color used for drawing the background of selected text.

Parameters

uiSelectionColor

The background color of selected text.

void CGUIEditableText::SetTextString ( const eC_String &  rkTextString)

virtual

Replaces the current text with another one. This results in deleting the current text and inserting the new one. The cursor position is at the beginning of the new text and ResetSelection() is called.

Note

This is a time-consuming function.

Parameters

rkTextString

The new text.

Reimplemented from CGUIText.

void CGUIEditableText::SetWordWrap	(	eC_Bool	bWordWrap,
		const eC_Value &	vWidth = eC_FromInt(0)
	)

Enables or disables the word wrap functionalities. If the word wrap is enabled, the text width is set to be the given width. Otherwise, the text width is adjusted to be the required width of current text string.

Parameters

bWordWrap	Indicate whether the word wrap is enabled or not.
vWidth	The width that is set to the control is the word wrap is enabled.

void CGUIEditableText::ToggleCursor

(

)

Toggles the cursor visibility. Convenience method for controls that implement a blinking cursor.

See Also

SetCursorVisible()

void CGUIEditableText::WriteToStream ( const eC_Bool  bWriteTextType = false)

virtual

Called by the framework when writing streaming files. When deriving a new text class in an application, re-implement this method.

Parameters

bWriteTextType

Indicates whether the ID needs to be written. If the framework calls this method, it passes true here. The base class implementation has to be called with false (default). If called with true, the first two tags written must be this text's XML name tag (see GetXMLTag()) and its text type ID. After all attributes are written, the name tag has to be written again as a closing tag (preceded by a slash).

Reimplemented from CGUIText.

---

The documentation for this class was generated from the following files:

• GUIEditableText.h
• GUIEditableText.cpp
