Class for handling a text. More...

#include <GUIText.h>

Inheritance diagram for CGUIText:

[legend]

Classes
class	ExtendedString_t
	Class containing a text, its width and its height. More...

Public Types
enum	HorAligned_t { H_LEFT , H_CENTERED , H_RIGHT , H_PROPERTY }
	Possible horizontal alignments. More...

enum	TextColorTypeFlags_t { TEXT_COLOR_STANDARD_IS_PROPERTY = 1 , TEXT_COLOR_HIGHLIGHTED_IS_PROPERTY = 2 , TEXT_COLOR_GRAYED_OUT_IS_PROPERTY = 4 , TEXT_COLOR_PRESSED_IS_PROPERTY = 8 }
	Enumeration indicating if a property or a color value is used for each text color.

enum	VerAligned_t { V_TOP , V_CENTERED , V_BOTTOM }
	Possible vertical alignments. More...

Public Member Functions
	CGUIText (const CGUIObject *const pkParentObject, const eC_String &kText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIObject const pkParentObject, const eC_String const pkText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIObject *const pkParentObject, const TextResource_t &eTextID, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIText &kTextToBeCopied)

virtual	~CGUIText ()
	Destructor.

virtual CGUIText *	Clone () const

void	FitHeightToContainedText ()

void	GetAdjustment (eC_Value &vXAdjustment, eC_Value &vYAdjustment) const

eC_Bool	GetAutoSize () const

const CGUIObject *	GetContainingObject () const

FontResource_t	GetFont () const

eC_Int	GetFontSize () const

eC_Float	GetFontSpacing () const

HorAligned_t	GetHorAlign () const

virtual eC_Value	GetLineSpacing () const

eC_UInt	GetNumberOfLines ()

virtual eC_Value	GetRelXPos () const

virtual eC_Value	GetRelYPos () const

virtual void	GetRequiredOrgTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)

virtual eC_Value	GetRequiredTextHeightForWidth (eC_Value vAvailableWidth=0)

virtual void	GetRequiredTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)

CGUICommonEnums::Rotation_t	GetRotation () const

const CGUIRect &	GetSpecificClipRect () const

const eC_String *	GetText () const

void	GetTextColor (eC_UInt &uiTextColorStandard, eC_UInt &uiTextColorHighlighted, eC_UInt &uiTextColorGrayedOut, eC_UInt &uiTextColorPressed) const

void	GetTextColor (GlobalProperty_t &eTextColorStandard, GlobalProperty_t &eTextColorHighlighted, GlobalProperty_t &eTextColorGrayedOut, GlobalProperty_t &eTextColorPressed) const

eC_UInt	GetTextColorGrayedOut () const

eC_UInt	GetTextColorHighlighted () const

eC_UInt	GetTextColorPressed () const

eC_UInt	GetTextColorStandard () const

virtual eC_Value	GetTextHeight () const

TextResource_t	GetTextID () const

virtual eC_Value	GetTextWidth () const

VerAligned_t	GetVerAlign () const

void	InvalidateArea ()

eC_Bool	IsBidi () const

eC_Bool	IsTextCut ()

eC_Bool	IsTextID () const

eC_Bool	IsTextSingleLine () const

CGUIText &	operator= (const CGUIText &kSource)

virtual void	PrintText ()

virtual void	ReadFromStream ()

void	SetAdjustment (const eC_Value &vXAdjustment, const eC_Value &vYAdjustment)

void	SetAligned (const VerAligned_t &eVerAligned=V_TOP, const HorAligned_t &eHorAligned=H_LEFT)

void	SetAlignedHorizontal (const HorAligned_t &eHorAligned=H_LEFT)

void	SetAlignedVertical (const VerAligned_t &eVerAligned=V_TOP)

void	SetAutoSize (const eC_Bool &bAutoSize)

void	SetContainingObject (const CGUIObject *const pkParent)

virtual void	SetFont (const FontResource_t &eFontID)

void	SetFontSpacing (const eC_Float &fFontSpacing)

virtual void	SetLineSpacing (const eC_Value vLineSpacing)

void	SetRelRect (const CGUIRect &kRect)

virtual void	SetRelXPos (const eC_Value &vRelXPos)

virtual void	SetRelYPos (const eC_Value &vRelYPos)

void	SetRotation (const CGUICommonEnums::Rotation_t eRotation)

void	SetSpecificClipRect (const CGUIRect &kRect)

void	SetTextAlignmentProperty (const GlobalProperty_t &eTextAlignmentProperty)

virtual void	SetTextColor (const eC_UInt &uiTextColorStandard, const eC_UInt &uiTextColorHighlighted, const eC_UInt &uiTextColorGrayedOut, const eC_UInt &uiTextColorPressed)

virtual void	SetTextColor (const GlobalProperty_t &eTextColorStandard, const GlobalProperty_t &eTextColorHighlighted, const GlobalProperty_t &eTextColorGrayedOut, const GlobalProperty_t &eTextColorPressed)

void	SetTextColorGrayedOut (const eC_UInt &uiTextColorGrayedOut)

void	SetTextColorGrayedOut (const GlobalProperty_t &eTextColorPropertyGrayedOut)

void	SetTextColorHighlighted (const eC_UInt &uiTextColorHighlighted)

void	SetTextColorHighlighted (const GlobalProperty_t &eTextColorPropertyHighlighted)

void	SetTextColorPressed (const eC_UInt &uiTextColorPressed)

void	SetTextColorPressed (const GlobalProperty_t &eTextColorPropertyPressed)

void	SetTextColorStandard (const eC_UInt &uiTextColorStandard)

void	SetTextColorStandard (const GlobalProperty_t &eTextColorPropertyStandard)

virtual void	SetTextHeight (const eC_Value &vTextHeight)

virtual void	SetTextID (const TextResource_t &eTextID)

virtual void	SetTextSingleLine (const eC_Bool &bSingleLine)

virtual void	SetTextString (const eC_String &kTextString)

void	SetTextString (const eC_String *pkTextString)

virtual void	SetTextWidth (const eC_Value &vTextWidth)

virtual void	WriteToStream (const eC_Bool bWriteTextType=false)

Public Member Functions inherited from CGUIColorPropertyObserver
	CGUIColorPropertyObserver ()
	default-constructor

	~CGUIColorPropertyObserver ()
	destructor

eC_UInt	AddColorProperty (const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

void	AddColorProperty (const eC_UInt &uiIndex, const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

ColorValue_t	GetColorProperty (const eC_UInt &uiIndex) const

eC_UInt	GetColorValue (const eC_UInt &uiIndex) const

virtual void	OnColorPropertyChange ()

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

void	RemoveColorProperty (const eC_UInt &uiIndex)

void	SetColorProperty (const eC_UInt &uiIndex, const ColorValue_t &kColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const eC_UInt &uiColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const GlobalProperty_t &eColorProperty)

Public Member Functions inherited from CGUIObserver
	CGUIObserver ()
	Default constructor.

virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.

const eC_TListDoubleLinked< CGUISubject * > &	GetSubjectList () const

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)

virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)

virtual void	OnNotification (const eC_String &kMessage)

void	SetAutoDelete (const eC_Bool bAutoDelete)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Member Functions
static eC_String	GetEllipsisString ()

static eC_String	GetHyphenString ()

static void	SetEllipsisString (const eC_String &kEllipsis)

static void	SetHyphenString (const eC_String &kHyphen)

Static Public Attributes
static const eC_Char	XMLTAG_TEXT_COLOR_GRAYEDOUT []
	xml-tag for grayedout-color

static const eC_Char	XMLTAG_TEXT_COLOR_HIGHLIGHTED []
	xml-tag for highlighted-color

static const eC_Char	XMLTAG_TEXT_COLOR_PRESSED []
	xml-tag for pressed-color

static const eC_Char	XMLTAG_TEXT_COLOR_PROPERTY_FLAGS []
	XML tag to be used when writing text colors into a stream. More...

static const eC_Char	XMLTAG_TEXT_COLOR_STANDARD []
	xml-tag for standard-color

static const eC_Char	XMLTAG_TEXTID []
	XML tag to be used when writing a text ID into a stream.

static const eC_Char	XMLTAG_TEXTTYPEID []
	XML tag to be used when writing a text type ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Types
typedef eC_TListDoubleLinked< ExtendedString_t >	ExtendedStringList_t
	The extended string list is a double-linked list of extended strings.

typedef eC_TListDoubleLinked< eC_UInt >	UIntList
	Double linked List of unsigned integers.

Protected Member Functions
virtual void	AdaptText ()

virtual void	CollectHyphenationMarks (eC_String &rkStr, eC_UInt uiOffset)

eC_Bool	ContainsHyphenationMarks (const eC_String &kStr) const

void	CreateLocalTextCopy ()

virtual void	FitString (ExtendedString_t &rkResultStrData, const eC_String &rkStrToAnalyse, eC_String &rkRestStr, eC_UInt &uiOffset)

virtual eC_Value	GetHorStartAbsXPos ()

virtual eC_Value	GetPrintLineAbsXPos ()

virtual eC_Value	GetPrintLineAbsXPos (const eC_UInt uiLine)

virtual eC_Value	GetPrintLineAbsXPos (const eC_Value &vWidth, const eC_Value &vHeight)

virtual eC_Value	GetPrintLineAbsYPos ()

virtual eC_Value	GetPrintLineAbsYPos (const eC_UInt uiLine)

virtual eC_Value	GetPrintLineAbsYPos (const eC_Value &vWidth, const eC_Value &vHeight)

eC_Value	GetRequiredTextHeight () const

eC_Value	GetRequiredTextWidth () const

virtual eC_Value	GetVerStartAbsYPos ()

virtual void	OnNotification ()

eC_Bool	PrepareClipRect ()

virtual void	PreparePrint ()

void	ReadFontColors (const eC_UInt uiVersion)

void	SetRequiredTextHeight (eC_Value vRequiredTextHeight)

void	SetRequiredTextWidth (eC_Value vRequiredTextWidth)

void	SetTextCut (const eC_Bool bIsCut)

void	WriteFontColors ()
	Helper function for WriteStream().

Protected Member Functions inherited from CGUIObserver
virtual void	AddSubject (CGUISubject *pSubjectToAdd)

virtual void	RemoveSubject (CGUISubject *pSubjectToRemove)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
eC_Bool	m_bAdaptText

eC_Bool	m_bSingleLine
	Indicates whether this text is single- or multi-line.

eC_Bool	m_bTextCut
	Indicates whether the text is cut and has an appended ellipsis.

eC_Bool	m_bTextIDLocalCopy

eC_Bool	m_bTextIsBiDi
	Indicates whether the text is a BiDi-text.

eC_Bool	m_bUseEllipsis
	use ellipsis if text is too long

FontResource_t	m_eFont
	Font ID for this text object.

HorAligned_t	m_eHorAligned
	Horizontal alignment.

CGUICommonEnums::Rotation_t	m_eRotation
	rotation for the text

GlobalProperty_t	m_eTextAlignmentProperty
	Property used for the text color for alignment. By default, this value is DUMMY_PROPERTY, i.e. a fixed alignment is used.

TextResource_t	m_eTextID

VerAligned_t	m_eVerAligned
	Vertical alignment.

eC_Float	m_fFontSpacing
	Font spacing for the text object.

UIntList	m_kHyphens
	List of hyphen positions in the original text.

ExtendedStringList_t	m_kListStringsExtended
	List of strings to be printed, and their cached width and height.

const CGUIObject *	m_pkParentObject
	The object containing (and printing) this text.

eC_String *	m_pkText

eC_Value	m_vLineHeight
	The height of one text line with this text's font.

eC_Value	m_vLineSpacing
	The line spacing factor.

eC_Value	m_vRelXPos
	X position of this text's printing area relative to the parent object.

eC_Value	m_vRelYPos
	Y position of this text's printing area relative to the parent object.

eC_Value	m_vRequiredOrgTextHeight

eC_Value	m_vRequiredOrgTextWidth

eC_Value	m_vTextHeight
	Height of this text's printing area.

eC_Value	m_vTextWidth
	Width of this text's printing area.

eC_Value	m_vXAdjustment
	Printing adjustment for m_vRelXPos.

eC_Value	m_vYAdjustment
	Printing adjustment for m_vRelYPos.

Static Protected Attributes
static const ExtendedString_t	ms_ckEmptyExtendedString
	An empty Extended String.

static const eC_String	ms_ckEmptyString
	An empty string.

static const eC_String	ms_ckSingleSpace
	A single space character for text size calculations.

Detailed Description

Class for handling a text.

Objects of this class represent texts but are no CGUIObject instances. They are instead assigned to a "parent" GUI object that has to take care of printing the text in its DoDraw implementation when needed. Controls (CGUIObjects) that want to display text should use CGUIText. For an example of how to print a simple text somewhere in your GUI, have a look at CGUIBaseTextField.

Each text object has basic attributes like font, text color and so on. It also has an area in which the text is aligned. This area is positioned relative to its containing ("parent") GUI object and can be adjusted by calling the methods SetRelXPos(), SetRelYPos(), SetTextWidth() and SetTextHeight(). The horizontal and vertical alignment can be set by calling SetAligned().

Clipping is done at the borders of the assigned containing CGUIObject but no extra clipping is done for the area in which the text is aligned. The area in which the text is aligned does only matter for formatting and positioning the text (line wrapping, cutting with ellipsis, position offset from containing object) but not for clipping. Therefore, if part of CGUIText's area is outside of CGUIObject's area and text is placed into this part then part of the text will be invisible because of clipping CGUIObject. That is, the text graphics belong to the graphics of the assigned containing CGUIObject in the same way as all other graphic of that GUI object.

A text is either a single-line or multi-line text (set either at construction time or later by calling SetTextSingleLine()). A single line text always shows only one line of text, whereas in multi-line mode the text may be wrapped at blank characters to achieve optimum line width usage. To further optimise line width usage, it is possible to enter "soft hyphenation" markers ("\-") in texts. These markers are not printed but enable multi-line texts to break words into pieces and insert hyphens in these places.

To print the character sequence backslash minus ("\-"), another backspace has to be prefixed to escape the special meaning, like this: "\\-".

To force linebreaks, enter ccLinebreak characters into the text.

In both single and multi-line texts, the text is cut off if it is too long to be displayed in its CGUIText area and an ellipsis ("...") is appended at the end. Certainly the ellipsis will be inside CGUIText's area.

Objects of this class can represent two different kinds of text: ID texts and string texts. An ID text is represented by a valid TextResource_t ID that is used to access the text in CGUILocalisationHandler whereas string texts manage an independent string on their own. Each text object internally has a text ID but only ID texts have a valid one; for string texts, the ID is invalid (TEXT_START_TAG). To determine what kind of text an object is, call IsTextID(). A CGUIText object can change its type during its lifetime if SetTextString() or SetTextID() is called.

Example:

// Create a text.
CGUIText* pkText = new CGUIText(this,                           // attach to "this" object
"Hello World!",                 // Text to display in this text object
eC_FromInt(0), eC_FromInt(0),   // Position at coordinates 0,0 relative to containing object
true);                          // This text shall be single-line (=no word wrap)

// Sets the font.
pkText->SetFont(FontResource_t(GUI_PROP_DEFAULT_FONT));

// The colors of the text. They are used for different states of the containing object.
pkText->SetTextColor(0xffff0000, 0xffff00ff, 0xff0000ff, 0xff00ffff);

// Print text. This method is normally called in the DoDraw method of the containing object.
pkText->PrintText();

Member Enumeration Documentation

◆ HorAligned_t

enum CGUIText::HorAligned_t

Possible horizontal alignments.

Enumerator
H_LEFT	The text is left-aligned.
H_CENTERED	The text is horizontally centered.
H_RIGHT	The text is right-aligned.
H_PROPERTY	The text is aligned according to property.

◆ VerAligned_t

enum CGUIText::VerAligned_t

Possible vertical alignments.

Enumerator
V_TOP	The text is aligned at the top of its area.
V_CENTERED	The text is vertically centered in its area.
V_BOTTOM	The text is aligned at the bottom of its area.

Constructor & Destructor Documentation

◆ CGUIText() [1/4]

CGUIText::CGUIText	(	const CGUIObject *const	pkParentObject,
		const eC_String &	kText,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs a string text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
kText	Reference of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIText() [2/4]

CGUIText::CGUIText	(	const CGUIObject *const	pkParentObject,
		const eC_String *const	pkText,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs a string text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
pkText	Pointer of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIText() [3/4]

CGUIText::CGUIText	(	const CGUIObject *const	pkParentObject,
		const TextResource_t &	eTextID,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs an ID text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
eTextID	ID of the internationalised text.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIText() [4/4]

CGUIText::CGUIText ( const CGUIText & kTextToBeCopied )

Copy constructor.

Parameters

kTextToBeCopied The text object to be copied.

Member Function Documentation

◆ AdaptText()

virtual void CGUIText::AdaptText ( )

protectedvirtual

Adapt the text to the given width of the text field. The only adaptation made is replacing some trailing part of the last text line by Ellipsis characters. No font attribute, like font size, is changed. The function also removes HyphenationMarks from a single line text and calculates the required text width and height. For multi line texts this method breaks the original text into a list of strings at positions indicated by the user. It then calls CreateStringList() for further processing. This method only performs calculations if m_bAdaptText is set to true. Therefore, any method that changes attributes related to the text layout (including font settings, area size and so on) should set this flag to true instead of calling this method directly. It is called in as few places as possible.

Reimplemented in CGUIRichText, and CGUIScrollingText.

◆ Clone()

virtual CGUIText * CGUIText::Clone ( ) const

virtual

Clones the instance of the GUIText object.

Returns: Reference to the cloned GUIText object.

Reimplemented in CGUIEditableText, CGUIRichText, and CGUIScrollingText.

◆ CollectHyphenationMarks()

virtual void CGUIText::CollectHyphenationMarks	(	eC_String &	rkStr,
		eC_UInt	uiOffset
	)

protectedvirtual

Removes hyphenation marks from a string and stores their positions in a list. It goes through the string, removes every hyphenation mark and adds its position (adjusted with the offset) to the list.

Parameters

[in,out]	rkStr	The string to be searched for hyphenation marks. When this method returns, all of them are removed.
[in]	uiOffset	Offset of rkStr in this text's string.

◆ ContainsHyphenationMarks()

eC_Bool CGUIText::ContainsHyphenationMarks ( const eC_String & kStr ) const

protected

Checks a string for non-escaped hyphenation marks.

Parameters

kStr	The string to be checked for hyphenation marks.

Returns: True if kStr contains at least one hyphenation mark, otherwise False.

◆ CreateLocalTextCopy()

void CGUIText::CreateLocalTextCopy ( )

protected

This creates a copy of a TextID which is stored in the localisation handler, for local modifications. The copy is stored in m:pkText. If a local copy already exists, this will do nothing.

◆ FitHeightToContainedText()

void CGUIText::FitHeightToContainedText ( )

Resizes the GUIText's height so that the contained text will be fully visible and not truncated. The text's width will be left untouched.

◆ FitString()

virtual void CGUIText::FitString	(	ExtendedString_t &	rkResultStrData,
		const eC_String &	rkStrToAnalyse,
		eC_String &	rkRestStr,
		eC_UInt &	uiOffset
	)

protectedvirtual

Fits a string to the area width of this text object. The goal of this method is to cut as few characters as possible from the string while using as much of the area width of this text object as possible.

This method returns not only the result (fitting ExtendedString) but also the string that was cut off to make it available for further processing.

The algorithm starts by searching for a fitting word boundary (blank characters). Starting from the beginning of the found word, it tries adjusting the width character by character. It then applies hyphenation and adjusts the result strings.

Parameters

[out]	rkResultStrData	The result of the analysis is stored here.
[in]	rkStrToAnalyse	The string that is to be analysed.
[out]	rkRestStr	Returns the string that did not fit and was cut off of pkStrToAnalyse.
[in,out]	uiOffset	The absolute offset (position) of pkStrToAnalyse in the original text represented by this object. Required for finding the correct hyphenation points. When this method returns, this value is updated to reflect the offset of pkRestStr for further processing.

◆ GetAdjustment()

void CGUIText::GetAdjustment	(	eC_Value &	vXAdjustment,
		eC_Value &	vYAdjustment
	)		const

inline

Returns adjustment values. These values are only used by PrintText(). The values are added to the current relative x and y positions, but only for printing. A common use case for this feature is a button that displays its text one or two pixels displaced while the button is pressed down.

Parameters

vXAdjustment	The adjustment in X direction.
vYAdjustment	The adjustment in Y direction.

◆ GetAutoSize()

eC_Bool CGUIText::GetAutoSize ( ) const

Get autosize of control

Returns: true if active

◆ GetContainingObject()

const CGUIObject * CGUIText::GetContainingObject ( ) const

inline

Get the object which contains the text.

Returns: The object which contains the text.

◆ GetEllipsisString()

static eC_String CGUIText::GetEllipsisString ( )

inlinestatic

Returns the marker which will be append if a text has to be cut-off because of insufficient space.

Returns: String to be append on cut-off texts.

◆ GetFont()

FontResource_t CGUIText::GetFont ( ) const

inline

Retrieves the font.

Returns: Font identifier.

◆ GetFontSize()

eC_Int CGUIText::GetFontSize ( ) const

Retrieves the font size of set font.

Returns: Font size.

◆ GetFontSpacing()

eC_Float CGUIText::GetFontSpacing ( ) const

inline

Retrieves the font spacing (space between two letters).

Returns: Font spacing in subpixels.

◆ GetHorAlign()

HorAligned_t CGUIText::GetHorAlign ( ) const

inline

Retrieves the horizontal alignment.

Returns: Horizontal alignment.

◆ GetHorStartAbsXPos()

virtual eC_Value CGUIText::GetHorStartAbsXPos ( )

protectedvirtual

Get the absolute horizontal position at which the first line of the text begins. Takes the alignment into account.

Returns: The horizontal absolute position at which the first line of text should be printed.

◆ GetHyphenString()

static eC_String CGUIText::GetHyphenString ( )

inlinestatic

Returns the hyphen string which will be used on cutting strings.

Returns: Currently set hyphen string.

◆ GetLineSpacing()

virtual eC_Value CGUIText::GetLineSpacing ( ) const

inlinevirtual

Returns the current line spacing factor.

Returns: Current line spacing factor.

◆ GetNumberOfLines()

eC_UInt CGUIText::GetNumberOfLines ( )

Returns the number of lines in this text.

Returns: Total number of lines in text.

◆ GetPrintLineAbsXPos() [1/3]

virtual eC_Value CGUIText::GetPrintLineAbsXPos ( )

protectedvirtual

Get the absolute horizontal position at which the internal text should be printed with regard to the active horizontal alignment. Calls GetPrintLineAbsXPos with the cached width of the internal string.

Returns: The X position where kString should be printed.

◆ GetPrintLineAbsXPos() [2/3]

virtual eC_Value CGUIText::GetPrintLineAbsXPos ( const eC_UInt uiLine )

protectedvirtual

Get the absolute horizontal position at which a line of a multi-line text should be printed, with regard to the active horizontal alignment. Calls GetPrintLineAbsXPos with the cached width of the given line of text.

Parameters

uiLine Index of the line of text which is to be printed.

Returns: The X position where kString should be printed.

◆ GetPrintLineAbsXPos() [3/3]

virtual eC_Value CGUIText::GetPrintLineAbsXPos	(	const eC_Value &	vWidth,
		const eC_Value &	vHeight
	)

protectedvirtual

Get the absolute horizontal position at which the text with the given width should be printed, with regard to the active horizontal alignment.

Parameters

vWidth	width of the text to be printed.
vHeight	height of the text to be printed.

Returns: The X position where kString should be printed.

◆ GetPrintLineAbsYPos() [1/3]

virtual eC_Value CGUIText::GetPrintLineAbsYPos ( )

protectedvirtual

Get the absolute vertical position at which the internal text should be printed with regard to the active vertical alignment. Calls GetPrintLineAbsYPos with the cached width of the internal string.

Returns: The Y position where kString should be printed.

◆ GetPrintLineAbsYPos() [2/3]

virtual eC_Value CGUIText::GetPrintLineAbsYPos ( const eC_UInt uiLine )

protectedvirtual

Get the absolute vertical position at which a line of a multi-line text should be printed, with regard to the active vertical alignment. Calls GetPrintLineAbsYPos with the cached width of the given line of text.

Parameters

uiLine Index of the line of text which is to be printed.

Returns: The Y position where kString should be printed.

◆ GetPrintLineAbsYPos() [3/3]

virtual eC_Value CGUIText::GetPrintLineAbsYPos	(	const eC_Value &	vWidth,
		const eC_Value &	vHeight
	)

protectedvirtual

Get the absolute vertical position at which the text with the given width should be printed, with regard to the active vertical alignment.

Parameters

vWidth	width of the text to be printed.
vHeight	height of the text to be printed.

Returns: The Y position where kString should be printed.

◆ GetRelXPos()

virtual eC_Value CGUIText::GetRelXPos ( ) const

inlinevirtual

Returns the relative x position to the parent object.

Returns: The x position of this text relative to the parent object.

Reimplemented in CGUIScrollingText.

◆ GetRelYPos()

virtual eC_Value CGUIText::GetRelYPos ( ) const

inlinevirtual

Returns the relative y position to the parent object.

Returns: The y position of this text relative to the parent object.

Reimplemented in CGUIScrollingText.

◆ GetRequiredOrgTextSpace()

virtual void CGUIText::GetRequiredOrgTextSpace	(	eC_Value &	vTextWidth,
		eC_Value &	vTextHeight
	)

virtual

Get the required space for the text. Calculates the space required for printing the original text string in a single line. No line breaks or hyphenation markers are taken into account.

Parameters

[out]	vTextWidth	The required text width.
[out]	vTextHeight	The required text height.

Reimplemented in CGUIRichText.

◆ GetRequiredTextHeight()

eC_Value CGUIText::GetRequiredTextHeight ( ) const

inlineprotected

Returns the required text height.

Returns: Required text height

◆ GetRequiredTextHeightForWidth()

virtual eC_Value CGUIText::GetRequiredTextHeightForWidth ( eC_Value vAvailableWidth = 0 )

virtual

Get the required height for the complete, uncut text for a given width. If the text is a multi-line text, the required height for the wrapped text is returned. If the text is single-line, height for the single line is returned.

Parameters

[in] vAvailableWidth The available width for the text. By default, the current width is used.

Returns: The required height.

◆ GetRequiredTextSpace()

virtual void CGUIText::GetRequiredTextSpace	(	eC_Value &	vTextWidth,
		eC_Value &	vTextHeight
	)

virtual

Get the required space for the text. If the text is a multi-line text, the required space for the wrapped text is returned. If the text is single-line, the width of the whole text is returned. Note that the returned width will also include potential ellipsis in case the text got truncated.

Parameters

[out]	vTextWidth	The required text width.
[out]	vTextHeight	The required text height.

◆ GetRequiredTextWidth()

eC_Value CGUIText::GetRequiredTextWidth ( ) const

inlineprotected

Returns the required text width.

Returns: Required text width

◆ GetRotation()

CGUICommonEnums::Rotation_t CGUIText::GetRotation ( ) const

Get current rotation of text

Returns: rotation

◆ GetSpecificClipRect()

const CGUIRect & CGUIText::GetSpecificClipRect ( ) const

inline

Get the currently set specific cliprect.

Returns: The rect (if set), or an invalid rect ((0,0,0,0) if no specific cliprect was set.

◆ GetText()

const eC_String * CGUIText::GetText ( ) const

Retrieves the text. The text is returned as an eC_String* and can be NULL.

Returns: A pointer to the text of this object.

◆ GetTextColor() [1/2]

void CGUIText::GetTextColor	(	eC_UInt &	uiTextColorStandard,
		eC_UInt &	uiTextColorHighlighted,
		eC_UInt &	uiTextColorGrayedOut,
		eC_UInt &	uiTextColorPressed
	)		const

Retrieves the text color.

Parameters

uiTextColorStandard	Standard Text color in ARGB coding (e.g. 0xFFFFFFFF).
uiTextColorHighlighted	Text color in ARGB coding if the parent object is highlighted.
uiTextColorGrayedOut	Text color in ARGB coding if the parent object is grayed out.
uiTextColorPressed	Text color in ARGB coding if the parent object is pressed.

◆ GetTextColor() [2/2]

void CGUIText::GetTextColor	(	GlobalProperty_t &	eTextColorStandard,
		GlobalProperty_t &	eTextColorHighlighted,
		GlobalProperty_t &	eTextColorGrayedOut,
		GlobalProperty_t &	eTextColorPressed
	)		const

Retrieves the text color.

Parameters

eTextColorStandard	Standard Text color as property (e.g. 0xFFFFFFFF).
eTextColorHighlighted	Text color as property if the parent object is highlighted.
eTextColorGrayedOut	Text color as property if the parent object is grayed out.
eTextColorPressed	Text color as property if the parent object is pressed.

◆ GetTextColorGrayedOut()

eC_UInt CGUIText::GetTextColorGrayedOut ( ) const

Returns the currently used color for grayedout-state

Returns: grayedout-color

◆ GetTextColorHighlighted()

eC_UInt CGUIText::GetTextColorHighlighted ( ) const

Returns the currently used color for highlighted-state

Returns: highlighted-color

◆ GetTextColorPressed()

eC_UInt CGUIText::GetTextColorPressed ( ) const

Returns the currently used color for pressed-state

Returns: pressed-color

◆ GetTextColorStandard()

eC_UInt CGUIText::GetTextColorStandard ( ) const

Returns the currently used color for standard-state

Returns: standard-color

◆ GetTextHeight()

virtual eC_Value CGUIText::GetTextHeight ( ) const

inlinevirtual

Get the height of the text area.

Returns: The height of the text area.

Reimplemented in CGUIScrollingText.

◆ GetTextID()

TextResource_t CGUIText::GetTextID ( ) const

inline

Retrieves the TextID represented by this object.

Returns: The TextID of the text attribute of this object. Attention! For a string text the ID is invalid. To determine the type of a text object, use IsTextID().

◆ GetTextWidth()

virtual eC_Value CGUIText::GetTextWidth ( ) const

inlinevirtual

Get the width of the text area.

Returns: The width of the text area.

Reimplemented in CGUIScrollingText.

◆ GetVerAlign()

VerAligned_t CGUIText::GetVerAlign ( ) const

inline

Retrieves the vertical alignment.

Returns: Vertical alignment.

◆ GetVerStartAbsYPos()

virtual eC_Value CGUIText::GetVerStartAbsYPos ( )

protectedvirtual

Get the absolute vertical position at which the first line of the text begins. Takes the alignment into account.

Returns: The vertical absolute position at which the first line of text should be printed.

◆ InvalidateArea()

void CGUIText::InvalidateArea ( )

Invalidates the area of the text to be printed. Note that InvalidateArea has to be called before and after changing the text of this object! Example:

pMyText->InvalidateArea();
pMyText->SetTextString("Hello Guiliani!");
pMyText->InvalidateArea();

◆ IsBidi()

eC_Bool CGUIText::IsBidi ( ) const

Checks if the currently set text contains any BiDi-characters.

Returns: true if text contains BiDi-chracters

◆ IsTextCut()

eC_Bool CGUIText::IsTextCut ( )

inline

Determine whether the text is cut and an ellipsis (...) is appended.

Returns: True if the string is cut and an ellipsis is appended, otherwise False.

◆ IsTextID()

eC_Bool CGUIText::IsTextID ( ) const

Checks whether this text object is an ID text or a string text.

Returns: True if this text represents an ID, False if it represents a string.

◆ IsTextSingleLine()

eC_Bool CGUIText::IsTextSingleLine ( ) const

inline

Determines whether this text is single- or multi-line.

Returns: True if the text is single-line, False if it is multi-line.

◆ OnNotification()

virtual void CGUIText::OnNotification ( )

protectedvirtual

Observe the localisation handler and the property handler. If the text behind an ID is changed in the localisation handler and this text is an ID text, this function will be called. If a color property which is used by this text is changed, the property handler calls this function.

Reimplemented from CGUIColorPropertyObserver.

Reimplemented in CGUIRichText.

◆ operator=()

CGUIText & CGUIText::operator= ( const CGUIText & kSource )

Copies the base attributes from a source object. This text object will have the same containing object as the source. If you want to set another containing object, you should use SetContainingObject() to set it.

Parameters

kSource The source object whose attributes are copied.

Returns: CGUIText& Reference to this object.

◆ PrepareClipRect()

eC_Bool CGUIText::PrepareClipRect ( )

protected

Prepare the clipping rectangle for text printing. This will set the clipping rectangle to the intersecting rectangle of the text's specific clipping rectangle with the GUI's currently set clipping rectangle.

Returns: false if the resulting clipping rectangle would be incomprehensive and the text must not be printed, true otherwise.

◆ PreparePrint()

virtual void CGUIText::PreparePrint ( )

protectedvirtual

Prepare to print the text. This function may only be used in PrintText. It prepares the graphics wrapper state with the correct font, color etc.

Reimplemented in CGUIScrollingText.

◆ PrintText()

virtual void CGUIText::PrintText ( )

virtual

Prints the text. This function may only be called from the DoDraw() implementation of the text's containing GUI object as it uses absolute positioning.

Reimplemented in CGUIEditableText, CGUIRichText, and CGUIScrollingText.

◆ ReadFontColors()

void CGUIText::ReadFontColors ( const eC_UInt uiVersion )

protected

Helper function for ReadFromStream().

Parameters

uiVersion

◆ ReadFromStream()

virtual void CGUIText::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also: CGUIObject::ReadFromStream()

Reimplemented from CGUIStreamableObject.

Reimplemented in CGUIEditableText, CGUIRichText, and CGUIScrollingText.

◆ SetAdjustment()

void CGUIText::SetAdjustment	(	const eC_Value &	vXAdjustment,
		const eC_Value &	vYAdjustment
	)

inline

Set positional adjustment values. These values are only used by PrintText(). The values are added to the current relative x and y positions, but only for printing. A common use case for this feature is a button that displays its text one or two pixels displaced while the button is pressed down.

Parameters

vXAdjustment	The adjustment in X direction.
vYAdjustment	The adjustment in Y direction.

◆ SetAligned()

void CGUIText::SetAligned	(	const VerAligned_t &	eVerAligned = `V_TOP`,
		const HorAligned_t &	eHorAligned = `H_LEFT`
	)

Sets the text alignment.

Parameters

eVerAligned	Vertical alignment
eHorAligned	Horizontal alignment

◆ SetAlignedHorizontal()

void CGUIText::SetAlignedHorizontal ( const HorAligned_t & eHorAligned = H_LEFT )

Sets horizontal alignment.

Parameters

eHorAligned Horizontal alignment

◆ SetAlignedVertical()

void CGUIText::SetAlignedVertical ( const VerAligned_t & eVerAligned = V_TOP )

Sets vertical alignment.

Parameters

eVerAligned Vertical alignment

◆ SetAutoSize()

void CGUIText::SetAutoSize ( const eC_Bool & bAutoSize )

Set autosizing of control.

Parameters

bAutoSize ture if active

◆ SetContainingObject()

void CGUIText::SetContainingObject ( const CGUIObject *const pkParent )

inline

Sets the object which contains the text. This method just changes the internal pointer to the containing object without re-calculating the text layout. If necessary, adjust the text positioning and area size manually.

Parameters

pkParent The object which contains the text.

◆ SetEllipsisString()

static void CGUIText::SetEllipsisString ( const eC_String & kEllipsis )

inlinestatic

Sets the marker which will be append if a text has to be cut-off because of insufficient space.

Parameters

kEllipsis String to be append on cut-off texts.

◆ SetFont()

virtual void CGUIText::SetFont ( const FontResource_t & eFontID )

virtual

Sets the font.

Parameters

eFontID The identifier of the font to set.

Reimplemented in CGUIEditableText, and CGUIRichText.

◆ SetFontSpacing()

void CGUIText::SetFontSpacing ( const eC_Float & fFontSpacing )

Sets the font spacing (space between letters).

Parameters

fFontSpacing Font spacing in subpixels (1.0 subpixels equals 1 pixel).

◆ SetHyphenString()

static void CGUIText::SetHyphenString ( const eC_String & kHyphen )

inlinestatic

Sets the hyphen string which will be used on cutting strings.

Parameters

kHyphen Hyphen string to use.

◆ SetLineSpacing()

virtual void CGUIText::SetLineSpacing ( const eC_Value vLineSpacing )

virtual

Sets the line spacing factor (default line spacing factor is 1). Valid values are in the range of 0-100.

Parameters

vLineSpacing The line spacing factor.

◆ SetRelRect()

void CGUIText::SetRelRect ( const CGUIRect & kRect )

inline

Sets the relative rectangle for this text

Parameters

kRect Rectangle relative to containing object which is available for the text

◆ SetRelXPos()

virtual void CGUIText::SetRelXPos ( const eC_Value & vRelXPos )

inlinevirtual

Sets relative x position to the parent object. The effect depends on the alignment. If the text is left aligned, this value is used relative to the left border of the parent object, if it is right aligned, relative to the right border of the parent object. If the text is centered, changing this value has no effect. Attention: the text width will not be re-adjusted by this method. If required, please set it by using SetTextWidth().

Parameters

vRelXPos Relative x position.

Reimplemented in CGUIScrollingText.

◆ SetRelYPos()

virtual void CGUIText::SetRelYPos ( const eC_Value & vRelYPos )

inlinevirtual

Sets relative y position to the parent object. The effect depends on the alignment. If the text is top aligned, this value is used relative to the top border of the parent object, if it is bottom aligned, relative to the bottom border of the parent object. If the text is centered, changing this has no effect. Attention: the text height will not be re-adjusted by this method. If required, please set it by using SetTextHeight().

Parameters

vRelYPos Relative y position.

Reimplemented in CGUIScrollingText.

◆ SetRequiredTextHeight()

void CGUIText::SetRequiredTextHeight ( eC_Value vRequiredTextHeight )

inlineprotected

Sets the required text height.

Parameters

vRequiredTextHeight Required text height to set.

◆ SetRequiredTextWidth()

void CGUIText::SetRequiredTextWidth ( eC_Value vRequiredTextWidth )

inlineprotected

Sets the required text width.

Parameters

vRequiredTextWidth Required text width to set.

◆ SetRotation()

void CGUIText::SetRotation ( const CGUICommonEnums::Rotation_t eRotation )

set rotation of text

Parameters

eRotation rotation

◆ SetSpecificClipRect()

void CGUIText::SetSpecificClipRect ( const CGUIRect & kRect )

inline

Set a clip rect that different from the relative text position and text dimension. Setting a rectangle of width or height of zero will disable the specific clip rect and default to clipping against the containing object.

Parameters

kRect The rect (in coordinates relative to the containing object) that shall be used for clipping the text.

◆ SetTextAlignmentProperty()

void CGUIText::SetTextAlignmentProperty ( const GlobalProperty_t & eTextAlignmentProperty )

Set a global alignment property

Parameters

eTextAlignmentProperty The id of the property.

◆ SetTextColor() [1/2]

virtual void CGUIText::SetTextColor	(	const eC_UInt &	uiTextColorStandard,
		const eC_UInt &	uiTextColorHighlighted,
		const eC_UInt &	uiTextColorGrayedOut,
		const eC_UInt &	uiTextColorPressed
	)

virtual

Sets the color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorStandard	Standard Text color in ARGB coding (e.g. 0xFFFFFFFF).
uiTextColorHighlighted	Text color in ARGB coding used if the parent object is highlighted.
uiTextColorGrayedOut	Text color in ARGB coding used if the parent object is grayed out.
uiTextColorPressed	Text color in ARGB coding used if the parent object is pressed.

Reimplemented in CGUIRichText.

◆ SetTextColor() [2/2]

virtual void CGUIText::SetTextColor	(	const GlobalProperty_t &	eTextColorStandard,
		const GlobalProperty_t &	eTextColorHighlighted,
		const GlobalProperty_t &	eTextColorGrayedOut,
		const GlobalProperty_t &	eTextColorPressed
	)

virtual

Sets the color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

eTextColorStandard	Standard Text color as property (e.g. 0xFFFFFFFF).
eTextColorHighlighted	Text color as property used if the parent object is highlighted.
eTextColorGrayedOut	Text color as property used if the parent object is grayed out.
eTextColorPressed	Text color as property used if the parent object is pressed.

◆ SetTextColorGrayedOut() [1/2]

void CGUIText::SetTextColorGrayedOut ( const eC_UInt & uiTextColorGrayedOut )

Sets the grayed out color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorGrayedOut Text color in ARGB coding used if the parent object is grayed out.

◆ SetTextColorGrayedOut() [2/2]

void CGUIText::SetTextColorGrayedOut ( const GlobalProperty_t & eTextColorPropertyGrayedOut )

Set a global color property as grayed out color.

Parameters

eTextColorPropertyGrayedOut The id of the property.

◆ SetTextColorHighlighted() [1/2]

void CGUIText::SetTextColorHighlighted ( const eC_UInt & uiTextColorHighlighted )

Sets the highlighted color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorHighlighted Text color in ARGB coding used if the parent object is highlighted.

◆ SetTextColorHighlighted() [2/2]

void CGUIText::SetTextColorHighlighted ( const GlobalProperty_t & eTextColorPropertyHighlighted )

Set a global color property as highlighted color.

Parameters

eTextColorPropertyHighlighted The id of the property.

◆ SetTextColorPressed() [1/2]

void CGUIText::SetTextColorPressed ( const eC_UInt & uiTextColorPressed )

Sets the pressed color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorPressed Text color in ARGB coding used if the parent object is pressed.

◆ SetTextColorPressed() [2/2]

void CGUIText::SetTextColorPressed ( const GlobalProperty_t & eTextColorPropertyPressed )

Set a global color property as pressed color.

Parameters

eTextColorPropertyPressed The id of the property.

◆ SetTextColorStandard() [1/2]

void CGUIText::SetTextColorStandard ( const eC_UInt & uiTextColorStandard )

Sets the standard color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorStandard Standard Text color in ARGB coding (e.g. 0xFFFFFFFF).

◆ SetTextColorStandard() [2/2]

void CGUIText::SetTextColorStandard ( const GlobalProperty_t & eTextColorPropertyStandard )

Set a global color property as standard color.

Parameters

eTextColorPropertyStandard The id of the property.

◆ SetTextCut()

void CGUIText::SetTextCut ( const eC_Bool bIsCut )

inlineprotected

Sets the internal flagindicating thwther this text has been truncated.

Parameters

bIsCut True means that the string was truncated, False means that it was not truncated

◆ SetTextHeight()

virtual void CGUIText::SetTextHeight ( const eC_Value & vTextHeight )

virtual

Sets the text height.

Parameters

vTextHeight The height assigned to the text.

Reimplemented in CGUIScrollingText.

◆ SetTextID()

virtual void CGUIText::SetTextID ( const TextResource_t & eTextID )

virtual

Sets the text ID.

Parameters

eTextID The ID of the text to assign to this object.

Reimplemented in CGUIRichText.

◆ SetTextSingleLine()

virtual void CGUIText::SetTextSingleLine ( const eC_Bool & bSingleLine )

virtual

Sets the text line wrapping mode (single or multi-line).

Parameters

bSingleLine true: single line; false: multi-line.

◆ SetTextString() [1/2]

virtual void CGUIText::SetTextString ( const eC_String & kTextString )

virtual

Sets the string text to be represented by this object.

Parameters

kTextString The string to be assigned to this object.

Reimplemented in CGUIRichText, and CGUIEditableText.

◆ SetTextString() [2/2]

void CGUIText::SetTextString ( const eC_String * pkTextString )

Sets the string text to be represented by this object.

Parameters

pkTextString The string to be assigned to this object.

◆ SetTextWidth()

virtual void CGUIText::SetTextWidth ( const eC_Value & vTextWidth )

virtual

Sets the text width.

Parameters

vTextWidth The width assigned to the text.

Reimplemented in CGUIScrollingText.

◆ WriteToStream()

virtual void CGUIText::WriteToStream ( const eC_Bool bWriteTextType = false )

virtual

Called by the framework when writing streaming files. When deriving a new text class in an application, re-implement this method.

Parameters

bWriteTextType Indicates whether the ID needs to be written. If the framework calls this method, it passes true here. The base class implementation has to be called with false (default). If called with true, the first two tags written must be this text's XML name tag (see GetXMLTag()) and its text type ID. After all attributes are written, the name tag has to be written again as a closing tag (preceded by a slash).

Reimplemented from CGUIStreamableObject.

Reimplemented in CGUIEditableText, CGUIRichText, and CGUIScrollingText.

Member Data Documentation

◆ m_bAdaptText

eC_Bool CGUIText::m_bAdaptText

protected

Flag to keep track of whether AdaptText() needs to perform calculations upon its next call. Every method that changes text attributes that can potentially lead to a change in the text layout should set this flag to true. AdaptText() resets it.

◆ m_bTextIDLocalCopy

eC_Bool CGUIText::m_bTextIDLocalCopy

protected

Set to True if this text is an ID text but m_pkText points to a local copy instead to the string in the localisation handler. This happens if the string contains hyphenation marks.

◆ m_eTextID

TextResource_t CGUIText::m_eTextID

protected

The ID of the text. If this text is constructed with an ID or changed later (by calling SetTextID()) the ID is stored here. If this text is constructed with a string or changed later by calling SetTextString() this ID is set to TEXT_START_TAG, indicating that it is invalid.

◆ m_pkText

eC_String* CGUIText::m_pkText

protected

This contains the text string if it is a string literal, or a locally modified copy of a string in the Localisation handler. For instances of CGUIText which are referencing an unmodified TextResource in the localisation handler, this is NULL. A TextID will for instance be stored in a local copy if it is truncated or was word-wrapped.

See also: GetText()

◆ m_vRequiredOrgTextHeight

eC_Value CGUIText::m_vRequiredOrgTextHeight

protected

The required height of this text's original (not wrapped) string as calculated by the most recent call to AdaptText().

◆ m_vRequiredOrgTextWidth

eC_Value CGUIText::m_vRequiredOrgTextWidth

protected

The required width of this text's original (not wrapped) string as calculated by the most recent call to AdaptText().

◆ XMLTAG_TEXT_COLOR_PROPERTY_FLAGS

const eC_Char CGUIText::XMLTAG_TEXT_COLOR_PROPERTY_FLAGS[]

static

XML tag to be used when writing text colors into a stream.

xml-tag of color-properties

The documentation for this class was generated from the following file:

GUIText.h

Classes

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Types

Protected Member Functions

Protected Attributes

Static Protected Attributes

Detailed Description

Member Enumeration Documentation

◆ HorAligned_t

◆ VerAligned_t

Constructor & Destructor Documentation

◆ CGUIText() [1/4]

◆ CGUIText() [2/4]

◆ CGUIText() [3/4]

◆ CGUIText() [4/4]

Member Function Documentation

◆ AdaptText()

◆ Clone()

◆ CollectHyphenationMarks()

◆ ContainsHyphenationMarks()

◆ CreateLocalTextCopy()

◆ FitHeightToContainedText()

◆ FitString()

◆ GetAdjustment()

◆ GetAutoSize()

◆ GetContainingObject()

◆ GetEllipsisString()

◆ GetFont()

◆ GetFontSize()

◆ GetFontSpacing()

◆ GetHorAlign()

◆ GetHorStartAbsXPos()

◆ GetHyphenString()

◆ GetLineSpacing()

◆ GetNumberOfLines()

◆ GetPrintLineAbsXPos() [1/3]

◆ GetPrintLineAbsXPos() [2/3]

◆ GetPrintLineAbsXPos() [3/3]

◆ GetPrintLineAbsYPos() [1/3]

◆ GetPrintLineAbsYPos() [2/3]

◆ GetPrintLineAbsYPos() [3/3]

◆ GetRelXPos()

◆ GetRelYPos()

◆ GetRequiredOrgTextSpace()

◆ GetRequiredTextHeight()

◆ GetRequiredTextHeightForWidth()

◆ GetRequiredTextSpace()

◆ GetRequiredTextWidth()

◆ GetRotation()

◆ GetSpecificClipRect()

◆ GetText()

◆ GetTextColor() [1/2]

◆ GetTextColor() [2/2]

◆ GetTextColorGrayedOut()

◆ GetTextColorHighlighted()

◆ GetTextColorPressed()

◆ GetTextColorStandard()

◆ GetTextHeight()

◆ GetTextID()

◆ GetTextWidth()

◆ GetVerAlign()

◆ GetVerStartAbsYPos()

◆ InvalidateArea()

◆ IsBidi()

◆ IsTextCut()

◆ IsTextID()

◆ IsTextSingleLine()

◆ OnNotification()

◆ operator=()

◆ PrepareClipRect()

◆ PreparePrint()

◆ PrintText()

◆ ReadFontColors()

◆ ReadFromStream()

◆ SetAdjustment()

◆ SetAligned()

◆ SetAlignedHorizontal()
