CGUIObserver Class Reference

Observer Base class for Observer-Design-Pattern within Guiliani. More...

#include <GUIObserver.h>

Inheritance diagram for CGUIObserver:

Public Member Functions
	CGUIObserver ()
	Default constructor.
virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.
const eC_TListDoubleLinked< CGUISubject * > &	GetSubjectList () const
virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...
virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)
virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)
virtual void	OnNotification (const eC_String &kMessage)
void	SetAutoDelete (const eC_Bool bAutoDelete)

Protected Member Functions
virtual void	AddSubject (CGUISubject *pSubjectToAdd)
virtual void	RemoveSubject (CGUISubject *pSubjectToRemove)

Friends
class	CGUISubject

Detailed Description

Observer Base class for Observer-Design-Pattern within Guiliani.

Use this base class if you wish to follow the observer-design-pattern within your application. Simply derive the class that you want to act as an observer from CGUIObserver, and implement the desired functionality within OnNotification(). This method will be called whenever an observed subject changes.

Member Function Documentation

AddSubject()

virtual void CGUIObserver::AddSubject ( CGUISubject *  pSubjectToAdd )

protectedvirtual

Called by the subject when the Observer is added. ATTENTION: Call base implementation when deriving from this method.

Parameters

pSubjectToAdd

The Subject that shall be added to the internal list.

GetSubjectList()

const eC_TListDoubleLinked< CGUISubject * > & CGUIObserver::GetSubjectList ( ) const

inline

Returns

The list of all subjects to which this observer is registered

OnNotification() [1/4]

virtual void CGUIObserver::OnNotification ( )

inlinevirtual

Called by CGUISubject whenever an observed object triggers an update.

Reimplemented in CGUICalendar, CGUIRichText, CGUIText, and CGUIColorPropertyObserver.

OnNotification() [2/4]

virtual void CGUIObserver::OnNotification ( const CGUIObject *const  pkUpdatedObject )

inlinevirtual

Called by a subject whenever the observed object triggers update.

Parameters

pkUpdatedObject

The observed object (can be NULL)

OnNotification() [3/4]

virtual void CGUIObserver::OnNotification ( const CGUIValue &  kObservedValue, const CGUIObject *const  pkUpdatedObject, const eC_UInt  uiX = 0, const eC_UInt  uiY = 0  )

inlinevirtual

Called by a subject whenever the observed value changes.

Parameters

kObservedValue	The updated observed value.
pkUpdatedObject	The observed object (can be NULL)
uiX	X-Index Additional X-Index in case the updated value is part of a multidimensional array
uiY	Y-Index Additional Y-Index in case the updated value is part of a multidimensional array

Reimplemented in CGUIComboBox, CGUIScrollBar, and CDataPoolEntry.

OnNotification() [4/4]

virtual void CGUIObserver::OnNotification ( const eC_String &  kMessage )

inlinevirtual

Called by CGUISubject whenever an observed object triggers an update.

Parameters

kMessage

The updated string value.

RemoveSubject()

virtual void CGUIObserver::RemoveSubject ( CGUISubject *  pSubjectToRemove )

protectedvirtual

Called on destruction of the subject to reset the internal Subject pointer. ATTENTION: Call base implementation when deriving from this method.

Parameters

pSubjectToRemove

The Subject that shall be removed from the internal list.

SetAutoDelete()

void CGUIObserver::SetAutoDelete ( const eC_Bool  bAutoDelete )

inline

Specifies if this observer will automatically delete itself when the number of observed subjects reaches zero.

Parameters

bAutoDelete

If True, this observer will delete itself when RemoveSubject() is called for the last observed subject.

Friends And Related Function Documentation

CGUISubject

friend class CGUISubject

friend

---

The documentation for this class was generated from the following file:

• GUIObserver.h
