Text implementation which supports rich text. More...

#include <GUIRichText.h>

Inheritance diagram for CGUIRichText:

[legend]

Classes
class	CRichTextFragment
	One fragment of a rich text. More...

Public Member Functions
	CGUIRichText (const CGUIObject *const pkParentObject, const eC_String &kText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIRichText (const CGUIObject const pkParentObject, const eC_String const pkText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIRichText (const CGUIObject *const pkParentObject, const TextResource_t &eTextID, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIRichText (const CGUIRichText &kTextToBeCopied)

virtual	~CGUIRichText ()

virtual CGUIRichText *	Clone () const

void	EnablePreformatting (const eC_Bool &bPreformatText)

const eC_String &	GetFormatTagBold () const

const eC_String &	GetFormatTagClosing () const

const eC_String &	GetFormatTagColor () const

const eC_String &	GetFormatTagFinished () const

const eC_String &	GetFormatTagItalic () const

const eC_String &	GetFormatTagLineBreak () const

const eC_String &	GetFormatTagListItem () const

const eC_String &	GetFormatTagNoBreak () const

const eC_String &	GetFormatTagOpening () const

const eC_String &	GetFormatTagOrderedList () const

const eC_String &	GetFormatTagUnderlined () const

const eC_String &	GetFormatTagUnorderedList () const

virtual void	GetRequiredOrgTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)

eC_Bool	IsTextPreformatted ()

CGUIRichText &	operator= (const CGUIRichText &kSource)

virtual void	PrintText ()

virtual void	SetFont (const FontResource_t &eFontID)

void	SetFormatTagBold (const eC_String &kTag)

void	SetFormatTagClosing (const eC_String &kTag)

void	SetFormatTagColor (const eC_String &kTag)

void	SetFormatTagFinished (const eC_String &kTag)

void	SetFormatTagItalic (const eC_String &kTag)

void	SetFormatTagLineBreak (const eC_String &kTag)

void	SetFormatTagListItem (const eC_String &kTag)

void	SetFormatTagNoBreak (const eC_String &kTag)

void	SetFormatTagOpening (const eC_String &kTag)

void	SetFormatTagOrderedList (const eC_String &kTag)

void	SetFormatTagUnderlined (const eC_String &kTag)

void	SetFormatTagUnorderedList (const eC_String &kTag)

virtual void	SetRichFonts (const FontResource_t &eFontNormal=DUMMY_FONT, const FontResource_t &eFontBold=DUMMY_FONT, const FontResource_t &eFontItalic=DUMMY_FONT, const FontResource_t &eFontBoldItalic=DUMMY_FONT)

virtual void	SetTextColor (const eC_UInt &uiTextColorStandard, const eC_UInt &uiTextColorHighlighted, const eC_UInt &uiTextColorGrayedOut, const eC_UInt &uiTextColorPressed)

virtual void	SetTextID (const TextResource_t &eTextID)

virtual void	SetTextString (const eC_String &kTextString)

Public Member Functions inherited from CGUIText
	CGUIText (const CGUIObject *const pkParentObject, const eC_String &kText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIObject const pkParentObject, const eC_String const pkText, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIObject *const pkParentObject, const TextResource_t &eTextID, const eC_Value &vXPos=eC_FromInt(0), const eC_Value &vYPos=eC_FromInt(0), const eC_Bool &bSingleLine=true)

	CGUIText (const CGUIText &kTextToBeCopied)

virtual	~CGUIText ()
	Destructor.

virtual CGUIText *	Clone () const

void	FitHeightToContainedText ()

void	GetAdjustment (eC_Value &vXAdjustment, eC_Value &vYAdjustment) const

eC_Bool	GetAutoSize () const

const CGUIObject *	GetContainingObject () const

FontResource_t	GetFont () const

eC_Int	GetFontSize () const

eC_Float	GetFontSpacing () const

HorAligned_t	GetHorAlign () const

virtual eC_Value	GetLineSpacing () const

eC_UInt	GetNumberOfLines ()

virtual eC_Value	GetRelXPos () const

virtual eC_Value	GetRelYPos () const

virtual void	GetRequiredOrgTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)

virtual eC_Value	GetRequiredTextHeightForWidth (eC_Value vAvailableWidth=0)

virtual void	GetRequiredTextSpace (eC_Value &vTextWidth, eC_Value &vTextHeight)

CGUICommonEnums::Rotation_t	GetRotation () const

const CGUIRect &	GetSpecificClipRect () const

const eC_String *	GetText () const

void	GetTextColor (eC_UInt &uiTextColorStandard, eC_UInt &uiTextColorHighlighted, eC_UInt &uiTextColorGrayedOut, eC_UInt &uiTextColorPressed) const

void	GetTextColor (GlobalProperty_t &eTextColorStandard, GlobalProperty_t &eTextColorHighlighted, GlobalProperty_t &eTextColorGrayedOut, GlobalProperty_t &eTextColorPressed) const

eC_UInt	GetTextColorGrayedOut () const

eC_UInt	GetTextColorHighlighted () const

eC_UInt	GetTextColorPressed () const

eC_UInt	GetTextColorStandard () const

virtual eC_Value	GetTextHeight () const

TextResource_t	GetTextID () const

virtual eC_Value	GetTextWidth () const

VerAligned_t	GetVerAlign () const

void	InvalidateArea ()

eC_Bool	IsBidi () const

eC_Bool	IsTextCut ()

eC_Bool	IsTextID () const

eC_Bool	IsTextSingleLine () const

CGUIText &	operator= (const CGUIText &kSource)

virtual void	PrintText ()

virtual void	ReadFromStream ()

void	SetAdjustment (const eC_Value &vXAdjustment, const eC_Value &vYAdjustment)

void	SetAligned (const VerAligned_t &eVerAligned=V_TOP, const HorAligned_t &eHorAligned=H_LEFT)

void	SetAlignedHorizontal (const HorAligned_t &eHorAligned=H_LEFT)

void	SetAlignedVertical (const VerAligned_t &eVerAligned=V_TOP)

void	SetAutoSize (const eC_Bool &bAutoSize)

void	SetContainingObject (const CGUIObject *const pkParent)

virtual void	SetFont (const FontResource_t &eFontID)

void	SetFontSpacing (const eC_Float &fFontSpacing)

virtual void	SetLineSpacing (const eC_Value vLineSpacing)

void	SetRelRect (const CGUIRect &kRect)

virtual void	SetRelXPos (const eC_Value &vRelXPos)

virtual void	SetRelYPos (const eC_Value &vRelYPos)

void	SetRotation (const CGUICommonEnums::Rotation_t eRotation)

void	SetSpecificClipRect (const CGUIRect &kRect)

void	SetTextAlignmentProperty (const GlobalProperty_t &eTextAlignmentProperty)

virtual void	SetTextColor (const eC_UInt &uiTextColorStandard, const eC_UInt &uiTextColorHighlighted, const eC_UInt &uiTextColorGrayedOut, const eC_UInt &uiTextColorPressed)

virtual void	SetTextColor (const GlobalProperty_t &eTextColorStandard, const GlobalProperty_t &eTextColorHighlighted, const GlobalProperty_t &eTextColorGrayedOut, const GlobalProperty_t &eTextColorPressed)

void	SetTextColorGrayedOut (const eC_UInt &uiTextColorGrayedOut)

void	SetTextColorGrayedOut (const GlobalProperty_t &eTextColorPropertyGrayedOut)

void	SetTextColorHighlighted (const eC_UInt &uiTextColorHighlighted)

void	SetTextColorHighlighted (const GlobalProperty_t &eTextColorPropertyHighlighted)

void	SetTextColorPressed (const eC_UInt &uiTextColorPressed)

void	SetTextColorPressed (const GlobalProperty_t &eTextColorPropertyPressed)

void	SetTextColorStandard (const eC_UInt &uiTextColorStandard)

void	SetTextColorStandard (const GlobalProperty_t &eTextColorPropertyStandard)

virtual void	SetTextHeight (const eC_Value &vTextHeight)

virtual void	SetTextID (const TextResource_t &eTextID)

virtual void	SetTextSingleLine (const eC_Bool &bSingleLine)

virtual void	SetTextString (const eC_String &kTextString)

void	SetTextString (const eC_String *pkTextString)

virtual void	SetTextWidth (const eC_Value &vTextWidth)

virtual void	WriteToStream (const eC_Bool bWriteTextType=false)

Public Member Functions inherited from CGUIColorPropertyObserver
	CGUIColorPropertyObserver ()
	default-constructor

	~CGUIColorPropertyObserver ()
	destructor

eC_UInt	AddColorProperty (const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

void	AddColorProperty (const eC_UInt &uiIndex, const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

ColorValue_t	GetColorProperty (const eC_UInt &uiIndex) const

eC_UInt	GetColorValue (const eC_UInt &uiIndex) const

virtual void	OnColorPropertyChange ()

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

void	RemoveColorProperty (const eC_UInt &uiIndex)

void	SetColorProperty (const eC_UInt &uiIndex, const ColorValue_t &kColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const eC_UInt &uiColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const GlobalProperty_t &eColorProperty)

Public Member Functions inherited from CGUIObserver
	CGUIObserver ()
	Default constructor.

virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.

const eC_TListDoubleLinked< CGUISubject * > &	GetSubjectList () const

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)

virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)

virtual void	OnNotification (const eC_String &kMessage)

void	SetAutoDelete (const eC_Bool bAutoDelete)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Protected Types
enum	ListType_t { LT_ORDERED , LT_UNORDERED , LT_NONE }
	List type.

typedef eC_TListDoubleLinked< CRichTextFragment >	RichTextFragmentList
	A rich text fragment list is a double-linked list of rich text fragments.

Protected Types inherited from CGUIText
typedef eC_TListDoubleLinked< ExtendedString_t >	ExtendedStringList_t
	The extended string list is a double-linked list of extended strings.

typedef eC_TListDoubleLinked< eC_UInt >	UIntList
	Double linked List of unsigned integers.

Protected Member Functions
void	AdaptText ()

void	FitFragmentWithEllipsis (CRichTextFragment &TextFragment, eC_Value vMaxWidth)

void	OnNotification ()

void	ParseTextToRich ()

void	PreformatText ()

void	PreparePrintForFragment (const CRichTextFragment &Fragment)

virtual void	ReadFromStream ()

void	SplitFragment (CRichTextFragment &FirstTextFragment, CRichTextFragment &SecondTextFragment, eC_Value vMaxWidth, eC_UInt uiCharOffsetFromStart)

virtual void	WriteToStream (const eC_Bool bWriteTextType=false)

Protected Member Functions inherited from CGUIText
virtual void	AdaptText ()

virtual void	CollectHyphenationMarks (eC_String &rkStr, eC_UInt uiOffset)

eC_Bool	ContainsHyphenationMarks (const eC_String &kStr) const

void	CreateLocalTextCopy ()

virtual void	FitString (ExtendedString_t &rkResultStrData, const eC_String &rkStrToAnalyse, eC_String &rkRestStr, eC_UInt &uiOffset)

virtual eC_Value	GetHorStartAbsXPos ()

virtual eC_Value	GetPrintLineAbsXPos ()

virtual eC_Value	GetPrintLineAbsXPos (const eC_UInt uiLine)

virtual eC_Value	GetPrintLineAbsXPos (const eC_Value &vWidth, const eC_Value &vHeight)

virtual eC_Value	GetPrintLineAbsYPos ()

virtual eC_Value	GetPrintLineAbsYPos (const eC_UInt uiLine)

virtual eC_Value	GetPrintLineAbsYPos (const eC_Value &vWidth, const eC_Value &vHeight)

eC_Value	GetRequiredTextHeight () const

eC_Value	GetRequiredTextWidth () const

virtual eC_Value	GetVerStartAbsYPos ()

virtual void	OnNotification ()

eC_Bool	PrepareClipRect ()

virtual void	PreparePrint ()

void	ReadFontColors (const eC_UInt uiVersion)

void	SetRequiredTextHeight (eC_Value vRequiredTextHeight)

void	SetRequiredTextWidth (eC_Value vRequiredTextWidth)

void	SetTextCut (const eC_Bool bIsCut)

void	WriteFontColors ()
	Helper function for WriteStream().

Protected Member Functions inherited from CGUIObserver
virtual void	AddSubject (CGUISubject *pSubjectToAdd)

virtual void	RemoveSubject (CGUISubject *pSubjectToRemove)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
eC_Bool	m_bPreformatText
	Controls whether PreformatText() is called.

FontResource_t	m_eFontBold
	font resource: bold

FontResource_t	m_eFontBoldItalic
	font resource: bold italic

FontResource_t	m_eFontItalic
	font resource: italic

eC_TArray< eC_Value >	m_kLineWidths
	Width of each line of text (required for X-Alignments)

RichTextFragmentList	m_kOriginalRichTextFragments
	Original list of all Text-fragments within this text.

RichTextFragmentList	m_kRichTextFragments

eC_String	m_kTagBold
	Format tag: bold.

eC_String	m_kTagClosing
	Format tag: closing.

eC_String	m_kTagColor
	Format tag: color.

eC_String	m_kTagFinished
	Format tag: finished.

eC_String	m_kTagItalic
	Format tag: italic.

eC_String	m_kTagLineBreak
	Format tag: line break.

eC_String	m_kTagListItem
	Format tag: list item.

eC_String	m_kTagNoBreak
	Format tag: no break.

eC_String	m_kTagOpening
	Format tag: opening.

eC_String	m_kTagOrderedList
	Format tag: ordered list.

eC_String	m_kTagUnderlined
	Format tag: underlined.

eC_String	m_kTagUnorderedList
	Format tag: unordered list.

eC_String	m_kUnorderedListSign
	The unordered list sign.

eC_Value	m_vListIndentation
	Default list indentation.

eC_Value	m_vSpaceWidth
	Width of a space to avoid calling RequiredSpace() too often.

eC_Value	m_vUnorderedListSignWidth
	Width of the unordered list sign.

Protected Attributes inherited from CGUIText
eC_Bool	m_bAdaptText

eC_Bool	m_bSingleLine
	Indicates whether this text is single- or multi-line.

eC_Bool	m_bTextCut
	Indicates whether the text is cut and has an appended ellipsis.

eC_Bool	m_bTextIDLocalCopy

eC_Bool	m_bTextIsBiDi
	Indicates whether the text is a BiDi-text.

eC_Bool	m_bUseEllipsis
	use ellipsis if text is too long

FontResource_t	m_eFont
	Font ID for this text object.

HorAligned_t	m_eHorAligned
	Horizontal alignment.

CGUICommonEnums::Rotation_t	m_eRotation
	rotation for the text

GlobalProperty_t	m_eTextAlignmentProperty
	Property used for the text color for alignment. By default, this value is DUMMY_PROPERTY, i.e. a fixed alignment is used.

TextResource_t	m_eTextID

VerAligned_t	m_eVerAligned
	Vertical alignment.

eC_Float	m_fFontSpacing
	Font spacing for the text object.

UIntList	m_kHyphens
	List of hyphen positions in the original text.

ExtendedStringList_t	m_kListStringsExtended
	List of strings to be printed, and their cached width and height.

const CGUIObject *	m_pkParentObject
	The object containing (and printing) this text.

eC_String *	m_pkText

eC_Value	m_vLineHeight
	The height of one text line with this text's font.

eC_Value	m_vLineSpacing
	The line spacing factor.

eC_Value	m_vRelXPos
	X position of this text's printing area relative to the parent object.

eC_Value	m_vRelYPos
	Y position of this text's printing area relative to the parent object.

eC_Value	m_vRequiredOrgTextHeight

eC_Value	m_vRequiredOrgTextWidth

eC_Value	m_vTextHeight
	Height of this text's printing area.

eC_Value	m_vTextWidth
	Width of this text's printing area.

eC_Value	m_vXAdjustment
	Printing adjustment for m_vRelXPos.

eC_Value	m_vYAdjustment
	Printing adjustment for m_vRelYPos.

Additional Inherited Members
Public Types inherited from CGUIText
enum	HorAligned_t { H_LEFT , H_CENTERED , H_RIGHT , H_PROPERTY }
	Possible horizontal alignments. More...

enum	TextColorTypeFlags_t { TEXT_COLOR_STANDARD_IS_PROPERTY = 1 , TEXT_COLOR_HIGHLIGHTED_IS_PROPERTY = 2 , TEXT_COLOR_GRAYED_OUT_IS_PROPERTY = 4 , TEXT_COLOR_PRESSED_IS_PROPERTY = 8 }
	Enumeration indicating if a property or a color value is used for each text color.

enum	VerAligned_t { V_TOP , V_CENTERED , V_BOTTOM }
	Possible vertical alignments. More...

Static Public Member Functions inherited from CGUIText
static eC_String	GetEllipsisString ()

static eC_String	GetHyphenString ()

static void	SetEllipsisString (const eC_String &kEllipsis)

static void	SetHyphenString (const eC_String &kHyphen)

Static Public Attributes inherited from CGUIText
static const eC_Char	XMLTAG_TEXT_COLOR_GRAYEDOUT []
	xml-tag for grayedout-color

static const eC_Char	XMLTAG_TEXT_COLOR_HIGHLIGHTED []
	xml-tag for highlighted-color

static const eC_Char	XMLTAG_TEXT_COLOR_PRESSED []
	xml-tag for pressed-color

static const eC_Char	XMLTAG_TEXT_COLOR_PROPERTY_FLAGS []
	XML tag to be used when writing text colors into a stream. More...

static const eC_Char	XMLTAG_TEXT_COLOR_STANDARD []
	xml-tag for standard-color

static const eC_Char	XMLTAG_TEXTID []
	XML tag to be used when writing a text ID into a stream.

static const eC_Char	XMLTAG_TEXTTYPEID []
	XML tag to be used when writing a text type ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Static Protected Attributes inherited from CGUIText
static const ExtendedString_t	ms_ckEmptyExtendedString
	An empty Extended String.

static const eC_String	ms_ckEmptyString
	An empty string.

static const eC_String	ms_ckSingleSpace
	A single space character for text size calculations.

Detailed Description

Text implementation which supports rich text.

Text implementation which supports rich text (bold, italic, underlined, color...) via tags embedded in the supplied text string. It is recommended to only use rich text where necessary, since it requires significantly more performance that Guiliani's plain standard texts. Prior to using the rich text object you need to supply it with one font each for "bold", "italic" and "bold-italic". Otherwise, the text's default font identifier will be used instead.

Format tags must be embedded in the following syntax (equal to normal HTML syntax):

<[FORMAT_TAG1]><[FORMAT_TAG2]>[STRING TO OUTPUT]</[FORMAT_TAG1]></[FORMAT_TAG2]>

The following format tags are supported:

"<colorFFFFFF55>some string</colorFFFFFF55>" Sets the color used for printing the given string. Color format is AARRGGBB.

"some string" Prints the given string using the bold-font.

"some string" Prints the given string using the italic-font.

"some string" Prints the given string using the underlined-font.

"some string" Avoids line breaking the string.

Example:

// Create a textfield
CGUIBaseTextField* pTextField = new CGUIBaseTextField(this, 10, 300, 250, 40, "", false);

// A demo string including rich text formatting
eC_String kRichText("This is a <colorFFFFFF55>text</colorFFFFFF55> which shall Wg demonstrate the use of <b>rich Wg text</b> features within <i><colorFFFF0000>Guiliani</colorFFFF0000></i>.");

// Create richtext object
CGUIRichText* pRichText = new CGUIRichText(this, kRichText);

// Supply fonts for each format tag
FontResource_t FontNormal = GETRESMANAGER.RegisterDynamicFont("DejaVuSerifCondensed.ttf", 15, CFntWrap::FNT_NORMAL, true);
GETRESMANAGER.RequestFontResource(FontNormal);
FontResource_t FontBold = GETRESMANAGER.RegisterDynamicFont("DejaVuSerifCondensed-Bold.ttf", 17, CFntWrap::FNT_BOLD, true);
GETRESMANAGER.RequestFontResource(FontBold);
FontResource_t FontItalic = GETRESMANAGER.RegisterDynamicFont("DejaVuSerifCondensed-Italic.ttf", 15, CFntWrap::FNT_ITALIC, true);
GETRESMANAGER.RequestFontResource(FontItalic);
FontResource_t FontBoldItalic = GETRESMANAGER.RegisterDynamicFont("DejaVuSerifCondensed-BoldItalic.ttf", 15, static_cast<CFntWrap::GUIFont_t>(CFntWrap::FNT_BOLD | CFntWrap::FNT_ITALIC), true);
GETRESMANAGER.RequestFontResource(FontBoldItalic);
pRichText->SetRichFonts(FontNormal, FontBold, FontItalic, FontBoldItalic);

// Associate richtext with text field
pTextField->SetText(pRichText);
pRichText->SetTextWidth(pTextField->GetWidth());
pRichText->SetTextHeight(pTextField->GetHeight());
pRichText->SetAligned(CGUIText::V_CENTERED, CGUIText::H_CENTERED);
pRichText->SetTextSingleLine(false);

Constructor & Destructor Documentation

◆ CGUIRichText() [1/4]

CGUIRichText::CGUIRichText	(	const CGUIObject *const	pkParentObject,
		const eC_String &	kText,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs a string rich text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
kText	Reference of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIRichText() [2/4]

CGUIRichText::CGUIRichText	(	const CGUIObject *const	pkParentObject,
		const eC_String *const	pkText,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs a string rich text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
pkText	Pointer of text string.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIRichText() [3/4]

CGUIRichText::CGUIRichText	(	const CGUIObject *const	pkParentObject,
		const TextResource_t &	eTextID,
		const eC_Value &	vXPos = `eC_FromInt(0)`,
		const eC_Value &	vYPos = `eC_FromInt(0)`,
		const eC_Bool &	bSingleLine = `true`
	)

Constructs an ID rich text. By default, the text width and height are set to the width and height of the parent object minus the relative positions.

Parameters

pkParentObject	Pointer to object containing the text.
eTextID	ID of the internationalised text.
vXPos	X position of text relative to the parent.
vYPos	Y position of text relative to the parent.
bSingleLine	true: text is always displayed in a single line, false: lines can be wrapped.

◆ CGUIRichText() [4/4]

CGUIRichText::CGUIRichText ( const CGUIRichText & kTextToBeCopied )

Copy constructor.

Parameters

kTextToBeCopied The rich text object to be copied.

◆ ~CGUIRichText()

virtual CGUIRichText::~CGUIRichText ( )

virtual

Destructor

Member Function Documentation

◆ AdaptText()

void CGUIRichText::AdaptText ( )

protectedvirtual

Adapt the text to the given width of the text field. The only adaptation made is replacing some trailing part of the last text line by Ellipsis characters. No font attribute, like font size, is changed. The function also removes HyphenationMarks from a single line text and calculates the required text width and height. For multi line texts this method breaks the original text into a list of strings at positions indicated by the user. It then calls CreateStringList() for further processing. This method only performs calculations if m_bAdaptText is set to true. Therefore, any method that changes attributes related to the text layout (including font settings, area size and so on) should set this flag to true instead of calling this method directly. It is called in as few places as possible.

Reimplemented from CGUIText.

◆ Clone()

virtual CGUIRichText * CGUIRichText::Clone ( ) const

virtual

Clones the instance of the GUIRichText object.

Returns: Pointer to the cloned GUIRichText object.

Reimplemented from CGUIText.

◆ EnablePreformatting()

void CGUIRichText::EnablePreformatting ( const eC_Bool & bPreformatText )

inline

Enables the preformatting of the text by removing useless spaces, truncating leading and ending spaces and removing the line breaks.

Parameters

bPreformatText true to enable preformatting.

◆ FitFragmentWithEllipsis()

void CGUIRichText::FitFragmentWithEllipsis	(	CRichTextFragment &	TextFragment,
		eC_Value	vMaxWidth
	)

protected

Truncates a Text-fragment, so that it will fit into the supplied horizontal space. If the fragment fits completely into the available space, nothing will be done. If it does not, it will be truncated using ellipsis.

Parameters

TextFragment	Text fragment which will be adapted.
vMaxWidth	Available width which must not be exceeded

◆ GetFormatTagBold()

const eC_String & CGUIRichText::GetFormatTagBold ( ) const

inline

Returns the indicator string for the bold tag.

Returns: Indicator string.

◆ GetFormatTagClosing()

const eC_String & CGUIRichText::GetFormatTagClosing ( ) const

inline

Returns the indicator string for the tag closing sign.

Returns: Indicator string.

◆ GetFormatTagColor()

const eC_String & CGUIRichText::GetFormatTagColor ( ) const

inline

Returns the indicator string for the color tag.

Returns: Indicator string.

◆ GetFormatTagFinished()

const eC_String & CGUIRichText::GetFormatTagFinished ( ) const

inline

Returns the indicator string for the tag finished sign.

Returns: Indicator string.

◆ GetFormatTagItalic()

const eC_String & CGUIRichText::GetFormatTagItalic ( ) const

inline

Returns the indicator string for the italic tag.

Returns: Indicator string.

◆ GetFormatTagLineBreak()

const eC_String & CGUIRichText::GetFormatTagLineBreak ( ) const

inline

Returns the indicator string for the force line break tag.

Returns: Indicator string.

◆ GetFormatTagListItem()

const eC_String & CGUIRichText::GetFormatTagListItem ( ) const

inline

Returns the indicator string for the list item tag.

Returns: Indicator string.

◆ GetFormatTagNoBreak()

const eC_String & CGUIRichText::GetFormatTagNoBreak ( ) const

inline

Returns the indicator string for the no line break tag.

Returns: Indicator string.

◆ GetFormatTagOpening()

const eC_String & CGUIRichText::GetFormatTagOpening ( ) const

inline

Returns the indicator string for the tag opening sign.

Returns: Indicator string.

◆ GetFormatTagOrderedList()

const eC_String & CGUIRichText::GetFormatTagOrderedList ( ) const

inline

Returns the indicator string for the ordered list tag.

Returns: Indicator string.

◆ GetFormatTagUnderlined()

const eC_String & CGUIRichText::GetFormatTagUnderlined ( ) const

inline

Returns the indicator string for the underlined tag.

Returns: Indicator string.

◆ GetFormatTagUnorderedList()

const eC_String & CGUIRichText::GetFormatTagUnorderedList ( ) const

inline

Returns the indicator string for the unordered list tag.

Returns: Indicator string.

◆ GetRequiredOrgTextSpace()

virtual void CGUIRichText::GetRequiredOrgTextSpace	(	eC_Value &	vTextWidth,
		eC_Value &	vTextHeight
	)

virtual

Get the required space for the text. Calculates the space required for printing the original text string in a single line. No line breaks or hyphenation markers are taken into account.

Parameters

[out]	vTextWidth	The required text width.
[out]	vTextHeight	The required text height.

Reimplemented from CGUIText.

◆ IsTextPreformatted()

eC_Bool CGUIRichText::IsTextPreformatted ( )

inline

Indicates if preformatting is enabled or not.

Returns: True if preformatting of the text is enabled

◆ OnNotification()

void CGUIRichText::OnNotification ( )

protectedvirtual

Check if the text colors are updated and parse the text again if necessary.

Reimplemented from CGUIText.

◆ operator=()

CGUIRichText & CGUIRichText::operator= ( const CGUIRichText & kSource )

Copies the base attributes from a source object. This rich text object will have the same containing object as the source. If you want to set another containing object, you should use SetContainingObject() to set it.

Parameters

kSource The source object whose attributes are copied.

Returns: Where to assign to

◆ ParseTextToRich()

void CGUIRichText::ParseTextToRich ( )

protected

Parses the text for rich text tags and formats it accordingly. Please refer to the class documentation for a description of the supported rich text tags.

◆ PreformatText()

void CGUIRichText::PreformatText ( )

protected

Removes line breaks, trims blanks at the beginning and end and combines repeated blanks.

◆ PreparePrintForFragment()

void CGUIRichText::PreparePrintForFragment ( const CRichTextFragment & Fragment )

protected

Sets the font and all accompanying attributes of a text fragment. This needs to be called prior to any RequiredSpace() calls

Parameters

Fragment

◆ PrintText()

virtual void CGUIRichText::PrintText ( )

virtual

Prints the text. This function may only be called from the DoDraw() implementation of the text's containing GUI object as it uses absolute positioning.

Reimplemented from CGUIText.

◆ ReadFromStream()

virtual void CGUIRichText::ReadFromStream ( )

protectedvirtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also: CGUIObject::ReadFromStream()

Reimplemented from CGUIText.

◆ SetFont()

virtual void CGUIRichText::SetFont ( const FontResource_t & eFontID )

inlinevirtual

Sets all fonts (Normal, Bold, Italic, BoldItalic) to the given FontID

Parameters

eFontID ID for all internal fonts

Reimplemented from CGUIText.

◆ SetFormatTagBold()

void CGUIRichText::SetFormatTagBold ( const eC_String & kTag )

inline

Sets the indicator string for the bold tag.

Parameters

kTag	String to set.

◆ SetFormatTagClosing()

void CGUIRichText::SetFormatTagClosing ( const eC_String & kTag )

inline

Sets the string for tag closing sign (e.g. ">")

Parameters

kTag	String to set.

◆ SetFormatTagColor()

void CGUIRichText::SetFormatTagColor ( const eC_String & kTag )

inline

Sets the indicator string for the color tag.

Parameters

kTag	String to set.

◆ SetFormatTagFinished()

void CGUIRichText::SetFormatTagFinished ( const eC_String & kTag )

inline

Sets the string for tag finished sign (e.g. "/")

Parameters

kTag	String to set.

◆ SetFormatTagItalic()

void CGUIRichText::SetFormatTagItalic ( const eC_String & kTag )

inline

Sets the indicator string for the italic tag.

Parameters

kTag	String to set.

◆ SetFormatTagLineBreak()

void CGUIRichText::SetFormatTagLineBreak ( const eC_String & kTag )

inline

Sets the indicator string for the forced line break tag.

Parameters

kTag	String to set.

◆ SetFormatTagListItem()

void CGUIRichText::SetFormatTagListItem ( const eC_String & kTag )

inline

Sets the indicator string for the list item tag.

Parameters

kTag	String to set.

◆ SetFormatTagNoBreak()

void CGUIRichText::SetFormatTagNoBreak ( const eC_String & kTag )

inline

Sets the indicator string for the no line break tag.

Parameters

kTag	String to set.

◆ SetFormatTagOpening()

void CGUIRichText::SetFormatTagOpening ( const eC_String & kTag )

inline

Sets the string for tag opening sign (e.g. "<")

Parameters

kTag	String to set.

◆ SetFormatTagOrderedList()

void CGUIRichText::SetFormatTagOrderedList ( const eC_String & kTag )

inline

Sets the indicator string for the ordered list tag.

Parameters

kTag	String to set.

◆ SetFormatTagUnderlined()

void CGUIRichText::SetFormatTagUnderlined ( const eC_String & kTag )

inline

Sets the indicator string for the underlined tag.

Parameters

kTag	String to set.

◆ SetFormatTagUnorderedList()

void CGUIRichText::SetFormatTagUnorderedList ( const eC_String & kTag )

inline

Sets the indicator string for the unordered list tag.

Parameters

kTag	String to set.

◆ SetRichFonts()

virtual void CGUIRichText::SetRichFonts	(	const FontResource_t &	eFontNormal = `DUMMY_FONT`,
		const FontResource_t &	eFontBold = `DUMMY_FONT`,
		const FontResource_t &	eFontItalic = `DUMMY_FONT`,
		const FontResource_t &	eFontBoldItalic = `DUMMY_FONT`
	)

virtual

Sets the font resources which will be used for rich text formatting

Parameters

eFontNormal	Normal font
eFontBold	Bold font
eFontItalic	Italic font
eFontBoldItalic	Bold italic font

◆ SetTextColor()

virtual void CGUIRichText::SetTextColor	(	const eC_UInt &	uiTextColorStandard,
		const eC_UInt &	uiTextColorHighlighted,
		const eC_UInt &	uiTextColorGrayedOut,
		const eC_UInt &	uiTextColorPressed
	)

virtual

Sets the color of the text. The colors are used when printing the text. The state of the containing CGUIObject determines which color is used.

Parameters

uiTextColorStandard	Standard Text color in ARGB coding (e.g. 0xFFFFFFFF).
uiTextColorHighlighted	Text color in ARGB coding used if the parent object is highlighted.
uiTextColorGrayedOut	Text color in ARGB coding used if the parent object is grayed out.
uiTextColorPressed	Text color in ARGB coding used if the parent object is pressed.

Reimplemented from CGUIText.

◆ SetTextID()

virtual void CGUIRichText::SetTextID ( const TextResource_t & eTextID )

virtual

Sets the text ID.

Parameters

eTextID The ID of the text to assign to this object.

Reimplemented from CGUIText.

◆ SetTextString()

virtual void CGUIRichText::SetTextString ( const eC_String & kTextString )

virtual

Sets the string text to be represented by this object.

Parameters

kTextString The string to be assigned to this object.

Reimplemented from CGUIText.

◆ SplitFragment()

void CGUIRichText::SplitFragment	(	CRichTextFragment &	FirstTextFragment,
		CRichTextFragment &	SecondTextFragment,
		eC_Value	vMaxWidth,
		eC_UInt	uiCharOffsetFromStart
	)

protected

Checks if a text-fragment fits completely into the given horizontal space. If not, the fragment will be split into two separate fragments, where the first one optimally uses the available space, while the second one contains the remaining text portion.

Parameters

FirstTextFragment	Text fragment whose length will be checked, and which will be split up if necessary
SecondTextFragment	This will contain any remaining text of FirstTextFragment, which did not fit into the given space.
vMaxWidth	Available width for First text fragment. It will be split when exceeding this width.
uiCharOffsetFromStart	Offset in characters from beginning of the entire text

◆ WriteToStream()

virtual void CGUIRichText::WriteToStream ( const eC_Bool bWriteTextType = false )

protectedvirtual

Called by the framework when writing streaming files. When deriving a new text class in an application, re-implement this method.

Parameters

bWriteTextType Indicates whether the ID needs to be written. If the framework calls this method, it passes true here. The base class implementation has to be called with false (default). If called with true, the first two tags written must be this text's XML name tag (see GetXMLTag()) and its text type ID. After all attributes are written, the name tag has to be written again as a closing tag (preceded by a slash).

Reimplemented from CGUIText.

Member Data Documentation

◆ m_kRichTextFragments

RichTextFragmentList CGUIRichText::m_kRichTextFragments

protected

List of all Text-fragments within this text. This list will be overwritten on every AdaptText() call.

The documentation for this class was generated from the following file:

GUIRichText.h

Classes

Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ CGUIRichText() [1/4]

◆ CGUIRichText() [2/4]

◆ CGUIRichText() [3/4]

◆ CGUIRichText() [4/4]

◆ ~CGUIRichText()

Member Function Documentation

◆ AdaptText()

◆ Clone()

◆ EnablePreformatting()

◆ FitFragmentWithEllipsis()

◆ GetFormatTagBold()

◆ GetFormatTagClosing()

◆ GetFormatTagColor()

◆ GetFormatTagFinished()

◆ GetFormatTagItalic()

◆ GetFormatTagLineBreak()

◆ GetFormatTagListItem()

◆ GetFormatTagNoBreak()

◆ GetFormatTagOpening()

◆ GetFormatTagOrderedList()

◆ GetFormatTagUnderlined()

◆ GetFormatTagUnorderedList()

◆ GetRequiredOrgTextSpace()

◆ IsTextPreformatted()

◆ OnNotification()

◆ operator=()

◆ ParseTextToRich()

◆ PreformatText()

◆ PreparePrintForFragment()

◆ PrintText()

◆ ReadFromStream()

◆ SetFont()

◆ SetFormatTagBold()

◆ SetFormatTagClosing()

◆ SetFormatTagColor()

◆ SetFormatTagFinished()

◆ SetFormatTagItalic()

◆ SetFormatTagLineBreak()

◆ SetFormatTagListItem()

◆ SetFormatTagNoBreak()

◆ SetFormatTagOpening()

◆ SetFormatTagOrderedList()

◆ SetFormatTagUnderlined()

◆ SetFormatTagUnorderedList()

◆ SetRichFonts()

◆ SetTextColor()

◆ SetTextID()

◆ SetTextString()

◆ SplitFragment()

◆ WriteToStream()

Member Data Documentation

◆ m_kRichTextFragments
