The font wrapper base class. More...

#include <FntWrap.h>

Inheritance diagram for CFntWrap:

[legend]

Classes
struct	GlyphMetrics_t

Public Types
enum	GUIFont_t { FNT_NORMAL = 0 , FNT_ITALIC = 1 , FNT_UNDERLINED = 2 , FNT_BOLD = 4 }

enum	TextOperation_t { RENDER_TEXT , GET_REQUIRED_SPACE }

Public Member Functions
void	ChangeFont (const FontResource_t &eFontID, const eC_String &pcPath, const eC_UInt uiFontSize, const GUIFont_t &eFontStyle)

virtual void	FittingNumChars (const eC_String *const pkText, eC_Value vWidthMax, eC_UInt &uiNumChars, const eC_Bool &bStartAtEnd=false)

virtual eC_Int	GetAscender () const

virtual eC_Int	GetDescender () const

virtual void	GetGlyphMetrics (const eC_Char cChar, GlyphMetrics_t &kMetrics)

virtual eC_Int	GetInternalLeading () const

virtual eC_UInt	GetNOFFonts ()

CGUICommonEnums::Rotation_t	GetRotation () const

virtual eC_Value	GetTextXPosAdjustment (const CGUIText::HorAligned_t eHorAlignment)

virtual eC_Value	GetTextYPosAdjustment (const CGUIText::VerAligned_t eVerAlignment)

virtual void	LoadFont (const FontResource_t &eFontID)

virtual void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)=0

virtual void	SetFont (const FontResource_t &eID)

virtual void	SetFontSpacing (const eC_Float &fSpacing)

virtual eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)

void	SetRotation (const CGUICommonEnums::Rotation_t &eRotation)

virtual void	Text (const eC_Value &vX1, const eC_Value &vY1, const eC_String *const lpString)=0

virtual void	UnloadFont (const FontResource_t &eFontID)

Static Public Member Functions
static void	DeleteInstance ()

Protected Member Functions
	CFntWrap ()
	Constructor.

virtual	~CFntWrap ()
	Destructor.

Protected Attributes
FontResource_t	m_eCurFont
	Current font id.

CGUICommonEnums::Rotation_t	m_eRotation
	Rotation.

eC_UInt	m_uiNOFFonts
	Total number of fonts.

eC_Value	m_vSpacing
	Font spacing, i.e the space between letters.

Friends
class	CGUIComponentManager

Detailed Description

The font wrapper base class.

This is the font wrapper base class. Guiliani is designed independently of a certain font engine. This class declares interfaces for handling all font functions such as loading fonts and printing text on the screen.

Please be aware that due to the cross-platform character of the framework, not all functions declared within the CFntWrap base class need to be available in all platform-specific implementations.

Member Enumeration Documentation

◆ GUIFont_t

enum CFntWrap::GUIFont_t

Definition of font styles.

◆ TextOperation_t

enum CFntWrap::TextOperation_t

Internal flag to indicate whether the text is actually being rendered or only its size is being calculated. Used by function RenderTextInternal().

Enumerator
RENDER_TEXT	render the text
GET_REQUIRED_SPACE	get required space for text

Member Function Documentation

◆ ChangeFont()

void CFntWrap::ChangeFont	(	const FontResource_t &	eFontID,
		const eC_String &	pcPath,
		const eC_UInt	uiFontSize,
		const GUIFont_t &	eFontStyle
	)

Change the font at position eFontID with the font identified by pcPath. If the font already exists, it is unloaded first.

Parameters

eFontID	id (and hence index) of the font.
pcPath	Path or name of the font.
uiFontSize	Size of the font.
eFontStyle	Style of the font (italic, underline, bold, ... see GUIFont.h).

◆ DeleteInstance()

static void CFntWrap::DeleteInstance ( )

static

Delete the instance if it exists. Set the pointer NULL.

◆ FittingNumChars()

virtual void CFntWrap::FittingNumChars	(	const eC_String *const	pkText,
		eC_Value	vWidthMax,
		eC_UInt &	uiNumChars,
		const eC_Bool &	bStartAtEnd = `false`
	)

virtual

Calculates number of characters that fit in a given width with the currently active font.

Parameters

pkText	The text.
vWidthMax	Maximum width for the text in pixels.
uiNumChars	Reference value returning the number of characters that fit into that width.
bStartAtEnd	if this is true the text will be processed the other way round (e.g. RTL-languages)

◆ GetAscender()

virtual eC_Int CFntWrap::GetAscender ( ) const

inlinevirtual

Returns the currently set font's ascender-metric. If the ascender is not supported by a given Font-Wrapper, this returns 0.

Returns: ascender in pixels

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, and CFntWrapGlyphLibGL.

◆ GetDescender()

virtual eC_Int CFntWrap::GetDescender ( ) const

inlinevirtual

Returns the currently set font's descender-metric. If the descender is not supported by a given Font-Wrapper, this returns 0.

Returns: descender in pixels

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, and CFntWrapGlyphLibGL.

◆ GetGlyphMetrics()

virtual void CFntWrap::GetGlyphMetrics	(	const eC_Char	cChar,
		GlyphMetrics_t &	kMetrics
	)

inlinevirtual

Get the metrics of a glyph for a specific character

Parameters

cChar	character
kMetrics	metrics of glyph

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, and CFntWrapGlyphLibGL.

◆ GetInternalLeading()

virtual eC_Int CFntWrap::GetInternalLeading ( ) const

inlinevirtual

Returns the currently set font's internal leading. If the internal leading is not supported by a given Font-Wrapper, this returns 0.

Returns: internal leading in pixels

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, CFntWrapGlyphLibGL, and CFntWrapFreeTypeVG.

◆ GetNOFFonts()

virtual eC_UInt CFntWrap::GetNOFFonts ( )

inlinevirtual

Gets the number of fonts (array size).

Returns: Number of fonts.

◆ GetRotation()

CGUICommonEnums::Rotation_t CFntWrap::GetRotation ( ) const

inline

Get the current rotation for text-rendering

Returns: rotation

◆ GetTextXPosAdjustment()

virtual eC_Value CFntWrap::GetTextXPosAdjustment ( const CGUIText::HorAligned_t eHorAlignment )

inlinevirtual

Get the x position adjustment because of platform specific font structure.

Parameters

eHorAlignment The horizontal alignment of GUIText object.

Returns: The x position adjustment. The GUItext object should add this adjustment to get the correct position.

◆ GetTextYPosAdjustment()

virtual eC_Value CFntWrap::GetTextYPosAdjustment ( const CGUIText::VerAligned_t eVerAlignment )

inlinevirtual

Get the Y position adjustment because of platform specific font structure.

Parameters

eVerAlignment The vertical alignment of GUIText object.

Returns: The y position adjustment. The GUItext object should add this adjustment to get the correct position.

◆ LoadFont()

virtual void CFntWrap::LoadFont ( const FontResource_t & eFontID )

inlinevirtual

Loads a font identified by eFontID into an array of fonts at position eFontID. If the font already exists, it's not loaded again. Should only be called by a FntWrapper.

Parameters

eFontID id (and hence index) of the font. False else.

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, CFntWrapGlyphLibGL, and CFntWrapFreeTypeVG.

◆ RequiredSpace()

virtual void CFntWrap::RequiredSpace	(	const eC_String *const	pkText,
		eC_Value &	vWidth,
		eC_Value &	vHeight
	)

pure virtual

Calculates the required space in x- and y-direction of a given text with the currently active font.

Parameters

pkText	The text.
vWidth	Reference to width of the font in pixels.
vHeight	Reference to height of the font in pixels.

Implemented in CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapNull, and CFntWrapFreeTypeVG.

◆ SetFont()

virtual void CFntWrap::SetFont ( const FontResource_t & eID )

virtual

Sets a new font for the application.

Parameters

eID	id (and hence index) of the font.

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, and CFntWrapGlyphLib.

◆ SetFontSpacing()

virtual void CFntWrap::SetFontSpacing ( const eC_Float & fSpacing )

virtual

Sets a new font spacing, i.e the space between letters.

Parameters

fSpacing New font spacing.

◆ SetNOFFonts()

virtual eC_Bool CFntWrap::SetNOFFonts ( const eC_UInt uiNOFFonts )

virtual

Sets the total number of fonts. This is called internally by the ResourceManager when dynamically allocated font resources require the total number of fonts to be raised. Derived classes will have to override this method and resize their internal font-storage structures according to the new number of fonts which will have to be stored.

Parameters

uiNOFFonts The number of fonts

Returns: True if internal storage has been successfully adapted to support the requested number of fonts. False otherwise.

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapNull, CFntWrapFreeTypeGL, CFntWrapGlyphLibGL, and CFntWrapFreeTypeVG.

◆ SetRotation()

void CFntWrap::SetRotation ( const CGUICommonEnums::Rotation_t & eRotation )

inline

Set the current rotation for text-rendering

Parameters

eRotation rotation

◆ Text()

virtual void CFntWrap::Text	(	const eC_Value &	vX1,
		const eC_Value &	vY1,
		const eC_String *const	lpString
	)

pure virtual

Print the text to screen.

Parameters

vX1	Absolute x position of the top-left corner of the bounding rectangle.
vY1	Absolute y position of the top-left corner of the bounding rectangle.
lpString	The string to be printed.

Implemented in CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapNull, and CFntWrapFreeTypeVG.

◆ UnloadFont()

virtual void CFntWrap::UnloadFont ( const FontResource_t & eFontID )

inlinevirtual

Removes the font from the font list. Should only be called by a FntWrapper.

Parameters

eFontID Id of font to be removed.

Reimplemented in CFntWrapFreeTypeDAVE, CFntWrapGlyphLibDAVE, CFntWrapFreeType, CFntWrapGlyphLib, CFntWrapFreeTypeGL, CFntWrapGlyphLibGL, and CFntWrapFreeTypeVG.

Friends And Related Function Documentation

◆ CGUIComponentManager

friend class CGUIComponentManager

friend

The documentation for this class was generated from the following file:

FntWrap.h
