this class wraps FreeType2 More...

#include <FntWrapFreeType.h>

Inheritance diagram for CFntWrapFreeType:

[legend]

Static Public Member Functions
static eC_Bool	CreateInstance (const eC_UInt &uiCacheSize, const eC_UInt &uiMaxNumFaces=10, const eC_UInt &uiMaxNumSizeObjects=10)

Static Public Member Functions inherited from CFntWrap
static void	DeleteInstance ()

Protected Member Functions
	CFntWrapFreeType ()
	Default constructor.

	CFntWrapFreeType (const eC_UInt &uiCacheSize, const eC_UInt &uiMaxNumFaces, const eC_UInt &uiMaxNumSizeObjects)

virtual	~CFntWrapFreeType (void)
	Destructor.

virtual eC_Int	GetAscender () const

virtual eC_Int	GetDescender () const

virtual void	GetGlyphMetrics (const eC_Char cChar, GlyphMetrics_t &kMetrics)

virtual eC_Int	GetInternalLeading () const

virtual void	LoadFont (const FontResource_t &eFontID)

virtual void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)

virtual void	SetFont (const FontResource_t &eID)

virtual eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)

virtual void	Text (const eC_Value &vX1, const eC_Value &vY1, const eC_String *const lpString)

virtual void	UnloadFont (const FontResource_t &eFontID)

Protected Member Functions inherited from CFntWrap
	CFntWrap ()
	Constructor.

virtual	~CFntWrap ()
	Destructor.

Protected Attributes
eC_Bool	m_bUseCache
	if caching is used

FT_Library	m_pkFreeTypeLibrary
	handle to freetype-library

eC_UInt	m_uiCacheSize
	size of cache for font

eC_UInt	m_uiMaxNumFaces
	maximum number of faces

eC_UInt	m_uiMaxNumSizeObjects
	maximum size of one object

Protected Attributes inherited from CFntWrap
FontResource_t	m_eCurFont
	Current font id.

CGUICommonEnums::Rotation_t	m_eRotation
	Rotation.

eC_UInt	m_uiNOFFonts
	Total number of fonts.

eC_Value	m_vSpacing
	Font spacing, i.e the space between letters.

Additional Inherited Members
Public Types inherited from CFntWrap
enum	GUIFont_t { FNT_NORMAL = 0 , FNT_ITALIC = 1 , FNT_UNDERLINED = 2 , FNT_BOLD = 4 }

enum	TextOperation_t { RENDER_TEXT , GET_REQUIRED_SPACE }

Public Member Functions inherited from CFntWrap
void	ChangeFont (const FontResource_t &eFontID, const eC_String &pcPath, const eC_UInt uiFontSize, const GUIFont_t &eFontStyle)

virtual void	FittingNumChars (const eC_String *const pkText, eC_Value vWidthMax, eC_UInt &uiNumChars, const eC_Bool &bStartAtEnd=false)

virtual eC_Int	GetAscender () const

virtual eC_Int	GetDescender () const

virtual void	GetGlyphMetrics (const eC_Char cChar, GlyphMetrics_t &kMetrics)

virtual eC_Int	GetInternalLeading () const

virtual eC_UInt	GetNOFFonts ()

CGUICommonEnums::Rotation_t	GetRotation () const

virtual eC_Value	GetTextXPosAdjustment (const CGUIText::HorAligned_t eHorAlignment)

virtual eC_Value	GetTextYPosAdjustment (const CGUIText::VerAligned_t eVerAlignment)

virtual void	LoadFont (const FontResource_t &eFontID)

virtual void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)=0

virtual void	SetFont (const FontResource_t &eID)

virtual void	SetFontSpacing (const eC_Float &fSpacing)

virtual eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)

void	SetRotation (const CGUICommonEnums::Rotation_t &eRotation)

virtual void	Text (const eC_Value &vX1, const eC_Value &vY1, const eC_String *const lpString)=0

virtual void	UnloadFont (const FontResource_t &eFontID)

Detailed Description

this class wraps FreeType2

Constructor & Destructor Documentation

◆ CFntWrapFreeType()

CFntWrapFreeType::CFntWrapFreeType	(	const eC_UInt &	uiCacheSize,
		const eC_UInt &	uiMaxNumFaces,
		const eC_UInt &	uiMaxNumSizeObjects
	)

protected

Constructor.

Parameters

uiCacheSize	The maximum size of the FreeType cache in byte.
uiMaxNumFaces	Maximum number of opened font face objects managed by the FreeType cache.
uiMaxNumSizeObjects	Maximum number of opened size objects managed by the FreeType cache.

Member Function Documentation

◆ CreateInstance()

static eC_Bool CFntWrapFreeType::CreateInstance	(	const eC_UInt &	uiCacheSize,
		const eC_UInt &	uiMaxNumFaces = `10`,
		const eC_UInt &	uiMaxNumSizeObjects = `10`
	)

static

Create a FntWrap-FreeType object. It should be created in implementation after creation of GfxWrap.

Parameters

uiCacheSize	The max size of the freetype cache in bytes.
uiMaxNumFaces	Maximum number of opened font face objects managed by the FreeType cache.
uiMaxNumSizeObjects	Maximum number of opened size objects managed by the FreeType cache.

Returns: True, if it is successfully created, False otherwise.

◆ GetAscender()

virtual eC_Int CFntWrapFreeType::GetAscender ( ) const

inlineprotectedvirtual

Return the ascender for the font

Returns: ascender

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ GetDescender()

virtual eC_Int CFntWrapFreeType::GetDescender ( ) const

inlineprotectedvirtual

Return the descender for the font

Returns: descender

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ GetGlyphMetrics()

virtual void CFntWrapFreeType::GetGlyphMetrics	(	const eC_Char	cChar,
		GlyphMetrics_t &	kMetrics
	)

protectedvirtual

Return the glyph-metrics of specified character

Parameters

cChar	character
kMetrics	metrics of the glyph

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ GetInternalLeading()

virtual eC_Int CFntWrapFreeType::GetInternalLeading ( ) const

inlineprotectedvirtual

Return internal leading of font

Returns: internal leading

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ LoadFont()

virtual void CFntWrapFreeType::LoadFont ( const FontResource_t & eFontID )

protectedvirtual

Loads a font identified by eFontID into an array of fonts at position eFontID. If the font already exists, it's not loaded again. Should only be called by a FntWrapper.

Parameters

eFontID id (and hence index) of the font. False else.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ RequiredSpace()

virtual void CFntWrapFreeType::RequiredSpace	(	const eC_String *const	pkText,
		eC_Value &	vWidth,
		eC_Value &	vHeight
	)

protectedvirtual

Calculates the required space in x- and y-direction of a given text with the currently active font.

Parameters

pkText	The text.
vWidth	Reference to width of the font in pixels.
vHeight	Reference to height of the font in pixels.

Implements CFntWrap.

◆ SetFont()

virtual void CFntWrapFreeType::SetFont ( const FontResource_t & eID )

protectedvirtual

Sets a new font for the application.

Parameters

eID	id (and hence index) of the font.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE.

◆ SetNOFFonts()

virtual eC_Bool CFntWrapFreeType::SetNOFFonts ( const eC_UInt uiNOFFonts )

protectedvirtual

Sets the total number of fonts. This is called internally by the ResourceManager when dynamically allocated font resources require the total number of fonts to be raised. Derived classes will have to override this method and resize their internal font-storage structures according to the new number of fonts which will have to be stored.

Parameters

uiNOFFonts The number of fonts

Returns: True if internal storage has been successfully adapted to support the requested number of fonts. False otherwise.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

◆ Text()

virtual void CFntWrapFreeType::Text	(	const eC_Value &	vX1,
		const eC_Value &	vY1,
		const eC_String *const	lpString
	)

protectedvirtual

Print the text to screen.

Parameters

vX1	Absolute x position of the top-left corner of the bounding rectangle.
vY1	Absolute y position of the top-left corner of the bounding rectangle.
lpString	The string to be printed.

Implements CFntWrap.

◆ UnloadFont()

virtual void CFntWrapFreeType::UnloadFont ( const FontResource_t & eFontID )

protectedvirtual

Removes the font from the font list. Should only be called by a FntWrapper.

Parameters

eFontID Id of font to be removed.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapFreeTypeDAVE, and CFntWrapFreeTypeGL.

The documentation for this class was generated from the following file:

FntWrapFreeType.h
