CGUISubject Class Reference

Subject Base class for Observer-Design-Pattern within Guiliani. More...

#include <GUISubject.h>

Inheritance diagram for CGUISubject:

Public Member Functions
	CGUISubject ()
	Default constructor.
virtual	~CGUISubject ()
	Default destructor.
void	AddObserver (CGUIObserver *pObserver)
void	ClearObservers ()
	Removes all observers from the internal list.
const eC_TListDoubleLinked< CGUIObserver * > &	GetObserverList () const
void	NotifyObservers ()
void	NotifyObservers (const CGUIObject *const pkUpdatedObject)
void	NotifyObservers (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)
void	NotifyObservers (const eC_String &kMessage)
void	RemoveObserver (CGUIObserver *pObserver)

Friends
class	CGUIObserver

Detailed Description

Subject Base class for Observer-Design-Pattern within Guiliani.

Use this base class if you wish to follow the observer-design-pattern within your application. Simply derive the class that you want to act as a subject from CGUISubject and whenever you want to inform any potential observers about changes within your object, call NotifyObservers(). The AddObserver() and RemoveObserver() methods are used only to handle the list of objects observing your subject and do not need to be overridden in your derived class.

Member Function Documentation

AddObserver()

void CGUISubject::AddObserver

(

CGUIObserver *

pObserver

)

Adds an observer to the internal observer list. The observer will be notified whenever the subject triggers an update.

Parameters

pObserver

The observer to add.

GetObserverList()

const eC_TListDoubleLinked< CGUIObserver * > & CGUISubject::GetObserverList ( ) const

inline

Returns

The list of all observers that are currently observing this subject.

NotifyObservers() [1/4]

void CGUISubject::NotifyObservers

(

)

Triggers notification of all registered observers. CGUIObserver::OnNotification() will be called for each.

NotifyObservers() [2/4]

void CGUISubject::NotifyObservers

(

const CGUIObject *const

pkUpdatedObject

)

Triggers notification of all registered observers. CGUIObserver::OnNotification(const CGUIObject* const) will be called for each.

Parameters

pkUpdatedObject

Will be passed to CGUIObserver::OnNotification(const CGUIObject* const)

NotifyObservers() [3/4]

void CGUISubject::NotifyObservers	(	const CGUIValue &	kObservedValue,
		const CGUIObject *const	pkUpdatedObject,
		const eC_UInt	uiX = 0,
		const eC_UInt	uiY = 0
	)

Triggers notification of all registered observers. CGUIObserver::OnNotification(const CGUIValue&, const CGUIObject* const, const eC_UInt, const eC_UInt) will be called for each.

Parameters

kObservedValue	the updated value
pkUpdatedObject	the updated object (can be NULL)
uiX	X-Index of value to be set in case the updated value is part of a multidimensional array
uiY	Y-Index of value to be set in case the updated value is part of a multidimensional array

NotifyObservers() [4/4]

void CGUISubject::NotifyObservers

(

const eC_String &

kMessage

)

Triggers notification of all registered observers. CGUIObserver::OnNotification(const eC_String&) will be called for each.

Parameters

kMessage

Will be passed to CGUIObserver::OnNotification(const eC_String&)

RemoveObserver()

void CGUISubject::RemoveObserver

(

CGUIObserver *

pObserver

)

Removes a registered observer from the internal observer list.

Parameters

pObserver

The observer to remove.

Friends And Related Function Documentation

CGUIObserver

friend class CGUIObserver

friend

---

The documentation for this class was generated from the following file:

• GUISubject.h
