No-frills text input control, not to be used on its own. More...

#include <GUIEdit.h>

Inheritance diagram for CGUIEdit:

[legend]

Public Types
enum	AcceptedChars_t { AC_ALL , AC_LETTERS , AC_DIGITS , AC_ALPHANUMERIC , AC_NONE }
	Sets of characters that are accepted as input in a CGUIEdit. More...

Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Public Member Functions
	CGUIEdit ()

	CGUIEdit (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const eC_String &rkText, AcceptedChars_t eAcceptedChars=AC_ALL, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIEdit (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const eC_String &rkText, AcceptedChars_t eAcceptedChars=AC_ALL, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIEdit (const CGUIEdit &rkSource)

	~CGUIEdit ()

void	AddTextChangedObserver (CGUIObserver *pObserver)

eC_String	DeleteSelectedTextString ()

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX, const eC_Value &vDeltaY, const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDraw ()

eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)
	Edits the text in reaction to keyboard events. More...

void	EnsureCursorVisible ()

AcceptedChars_t	GetAcceptedChars () const

virtual void	GetFocus ()

CGUIEditableText *	GetLabel ()

eC_Int	GetMaxLength () const

eC_String	GetSelectedTextString ()

void	InsertTextString (const eC_String &rkTextString)

virtual eC_Bool	IsHighlightable () const

virtual void	LoseFocus ()

CGUIEdit &	operator= (const CGUIEdit &rkSource)

virtual void	ReadFromStream ()

void	RemoveTextChangedObserver (CGUIObserver *pObserver)

void	SetAcceptedChars (AcceptedChars_t eAcceptedChars)

void	SetHeight (const eC_Value &vY)

void	SetLabel (CGUIEditableText *pkText)

void	SetMaxLength (eC_Int iMaxLength)

void	SetResetCursorWhenFocusLost (const eC_Bool bResetCursor)

virtual void	SetTextID (const TextResource_t &eTextID)

virtual void	SetTextString (const eC_String &rkTextString)

void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Additional Inherited Members
Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Detailed Description

No-frills text input control, not to be used on its own.

If you want to have a fully functional input control, use CGUIBaseInputField or a derived class. Using CGUIEdit directly will lead to problems; especially focusing issues will occur.

This control maintains (and clips) a CGUIEditableText. It deals with keyboard input. It inserts, deletes and selects text as needed. It also animates the cursor of the text so that it appears to be blinking. The cursor position is also maintained here, performing the necessary operations when this control receives mouse events (button down sets the cursor position, dragging changes the selection, double clicking selects everything, SHIFT key combined with button down selects text).

When pressing the 'activate' (ENTER) key while this control is focused, the cursor blinking is stopped, and the event is transferred to the parent to be handled.

Pressing the BACKSPACE or DELETE key deletes the current selection. If no text is selected, a character next to the cursor is deleted.

The cursor can be moved around by pressing the cursor keys, HOME and END. If the SHIFT key is held down while pressing either of these keys, the text between the previous and the new cursor position is selected.

The set of characters that are accepted as input (see AcceptedChars_t) can be set when creating an object of this class. It may be changed later by calling SetAcceptedChars(). This attribute is only used for direct user input (i.e., DoChar()). The characters are not checked when changing the text in this control in other ways, like calling SetTextString(), InsertTextString() or streaming.

Platform Specific Limitations

GUIEdit does only work for horizontally left-alignment text (class CGUIEdit).

See CGUIEdit Platform Specific Limitations

Member Enumeration Documentation

◆ AcceptedChars_t

enum CGUIEdit::AcceptedChars_t

Sets of characters that are accepted as input in a CGUIEdit.

Enumerator
AC_ALL	All characters.
AC_LETTERS	All letters of the Latin alphabet and whitespace characters.
AC_DIGITS	Arabic digits.
AC_ALPHANUMERIC	Latin letters, arabic digits and whitespace characters.
AC_NONE	No characters.

Constructor & Destructor Documentation

◆ CGUIEdit() [1/4]

CGUIEdit::CGUIEdit	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const eC_String &	rkText,
		AcceptedChars_t	eAcceptedChars = `AC_ALL`,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

CGUIEdit constructor.

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object.
vY	X-position relative to its parent object.
vWidth	Width of the input field.
vHeight	Height of the input field.
rkText	Initial text to be shown in the input field.
eAcceptedChars	The character set accepted as input.
eID	Object Identifier of this input field (use NO_HANDLE if none is required).

◆ CGUIEdit() [2/4]

CGUIEdit::CGUIEdit	(	CGUICompositeObject *const	pkParent,
		const CGUIRect &	kRect,
		const eC_String &	rkText,
		AcceptedChars_t	eAcceptedChars = `AC_ALL`,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

CGUIEdit constructor.

Parameters

pkParent	Pointer to the designated parent object.
kRect	Client rectangle of the new CGUIEdit relative to the parent.
rkText	Initial text to be shown in the input field.
eAcceptedChars	The character set accepted as input.
eID	Object Identifier of this input field (use NO_HANDLE if none is required).

◆ CGUIEdit() [3/4]

CGUIEdit::CGUIEdit ( const CGUIEdit & rkSource )

Copy constructor.

Parameters

rkSource Original instance which is copied.

◆ ~CGUIEdit()

CGUIEdit::~CGUIEdit ( )

CGUIEdit destructor

◆ CGUIEdit() [4/4]

CGUIEdit::CGUIEdit ( )

Standard constructor

See also: CGUIObject().

Member Function Documentation

◆ DeleteSelectedTextString()

eC_String CGUIEdit::DeleteSelectedTextString ( )

Deletes the selected text (if any).

Returns: The selected text string before deletion.

◆ DoAnimate()

virtual void CGUIEdit::DoAnimate ( const eC_Value & vTimes = eC_FromInt(1) )

virtual

Animates the cursor by toggling the internal CGUIEditableText's cursor.

Parameters

vTimes Correction factor

Reimplemented from CGUIAnimatable.

◆ DoButtonDown()

virtual eC_Bool CGUIEdit::DoButtonDown	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Sets the cursor position to the position returned by CGUIEditableText::GetBestCursorPosition() and starts the cursor blinking animation. If SHIFT is pressed, the text between the current cursor position and clicked-position is selected.

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled.

Reimplemented from CGUIBehaviour.

◆ DoChar()

eC_Bool CGUIEdit::DoChar	(	const eC_UInt &	uiKey,
		const GUIKeyIdentifier_t &	eKeyIdentifier,
		const eC_UInt &	uiModifiers
	)

virtual

This implementation does the following:

If there is a selection, the selected text is replaced by the character.
If there is no selection, the character is inserted at the current cursor position.
Parameters

uiKey The code of the pressed key.

eKeyIdentifier The Guiliani key identifier.

uiModifiers Modifiers bitfield.

Returns
Always False.

Reimplemented from CGUIBehaviour.

◆ DoDoubleClick()

virtual eC_Bool CGUIEdit::DoDoubleClick	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

virtual

Selects the whole text.

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled.

Reimplemented from CGUIBehaviour.

◆ DoDrag()

virtual eC_Bool CGUIEdit::DoDrag	(	const eC_Value &	vDeltaX,
		const eC_Value &	vDeltaY,
		const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Extends the text selection.

Parameters

vDeltaX	Mouse movement in X since last frame
vDeltaY	Mouse movement in Y since last frame
vAbsX	Mouse position in X where event occurred
vAbsY	Mouse position in Y where event occurred

Returns: Always True

Reimplemented from CGUIBehaviour.

◆ DoDraw()

virtual eC_Bool CGUIEdit::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns: True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

◆ DoKeyDown()

eC_Bool CGUIEdit::DoKeyDown	(	const GUIKeyIdentifier_t &	eKeyIdentifier,
		const eC_UInt &	uiModifiers
	)

virtual

Edits the text in reaction to keyboard events.

This implementation does the following:

If cursor left or right is pressed, one of the following may happen:
1. If there is a selection and the SHIFT key is pressed, the selection may be extended. Otherwise, the selected text is deselected.
2. If there is no selection, the cursor is moved one character to the left or right, depending on the pressed key.
If ESCAPE key is pressed and there is a selection, the selected text is deselected.
If HOME or END key is pressed, one of the following may happen:
1. If SHIFT key is pressed, the text between the current cursor and the beginning or end of the line is selected.
2. If SHIFT key is not pressed, the cursor goes to the beginning or the end of the line.
  Parameters

  eKeyIdentifier The Guiliani key identifier.

  uiModifiers Modifiers bitfield.

  Returns
  different values based on the action carried out:
True if cursor left or cursor right was pressed. This is necessary to keep focusing reasonable.
false for any other type of event to allow further processing by parent objects.

Reimplemented from CGUIBehaviour.

◆ EnsureCursorVisible()

void CGUIEdit::EnsureCursorVisible ( )

Computes the cursor pixel position from the current cursor position. If the cursor is outside the containing object so that it would be clipped, this method ensures the cursor's visibility by scrolling the text vertically.

◆ GetAcceptedChars()

AcceptedChars_t CGUIEdit::GetAcceptedChars ( ) const

inline

Returns: The current set of characters accepted as input as set by SetAcceptedChars() or the constructor.

◆ GetFocus()

virtual void CGUIEdit::GetFocus ( )

virtual

Starts the cursor blinking animation.

Reimplemented from CGUIBehaviour.

◆ GetLabel()

CGUIEditableText * CGUIEdit::GetLabel ( )

inline

Get the CGUIEditableText label of the input field.

Returns: Pointer to the label.

◆ GetMaxLength()

eC_Int CGUIEdit::GetMaxLength ( ) const

inline

Returns: the maximum length of the input text.

◆ GetSelectedTextString()

eC_String CGUIEdit::GetSelectedTextString ( )

Gets the selected text.

Returns: The currently selected text.

◆ InsertTextString()

void CGUIEdit::InsertTextString ( const eC_String & rkTextString )

Deletes selected text (if any) and inserts text at the cursor's position. If the total length after inserting would exceed the max length, the text passed text is truncated before inserting (existing text is not deleted).

Parameters

rkTextString The string to be inserted.

◆ IsHighlightable()

virtual eC_Bool CGUIEdit::IsHighlightable ( ) const

inlinevirtual

This method checks if an object is highlightable. This refers to whether it can be highlighted via the event handler. If true the event handler may mark this object as the currently highlighted one. Thus, there is no special flag in CGUIObject that determines if an object is highlightable. The default determination is that the control is in none of the following states:

invisible
grayed-out
disabled if so the return value will be true. NOTE: when an object is not highlightable, it will never receive DoMouseEnter and DoMouseLeave-events
Returns
True if highlightable, False otherwise

Reimplemented from CGUIObject.

◆ LoseFocus()

virtual void CGUIEdit::LoseFocus ( )

virtual

Deselects all text by resetting the cursor position to 0 and stops the cursor blinking animation.

See also: CGUIEditableText::SetCursorPosition()

Reimplemented from CGUIBehaviour.

◆ operator=()

CGUIEdit & CGUIEdit::operator= ( const CGUIEdit & rkSource )

Assignment operator method of the CGUIEdit class.

Parameters

rkSource Source object to be copied.

Returns: Copied object.

◆ ReadFromStream()

virtual void CGUIEdit::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. Only for use with GUIFactory. GUIStreamingFileReader has to be set in CGUI::Init().

See also: CGUIFactory

Reimplemented from CGUIObject.

◆ RemoveTextChangedObserver()

void CGUIEdit::RemoveTextChangedObserver ( CGUIObserver * pObserver )

Unsubscribe an observer that subscribed as TextChanged observer.

Parameters

pObserver The Observer that wants to unsubscribe.

◆ SetAcceptedChars()

void CGUIEdit::SetAcceptedChars ( AcceptedChars_t eAcceptedChars )

Set the type of characters that are accepted by DoChar(). This method does not check the current text and does not modify it.

Parameters

eAcceptedChars The character set accepted as input.

See also: GetAcceptedChars()

◆ SetHeight()

void CGUIEdit::SetHeight ( const eC_Value & vY )

virtual

Set the height of the edit field. Reimplemented because this affects the internal text and its cursor.

Parameters

vY	New height of the edit field.

Reimplemented from CGUIObject.

◆ SetLabel()

void CGUIEdit::SetLabel ( CGUIEditableText * pkText )

Changes the internal text. Deletes the previous text and stores the pointer passed to this method.

Parameters

pkText The new text to be used.

◆ SetMaxLength()

void CGUIEdit::SetMaxLength ( eC_Int iMaxLength )

Set the maximum length of the input text.

Parameters

iMaxLength The maximum length of input text.

◆ SetResetCursorWhenFocusLost()

void CGUIEdit::SetResetCursorWhenFocusLost ( const eC_Bool bResetCursor )

inline

Specifies whether the cursor position and blinking state will be reset when the focus is lost. By default, a CGUIEdit will reset the cursor when it loses the focus. For use cases with onscreen keyboards this behaviour might not be desired.

Parameters

bResetCursor True will reset the cursor, False will leave it untouched.

◆ SetTextID()

virtual void CGUIEdit::SetTextID ( const TextResource_t & eTextID )

virtual

This sets the text string associated with the given TextID.

Note: This will NOT use the actual TextID and will therefore NOT be updated if the TextID's text changes.

Parameters

eTextID TextID whose associated text shall be shown on the GUIEdit.

◆ SetTextString()

virtual void CGUIEdit::SetTextString ( const eC_String & rkTextString )

virtual

Set the text. If there already is text, it is replaced completely. If the text's length exceeds the max length, it is truncated.

Parameters

rkTextString The string to be assigned to this object.

◆ SetWidth()

void CGUIEdit::SetWidth ( const eC_Value & vX )

virtual

Sets this object's width to a new value.

Parameters

vX	the new width

Reimplemented from CGUIObject.

◆ WriteToStream()

virtual void CGUIEdit::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all object attributes to the streaming file. StreamWriter has to be initialized. Only for use with GUIStreamWriter.

Parameters

bWriteClassID This flag is used to select if writing of ControlID, leading and trailing tags is performed. Only GUIStreamWriter and GUICompositeObject have to set this flag true.

See also: CGUIStreamWriter

Reimplemented from CGUIObject.

The documentation for this class was generated from the following file:

GUIEdit.h

uiKey	The code of the pressed key.
eKeyIdentifier	The Guiliani key identifier.
uiModifiers	Modifiers bitfield.

Public Types

Public Member Functions

Additional Inherited Members

Detailed Description

Platform Specific Limitations

Member Enumeration Documentation

◆ AcceptedChars_t

Constructor & Destructor Documentation

◆ CGUIEdit() [1/4]

◆ CGUIEdit() [2/4]

◆ CGUIEdit() [3/4]

◆ ~CGUIEdit()

◆ CGUIEdit() [4/4]

Member Function Documentation

◆ DeleteSelectedTextString()

◆ DoAnimate()

◆ DoButtonDown()

◆ DoChar()

◆ DoDoubleClick()

◆ DoDrag()

◆ DoDraw()

◆ DoKeyDown()

◆ EnsureCursorVisible()

◆ GetAcceptedChars()

◆ GetFocus()

◆ GetLabel()

◆ GetMaxLength()

◆ GetSelectedTextString()

◆ InsertTextString()

◆ IsHighlightable()

◆ LoseFocus()

◆ operator=()

◆ ReadFromStream()

◆ RemoveTextChangedObserver()

◆ SetAcceptedChars()

◆ SetHeight()

◆ SetLabel()

◆ SetMaxLength()

◆ SetResetCursorWhenFocusLost()

◆ SetTextID()

◆ SetTextString()

◆ SetWidth()

◆ WriteToStream()
