CGUIGauge Class Reference

Basic gauge control, which visualizes values on a meter using a needle. More...

#include <GUIGauge.h>

Inheritance diagram for CGUIGauge:

Public Member Functions
	CGUIGauge (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const eC_Int iMin, const eC_Int iMax, const eC_Value vMinAngle, const eC_Value vMaxAngle, const ImageResource_t eGaugeImage, const eC_Value &vNeedleLength, const ObjectHandle_t &eID=NO_HANDLE)
	CGUIGauge (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const eC_Int iMin, const eC_Int iMax, const eC_Value vMinAngle, const eC_Value vMaxAngle, const ImageResource_t eGaugeImage, const ImageResource_t eNeedleImage, const ObjectHandle_t &eID=NO_HANDLE)
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	DoDraw ()
ImageResource_t	GetGaugeImage () const
eC_Value	GetMaxAngle () const
eC_Value	GetMinAngle () const
eC_UInt	GetNeedleColor () const
ImageResource_t	GetNeedleImage () const
eC_Value	GetNeedleLength () const
eC_Value	GetNeedleWidth () const
eC_UInt	GetShadowColor () const
virtual eC_Bool	IsHighlightable () const
virtual void	ReadFromStream ()
void	SetGaugeImage (const ImageResource_t eGaugeImageID)
void	SetMaxAngle (const eC_Value vMaxAngle)
void	SetMinAngle (const eC_Value vMinAngle)
void	SetNeedleColor (const eC_UInt &uiNeedleColor)
void	SetNeedleColor (const GlobalProperty_t &eNeedleColor)
void	SetNeedleImage (const ImageResource_t eNeedleImageID)
void	SetNeedleLength (const eC_Value vLength)
void	SetNeedleWidth (const eC_Value vWidth)
void	SetShadowColor (const eC_UInt &uiShadowColor)
void	SetShadowColor (const GlobalProperty_t &eShadowColor)
void	SetSimulate (const eC_Bool bSimulate)
virtual void	WriteToStream (const eC_Bool bWriteClassID)
Public Member Functions inherited from CGUIAbstractBar
void	AnimateToValue (const eC_Int iTargetValue)
eC_Bool	Decrease ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_UInt	GetAnimationInterval () const
eC_UInt	GetAnimationSpeed () const
const CGUIRange &	GetRange () const
eC_Bool	Increase ()
virtual eC_Bool	OnValueChange ()
void	SetAnimationInterval (const eC_UInt &ruiAnimationInterval)
void	SetAnimationSpeed (const eC_UInt &ruiAnimationSpeed)
void	SetBase (CGUIRange::Base_t eBase)
void	SetLevel (eC_Value vPercent)
void	SetLevelPercentage (eC_UInt uiPercentage)
void	SetMaximumLevelIsAlwaysValid (eC_Bool bNotOnlyMultiplesOfStepSize)
void	SetMaxValue (eC_Int iMaxValue)
void	SetMinValue (eC_Int iMinValue)
void	SetRange (eC_Int iMinValue, eC_Int iMaxValue)
void	SetStepSize (eC_UInt uiIntValues)
void	SetStepSizeLevel (eC_Value vPercent)
void	SetStepSizeLevelPercentage (eC_UInt uiPercentage)
virtual eC_Bool	SetValue (const CGUIValue &rkValue)
Public Member Functions inherited from CGUIObject
	CGUIObject ()
	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)
	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)
	CGUIObject (const CGUIObject &kSource)
virtual	~CGUIObject ()
void	AddValueObserver (CGUIObserver *pkObserver)
eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const
virtual eC_Bool	ClaimFocus ()
virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)
eC_Bool	DataPoolConnectorExists () const
void	DeleteSnapshot ()
virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)
virtual eC_Bool	DoDraw ()
virtual eC_Bool	DoDrawSnapshot ()
virtual void	EnableSnapshotDrawing ()
virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)
virtual eC_Bool	FocusAny ()
virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)
virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)
CGUIRect	GetAbsRect () const
eC_Value	GetAbsXPos () const
eC_Value	GetAbsXPosCenter () const
eC_Value	GetAbsXPosREdge () const
eC_Value	GetAbsYPos () const
eC_Value	GetAbsYPosBEdge () const
eC_Value	GetAbsYPosCenter () const
eC_UByte	GetAlpha () const
CGUIBehaviourDecorator *	GetBehaviour ()
const CGUIBehaviourDecorator *	GetBehaviour () const
GUIBitmapPlaneID_t	GetBitmapID () const
CGUIBitmapPlane &	GetBitmapPlane () const
CGUIRect	GetCurrentAbsRect () const
eC_Value	GetCurrentAbsXPos () const
eC_Value	GetCurrentAbsXPosCenter () const
eC_Value	GetCurrentAbsXPosREdge () const
eC_Value	GetCurrentAbsYPos () const
eC_Value	GetCurrentAbsYPosBEdge () const
eC_Value	GetCurrentAbsYPosCenter () const
CDataPoolConnector &	GetDataPoolConnector ()
eC_Value	GetDistanceBottom () const
eC_Value	GetDistanceRight () const
eC_Value	GetHalfHeight () const
eC_Value	GetHalfWidth () const
eC_Value	GetHeight () const
ObjectHandle_t	GetID () const
CGUILayouter *	GetLayouter ()
const CGUILayouter *	GetLayouter () const
ObjectHandle_t	GetNeighborBottomID () const
ObjectHandle_t	GetNeighborLeftID () const
ObjectHandle_t	GetNeighborRightID () const
ObjectHandle_t	GetNeighborTopID () const
CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)
const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const
CGUIRect	GetOriginRect () const
CGUICompositeObject *	GetParent ()
const CGUICompositeObject *	GetParent () const
CGUIRect	GetRelRect () const
eC_Value	GetRelXPos () const
eC_Value	GetRelXPosCenter () const
eC_Value	GetRelXPosREdge () const
eC_Value	GetRelYPos () const
eC_Value	GetRelYPosBEdge () const
eC_Value	GetRelYPosCenter () const
eC_Value	GetWidth () const
void	InvalidateArea ()
eC_Bool	IsClickable () const
eC_Bool	IsClickThrough () const
virtual eC_Bool	IsCompositeObject () const
eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const
eC_Bool	IsDisabled () const
eC_Bool	IsDragable () const
eC_Bool	IsDragged () const
eC_Bool	IsDrawingSnapshot () const
eC_Bool	IsFocussable () const
eC_Bool	IsFocussed () const
eC_Bool	IsGrayedOut () const
virtual eC_Bool	IsHighlightable () const
eC_Bool	IsHighlighted () const
eC_Bool	IsInvisible () const
eC_Bool	IsPressed () const
eC_Bool	IsStopFocus () const
void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)
CGUIObject &	operator= (const CGUIObject &kSource)
virtual void	ReadFromStream ()
virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const
void	RemoveValueObserver (CGUIObserver *pkObserver)
void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))
eC_Bool	RequestFocus ()
void	SetAlpha (eC_UByte ubAlpha)
void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)
void	SetClickThrough (const eC_Bool &bClickThrough)
virtual void	SetDisabled (const eC_Bool &bDisabled)
virtual void	SetFocussable (const eC_Bool &bFocussable)
virtual void	SetGrayedOut (const eC_Bool &bGrayOut)
virtual void	SetHeight (const eC_Value &vY)
void	SetID (const ObjectHandle_t &eID)
virtual void	SetInvisible (const eC_Bool &bInvisible)
void	SetLayouter (CGUILayouter *pLayouter)
void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)
void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)
void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)
void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)
void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)
virtual void	SetParent (CGUICompositeObject *const pkParent)
void	SetRelRect (const CGUIRect &kNewRect)
virtual void	SetRelXPos (const eC_Value &vX)
void	SetRelXPosCenter (const eC_Value &vXCenter)
void	SetRelXPosREdge (const eC_Value &vX)
virtual void	SetRelYPos (const eC_Value &vY)
void	SetRelYPosBEdge (const eC_Value &vY)
void	SetRelYPosCenter (const eC_Value &vYCenter)
void	SetStopFocus (const eC_Bool &bDontFocusToParent)
virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)
virtual eC_Bool	SetValue (const CGUIValue &rkValue)
virtual void	SetWidth (const eC_Value &vX)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)
virtual void	OnCreate ()
virtual void	OnDelete ()
virtual void	OnHide ()
virtual void	OnShow ()
virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoDrag (const eC_Value &vDeltaX=eC_FromInt(-1), const eC_Value &vDeltaY=eC_FromInt(-1), const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))
virtual void	GetFocus ()
virtual void	LoseFocus ()
virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)
virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)
virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)
virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)
virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)
virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)
virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIColorPropertyObserver
	CGUIColorPropertyObserver ()
	default-constructor
	~CGUIColorPropertyObserver ()
	destructor
eC_UInt	AddColorProperty (const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)
void	AddColorProperty (const eC_UInt &uiIndex, const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)
ColorValue_t	GetColorProperty (const eC_UInt &uiIndex) const
eC_UInt	GetColorValue (const eC_UInt &uiIndex) const
virtual void	OnColorPropertyChange ()
virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...
void	RemoveColorProperty (const eC_UInt &uiIndex)
void	SetColorProperty (const eC_UInt &uiIndex, const ColorValue_t &kColorValue)
void	SetColorProperty (const eC_UInt &uiIndex, const eC_UInt &uiColorValue)
void	SetColorProperty (const eC_UInt &uiIndex, const GlobalProperty_t &eColorProperty)
Public Member Functions inherited from CGUIObserver
	CGUIObserver ()
	Default constructor.
virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.
const eC_TListDoubleLinked< CGUISubject * > &	GetSubjectList () const
virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...
virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)
virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)
virtual void	OnNotification (const eC_String &kMessage)
void	SetAutoDelete (const eC_Bool bAutoDelete)

Protected Member Functions
void	CalculateEndpoint ()
	Calculates the endpoint of the needle's tip after rotation.
virtual void	DrawGauge ()
	Helper method for drawing the gauge.
virtual void	DrawNeedle ()
	Helper method for drawing the needle.
void	Init (const eC_Int iMin, const eC_Int iMax, const eC_Value vMinAngle, const eC_Value vMaxAngle, const ImageResource_t eGaugeImage)
virtual eC_Bool	OnValueChange ()
void	SmartInvalidation ()
	Improved invalidation method, which does not simply invalidate the entire object, but instead only the area covered by the needle.
void	UpdateNeedleAngle ()
	Updates the needle's rotationangle with respect to Min/Max Value and Min/Max Angle.
Protected Member Functions inherited from CGUIAbstractBar
	CGUIAbstractBar ()
	CGUIAbstractBar (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)
	CGUIAbstractBar (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)
	CGUIAbstractBar (const CGUIAbstractBar &kSource)
CGUIAbstractBar &	operator= (const CGUIAbstractBar &kSource)
virtual void	ReadFromStream ()
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()
virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const
Protected Member Functions inherited from CGUIObserver
virtual void	AddSubject (CGUISubject *pSubjectToAdd)
virtual void	RemoveSubject (CGUISubject *pSubjectToRemove)

Additional Inherited Members
Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }
Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.
static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.
static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.
static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.
static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.
static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.
static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.
static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.
static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.
static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.
static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.
static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.
static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.
Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

Basic gauge control, which visualizes values on a meter using a needle.

The "gauge" control is used to visualize values on a meter using a needle. The visualization can be customized by either supplying images, for both the background and the needle, or by drawing the needle with a line of customizable color and length. The usage of the "gauge" control is very easy as only minimal value, maximal value and maximal rotation have to be defined. The current position of the needle is calculated automatically through the given value. The "gauge" control can be used in a wide range of use-cases e.g. to present an analog clock or a speedometer (Class: CGUIGauge).

The gauge is derived from the CGUIAbstractBar baseclass. It defines a range of valid values along with a minimum- and maximum value for the contained needle. It visualizes any value within the valid range by rotating the needle to the respective angle.

The visualization can be customized by either supplying images, for both the background and the needle, or by drawing the needle with a line of customizable color and length. The simple line-based visualization is useful as a fallback solution if you do not have access to the final needle graphics yet.

Another application of the gauge control is as an interactive object, which enables the user to select a value from a given range. This can be done by using the CGUIAbstractBar::SetStepSize and CGUIAbstractBar::SetMinValue / CGUIAbstractBar::SetMaxValue APIs. The control is then operated via the Increase() and Decrease() APIs of CGUIAbstractBar, which are by default mapped onto GK_PAGEDOWN / GK_PAGEUP.

Note

Since the needle is only allowed to reside at valid positions (e.g. integers between given Minimum and Maximum) its movement may appear jerky e.g., if the range of values is 0-100 and the range of angles is 0-180. If you wish to achieve a smooth rotation, increase the range of values.

Example:

// Create gauge object (visualized using bitmaps)
CGUIGauge* pGauge = new CGUIGauge(
    pkPage4,
    eC_FromInt(300), eC_FromInt(300), // Position
    eC_FromInt(400), eC_FromInt(400), // Size
    0, 2000,                          // Value range
    eC_FromInt(-20), eC_FromInt(200), // Min- and Max angle of needle
    eGaugeImage, eNeedleImage);       // Bitmaps for background and needle

// Sets the gauge to the given value (The needle will reflect the value automatically)
pGauge->SetValue((eC_Int)50);

// Increases the gauge to the next valid value
pGauge->Increase();

// Reconfigures the gauge to only allow (integer!) values from 0 through 9
pGauge->SetMinValue(0);
pGauge->SetMaxValue(9);

// Simulates the needle movement by animating the needle with dummy values
pGauge->SetSimulate(true);

Example2:

// Create gauge object (visualized using background-bitmap and vector-based needle)
CGUIGauge* pGauge = new CGUIGauge(
    pkPage4,
    eC_FromInt(300), eC_FromInt(300), // Position
    eC_FromInt(400), eC_FromInt(400), // Size
    0, 2000,                          // Value range
    eC_FromInt(-20), eC_FromInt(200), // Min- and Max angle of needle
    eGaugeImage, DUMMY_IMAGE);       // Bitmap for background, needle is drawn as vector

// set needle-length to 50 pixels
pGauge->SetNeedleLength(eC_FromInt(50));

// set needle-width to 3 pixels
pGauge->SetNeedleWidth(eC_FromInt(3));

// Simulates the needle movement by animating the needle with dummy values
pGauge->SetSimulate(true);

Constructor & Destructor Documentation

CGUIGauge() [1/2]

CGUIGauge::CGUIGauge	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const eC_Int	iMin,
		const eC_Int	iMax,
		const eC_Value	vMinAngle,
		const eC_Value	vMaxAngle,
		const ImageResource_t	eGaugeImage,
		const eC_Value &	vNeedleLength,
		const ObjectHandle_t &	eID = NO_HANDLE
	)

Constructs a gauge with a vector needle.

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object.
vY	Y-position relative to its parent object.
vWidth	Width of the gauge.
vHeight	Height of the gauge.
iMin	Minimum allowed value
iMax	Maximum allowed value
vMinAngle	Minimum allowed needle angle
vMaxAngle	Maximum allowed needle angle
eGaugeImage	Image used to represent the gauge itself (without needle)
vNeedleLength	Length of the needle in pixels (From center of gauge to its tip)
eID	ObjectID of the gauge

CGUIGauge() [2/2]

CGUIGauge::CGUIGauge	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const eC_Int	iMin,
		const eC_Int	iMax,
		const eC_Value	vMinAngle,
		const eC_Value	vMaxAngle,
		const ImageResource_t	eGaugeImage,
		const ImageResource_t	eNeedleImage,
		const ObjectHandle_t &	eID = NO_HANDLE
	)

Constructs a gauge with a bitmap needle

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object.
vY	Y-position relative to its parent object.
vWidth	Width of the gauge.
vHeight	Height of the gauge.
iMin	Minimum allowed value
iMax	Maximum allowed value
vMinAngle	Minimum allowed needle angle
vMaxAngle	Maximum allowed needle angle
eGaugeImage	Image used to represent the gauge itself (without needle)
eNeedleImage	Image used to represent the needle (Will be rotated to corresponding angle)
eID	ObjectID of the gauge

Member Function Documentation

DoAnimate()

virtual void CGUIGauge::DoAnimate ( const eC_Value &  vTimes = eC_FromInt(1) )

virtual

Called when the timer of an animation callback belonging to this animatable has expired.

Parameters

vTimes

The factor of the registered callback time in relation to the actually elapsed time. For example, the elapsed time is 80ms, and the standard time is 50ms, then vTimes is 1.6. If the given time in GETTIMER.AddAnimationCallback is 0, It will be set to -1.

Reimplemented from CGUIAbstractBar.

DoDraw()

virtual eC_Bool CGUIGauge::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns

True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

GetGaugeImage()

ImageResource_t CGUIGauge::GetGaugeImage

(

)

const

Gets the image, which will be used for visualizing the gauge

Returns

image ID

GetMaxAngle()

eC_Value CGUIGauge::GetMaxAngle

(

)

const

Gets the maximum allowed rotation angle (in degrees) for the needle.

Returns

maximum angle

GetMinAngle()

eC_Value CGUIGauge::GetMinAngle

(

)

const

Gets the minimum allowed rotation angle (in degrees) for the needle. 0 = Needle points to the left 90 = Needle points upwards 180 = Needle points right 270 = Needle points downwards

Returns

minimum angle

GetNeedleColor()

eC_UInt CGUIGauge::GetNeedleColor

(

)

const

Get the color of the needle

Returns

needle color

GetNeedleImage()

ImageResource_t CGUIGauge::GetNeedleImage

(

)

const

Get the image used for the needle

Returns

needle image

GetNeedleLength()

eC_Value CGUIGauge::GetNeedleLength

(

)

const

Gets length for vector needle.

Returns

needle length in pixels

GetNeedleWidth()

eC_Value CGUIGauge::GetNeedleWidth

(

)

const

Gets width for vector needle.

Returns

needle width in pixels

GetShadowColor()

eC_UInt CGUIGauge::GetShadowColor

(

)

const

Get the color of the shadow

Returns

shadow color

Init()

void CGUIGauge::Init ( const eC_Int  iMin, const eC_Int  iMax, const eC_Value  vMinAngle, const eC_Value  vMaxAngle, const ImageResource_t  eGaugeImage  )

protected

Internal helper method for initialization

Parameters

iMin
iMax
vMinAngle
vMaxAngle
eGaugeImage

IsHighlightable()

virtual eC_Bool CGUIGauge::IsHighlightable ( ) const

inlinevirtual

This method checks if an object is highlightable. This refers to whether it can be highlighted via the event handler. If true the event handler may mark this object as the currently highlighted one. Thus, there is no special flag in CGUIObject that determines if an object is highlightable. The default determination is that the control is in none of the following states:

• invisible
• grayed-out
• disabled if so the return value will be true. NOTE: when an object is not highlightable, it will never receive DoMouseEnter and DoMouseLeave-events

  Returns

  True if highlightable, False otherwise

Reimplemented from CGUIObject.

OnValueChange()

virtual eC_Bool CGUIGauge::OnValueChange ( )

protectedvirtual

Called by the framework whenever the GUIAbstractBar's (and therefore the gauge's value) changes. This causes an update of the needle's angle.

Returns

Always True

Reimplemented from CGUIAbstractBar.

ReadFromStream()

virtual void CGUIGauge::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. Only for use with GUIFactory. GUIStreamingFileReader has to be set in CGUI::Init().

See also

CGUIFactory

Reimplemented from CGUIAbstractBar.

SetGaugeImage()

void CGUIGauge::SetGaugeImage

(

const ImageResource_t

eGaugeImageID

)

Sets the image, which will be used for visualizing the gauge

Parameters

eGaugeImageID

The image ID

SetMaxAngle()

void CGUIGauge::SetMaxAngle

(

const eC_Value

vMaxAngle

)

Sets the maximum allowed rotation angle (in degrees) for the needle.

Parameters

vMaxAngle

New maximum angle

See also

SetMinAngle

SetMinAngle()

void CGUIGauge::SetMinAngle

(

const eC_Value

vMinAngle

)

Sets the minimum allowed rotation angle (in degrees) for the needle. 0 = Needle points to the left 90 = Needle points upwards 180 = Needle points right 270 = Needle points downwards

Parameters

vMinAngle

New minimum angle

SetNeedleColor() [1/2]

void CGUIGauge::SetNeedleColor

(

const eC_UInt &

uiNeedleColor

)

Set the color of the needle which is used when needle-image is set to DUMMY_IMAGE

Parameters

uiNeedleColor

color

SetNeedleColor() [2/2]

void CGUIGauge::SetNeedleColor

(

const GlobalProperty_t &

eNeedleColor

)

Set the color of the needle which is used when needle-image is set to DUMMY_IMAGE

Parameters

eNeedleColor

color

SetNeedleImage()

void CGUIGauge::SetNeedleImage

(

const ImageResource_t

eNeedleImageID

)

Sets the image, which will be used for visualizing the needle. The needle image will be centered within the gauge and will be rotated around its own center. It will always be displayed in its original size, regardless of the surrounding gauge's size.

Parameters

eNeedleImageID

The image ID

SetNeedleLength()

void CGUIGauge::SetNeedleLength

(

const eC_Value

vLength

)

Sets length for vector needle. This has no effect when using a bitmap for the needle

Parameters

vLength

New needle length in pixels

SetNeedleWidth()

void CGUIGauge::SetNeedleWidth

(

const eC_Value

vWidth

)

Sets width for vector needle. This has no effect when using a bitmap for the needle

Parameters

vWidth

New needle width in pixels

SetShadowColor() [1/2]

void CGUIGauge::SetShadowColor

(

const eC_UInt &

uiShadowColor

)

Set the color of the shadow which is used when needle-image is set to DUMMY_IMAGE

Parameters

uiShadowColor

color

SetShadowColor() [2/2]

void CGUIGauge::SetShadowColor

(

const GlobalProperty_t &

eShadowColor

)

Set the color of the shadow which is used when needle-image is set to DUMMY_IMAGE

Parameters

eShadowColor

color

SetSimulate()

void CGUIGauge::SetSimulate

(

const eC_Bool

bSimulate

)

Simulates needle movement by feeding the gauge with dummy values. This is especially useful during a project's prototyping phase

Parameters

bSimulate

TRUE starts simulation mode, FALSE stops simulation

WriteToStream()

virtual void CGUIGauge::WriteToStream ( const eC_Bool  bWriteClassID )

virtual

Writes all object attributes to the streaming file. StreamWriter has to be initialized. Only for use with GUIStreamWriter.

Parameters

bWriteClassID

This flag is used to select if writing of ControlID, leading and trailing tags is performed. Only GUIStreamWriter and GUICompositeObject have to set this flag true.

See also

CGUIStreamWriter

Reimplemented from CGUIAbstractBar.

---

The documentation for this class was generated from the following file:

• GUIGauge.h
