CGfxEnv Class Reference

#include <GfxEnv.h>

Inheritance diagram for CGfxEnv:

Public Types
enum	SurfaceMode_t { SM_OPENGL , SM_FRAMEBUFFER }

Public Member Functions
eC_Bool	AddLayer (const LayerConfiguration_t &kLayerConfig)
void	AddMainLayer (const eC_UInt &uiLayerID=0, const eC_Bool &bCached=false)
eC_UByte	ApplyGlobalAlpha (const eC_UByte &ubAlpha) const
virtual void	DeInitDisplay ()
virtual void	EndOfRefresh ()
eC_UInt	GetActiveLayerID () const
virtual eC_UByte	GetBPP () const
virtual eC_UInt	GetBufferCount () const
eC_UByte	GetBytesPerPixel (const CGUICommonEnums::ImageType_t &ePixFormat) const
virtual CGUICommonEnums::ImageType_t	GetColorFormat () const
void *	GetDisplayBuffer (const eC_UInt &uiLayerID) const
virtual void **	GetFrameBuffers () const
eC_UByte	GetGlobalAlpha () const
virtual eC_UInt	GetHeight () const
eC_UByte	GetLayerAlpha (const eC_UInt &uiLayerID) const
eC_Bool	GetLayerBufferSize (const eC_UInt &uiLayerID, eC_UInt &uiWidth, eC_UInt &uiHeight, eC_UByte &ubBPP)
eC_Bool	GetLayerChromaKey (const eC_UInt &uiLayerID, eC_Bool &bChromaKeyActive, eC_UInt &uiChromaKey, eC_UByte &ubAlpha) const
eC_Bool	GetLayerConfig (const eC_UInt &uiLayerIndex, LayerConfiguration_t &rkLayerConfig) const
eC_Bool	GetLayerConfigForID (const eC_UInt &uiLayerID, LayerConfiguration_t &rkLayerConfig) const
eC_Bool	GetLayerConfigForMainLayer (LayerConfiguration_t &rkLayerConfig) const
eC_Bool	GetLayerIndexForID (const eC_UInt &uiLayerID, eC_UInt &ruiLayerIndex) const
eC_Bool	GetLayerPosition (const eC_UInt &uiLayerID, eC_Int &iXPos, eC_Int &iYPos)
eC_Bool	GetLayerVisibleSize (const eC_UInt &uiLayerID, eC_UInt &uiWidth, eC_UInt &uiHeight)
eC_UInt	GetMainLayerID () const
virtual void *	GetMergeBuffer () const
eC_UInt	GetNumberOfLayers () const
void *	GetRenderBuffer (const eC_UInt &uiLayerID) const
virtual SurfaceMode_t	GetSurfaceMode () const
virtual eC_UInt	GetWidth () const
virtual eC_UInt	InitDisplay ()
void	InitLayers ()
void	InvalidateLayer (const eC_UInt &uiLayerID)
virtual eC_Bool	IsCreated () const
eC_Bool	IsLayerModified (const eC_UInt &uiLayerID) const
eC_Bool	IsLayerVisible (const eC_UInt &uiLayerID) const
eC_Bool	IsMainLayer (const eC_UInt &uiLayerID) const
virtual eC_Bool	IsNull ()
virtual eC_Bool	IsResizable () const
virtual eC_Bool	IsVSyncEnabled () const
virtual eC_Bool	NeedsManualMerge () const
virtual eC_Bool	RefreshScreen (const CGUIRect &rkInvalidatedArea)
virtual eC_Bool	RefreshScreen (const eC_TListDoubleLinked< CGUIRect > &kInvalidatedRectList)
eC_Bool	SetActiveLayerID (const eC_UInt &uiLayerID, const eC_Bool &bMarkAsModified=false)
virtual void	SetCliprect (const CGUIRect &rkNewClipRect)
virtual void	SetDevice (void *pkDevice)
void	SetGfxWrap (CGfxWrap *pkGfxWrap)
void	SetGlobalAlpha (const eC_UByte &ubGlobalAlpha)
eC_Bool	SetLayerAlpha (const eC_UInt &uiLayerID, const eC_UByte &ubAlpha)
eC_Bool	SetLayerChromaKey (const eC_UInt &uiLayerID, const eC_Bool &bChromaKeyActive, const eC_UInt &uiChromaKey, const eC_UByte &ubAlpha)
eC_Bool	SetLayerPosition (const eC_UInt &uiLayerID, const eC_Int &iXPos, const eC_Int &iYPos)
eC_Bool	SetLayerVisible (const eC_UInt &uiLayerID, const eC_Bool &bVisible)
eC_Bool	SetLayerVisiblePos (const eC_UInt &uiLayerID, const eC_Int &iXPos, const eC_Int &iYPos)
eC_Bool	SetLayerVisibleSize (const eC_UInt &uiLayerID, const eC_UInt &uiWidth, const eC_UInt &uiHeight)
void	SetMainLayerID (const eC_UInt &uiLayerID)
void	SetMainLayerProperties (const eC_UInt &uiLayerID, const eC_Bool &bCached)
void	SetObjectForLayerID (const eC_UInt &uiLayerID, CGUIObject *pkObject)
virtual void	SetScreenSize (const eC_UInt &uiWidth, const eC_UInt &uiHeight)
virtual void	SetVSyncEnabled (const eC_Bool &bVSyncEnabled)
virtual void	SetWindowCaption (const eC_String &kCaption)
virtual void	StartOfRefresh ()
virtual eC_Bool	SupportsCopy () const
virtual eC_Bool	SwapBuffers ()
virtual void	UpdateLayer (const LayerConfiguration_t &kLayerConfig, const LayerUpdate_t &eUpdateReason)
virtual eC_Bool	UpdateLayerBuffers (const eC_UInt &uiLayerID, void *pkRenderBuffer, void *pkDisplayBuffer, const eC_UInt &uiWidth, const eC_UInt &uiHeight)
void	UpdateLayerPositions ()

Static Public Member Functions
static eC_Bool	CreateInstance (const SurfaceMode_t &eSurfaceMode, const CGUICommonEnums::ImageType_t &eScreenFormat, const eC_UInt &uiWidth, const eC_UInt &uiHeight, const eC_UInt &uiBufferCount=1, void **ppkBuffers=NULL, const eC_Bool &bResizable=false)
static void	DeleteInstance ()
	called to destroy and detach GfxEnv

Protected Member Functions
	CGfxEnv (const SurfaceMode_t &eSurfaceMode, const CGUICommonEnums::ImageType_t &eScreenFormat, const eC_UInt &uiWidth, const eC_UInt &uiHeight, const eC_UInt &uiBufferCount=1, void **ppkBuffers=NULL, const eC_Bool &bResizable=false)
virtual	~CGfxEnv ()
eC_UByte	GetBPPFromScreenFormat () const
virtual void	InitLayer (const LayerConfiguration_t &kLayerConfig)
void	UpdateMainLayer (const CGUICommonEnums::ImageType_t &eColorFormat, const eC_UInt &uiWidth, const eC_UInt &uiHeight, const eC_UInt &uiBufferCount, void **ppkBuffers)

Protected Attributes
eC_TArray< LayerConfiguration_t >	m_akLayers
	: *DCLayer_t, one DCLayer_t struct per layer storing general settings
eC_Bool	m_bNeedsManualMerge
	if supports merge
eC_Bool	m_bResizable
	resizable
eC_Bool	m_bSupportsCopy
	if supports copy
eC_Bool	m_bVSyncEnabled
	if vsync is enabled
CGUICommonEnums::ImageType_t	m_eColorFormat
	color-format
SurfaceMode_t	m_eSurfaceMode
	surface mode
eC_Int	m_iMainLayerID
	id of main-layer
CGfxWrap *	m_pkGfxWrap
	pointer to GfxWrapper
void **	m_ppkBuffers
	buffers for the main-screen
eC_UByte	m_ubBPP
	BPP of the surface.
eC_UByte	m_ubGlobalAlpha
	global alpha for blending
eC_UInt	m_uiActiveLayerID
	: unsigned int = Active Layer
eC_UInt	m_uiActiveLayerIndex
	index of currentl< active layer
eC_UInt	m_uiBufferCount
	number of buffers used
eC_UInt	m_uiHeight
	height of the surface
eC_UInt	m_uiWidth
	width of the surface

Friends
class	CGUIComponentManager

Detailed Description

This is the base-class for all GfxEnvXXX-classes dealing with environment used by the GfxWrap

This class is used to set up the environment for the actual GfxWrap with a generic interface. It will provide the size, buffers and all necessary data. Additionally it will hold all hardware layers.

Typical order of events:

After the frame has been drawn by the GfxWrap into the currently active render-buffer the refresh is done Inside the refresh the following things are done for each layer

• UpdateLayerBuffers to switch to the next buffer

After that EndOfRefresh and RefreshScreen with each invalidated region is called

Depending on the actual underlying API UpdateLayerBuffers can be used to execute cache-invalidation on the buffers currently used for drawing. Additionally the switch of buffers for the display-hardware can be done.

In EndOfRefresh the switch of all used buffers should already be done, thus it can be used to wait for a vertical sync-signal.

RefreshScreen can be used to copy the regions that have been redrawn in the last frame over to the new drawing-buffer to start the next frame.

Member Enumeration Documentation

SurfaceMode_t

enum CGfxEnv::SurfaceMode_t

Surface-mode

Enumerator
SM_OPENGL	use OpenGL for surface
SM_FRAMEBUFFER	use framebuffer for surface

Constructor & Destructor Documentation

CGfxEnv()

CGfxEnv::CGfxEnv ( const SurfaceMode_t &  eSurfaceMode, const CGUICommonEnums::ImageType_t &  eScreenFormat, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight, const eC_UInt &  uiBufferCount = 1, void **  ppkBuffers = NULL, const eC_Bool &  bResizable = false  )

protected

Constructor

Parameters

eSurfaceMode	OpenGL or Framebuffer
eScreenFormat	screen-format
uiWidth	width
uiHeight	height
uiBufferCount	number of buffers to use
ppkBuffers	buffers to use
bResizable	true if resizable

~CGfxEnv()

virtual CGfxEnv::~CGfxEnv ( )

protectedvirtual

Destructor

Member Function Documentation

AddLayer()

eC_Bool CGfxEnv::AddLayer

(

const LayerConfiguration_t &

kLayerConfig

)

Add layer to internal configuration. should only be called during startup of application

Parameters

kLayerConfig

layer-configuration

Returns

true if successful

AddMainLayer()

void CGfxEnv::AddMainLayer	(	const eC_UInt &	uiLayerID = 0,
		const eC_Bool &	bCached = false
	)

Set information for the main-layer

Parameters

uiLayerID	the id for the layer (default: 0)
bCached	true if the layer-memory is cached (default: false)

ApplyGlobalAlpha()

eC_UByte CGfxEnv::ApplyGlobalAlpha

(

const eC_UByte &

ubAlpha

)

const

Calculate the alpha-value according to the global alpha

Parameters

ubAlpha

input alpha-value

Returns

applied alpha

CreateInstance()

static eC_Bool CGfxEnv::CreateInstance ( const SurfaceMode_t &  eSurfaceMode, const CGUICommonEnums::ImageType_t &  eScreenFormat, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight, const eC_UInt &  uiBufferCount = 1, void **  ppkBuffers = NULL, const eC_Bool &  bResizable = false  )

static

Create Instance

Parameters

eSurfaceMode	surface-mode
eScreenFormat	screen-format
uiWidth	width
uiHeight	height
uiBufferCount	number of buffers to use
ppkBuffers	pointers to buffers
bResizable	true if resizable

Returns

true if successful

DeInitDisplay()

virtual void CGfxEnv::DeInitDisplay ( )

inlinevirtual

De-Initialize display

Reimplemented in CGfxEnvDAVE.

EndOfRefresh()

virtual void CGfxEnv::EndOfRefresh ( )

inlinevirtual

This will be called when all layers have been refreshed. To wait for V-sync this would be the right place.

Reimplemented in CGfxEnvCDC, CGfxEnvCDCDI, CGfxEnvDAVE, CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL2, and CGfxEnvWin.

GetActiveLayerID()

eC_UInt CGfxEnv::GetActiveLayerID

(

)

const

Return the id of the currently active layer

Returns

id of active layer

GetBPP()

virtual eC_UByte CGfxEnv::GetBPP ( ) const

virtual

Get the BPP of the surface

Returns

BPP

GetBPPFromScreenFormat()

eC_UByte CGfxEnv::GetBPPFromScreenFormat ( ) const

protected

Get the number of bits per pixel from the screen-format

Returns

number of bits

GetBufferCount()

virtual eC_UInt CGfxEnv::GetBufferCount ( ) const

virtual

Get number of used buffers

Returns

buffer-count

GetBytesPerPixel()

eC_UByte CGfxEnv::GetBytesPerPixel

(

const CGUICommonEnums::ImageType_t &

ePixFormat

)

const

Return the number of bytes per pixel for pixel-format

Parameters

ePixFormat

Returns

bpp

GetColorFormat()

virtual CGUICommonEnums::ImageType_t CGfxEnv::GetColorFormat ( ) const

virtual

Retrieve the Screen-Format (e.g. RGB565)

Returns

screen-format

GetDisplayBuffer()

void * CGfxEnv::GetDisplayBuffer

(

const eC_UInt &

uiLayerID

)

const

Get the currently active buffer which is used for display

Parameters

uiLayerID

id of layer

Returns

address of buffer or NULL if layer was not found

GetFrameBuffers()

virtual void ** CGfxEnv::GetFrameBuffers ( ) const

inlinevirtual

return the used framebuffer if any

Returns

framebuffer or NULL

Reimplemented in CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL, CGfxEnvSDL2, and CGfxEnvWin.

GetGlobalAlpha()

eC_UByte CGfxEnv::GetGlobalAlpha

(

)

const

Return the currently set global alpha-value

Returns

global alpha

GetHeight()

virtual eC_UInt CGfxEnv::GetHeight ( ) const

virtual

Get the height of the surface

Returns

height

Reimplemented in CGfxEnvSDL, and CGfxEnvSDL2.

GetLayerAlpha()

eC_UByte CGfxEnv::GetLayerAlpha

(

const eC_UInt &

uiLayerID

)

const

Get the current alpha-value for the given layer.

Parameters

uiLayerID

id of layer

Returns

alpha-value

GetLayerBufferSize()

eC_Bool CGfxEnv::GetLayerBufferSize	(	const eC_UInt &	uiLayerID,
		eC_UInt &	uiWidth,
		eC_UInt &	uiHeight,
		eC_UByte &	ubBPP
	)

Get the size of the buffer attached to the given layer.

Parameters

uiLayerID	id of layer
uiWidth	width of layer
uiHeight	height of layer
ubBPP	bytes per pixel

Returns

true if layer was found

GetLayerChromaKey()

eC_Bool CGfxEnv::GetLayerChromaKey	(	const eC_UInt &	uiLayerID,
		eC_Bool &	bChromaKeyActive,
		eC_UInt &	uiChromaKey,
		eC_UByte &	ubAlpha
	)		const

Get the current chroma-key settings for the given layer.

Parameters

uiLayerID	id of layer
bChromaKeyActive	true if chroma-keying is active
uiChromaKey	the color for chroma-keying
ubAlpha	alpha-value for replacement

Returns

true if layer was found

GetLayerConfig()

eC_Bool CGfxEnv::GetLayerConfig	(	const eC_UInt &	uiLayerIndex,
		LayerConfiguration_t &	rkLayerConfig
	)		const

Get configuration for given layer. Note: this will need an index instead of id

Parameters

uiLayerIndex	index of layer in internal data
rkLayerConfig	configuation of layer

Returns

true if config was found

GetLayerConfigForID()

eC_Bool CGfxEnv::GetLayerConfigForID	(	const eC_UInt &	uiLayerID,
		LayerConfiguration_t &	rkLayerConfig
	)		const

Get configuration for layer with given ID

Parameters

uiLayerID	id of layer
rkLayerConfig	configuation of layer

Returns

true if config was found

GetLayerConfigForMainLayer()

eC_Bool CGfxEnv::GetLayerConfigForMainLayer

(

LayerConfiguration_t &

rkLayerConfig

)

const

Get configuration for main-layer

Parameters

rkLayerConfig

configuation of layer

Returns

true if config was found

GetLayerIndexForID()

eC_Bool CGfxEnv::GetLayerIndexForID	(	const eC_UInt &	uiLayerID,
		eC_UInt &	ruiLayerIndex
	)		const

—— layer functionality ——

Get the internal index for given layer-id

Parameters

uiLayerID	id of requested layer
ruiLayerIndex	internal index

Returns

true if layer exists, otherwise false

GetLayerPosition()

eC_Bool CGfxEnv::GetLayerPosition	(	const eC_UInt &	uiLayerID,
		eC_Int &	iXPos,
		eC_Int &	iYPos
	)

Get the current position for the given layer

Parameters

uiLayerID	id of layer
iXPos	x-position
iYPos	y-position

Returns

true if layer was found

GetLayerVisibleSize()

eC_Bool CGfxEnv::GetLayerVisibleSize	(	const eC_UInt &	uiLayerID,
		eC_UInt &	uiWidth,
		eC_UInt &	uiHeight
	)

Get the visible size for the given layer

Parameters

uiLayerID	id of layer
uiWidth	visible width
uiHeight	visible height

Returns

true if layer was found

GetMainLayerID()

eC_UInt CGfxEnv::GetMainLayerID

(

)

const

Return the ID of the main-layer

Returns

main-layer ID

GetMergeBuffer()

virtual void * CGfxEnv::GetMergeBuffer ( ) const

inlinevirtual

Return merge-buffer

Returns

NULL by default

Reimplemented in CGfxEnvDAVE.

GetNumberOfLayers()

eC_UInt CGfxEnv::GetNumberOfLayers

(

)

const

Return number of configured layers

Returns

number of layers

GetRenderBuffer()

void * CGfxEnv::GetRenderBuffer

(

const eC_UInt &

uiLayerID

)

const

Get the currently active buffer which is used for rendering

Parameters

uiLayerID

id of layer

Returns

address of buffer or NULL if layer was not found

GetSurfaceMode()

virtual SurfaceMode_t CGfxEnv::GetSurfaceMode ( ) const

virtual

Retrieve the Surface-Mode

Returns

surface-mode

GetWidth()

virtual eC_UInt CGfxEnv::GetWidth ( ) const

virtual

Get the width of the surface

Returns

width

Reimplemented in CGfxEnvSDL, and CGfxEnvSDL2.

InitDisplay()

virtual eC_UInt CGfxEnv::InitDisplay ( )

inlinevirtual

Initialize display

Returns

1 on success, else 0

Reimplemented in CGfxEnvDAVE.

InitLayer()

virtual void CGfxEnv::InitLayer ( const LayerConfiguration_t &  kLayerConfig )

inlineprotectedvirtual

Initialize layer this can be used to execute platform-specific code is called when layer gets added to DCWrap

Parameters

kLayerConfig

layer-configuration

Reimplemented in CGfxEnvDAVE.

InitLayers()

void CGfxEnv::InitLayers

(

)

Initialize layers after all layers have been added

InvalidateLayer()

void CGfxEnv::InvalidateLayer

(

const eC_UInt &

uiLayerID

)

Refresh layer after content has been changed. This applies merely to layers containing user-defined content

Parameters

uiLayerID

id of layer to refresh

IsCreated()

virtual eC_Bool CGfxEnv::IsCreated ( ) const

virtual

Is surface created

Returns

true if created

Reimplemented in CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL, and CGfxEnvSDL2.

IsLayerModified()

eC_Bool CGfxEnv::IsLayerModified

(

const eC_UInt &

uiLayerID

)

const

Return if layer was recently modified

Parameters

uiLayerID

id of layer

Returns

True if modified

IsLayerVisible()

eC_Bool CGfxEnv::IsLayerVisible

(

const eC_UInt &

uiLayerID

)

const

Get current visibility of layer

Parameters

uiLayerID

id of layer

Returns

true if visible, else false

IsMainLayer()

eC_Bool CGfxEnv::IsMainLayer

(

const eC_UInt &

uiLayerID

)

const

Return if layer is set to be used as main-layer

Parameters

uiLayerID

id of layer

Returns

True if main-layer

IsNull()

virtual eC_Bool CGfxEnv::IsNull ( )

inlinevirtual

Check if Wrapper is NULL-implementation

Returns

true if NULL

Reimplemented in CGfxEnvNull.

IsResizable()

virtual eC_Bool CGfxEnv::IsResizable ( ) const

virtual

Get Resizable

Returns

resizable

IsVSyncEnabled()

virtual eC_Bool CGfxEnv::IsVSyncEnabled ( ) const

inlinevirtual

Return if VSync is enabled

Returns

true if VSync is enabled

NeedsManualMerge()

virtual eC_Bool CGfxEnv::NeedsManualMerge ( ) const

virtual

Get if merge is needed

Returns

merge needed

RefreshScreen() [1/2]

virtual eC_Bool CGfxEnv::RefreshScreen ( const CGUIRect &  rkInvalidatedArea )

inlinevirtual

Refresh the screen within the given invalidate area. This can be used to copy regions of the display-buffer to the drawing-buffer

Parameters

rkInvalidatedArea

This area will be refreshed.

Returns

True if OK

Reimplemented in CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL, and CGfxEnvWin.

RefreshScreen() [2/2]

virtual eC_Bool CGfxEnv::RefreshScreen ( const eC_TListDoubleLinked< CGUIRect > &  kInvalidatedRectList )

virtual

Refresh multiple parts of the screen

Parameters

kInvalidatedRectList

invalidated areas

Returns

True if OK

SetActiveLayerID()

eC_Bool CGfxEnv::SetActiveLayerID	(	const eC_UInt &	uiLayerID,
		const eC_Bool &	bMarkAsModified = false
	)

Set the given layer-id as the active all following access for rendering will be sent to the layer

Parameters

uiLayerID	id of layer
bMarkAsModified	layer will be marked as modified upon switch (default: false)

Returns

true if layer exists, otherwise false

SetCliprect()

virtual void CGfxEnv::SetCliprect ( const CGUIRect &  rkNewClipRect )

inlinevirtual

Set the clip rectangle.

Parameters

rkNewClipRect

The new clipping rectangle.

Reimplemented in CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, and CGfxEnvSDL.

SetDevice()

virtual void CGfxEnv::SetDevice ( void *  pkDevice )

inlinevirtual

Set a device

Parameters

pkDevice

Reimplemented in CGfxEnvDAVE.

SetGfxWrap()

void CGfxEnv::SetGfxWrap ( CGfxWrap *  pkGfxWrap )

inline

Set the GfxWrapper

Parameters

pkGfxWrap

SetGlobalAlpha()

void CGfxEnv::SetGlobalAlpha

(

const eC_UByte &

ubGlobalAlpha

)

Set the global alpha-value, which is used to correctly blend the layers during a transition

Parameters

ubGlobalAlpha

SetLayerAlpha()

eC_Bool CGfxEnv::SetLayerAlpha	(	const eC_UInt &	uiLayerID,
		const eC_UByte &	ubAlpha
	)

Set the alpha-value for blending between layer for the given layer.

Parameters

uiLayerID	id of layer
ubAlpha	alpha-value

Returns

true if layer was found

SetLayerChromaKey()

eC_Bool CGfxEnv::SetLayerChromaKey	(	const eC_UInt &	uiLayerID,
		const eC_Bool &	bChromaKeyActive,
		const eC_UInt &	uiChromaKey,
		const eC_UByte &	ubAlpha
	)

Set the chroma-key for blending between layer for the given layer.

Parameters

uiLayerID	id of layer
bChromaKeyActive	true if chroma-keying is active
uiChromaKey	the color for chroma-keying
ubAlpha	alpha-value for replacement

Returns

true if layer was found

SetLayerPosition()

eC_Bool CGfxEnv::SetLayerPosition	(	const eC_UInt &	uiLayerID,
		const eC_Int &	iXPos,
		const eC_Int &	iYPos
	)

Set the position for the given layer

Parameters

uiLayerID	id of layer
iXPos	x-position
iYPos	y-position

Returns

true if layer was found

SetLayerVisible()

eC_Bool CGfxEnv::SetLayerVisible	(	const eC_UInt &	uiLayerID,
		const eC_Bool &	bVisible
	)

Set the layer to visible

Parameters

uiLayerID	id of layer
bVisible	visibility of layer

Returns

true if layer was found

SetLayerVisiblePos()

eC_Bool CGfxEnv::SetLayerVisiblePos	(	const eC_UInt &	uiLayerID,
		const eC_Int &	iXPos,
		const eC_Int &	iYPos
	)

Set the visible position for the given layer

Parameters

uiLayerID	id of layer
iXPos	x-position
iYPos	y-position

Returns

true if layer was found

SetLayerVisibleSize()

eC_Bool CGfxEnv::SetLayerVisibleSize	(	const eC_UInt &	uiLayerID,
		const eC_UInt &	uiWidth,
		const eC_UInt &	uiHeight
	)

Set the visible size for the given layer

Parameters

uiLayerID	id of layer
uiWidth	visible width
uiHeight	visible height

Returns

true if layer was found

SetMainLayerID()

void CGfxEnv::SetMainLayerID

(

const eC_UInt &

uiLayerID

)

This will set the id of the main-layer

Parameters

uiLayerID

id of layer

SetMainLayerProperties()

void CGfxEnv::SetMainLayerProperties	(	const eC_UInt &	uiLayerID,
		const eC_Bool &	bCached
	)

Set the configuration of the main-layer

Parameters

uiLayerID	set layer-id (default: 0)
bCached	set to true if layer-memory is cached (default: false)

SetObjectForLayerID()

void CGfxEnv::SetObjectForLayerID	(	const eC_UInt &	uiLayerID,
		CGUIObject *	pkObject
	)

This will link an object to a specific layer. this info is used in UpdateLayerPositions

Parameters

uiLayerID	id of layer
pkObject	pointer to object

SetScreenSize()

virtual void CGfxEnv::SetScreenSize ( const eC_UInt &  uiWidth, const eC_UInt &  uiHeight  )

virtual

Set the screen-size this will normally result in recreating the surfaces

Parameters

uiWidth
uiHeight

Reimplemented in CGfxEnvSDL, and CGfxEnvSDL2.

SetVSyncEnabled()

virtual void CGfxEnv::SetVSyncEnabled ( const eC_Bool &  bVSyncEnabled )

virtual

Set if VSync is enabled

Parameters

bVSyncEnabled

set to true if VSync is enabled

SetWindowCaption()

virtual void CGfxEnv::SetWindowCaption ( const eC_String &  kCaption )

inlinevirtual

Set the window caption

Parameters

kCaption

Reimplemented in CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL, CGfxEnvSDL2, and CGfxEnvWin.

StartOfRefresh()

virtual void CGfxEnv::StartOfRefresh ( )

inlinevirtual

This will be called at the start of refresh

Reimplemented in CGfxEnvDAVE.

SupportsCopy()

virtual eC_Bool CGfxEnv::SupportsCopy ( ) const

virtual

Get if copy is supported

Returns

copy supported

SwapBuffers()

virtual eC_Bool CGfxEnv::SwapBuffers ( )

inlinevirtual

Swap buffers

Returns

true if successful

Reimplemented in CGfxEnvEGL, CGfxEnvFBDevice, CGfxEnvFBDeviceRZA2M, CGfxEnvSDL, CGfxEnvSDL2, and CGfxEnvWin.

UpdateLayer()

virtual void CGfxEnv::UpdateLayer ( const LayerConfiguration_t &  kLayerConfig, const LayerUpdate_t &  eUpdateReason  )

inlinevirtual

Update layer according to reason. This will be called when attributes of the layer (position, size, etc) have changed

Parameters

kLayerConfig	configuration of updated layer
eUpdateReason	reason of update

Reimplemented in CGfxEnvDAVE.

UpdateLayerBuffers()

virtual eC_Bool CGfxEnv::UpdateLayerBuffers ( const eC_UInt &  uiLayerID, void *  pkRenderBuffer, void *  pkDisplayBuffer, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight  )

virtual

Update buffers for layer

Parameters

uiLayerID	id of layer
pkRenderBuffer	currently used buffer for rendering
pkDisplayBuffer	currently used buffer for display
uiWidth	width of layer
uiHeight	height of layer

Returns

true if successful

Reimplemented in CGfxEnvCDC, CGfxEnvCDCDI, and CGfxEnvDAVE.

UpdateLayerPositions()

void CGfxEnv::UpdateLayerPositions

(

)

This will update the positions for all layers, BEFORE the redraw is done.

UpdateMainLayer()

void CGfxEnv::UpdateMainLayer ( const CGUICommonEnums::ImageType_t &  eColorFormat, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight, const eC_UInt &  uiBufferCount, void **  ppkBuffers  )

protected

Update settings of main-layer

Parameters

eColorFormat	color-format
uiWidth	width
uiHeight	height
uiBufferCount	number of buffers
ppkBuffers	pointer to buffers

---

The documentation for this class was generated from the following file:

• GfxEnv.h
