Base class for button controls. More...

#include <GUIBaseButton.h>

Inheritance diagram for CGUIBaseButton:

[legend]

Public Member Functions
	CGUIBaseButton ()

	CGUIBaseButton (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const eC_String &kText, CGUICommandPtr pkCommandObject, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIBaseButton (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const TextResource_t &eTextID, CGUICommandPtr pkCommandObject, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIBaseButton (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const eC_String &kText, CGUICommandPtr pkCommandObject, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIBaseButton (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const TextResource_t &eTextID, CGUICommandPtr pkCommandObject, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIBaseButton (const CGUIBaseButton &kSource)

virtual	~CGUIBaseButton (void)

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDraw ()

CGUICommandPtr	GetCommand () const

CGUIText *	GetLabel () const

CGUIBaseButton &	operator= (const CGUIBaseButton &kSource)

virtual void	ReadFromStream ()

void	SetCommand (CGUICommandPtr pkCommand)

virtual void	SetHeight (const eC_Value &vNewHeight)

void	SetLabel (const eC_String &kString)

void	SetLabel (const TextResource_t &eTextID)

void	SetText (CGUIText *pkText)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vNewWidth)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX=eC_FromInt(-1), const eC_Value &vDeltaY=eC_FromInt(-1), const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Protected Attributes
CGUICommandPtr	m_pkCommandObject
	Holds the attached command.

CGUIText *	m_pkLabel
	Holds the label.

Additional Inherited Members
Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Detailed Description

Base class for button controls.

Like all the "BaseXXXXX"-Classes, this serves primarily as base-class, from which you can derive your own customized objects. For a Button implementation which uses images to visualize itself, please refer to CGUIButton.

A button is an object that looks differently depending on its state (normal, highlighted, focused, pressed or grayed-out). Typically, a button does something when it is clicked. The behavior of a button can be implemented mainly in three ways:

The most elegant solution is to attach a CGUICommand object to the button. The command is executed each time the button is clicked. This is also a very modular approach since commands can be changed any time, so special derived button classes can be re-used easily. See SetCommand() and constructors.
A less elegant and less modular approach is to derive a class from this one and re-implement DoClick(). Since the implementation will tend to be very specific, the button will not be very reusable. It is of course possible to add further attributes to make it more flexible, but this could also more easily be done with commands.
The last way is to simply ignore DoClick() and not attach any commands. In this case, the Guiliani framework will call the button's parent composite object's DoClick() in which it can be determined which control was clicked (by its ID, or worse, by pointer comparison). Since this will usually lead to bloated and hard-to-maintain code, it is strongly discouraged to use this approach.

Example:
// Create base button

CGUIBaseButton *pBaseButton = new CGUIBaseButton(this,

eC_FromInt(0),

eC_FromInt(0),

eC_FromInt(50),

eC_FromInt(50),

"Button1",

NULL, // Replace the NULL with your command.

OBJ_BT_BUTTON1);

// Set the text of the button.

pBaseButton->SetLabel("ok");

CGUIBaseButton
Base class for button controls.
Definition: GUIBaseButton.h:69

CGUIBaseButton::CGUIBaseButton
CGUIBaseButton()

CGUIBaseButton::SetLabel
void SetLabel(const eC_String &kString)

Constructor & Destructor Documentation

◆ CGUIBaseButton() [1/6]

CGUIBaseButton::CGUIBaseButton	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const TextResource_t &	eTextID,
		CGUICommandPtr	pkCommandObject,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a button from relative coordinates and a text ID.

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object.
vY	Y-position relative to its parent object.
vWidth	Width of the button.
vHeight	Height of the button.
eTextID	ID of text string to be displayed on the button.
pkCommandObject	Pointer to command object which will be executed in reaction to a click.
eID	Object Identifier of this button (choose NO_HANDLE if none is required).

◆ CGUIBaseButton() [2/6]

CGUIBaseButton::CGUIBaseButton	(	CGUICompositeObject *const	pkParent,
		const CGUIRect &	kRect,
		const TextResource_t &	eTextID,
		CGUICommandPtr	pkCommandObject,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a button from a rectangle and a text ID.

Parameters

pkParent	Pointer to the designated parent object
kRect	Boundary rectangle relative to parent.
eTextID	ID of text string to be displayed on the button
pkCommandObject	Pointer to command object which will be executed in reaction to a click
eID	Object Identifier of this button (choose NO_HANDLE if none is required)

◆ CGUIBaseButton() [3/6]

CGUIBaseButton::CGUIBaseButton	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const eC_String &	kText,
		CGUICommandPtr	pkCommandObject,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a button from relative coordinates and a string.

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object.
vY	Y-position relative to its parent object.
vWidth	Width of the button.
vHeight	Height of the button.
kText	Text string that will be displayed on the button.
pkCommandObject	Pointer to command object which will be executed in reaction to a click.
eID	Object Identifier of this button

◆ CGUIBaseButton() [4/6]

CGUIBaseButton::CGUIBaseButton	(	CGUICompositeObject *const	pkParent,
		const CGUIRect &	kRect,
		const eC_String &	kText,
		CGUICommandPtr	pkCommandObject,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a button from a rectangle and a string.

Parameters

pkParent	Pointer to the designated parent object.
kRect	Boundary rectangle relative to parent.
kText	Text string that will be displayed on the button.
pkCommandObject	Pointer to command object which will be executed in reaction to a click.
eID	Object Identifier of this button

◆ CGUIBaseButton() [5/6]

CGUIBaseButton::CGUIBaseButton ( )

CGUIBaseButton standard constructor.

See also: CGUIObject().

◆ CGUIBaseButton() [6/6]

CGUIBaseButton::CGUIBaseButton ( const CGUIBaseButton & kSource )

CGUIBaseButton copy-constructor. Command is set to NULL.

Parameters

kSource Source object to be copied

◆ ~CGUIBaseButton()

virtual CGUIBaseButton::~CGUIBaseButton ( void )

virtual

Destructor, deletes command associated with DoClick()

Member Function Documentation

◆ DoButtonDown()

virtual eC_Bool CGUIBaseButton::DoButtonDown	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

virtual

Called when the mouse button or finger is pressed down over an object.

Note: DoButtonDown() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the object was pressed relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoButtonUp()

virtual eC_Bool CGUIBaseButton::DoButtonUp	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

virtual

Called when the mouse button or finger is released. The object under the mouse at the time of releasing will receive this event.

Note: DoButtonUp() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the button was released relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the mouse was released.
vAbsY	Y-position in screen coordinates where the mouse was released.

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoClick()

virtual eC_Bool CGUIBaseButton::DoClick	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

virtual

Called when the object receives a click event. A click can e.g., be the result of a mouse click, a finger press/release sequence on touchscreens, or be triggered by a GK_ACTION keyboard event.

Note: DoClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and released at the same position for in a certain time span, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

Reimplemented in CGUIBaseCheckBox, and CGUIBaseRadioButton.

◆ DoDraw()

virtual eC_Bool CGUIBaseButton::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns: True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

Reimplemented in CGUIBaseCheckBox, CGUIBaseRadioButton, CGUIBlendButton, CGUIButton, CGUICheckBox, CGUIIconButton, and CGUIRadioButton.

◆ GetCommand()

CGUICommandPtr CGUIBaseButton::GetCommand ( ) const

inline

Returns the command object that is currently attached to this button.

Returns: The command object that is currently attached to this button, or NULL if this button does not have a command.

◆ GetLabel()

CGUIText * CGUIBaseButton::GetLabel ( ) const

Returns: A pointer to the text object that represents the caption of the button. To accomplish a "SetLabel" functionality to change the label, you can use these calls: GetLabel()->SetTextString(newString)

◆ operator=()

CGUIBaseButton & CGUIBaseButton::operator= ( const CGUIBaseButton & kSource )

CGUIBaseButton operator= to copy the whole CGUIBaseButton. Command is set to NULL.

Parameters

kSource Source object to be copied

Returns: Copied object

◆ ReadFromStream()

virtual void CGUIBaseButton::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. Only for use with GUIFactory. GUIStreamingFileReader has to be set in CGUI::Init().

See also: CGUIFactory

Reimplemented from CGUIObject.

Reimplemented in CGUIBaseCheckBox, CGUIBaseRadioButton, CGUIBlendButton, CGUIButton, CGUICheckBox, CGUIIconButton, and CGUIRadioButton.

◆ SetCommand()

void CGUIBaseButton::SetCommand ( CGUICommandPtr pkCommand )

inline

Attaches a command to this button. This command is executed whenever the button is clicked.

Parameters

pkCommand The command to attach to this button.

◆ SetHeight()

virtual void CGUIBaseButton::SetHeight ( const eC_Value & vNewHeight )

virtual

Calls base class implementation and adjusts the size of the CGUIText with the same height difference (i.e., the pixel distance of the text's bottom edge to the button's bottom edge stays the same).

Parameters

vNewHeight The new height.

Reimplemented from CGUIObject.

◆ SetLabel() [1/2]

void CGUIBaseButton::SetLabel ( const eC_String & kString )

Changes the label on the button to a new CGUIText with string. The attributes of the text such as its font, color, size etc. will be copied. Subsequent calls to GetLabel() will return a CGUIText object.

Parameters

kString The new caption of the button.

Remarks: If this button does not have a label at the time this method is called, a new CGUIText object with default attributes is created.

◆ SetLabel() [2/2]

void CGUIBaseButton::SetLabel ( const TextResource_t & eTextID )

Changes the label on the button to a new CGUIText with ID. The attributes of the text such as its font, color, size etc. will be copied. Subsequent calls to GetLabel() will return a CGUIText object.

Parameters

eTextID The new caption of the button.

Remarks: If this button does not have a label at the time this method is called, a new CGUIText object with default attributes is created.

◆ SetText()

void CGUIBaseButton::SetText ( CGUIText * pkText )

Change the internal text object. This method deletes the old text. Use this to exchange the default CGUIText control created by this control object with another (possibly user-implemented) text. If you only want to change the text content, use SetLabel().

Parameters

pkText The new text object.

◆ SetValue()

virtual eC_Bool CGUIBaseButton::SetValue ( const CGUIValue & rkValue )

virtual

Sets the text label of this button.

See also: CGUIText::SetTextString()

Parameters

rkValue The CGUIValue containing the new value

Returns: Always True.

Reimplemented from CGUIObject.

Reimplemented in CGUIBaseCheckBox.

◆ SetWidth()

virtual void CGUIBaseButton::SetWidth ( const eC_Value & vNewWidth )

virtual

Calls base class implementation and adjusts the size of the CGUIText with the same width difference (i.e., the pixel distance of the text's right edge to the button's right edge stays the same).

Parameters

vNewWidth The new width.

Reimplemented from CGUIObject.

◆ WriteToStream()

virtual void CGUIBaseButton::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all object attributes to the streaming file. StreamWriter has to be initialized. Only for use with GUIStreamWriter.

Parameters

bWriteClassID This flag is used to select if writing of ControlID, leading and trailing tags is performed. Only GUIStreamWriter and GUICompositeObject have to set this flag true.

See also: CGUIStreamWriter

Reimplemented from CGUIObject.

Reimplemented in CGUIBaseCheckBox, CGUIBaseRadioButton, CGUIBlendButton, CGUIButton, CGUICheckBox, CGUIIconButton, and CGUIRadioButton.

The documentation for this class was generated from the following file:

GUIBaseButton.h

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ CGUIBaseButton() [1/6]

◆ CGUIBaseButton() [2/6]

◆ CGUIBaseButton() [3/6]

◆ CGUIBaseButton() [4/6]

◆ CGUIBaseButton() [5/6]

◆ CGUIBaseButton() [6/6]

◆ ~CGUIBaseButton()

Member Function Documentation

◆ DoButtonDown()

◆ DoButtonUp()

◆ DoClick()

◆ DoDraw()

◆ GetCommand()

◆ GetLabel()

◆ operator=()

◆ ReadFromStream()

◆ SetCommand()

◆ SetHeight()

◆ SetLabel() [1/2]

◆ SetLabel() [2/2]

◆ SetText()

◆ SetValue()

◆ SetWidth()

◆ WriteToStream()
