CGUIAnimation Class Reference

Base class for modular Guiliani animations. More...

#include <GUIAnimation.h>

Inheritance diagram for CGUIAnimation:

Public Types
enum	AnimationStatus_t {   ANIMATION_RUNNING , ANIMATION_PAUSED , ANIMATION_STOPPED , ANIMATION_FINISHED ,   ANIMATION_DELETED }

Public Member Functions
virtual	~CGUIAnimation ()
void	AddAnimationObserver (CGUIAnimationObserver *pkObserver)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)=0
void	ContinueAnimation ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	GetAnimatedAttributes ()
CGUIObject *	GetAnimatedObject () const
ObjectHandle_t	GetAnimatedObjectID () const
eC_UInt	GetDuration () const
eC_UInt	GetID () const
eC_UInt	GetStepTime () const
virtual void	InitAttributes ()
eC_Bool	IsDeletedAfterFinish () const
eC_Bool	IsPaused () const
void	PauseAnimation ()
void	ReadFromStream ()
void	RemoveAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetAnimatedObject (CGUIObject *pkObject)
void	SetAnimatedObjectID (const ObjectHandle_t &eObject)
void	SetAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetDeletedAfterFinish (const eC_Bool bDeletedAfterFinish)
void	SetDuration (eC_UInt uiDuration)
void	StartAnimation ()
void	StopAnimation ()
void	UpdateAnimatedObjectPointer ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_Char	XMLTAG_ANIMATIONCLASSID []
	XML tag to be used when writing a animation class ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONENDTAG []
	XML tag to be used when finish writing CGUIAnimation information into the stream.
static const eC_Char	XMLTAG_ANIMATIONID []
	XML tag to be used when writing a animation ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONSTARTTAG []
	XML tag to be used when start writing CGUIAnimation information into the stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions
	CGUIAnimation ()
	CGUIAnimation (CGUIObject *pkAnimatedObject, eC_UInt uiDuration, eC_UInt uiStepTime=25, eC_Bool bDeletedAfterFinish=false)
void	AddAnimatedAttribute (CGUIAnimatedAttribute kAnimatedAttribute)
CGUIAnimatedAttribute &	GetAnimatedAttribute (const eC_UInt &uiAttributeIndex) const
virtual void	OnStatusChanged (AnimationStatus_t eStatus)
void	RemoveAnimatedAttributes ()
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	m_pkAnimatedAttributes
	available animated attributes

Friends
class	CGUIAnimationHandler

Detailed Description

Base class for modular Guiliani animations.

The "animations module" is providing standard animations for animation of objects. The object can appear in different ways: It can be shown immediately dropped from above fast dropped slowly from above dropped from above but it will be bouncing like a rubber ball

An animation object typically manipulates values of a GUIObject. After a specified step time, a timer event triggers the animation callback DoAnimate. GUIAnimations are using CGUIEasing functions to calculate the current attribute values.

DoAnimate triggers the CGUIEasing functions to recalculate the current value for attributes based on the elapsed time. Afterwards ApplyAnimation is called. This function reads the current values of the CGUIEasing functions and sets them in the animated object.

Basically there are two types of animations.

1. Animations with a specified duration. The CGUIEasing functions calculate the step size based on the duration, the StartValue and the TargetValue.

StepSize = (TargetValue - StartValue)/Duration;

2. Endless Animations. Endless animations do not have a defined end. They only have a step time after which DoAnimate is triggered. To have an endless animation the duration has to be set to 0. The CGUIEasing functions will calculate the step size for each animation step without using the duration.

StepSize = (TargetValue - StartValue);

It is possible to set an AnimationObserver which is informed whenever the status of the animation changes. Use the SetAnimationObserver() interface to register an observer.

Note

When reading the GUI from stream, the ReadFromStream() method will not set its observer pointer. It is the responsibility of the animation observer to set itself as observer in the animation again when it is reading from stream.

Member Enumeration Documentation

AnimationStatus_t

enum CGUIAnimation::AnimationStatus_t

Status message which is used for the animation observer which is set with SetAnimationObserver().

Enumerator
ANIMATION_RUNNING	The animation has just started running.
ANIMATION_PAUSED	The animation has just been paused.
ANIMATION_STOPPED	The animation has stopped. Either forcefully, or because it has ended.
ANIMATION_FINISHED	The animation has reached its end, and does therefore finish animating.
ANIMATION_DELETED	The animation has been deleted.

Constructor & Destructor Documentation

~CGUIAnimation()

virtual CGUIAnimation::~CGUIAnimation ( )

virtual

Destructor

CGUIAnimation() [1/2]

CGUIAnimation::CGUIAnimation ( )

protected

Default constructor for streaming. This constructor does not add the animation to the AnimationHandler since this is done after the AnimationHandler read the animation from stream.

CGUIAnimation() [2/2]

CGUIAnimation::CGUIAnimation ( CGUIObject *  pkAnimatedObject, eC_UInt  uiDuration, eC_UInt  uiStepTime = 25, eC_Bool  bDeletedAfterFinish = false  )

protected

Constructor Adds the animation to the AnimationHandler.

Parameters

pkAnimatedObject	The animated GUIObject. See GetAnimatedObject().
uiDuration	The duration of the animation in milliseconds.
uiStepTime	The step time of each animation step in milliseconds. See GetStepTime().
bDeletedAfterFinish	True if the animation shall be deleted after it was finished. (only for animations with a defined end).

Member Function Documentation

AddAnimatedAttribute()

void CGUIAnimation::AddAnimatedAttribute ( CGUIAnimatedAttribute  kAnimatedAttribute )

protected

Adds a new animated attribute

Parameters

kAnimatedAttribute

new animated attribute

AddAnimationObserver()

void CGUIAnimation::AddAnimationObserver ( CGUIAnimationObserver *  pkObserver )

inline

Add the animation observer. The observer will be informed by calling CGUIAnimationObserver::OnStatusChanged, whenever the status of the animation changes.

Parameters

pkObserver

The observer of the animation.

ApplyAnimation()

virtual void CGUIAnimation::ApplyAnimation ( eC_UInt  uiElapsedTime )

pure virtual

This function contains the animation logic. It typically accesses the animation's CGUIEasing functions to get the current values and sets these values in the animated object. This function is called by DoAnimate()

Parameters

uiElapsedTime

Time elapsed (in ms) since start of animation.

Implemented in CGUIAnimationAttribute, CGUIAnimationBlinking, CGUIAnimationMove, CGUIAnimationMoveInOut, CGUIAnimationSize, CGUIAnimationStdGUIObject, and CGUIAnimationTrigger.

ContinueAnimation()

void CGUIAnimation::ContinueAnimation

(

)

Continue the animation. The timer callback will be restored (installed again).

DoAnimate()

virtual void CGUIAnimation::DoAnimate ( const eC_Value &  vTimes = eC_FromInt(1) )

virtual

Called by the GUITimer after the callback time expired. Calls ApplyAnimation().

Parameters

vTimes

Ignored by base class, used by implemented animation to compensate for jitter

Reimplemented from CGUIAnimatable.

GetAnimatedAttribute()

CGUIAnimatedAttribute & CGUIAnimation::GetAnimatedAttribute ( const eC_UInt &  uiAttributeIndex ) const

protected

Get animated attribute for index

Parameters

uiAttributeIndex

index of attribute

Returns

Animated Attribute

GetAnimatedAttributes()

eC_TListDoubleLinked< CGUIAnimatedAttribute > * CGUIAnimation::GetAnimatedAttributes ( )

inline

Gets all available animated attributes for this animation

Returns

list of all animated attributes

GetAnimatedObject()

CGUIObject * CGUIAnimation::GetAnimatedObject ( ) const

inline

Returns

the animated GUIObject.

GetAnimatedObjectID()

ObjectHandle_t CGUIAnimation::GetAnimatedObjectID ( ) const

inline

Returns

the objectID of the animated object

GetDuration()

eC_UInt CGUIAnimation::GetDuration

(

)

const

Returns

The total duration of the animation in milliseconds. If the animation has no defined end, the duration is 0.

GetID()

eC_UInt CGUIAnimation::GetID ( ) const

inline

Returns

The unique id of the animation which is set when adding the animation to the CGUIAnimationHandler.

GetStepTime()

eC_UInt CGUIAnimation::GetStepTime ( ) const

inline

Returns

The time for each animation step in milliseconds.

InitAttributes()

virtual void CGUIAnimation::InitAttributes ( )

inlinevirtual

Called by StartAnimation(). Reimplement this method to initialize animation attributes before the animation is started if necessary.

Reimplemented in CGUIAnimationMove, and CGUIAnimationMoveInOut.

IsDeletedAfterFinish()

eC_Bool CGUIAnimation::IsDeletedAfterFinish ( ) const

inline

Returns

True if this animation will be deleted once it is finished. This is only applicable for animations with a defined end. If no duration was set, the animation has no defined end.

IsPaused()

eC_Bool CGUIAnimation::IsPaused ( ) const

inline

Checks if the animation is currently paused.

Returns

True if an animation is currently paused

OnStatusChanged()

virtual void CGUIAnimation::OnStatusChanged ( AnimationStatus_t  eStatus )

protectedvirtual

Called when the animation status changes. Informs the animation observer and removes the animation callback when the animation is no longer running.

Note

If overriding this function make sure that the base implementation is called to inform the observers.

Parameters

eStatus

The new status of the animation.

Reimplemented in CGUIAnimationAttribute, CGUIAnimationBlinking, CGUIAnimationMoveInOut, and CGUIAnimationTrigger.

PauseAnimation()

void CGUIAnimation::PauseAnimation

(

)

Pause the animation. The timer callback will be removed.

ReadFromStream()

void CGUIAnimation::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUIStreamableObject.

Reimplemented in CGUIAnimationAttribute, CGUIAnimationBlinking, CGUIAnimationMove, CGUIAnimationMoveInOut, CGUIAnimationSize, CGUIAnimationStdGUIObject, and CGUIAnimationTrigger.

RemoveAnimatedAttributes()

void CGUIAnimation::RemoveAnimatedAttributes ( )

protected

Removes all animated attributes.

RemoveAnimationObserver()

void CGUIAnimation::RemoveAnimationObserver ( CGUIAnimationObserver *  pkObserver )

inline

Removes given observer.

Parameters

pkObserver

observer

SetAnimatedObject()

void CGUIAnimation::SetAnimatedObject ( CGUIObject *  pkObject )

inline

Set the animated object.

Parameters

pkObject

The object which will be animated.

SetAnimatedObjectID()

void CGUIAnimation::SetAnimatedObjectID ( const ObjectHandle_t &  eObject )

inline

Set the animated object.

Parameters

eObject

The ObjectID

SetAnimationObserver()

void CGUIAnimation::SetAnimationObserver ( CGUIAnimationObserver *  pkObserver )

inline

Set the animation observer. All previous registered observer are removed. The observer will be informed by calling CGUIAnimationObserver::OnStatusChanged, whenever the status of the animation changes.

Parameters

pkObserver

The observer of the animation.

SetDeletedAfterFinish()

void CGUIAnimation::SetDeletedAfterFinish ( const eC_Bool  bDeletedAfterFinish )

inline

Specifies if this animation will be deleted once it is finished. This is only applicable for animations with a defined end. If no duration was set, the animation has no defined end.

Parameters

bDeletedAfterFinish

If True, delete the animation after is has finshed

SetDuration()

void CGUIAnimation::SetDuration

(

eC_UInt

uiDuration

)

Set the duration for the Animation in milliseconds.

Parameters

uiDuration

The new duration time.

StartAnimation()

void CGUIAnimation::StartAnimation ( )

virtual

Start the animation. This function registers a timer callback. ApplyAnimation() will be called after StepTime expired.

Reimplemented from CGUIAnimatable.

StopAnimation()

void CGUIAnimation::StopAnimation ( )

virtual

Stop the animation. The timer callback will be removed.

Reimplemented from CGUIAnimatable.

UpdateAnimatedObjectPointer()

void CGUIAnimation::UpdateAnimatedObjectPointer

(

)

Checks if the animated object pointer is valid and updates it if necessary

WriteToStream()

void CGUIAnimation::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIStreamableObject.

Reimplemented in CGUIAnimationAttribute, CGUIAnimationBlinking, CGUIAnimationMove, CGUIAnimationMoveInOut, CGUIAnimationSize, CGUIAnimationStdGUIObject, and CGUIAnimationTrigger.

Friends And Related Function Documentation

CGUIAnimationHandler

friend class CGUIAnimationHandler

friend

---

The documentation for this class was generated from the following file:

• GUIAnimation.h
