CGUIAnimationMoveInOut Class Reference

Animation moving an object into or out of the visible area. More...

#include <GUIAnimationMoveInOut.h>

Inheritance diagram for CGUIAnimationMoveInOut:

Public Types
enum	MoveDirection_t { MOVE_TOP , MOVE_BOTTOM , MOVE_LEFT , MOVE_RIGHT }
Public Types inherited from CGUIAnimation
enum	AnimationStatus_t {   ANIMATION_RUNNING , ANIMATION_PAUSED , ANIMATION_STOPPED , ANIMATION_FINISHED ,   ANIMATION_DELETED }

Public Member Functions
	CGUIAnimationMoveInOut ()
	CGUIAnimationMoveInOut (CGUIObject *pAnimatedObject, CGUIEasing::EasingType_t eEasingX, CGUIEasing::EasingType_t eEasingY, MoveDirection_t eDirection, eC_Bool bMoveOutOnStart=false, eC_UInt uiDuration=1000, eC_UInt uiStepTime=25)
void	ApplyAnimation (eC_UInt uiElapsedTime)
eC_Value	GetOriginalXPos ()
eC_Value	GetOriginalYPos ()
eC_Bool	IsMovingOut ()
void	ReadFromStream ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimation
virtual	~CGUIAnimation ()
void	AddAnimationObserver (CGUIAnimationObserver *pkObserver)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)=0
void	ContinueAnimation ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	GetAnimatedAttributes ()
CGUIObject *	GetAnimatedObject () const
ObjectHandle_t	GetAnimatedObjectID () const
eC_UInt	GetDuration () const
eC_UInt	GetID () const
eC_UInt	GetStepTime () const
virtual void	InitAttributes ()
eC_Bool	IsDeletedAfterFinish () const
eC_Bool	IsPaused () const
void	PauseAnimation ()
void	ReadFromStream ()
void	RemoveAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetAnimatedObject (CGUIObject *pkObject)
void	SetAnimatedObjectID (const ObjectHandle_t &eObject)
void	SetAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetDeletedAfterFinish (const eC_Bool bDeletedAfterFinish)
void	SetDuration (eC_UInt uiDuration)
void	StartAnimation ()
void	StopAnimation ()
void	UpdateAnimatedObjectPointer ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_UInt	MOVEINOUT_ANIMATION_CLASS_MIN_VERSION
	The minimal class version allowed.
static const eC_UInt	MOVEINOUT_ANIMATION_CLASS_VERSION
	The class version of the implementation.
Static Public Attributes inherited from CGUIAnimation
static const eC_Char	XMLTAG_ANIMATIONCLASSID []
	XML tag to be used when writing a animation class ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONENDTAG []
	XML tag to be used when finish writing CGUIAnimation information into the stream.
static const eC_Char	XMLTAG_ANIMATIONID []
	XML tag to be used when writing a animation ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONSTARTTAG []
	XML tag to be used when start writing CGUIAnimation information into the stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions
void	InitAttributes ()
void	OnStatusChanged (AnimationStatus_t eStatus)
Protected Member Functions inherited from CGUIAnimation
	CGUIAnimation ()
	CGUIAnimation (CGUIObject *pkAnimatedObject, eC_UInt uiDuration, eC_UInt uiStepTime=25, eC_Bool bDeletedAfterFinish=false)
void	AddAnimatedAttribute (CGUIAnimatedAttribute kAnimatedAttribute)
CGUIAnimatedAttribute &	GetAnimatedAttribute (const eC_UInt &uiAttributeIndex) const
virtual void	OnStatusChanged (AnimationStatus_t eStatus)
void	RemoveAnimatedAttributes ()
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Additional Inherited Members
Protected Attributes inherited from CGUIAnimation
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	m_pkAnimatedAttributes
	available animated attributes

Detailed Description

Animation moving an object into or out of the visible area.

This animation moves an object into or out of the visible area of its parent using its current position as start or end position. The Direction determines where the object is moved to or from.

For the move direction TOP and BOTTOM the object is translated vertically, for LEFT and RIGHT it is translated horizontally.

The flag bMoveOutOnStart determines if the object is moved from the current position out of the visible area of its parent (true), or from outside of the parents visible area to the current position (false).

The object is set visible when the animation is constructed and therefore initialized.

This example moves an object into the middle of the screen assuming that the animated object is a direct child of the GUI.

pAnimatedObject->SetRelXPos(GETGUI.GetHalfWidth() - pAnimatedObject->GetHalfWidth());
pAnimatedObject->SetRelYPos(GETGUI.GetHalfHeight() - pAnimatedObject->GetHalfHeight());

CGUIAnimation* pAnimation = new CGUIAnimationMoveInOut(pAnimatedObject,
CGUIEasing::EASE_LINEAR, CGUIEasing::EASE_LINEAR, CGUIAnimationMoveInOut::MOVE_TOP, false, 2000);

Member Enumeration Documentation

MoveDirection_t

enum CGUIAnimationMoveInOut::MoveDirection_t

Determies the move direction

Constructor & Destructor Documentation

CGUIAnimationMoveInOut() [1/2]

CGUIAnimationMoveInOut::CGUIAnimationMoveInOut

(

)

Default constructor for streaming.

CGUIAnimationMoveInOut() [2/2]

CGUIAnimationMoveInOut::CGUIAnimationMoveInOut	(	CGUIObject *	pAnimatedObject,
		CGUIEasing::EasingType_t	eEasingX,
		CGUIEasing::EasingType_t	eEasingY,
		MoveDirection_t	eDirection,
		eC_Bool	bMoveOutOnStart = false,
		eC_UInt	uiDuration = 1000,
		eC_UInt	uiStepTime = 25
	)

Constructor

Parameters

pAnimatedObject	The GUIObject that will be moved.
eEasingX	The easing type that is used for the XPos of the object.
eEasingY	The easing type that is used for the YPos of the object.
eDirection	The move direction.
bMoveOutOnStart	True to move the object into the screen, false to move it out of the screen.
uiDuration	The total duraiton of the animation in milliseconds. Based on the distance the duration determines the animation speed.
uiStepTime	The time between two animation steps in millisectionds.

Member Function Documentation

ApplyAnimation()

void CGUIAnimationMoveInOut::ApplyAnimation ( eC_UInt  uiElapsedTime )

virtual

This function contains the animation logic. It typically accesses the animation's CGUIEasing functions to get the current values and sets these values in the animated object. This function is called by DoAnimate() Adapts the objects position after each animation step based on the current value of the CGUIEasing functions.

Parameters

uiElapsedTime

Time elapsed (in ms) since start of animation.

Implements CGUIAnimation.

GetOriginalXPos()

eC_Value CGUIAnimationMoveInOut::GetOriginalXPos ( )

inline

Returns

The original XPosition of the object before the animation is started. This position is the start position (bMoveOutOnStart = false) / the destinaion position (bOutOnStart = true) for the animation.

GetOriginalYPos()

eC_Value CGUIAnimationMoveInOut::GetOriginalYPos ( )

inline

Returns

The original YPosition of the object before the animation is started. This position is the start position (bMoveOutOnStart = false) / the target position (bOutOnStart = true) for the animation.

InitAttributes()

void CGUIAnimationMoveInOut::InitAttributes ( )

protectedvirtual

Initializes the object position and sets the object visible.

Reimplemented from CGUIAnimation.

IsMovingOut()

eC_Bool CGUIAnimationMoveInOut::IsMovingOut ( )

inline

Returns

the move operation. True if the object is moving out of its parent's area, False if it is moving into the parent's area.

OnStatusChanged()

void CGUIAnimationMoveInOut::OnStatusChanged ( AnimationStatus_t  eStatus )

protectedvirtual

Makes the object invisible when it is moving out of the screen after the animation was finished. Also calls the base implementation to inform the animation observers.

Parameters

eStatus

The new status of the animation.

Reimplemented from CGUIAnimation.

ReadFromStream()

void CGUIAnimationMoveInOut::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUIAnimation.

WriteToStream()

void CGUIAnimationMoveInOut::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIAnimation.

---

The documentation for this class was generated from the following file:

• GUIAnimationMoveInOut.h
