CGUIAnimationSize Class Reference

This animation resizes a CGUIObject from a start dimension to a target dimension. More...

#include <GUIAnimationSize.h>

Inheritance diagram for CGUIAnimationSize:

Public Member Functions
	CGUIAnimationSize ()
	CGUIAnimationSize (CGUIObject *pAnimatedObject, CGUIEasing::EasingType_t eEasingWidth, CGUIEasing::EasingType_t eEasingHeight, eC_Value vStartWidth, eC_Value vStartHeight, eC_Value vTargetWidth, eC_Value vTargetHeight, eC_Bool bKeepCenterPosition, eC_UInt uiDuration, eC_UInt uiStepTime=25)
void	ApplyAnimation (eC_UInt uiElapsedTime)
void	ReadFromStream ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimation
virtual	~CGUIAnimation ()
void	AddAnimationObserver (CGUIAnimationObserver *pkObserver)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)=0
void	ContinueAnimation ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	GetAnimatedAttributes ()
CGUIObject *	GetAnimatedObject () const
ObjectHandle_t	GetAnimatedObjectID () const
eC_UInt	GetDuration () const
eC_UInt	GetID () const
eC_UInt	GetStepTime () const
virtual void	InitAttributes ()
eC_Bool	IsDeletedAfterFinish () const
eC_Bool	IsPaused () const
void	PauseAnimation ()
void	ReadFromStream ()
void	RemoveAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetAnimatedObject (CGUIObject *pkObject)
void	SetAnimatedObjectID (const ObjectHandle_t &eObject)
void	SetAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetDeletedAfterFinish (const eC_Bool bDeletedAfterFinish)
void	SetDuration (eC_UInt uiDuration)
void	StartAnimation ()
void	StopAnimation ()
void	UpdateAnimatedObjectPointer ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_UInt	SIZE_ANIMATION_CLASS_MIN_VERSION
	The minimal class version allowed.
static const eC_UInt	SIZE_ANIMATION_CLASS_VERSION
Static Public Attributes inherited from CGUIAnimation
static const eC_Char	XMLTAG_ANIMATIONCLASSID []
	XML tag to be used when writing a animation class ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONENDTAG []
	XML tag to be used when finish writing CGUIAnimation information into the stream.
static const eC_Char	XMLTAG_ANIMATIONID []
	XML tag to be used when writing a animation ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONSTARTTAG []
	XML tag to be used when start writing CGUIAnimation information into the stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Attributes
eC_Bool	m_bKeepCenterPosition
	Indicates if the object's center-point shall remain unchanged during animation.
Protected Attributes inherited from CGUIAnimation
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	m_pkAnimatedAttributes
	available animated attributes

Additional Inherited Members
Public Types inherited from CGUIAnimation
enum	AnimationStatus_t {   ANIMATION_RUNNING , ANIMATION_PAUSED , ANIMATION_STOPPED , ANIMATION_FINISHED ,   ANIMATION_DELETED }
Protected Member Functions inherited from CGUIAnimation
	CGUIAnimation ()
	CGUIAnimation (CGUIObject *pkAnimatedObject, eC_UInt uiDuration, eC_UInt uiStepTime=25, eC_Bool bDeletedAfterFinish=false)
void	AddAnimatedAttribute (CGUIAnimatedAttribute kAnimatedAttribute)
CGUIAnimatedAttribute &	GetAnimatedAttribute (const eC_UInt &uiAttributeIndex) const
virtual void	OnStatusChanged (AnimationStatus_t eStatus)
void	RemoveAnimatedAttributes ()
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Detailed Description

This animation resizes a CGUIObject from a start dimension to a target dimension.

The duration for the animation determines the animation's speed.

Example:

// This example resizes the object to half width and half height.

// The animation shall be done in 5 seconds.
const eC_UInt uiDuration = 5000;
const eC_Value vStartWidth = pkAnimatedObject->GetWidth();
const eC_Value vStartHeight = pkAnimatedObject->GetHeight();
const eC_Value vTargetWidth = pkAnimatedObject->GetHalfWidth();
const eC_Value vTargetHeight = pkAnimatedObject->GetHalfHeight();

// Now create the instance of the animation.
CGUIAnimationSize* pAnimation = new CGUIAnimationSize(pkAnimatedObject, CGUIEasing::EASE_LINEAR, CGUIEasing::EASE_LINEAR,
                vStartWidth, vStartHeight, vTargetWidth, vTargetHeight, uiDuration);

// To start the animation call the StartAnimation() method of the animation.
pAnimation->StartAnimation();

//If the instance of the animation is not available directly use the AnimationHandler.
GETANIMATIONHDL.GetAnimation(uiMyAnimationID);

Constructor & Destructor Documentation

CGUIAnimationSize() [1/2]

CGUIAnimationSize::CGUIAnimationSize	(	CGUIObject *	pAnimatedObject,
		CGUIEasing::EasingType_t	eEasingWidth,
		CGUIEasing::EasingType_t	eEasingHeight,
		eC_Value	vStartWidth,
		eC_Value	vStartHeight,
		eC_Value	vTargetWidth,
		eC_Value	vTargetHeight,
		eC_Bool	bKeepCenterPosition,
		eC_UInt	uiDuration,
		eC_UInt	uiStepTime = 25
	)

Constructor

Parameters

pAnimatedObject	The Object that shall be resized.
eEasingWidth	The easing type that is used for the width of the object.
eEasingHeight	The easing type that is used for the height of the object.
vStartWidth	Width at start of animation.
vStartHeight	Height at start of animation.
vTargetWidth	Target width of animated object.
vTargetHeight	Target height of animated object.
bKeepCenterPosition	If TRUE then the object's center position remains unchanged while resizing. if FALSE then the position of the object's top/left corner remains unchanged.
uiDuration	The duration for the complete animation in ms.
uiStepTime	The time between two animation steps in ms.

CGUIAnimationSize() [2/2]

CGUIAnimationSize::CGUIAnimationSize

(

)

Default constructor for streaming.

Member Function Documentation

ApplyAnimation()

void CGUIAnimationSize::ApplyAnimation ( eC_UInt  uiElapsedTime )

virtual

This function contains the animation logic. It typically accesses the animation's CGUIEasing functions to get the current values and sets these values in the animated object. Sets the width and height of the animated object using the CGUIEasing functions' current values. This function is called by DoAnimate()

Parameters

uiElapsedTime

Time elapsed (in ms) since start of animation.

Implements CGUIAnimation.

ReadFromStream()

void CGUIAnimationSize::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUIAnimation.

WriteToStream()

void CGUIAnimationSize::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIAnimation.

Member Data Documentation

SIZE_ANIMATION_CLASS_VERSION

const eC_UInt CGUIAnimationSize::SIZE_ANIMATION_CLASS_VERSION

static

The class version of the size animation class

---

The documentation for this class was generated from the following file:

• GUIAnimationSize.h
