CGUIAnimationStdGUIObject Class Reference

Generic animation of a standard object. More...

#include <GUIAnimationStdGUIObject.h>

Inheritance diagram for CGUIAnimationStdGUIObject:

Public Member Functions
	CGUIAnimationStdGUIObject (CGUIObject *pAnimatedObject, const CGUIEasing::EasingType_t &eEasingX, const CGUIEasing::EasingType_t &eEasingY, const CGUIEasing::EasingType_t &eEasingWidth, const CGUIEasing::EasingType_t &eEasingHeight, const CGUIEasing::EasingType_t &eEasingAlpha, const eC_UInt &uiDuration=1000, const eC_UInt &uiStepTime=25)
	CGUIAnimationStdGUIObject (CGUIObject *pkAnimatedObject, const CGUIEasing::EasingType_t &eEasing, const eC_UInt &uiDuration=1000, const eC_UInt &uiStepTime=25)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)
eC_Value	GetAnimatedObjectNthAttribute (const eC_UInt &uiN) const
CGUIEasing::EasingType_t	GetEasingForNthAttribute (const eC_UInt &uiN) const
eC_Bool	GetEnabledNthAttribute (const eC_UInt &uiN) const
eC_Value	GetStartValueForNthAttribute (const eC_UInt &uiN) const
eC_Value	GetTargetValueForNthAttribute (const eC_UInt &uiN) const
virtual void	ReadFromStream ()
void	SetAnimatedObjectNthAttribute (const eC_UInt &uiN, const eC_Value &vValue)
void	SetEasingForNthAttribute (const eC_UInt &uiN, const CGUIEasing::EasingType_t &eEasingType)
void	SetEnabledNthAttribute (const eC_UInt &uiN, const eC_Bool &bEnabled)
void	SetStartValueForNthAttribute (const eC_UInt &uiN, const eC_Value &vStart)
void	SetStartValues (const CGUIObject *pObj)
void	SetTargetValueForNthAttribute (const eC_UInt &uiN, const eC_Value &vTarget)
void	SetTargetValues (const CGUIObject *pObj)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimation
virtual	~CGUIAnimation ()
void	AddAnimationObserver (CGUIAnimationObserver *pkObserver)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)=0
void	ContinueAnimation ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	GetAnimatedAttributes ()
CGUIObject *	GetAnimatedObject () const
ObjectHandle_t	GetAnimatedObjectID () const
eC_UInt	GetDuration () const
eC_UInt	GetID () const
eC_UInt	GetStepTime () const
virtual void	InitAttributes ()
eC_Bool	IsDeletedAfterFinish () const
eC_Bool	IsPaused () const
void	PauseAnimation ()
void	ReadFromStream ()
void	RemoveAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetAnimatedObject (CGUIObject *pkObject)
void	SetAnimatedObjectID (const ObjectHandle_t &eObject)
void	SetAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetDeletedAfterFinish (const eC_Bool bDeletedAfterFinish)
void	SetDuration (eC_UInt uiDuration)
void	StartAnimation ()
void	StopAnimation ()
void	UpdateAnimatedObjectPointer ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_UInt	STDGUIOBJECT_ANIMATION_CLASS_VERSION
	class-version string
static const eC_String	XMLTAG_ATTRIBUTES []
	attributes-string
Static Public Attributes inherited from CGUIAnimation
static const eC_Char	XMLTAG_ANIMATIONCLASSID []
	XML tag to be used when writing a animation class ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONENDTAG []
	XML tag to be used when finish writing CGUIAnimation information into the stream.
static const eC_Char	XMLTAG_ANIMATIONID []
	XML tag to be used when writing a animation ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONSTARTTAG []
	XML tag to be used when start writing CGUIAnimation information into the stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Additional Inherited Members
Public Types inherited from CGUIAnimation
enum	AnimationStatus_t {   ANIMATION_RUNNING , ANIMATION_PAUSED , ANIMATION_STOPPED , ANIMATION_FINISHED ,   ANIMATION_DELETED }
Protected Member Functions inherited from CGUIAnimation
	CGUIAnimation ()
	CGUIAnimation (CGUIObject *pkAnimatedObject, eC_UInt uiDuration, eC_UInt uiStepTime=25, eC_Bool bDeletedAfterFinish=false)
void	AddAnimatedAttribute (CGUIAnimatedAttribute kAnimatedAttribute)
CGUIAnimatedAttribute &	GetAnimatedAttribute (const eC_UInt &uiAttributeIndex) const
virtual void	OnStatusChanged (AnimationStatus_t eStatus)
void	RemoveAnimatedAttributes ()
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const
Protected Attributes inherited from CGUIAnimation
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	m_pkAnimatedAttributes
	available animated attributes

Detailed Description

Generic animation of a standard object.

This animation animates a standard CGUIObject object through giving access to all important object attributes which are x position, y position, width, height and alpha value. For all of these attributes a separate CGUIEasing functions is used.

This example moves and changes the size of an object using CGUIEasing functions.

// The animation shall be done in 5 seconds.
const eC_UInt cuiDuration = 5000;

// Now create the instance of the animation.
CGUIAnimationStdGUIObject* pAnimation = new CGUIAnimationStdGUIObject(pkAnimatedObject,
CGUIEasing::EASE_LINEAR, CGUIEasing::EASE_LINEAR,
CGUIEasing::EASE_LINEAR, CGUIEasing::EASE_LINEAR,
CGUIEasing::EASE_LINEAR,
cuiDuration);

// To start the animation call the StartAnimation() method of the animation.
pAnimation->StartAnimation();

//If the instance of the animation is not available directly use the AnimationHandler.
eC_UInt uiMyAnimationID = pAnimation->GetID();

GETANIMATIONHDL.GetAnimation(uiMyAnimationID);

Constructor & Destructor Documentation

CGUIAnimationStdGUIObject() [1/2]

CGUIAnimationStdGUIObject::CGUIAnimationStdGUIObject	(	CGUIObject *	pAnimatedObject,
		const CGUIEasing::EasingType_t &	eEasingX,
		const CGUIEasing::EasingType_t &	eEasingY,
		const CGUIEasing::EasingType_t &	eEasingWidth,
		const CGUIEasing::EasingType_t &	eEasingHeight,
		const CGUIEasing::EasingType_t &	eEasingAlpha,
		const eC_UInt &	uiDuration = 1000,
		const eC_UInt &	uiStepTime = 25
	)

Constructor

Parameters

pAnimatedObject	The GUIObject that will be moved.
eEasingX	The easing type that is used for the XPos of the object.
eEasingY	The easing type that is used for the YPos of the object.
eEasingWidth	The easing type that is used for the width of the object.
eEasingHeight	The easing type that is used for the height of the object.
eEasingAlpha	The easing type that is used for the alpha of the object.
uiDuration	The total duration of the animation in milliseconds. Based on the distance the duration determines the animation speed.
uiStepTime	The time between two animation steps in milliseconds.

CGUIAnimationStdGUIObject() [2/2]

CGUIAnimationStdGUIObject::CGUIAnimationStdGUIObject	(	CGUIObject *	pkAnimatedObject,
		const CGUIEasing::EasingType_t &	eEasing,
		const eC_UInt &	uiDuration = 1000,
		const eC_UInt &	uiStepTime = 25
	)

Constructor

Parameters

pkAnimatedObject	The GUIObject that will be moved.
eEasing	The easing type that is used for all attributes.
uiDuration	The total duration of the animation in milliseconds. Based on the distance the duration determines the animation speed.
uiStepTime	The time between two animation steps in milliseconds.

Member Function Documentation

ApplyAnimation()

virtual void CGUIAnimationStdGUIObject::ApplyAnimation ( eC_UInt  uiElapsedTime )

virtual

This function contains the animation logic. It typically accesses the animation's CGUIEasing functions to get the current values and sets these values in the animated object. This function is called by DoAnimate()

Parameters

uiElapsedTime

Time elapsed (in ms) since start of animation.

Implements CGUIAnimation.

GetAnimatedObjectNthAttribute()

eC_Value CGUIAnimationStdGUIObject::GetAnimatedObjectNthAttribute

(

const eC_UInt &

uiN

)

const

Get the nth attribute

Parameters

uiN

index

Returns

attribute

GetEasingForNthAttribute()

CGUIEasing::EasingType_t CGUIAnimationStdGUIObject::GetEasingForNthAttribute

(

const eC_UInt &

uiN

)

const

Get the easing type for the nth attribute

Parameters

uiN

index

Returns

easing type

GetEnabledNthAttribute()

eC_Bool CGUIAnimationStdGUIObject::GetEnabledNthAttribute

(

const eC_UInt &

uiN

)

const

Get the nth attribute enabled

Parameters

uiN

index

Returns

enabled

GetStartValueForNthAttribute()

eC_Value CGUIAnimationStdGUIObject::GetStartValueForNthAttribute

(

const eC_UInt &

uiN

)

const

Get the start value type for the nth attribute

Parameters

uiN

index

Returns

start value

GetTargetValueForNthAttribute()

eC_Value CGUIAnimationStdGUIObject::GetTargetValueForNthAttribute

(

const eC_UInt &

uiN

)

const

Get the target value type for the nth attribute

Parameters

uiN

index

Returns

target value

ReadFromStream()

virtual void CGUIAnimationStdGUIObject::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUIAnimation.

SetAnimatedObjectNthAttribute()

void CGUIAnimationStdGUIObject::SetAnimatedObjectNthAttribute	(	const eC_UInt &	uiN,
		const eC_Value &	vValue
	)

Set the nth attribute

Parameters

uiN	index
vValue	attribute

SetEasingForNthAttribute()

void CGUIAnimationStdGUIObject::SetEasingForNthAttribute	(	const eC_UInt &	uiN,
		const CGUIEasing::EasingType_t &	eEasingType
	)

Set the easing type type for the nth attribute

Parameters

uiN	index
eEasingType	easing type

SetEnabledNthAttribute()

void CGUIAnimationStdGUIObject::SetEnabledNthAttribute	(	const eC_UInt &	uiN,
		const eC_Bool &	bEnabled
	)

Set the nth attribute to enabled

Parameters

uiN	index
bEnabled

SetStartValueForNthAttribute()

void CGUIAnimationStdGUIObject::SetStartValueForNthAttribute	(	const eC_UInt &	uiN,
		const eC_Value &	vStart
	)

Set the start value type for the nth attribute

Parameters

uiN	index
vStart	start value

SetStartValues()

void CGUIAnimationStdGUIObject::SetStartValues

(

const CGUIObject *

pObj

)

Retrieves the start values for this animation from the current status of the supplied GUIObject.

Parameters

pObj	Object whose current attributes will serve as the start values for this animation

SetTargetValueForNthAttribute()

void CGUIAnimationStdGUIObject::SetTargetValueForNthAttribute	(	const eC_UInt &	uiN,
		const eC_Value &	vTarget
	)

Set the start value type for the nth attribute

Parameters

uiN	index
vTarget	target value

SetTargetValues()

void CGUIAnimationStdGUIObject::SetTargetValues

(

const CGUIObject *

pObj

)

Retrieves the target values for this animation from the current status of the supplied GUIObject.

Parameters

pObj	Object whose current attributes will serve as the new target values for this animation

WriteToStream()

virtual void CGUIAnimationStdGUIObject::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIAnimation.

---

The documentation for this class was generated from the following file:

• GUIAnimationStdGUIObject.h
