CGUIQuitCmd Class Reference

Quits the Guiliani application by ending the main loop. More...

#include <GUIQuitCmd.h>

Inheritance diagram for CGUIQuitCmd:

Public Member Functions
virtual void	ReadFromStream ()
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUICommand
void	AddAdditionalCmd (CGUICommandPtr pkCmd, eC_Bool bOneTime=false)
CGUICommandPtr	GetAdditionalCmd (const eC_UInt &uiIndex) const
eC_UInt	GetNumberOfAdditionalCmds () const
eC_UInt	GetPriority () const
eC_UInt	GetTimeUntilNextExecution () const
eC_Bool	IsFinished () const
virtual void	ReadFromStream ()
void	RemoveAdditionalCmd (CGUICommandPtr pkCmd)
void	RemoveAllAdditionalCmds ()
	Removes all additional commands from this command's list.
void	SetPriority (eC_UInt uiPriority)
void	SetTimeUntilNextExecution (eC_UInt uiTime)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from NSmartPtr::RefCounted
	RefCounted ()
	Create RefCounted object. The reference count is initialized to 0.
virtual	~RefCounted ()
	Destroy reference counted object.
void	AddRef ()
	Increase reference count.
eC_Int	RefCount () const
void	Release ()
bool	Unique () const

Protected Member Functions
virtual void	Do ()
Protected Member Functions inherited from CGUICommand
	CGUICommand (const eC_UInt uiPriority=0, const eC_UInt uiTimeUntilFirstExecution=0, const eC_Bool bFinished=true)
virtual	~CGUICommand ()
	Destructor.
virtual void	Do ()=0
void	SetToBeFinished (eC_Bool bIsFinished)
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Additional Inherited Members
Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()
Static Public Attributes inherited from CGUICommand
static const eC_Char	XMLTAG_ADDITIONALCMDCOUNT []
	XML tag to be used when writing the additional command count into a stream.
static const eC_Char	XMLTAG_COMMANDCLASSID []
	XML tag to be used when writing the command class ID into a stream.
static const eC_Char	XMLTAG_REMOVE_AFTER_EXECUTION []
	XML tag to be used when writing the remove after execution flag.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

Quits the Guiliani application by ending the main loop.

This command calls CGUI::Quit.

Member Function Documentation

Do()

virtual void CGUIQuitCmd::Do ( )

protectedvirtual

Action of the command object. Must be implemented in the derived class.

Implements CGUICommand.

ReadFromStream()

virtual void CGUIQuitCmd::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUICommand.

WriteToStream()

virtual void CGUIQuitCmd::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUICommand.

---

The documentation for this class was generated from the following file:

• GUIQuitCmd.h
