Base class for stream writers. More...

#include <GUIStreamWriter.h>

Inheritance diagram for CGUIStreamWriter:

[legend]

Public Member Functions
virtual	~CGUIStreamWriter ()
	Destructor.

FileAlignment_t	GetFileAlignment () const

FileEndianess_t	GetFileEndianess () const

virtual const eC_String &	GetFileSuffix () const

FileType_t	GetFileType () const

virtual eC_Bool	SetFileAlignment (FileAlignment_t eFileAlignment)=0

virtual eC_Bool	SetFileEndianess (FileEndianess_t eFileEndianess)=0

void	SetStreamingFile (eC_File *pkStreamingFile)

virtual void	WriteAnimationChainID (AnimationHandle_t eID, const eC_Char *const pcTag)

void	WriteAnimationToFile (CGUIAnimation *pkAnimation) const

void	WriteBehaviourToFile (CGUIBehaviourDecorator *pkBehaviour) const

virtual void	WriteBinary (const eC_TArray< eC_UByte > &aData, const eC_Char *const pcTag)=0

virtual void	WriteBool (const eC_Bool bBool, const eC_Char *const pcTag)=0

virtual void	WriteByte (const eC_Byte bByte, const eC_Char *const pcTag)=0

virtual void	WriteColor (const ColorValue_t eColor, const eC_Char *const pcTag)=0

void	WriteCommandToFile (CGUICommandPtr pkCommand) const

virtual void	WriteCommentTag (const eC_Char *const pcTag)=0

virtual void	WriteCommentTag (const eC_String &kTag)=0

virtual void	WriteDataPoolID (DataPoolResource_t eID, const eC_Char *const pcTag)

virtual void	WriteFloat (const eC_Float fFloat, const eC_Char *const pcTag)=0

virtual void	WriteFontID (FontResource_t eID, const eC_Char *const pcTag)

virtual void	WriteGeneralResourceID (GeneralResource_t eID, const eC_Char *const pcTag)

virtual void	WriteHex (const eC_UInt uiInt, const eC_Char *const pcTag)=0

virtual void	WriteImageID (ImageResource_t eID, const eC_Char *const pcTag)

virtual void	WriteInt (const eC_Int iInt, const eC_Char *const pcTag)=0

void	WriteLayouterToFile (CGUILayouter *pkLayouter) const

virtual void	WriteObjectID (ObjectHandle_t eID, const eC_Char *const pcTag)

virtual void	WritePropertyID (GlobalProperty_t eID, const eC_Char *const pcTag)

virtual void	WriteShort (const eC_Short iShort, const eC_Char *const pcTag)=0

virtual void	WriteSoundID (SoundResource_t eID, const eC_Char *const pcTag)

virtual void	WriteStreamingFileHeader (const eC_Int iFileVersion)=0

virtual void	WriteString (const eC_String &pkString, const eC_Char *const pcTag)=0

virtual void	WriteTextID (TextResource_t eID, const eC_Char *const pcTag)

void	WriteTextToFile (CGUIText *pText) const

virtual void	WriteUByte (const eC_UByte ubByte, const eC_Char *const pcTag)=0

virtual void	WriteUInt (const eC_UInt uiInt, const eC_Char *const pcTag)=0

virtual void	WriteUShort (const eC_UShort usShort, const eC_Char *const pcTag)=0

virtual void	WriteUUID (UUID_t eID, const eC_Char *const pcTag)

Static Public Member Functions
static void	CreateInstance ()

static void	DeleteInstance ()

static CGUIStreamWriter &	GetInstance ()

Protected Member Functions
	CGUIStreamWriter (FileType_t eFileType, FileEndianess_t eFileEndianess, FileAlignment_t eFileAlignment)

Protected Attributes
FileAlignment_t	m_eFileAlignment
	Alignment of the file.

FileEndianess_t	m_eFileEndianess
	Endianess of the file.

FileType_t	m_eFileType
	File Type.

eC_File *	m_pkStreamingFile
	The file that the content is written into.

Detailed Description

Base class for stream writers.

Stream writers are used to write GUI definitions to files. This abstract base class defines the interfaces for handling streaming files and writing values to them.

Each instance of a stream writer operates on one file at a time. A file can be set by calling SetStreamingFile().

Note: CGUIStreamWriter is NOT responsible for destruction of the streaming file, this should be done by the file creator. Call SetStreamingFile(NULL) after destruction of it, to avoid streaming operations on a non valid file pointer.

After setting a file, the various write methods can be called. Each of them expects a 'tag' which can be a descriptive text string or something else. Implementations can use these tags in whatever way they want. They may choose to ignore the tags.

See also: Streaming

Constructor & Destructor Documentation

◆ CGUIStreamWriter()

CGUIStreamWriter::CGUIStreamWriter	(	FileType_t	eFileType,
		FileEndianess_t	eFileEndianess,
		FileAlignment_t	eFileAlignment
	)

protected

Constructor.

Parameters

eFileType	initial file type
eFileEndianess	initial file endianess
eFileAlignment	initial file alignment

Member Function Documentation

◆ CreateInstance()

static void CGUIStreamWriter::CreateInstance ( )

static

Create Instance

◆ DeleteInstance()

static void CGUIStreamWriter::DeleteInstance ( )

static

Delete Instance

◆ GetFileAlignment()

FileAlignment_t CGUIStreamWriter::GetFileAlignment ( ) const

inline

Gets the alignment of the file

Returns: alignment of the file

◆ GetFileEndianess()

FileEndianess_t CGUIStreamWriter::GetFileEndianess ( ) const

inline

Gets the endianess of the file

Returns: Endianess of the file

◆ GetFileSuffix()

virtual const eC_String & CGUIStreamWriter::GetFileSuffix ( ) const

virtual

Returns the file suffix which is associated with this writer's file format. This can be an empty string, if e.g. the writer works with formats which are unrelated to files.

Returns: String with the associated file suffix (e.g. ".xml")

Reimplemented in CGUIStreamWriterBinary, and CGUIStreamWriterXML.

◆ GetFileType()

FileType_t CGUIStreamWriter::GetFileType ( ) const

inline

Gets the type of the file

Returns: type of the file

◆ GetInstance()

static CGUIStreamWriter & CGUIStreamWriter::GetInstance ( )

static

Returns: Returns instance of current stream stack's top.

◆ SetFileAlignment()

virtual eC_Bool CGUIStreamWriter::SetFileAlignment ( FileAlignment_t eFileAlignment )

pure virtual

Sets the alignment of the streamed file

Parameters

eFileAlignment the desired alignment

Return values

true	operation successful
false	operation not supported

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ SetFileEndianess()

virtual eC_Bool CGUIStreamWriter::SetFileEndianess ( FileEndianess_t eFileEndianess )

pure virtual

Sets the endianess of the streamed file

Parameters

eFileEndianess the desired endianess

Return values

true	operation successful
false	operation not supported

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ SetStreamingFile()

void CGUIStreamWriter::SetStreamingFile ( eC_File * pkStreamingFile )

Sets the streaming file. Always sets the streaming file mode to the set endian

Parameters

pkStreamingFile Subsequent write method calls will write into this file.

◆ WriteAnimationChainID()

virtual void CGUIStreamWriter::WriteAnimationChainID	(	AnimationHandle_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes an animation chain ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The animation ID to be written.
pcTag	Optional descriptive tag.

◆ WriteAnimationToFile()

void CGUIStreamWriter::WriteAnimationToFile ( CGUIAnimation * pkAnimation ) const

Writes an animation object to the streaming file.

Parameters

pkAnimation Pointer to the animation which should be written.

◆ WriteBehaviourToFile()

void CGUIStreamWriter::WriteBehaviourToFile ( CGUIBehaviourDecorator * pkBehaviour ) const

Writes a behaviour object to the streaming file set by WriteDialogToFile().

Parameters

pkBehaviour Pointer to the behaviour which should be written.

◆ WriteBinary()

virtual void CGUIStreamWriter::WriteBinary	(	const eC_TArray< eC_UByte > &	aData,
		const eC_Char *const	pcTag
	)

pure virtual

Write binary stream. Array will be written to stream in raw mode.

Parameters

aData	Array containing data to post
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteBool()

virtual void CGUIStreamWriter::WriteBool	(	const eC_Bool	bBool,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a bool to the streaming file.

Parameters

bBool	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteByte()

virtual void CGUIStreamWriter::WriteByte	(	const eC_Byte	bByte,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a byte to the streaming file.

Parameters

bByte	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteColor()

virtual void CGUIStreamWriter::WriteColor	(	const ColorValue_t	eColor,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a color as a hex value to the streaming file. Same interface as WriteUInt but writers that produce human-readable output may use this method for hex output.

Parameters

eColor	color-value.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteCommandToFile()

void CGUIStreamWriter::WriteCommandToFile ( CGUICommandPtr pkCommand ) const

Writes a command object to the streaming file set by WriteDialogToFile().

Parameters

pkCommand Pointer to the command which should be written.

◆ WriteCommentTag() [1/2]

virtual void CGUIStreamWriter::WriteCommentTag ( const eC_Char *const pcTag )

pure virtual

Writes a single tag without a value.

Parameters

pcTag The tag to be written.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteCommentTag() [2/2]

virtual void CGUIStreamWriter::WriteCommentTag ( const eC_String & kTag )

pure virtual

Writes a single tag without a value.

Parameters

kTag	The tag to be written.

Implemented in CGUIStreamWriterJSON, CGUIStreamWriterXML, and CGUIStreamWriterBinary.

◆ WriteDataPoolID()

virtual void CGUIStreamWriter::WriteDataPoolID	(	DataPoolResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a DataPool ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The DataPool ID to be written.
pcTag	Optional descriptive tag.

◆ WriteFloat()

virtual void CGUIStreamWriter::WriteFloat	(	const eC_Float	fFloat,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a float to the set streaming file.

Parameters

fFloat	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteFontID()

virtual void CGUIStreamWriter::WriteFontID	(	FontResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a font ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The font ID to be written.
pcTag	Optional descriptive tag.

◆ WriteGeneralResourceID()

virtual void CGUIStreamWriter::WriteGeneralResourceID	(	GeneralResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a general resource ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The general resource ID to be written.
pcTag	Optional descriptive tag.

◆ WriteHex()

virtual void CGUIStreamWriter::WriteHex	(	const eC_UInt	uiInt,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a hex value to the streaming file. Same interface as WriteInt but writers that produce human-readable output may use this method for hex output.

Parameters

uiInt	unsigned integer value which should be written as hex.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteImageID()

virtual void CGUIStreamWriter::WriteImageID	(	ImageResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes an image ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The image ID to be written.
pcTag	Optional descriptive tag.

◆ WriteInt()

virtual void CGUIStreamWriter::WriteInt	(	const eC_Int	iInt,
		const eC_Char *const	pcTag
	)

pure virtual

Writes an integer to the streaming file.

Parameters

iInt	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteLayouterToFile()

void CGUIStreamWriter::WriteLayouterToFile ( CGUILayouter * pkLayouter ) const

Writes a layouter object to the streaming file set by WriteDialogToFile().

Parameters

pkLayouter Pointer to the layouter which should be written.

◆ WriteObjectID()

virtual void CGUIStreamWriter::WriteObjectID	(	ObjectHandle_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes an object handle to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The object ID to be written.
pcTag	Optional descriptive tag.

◆ WritePropertyID()

virtual void CGUIStreamWriter::WritePropertyID	(	GlobalProperty_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a Property ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The Property ID to be written.
pcTag	Optional descriptive tag.

◆ WriteShort()

virtual void CGUIStreamWriter::WriteShort	(	const eC_Short	iShort,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a Short to the streaming file.

Parameters

iShort	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterJSON, CGUIStreamWriterXML, and CGUIStreamWriterBinary.

◆ WriteSoundID()

virtual void CGUIStreamWriter::WriteSoundID	(	SoundResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a sound ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The sound ID to be written.
pcTag	Optional descriptive tag.

◆ WriteStreamingFileHeader()

virtual void CGUIStreamWriter::WriteStreamingFileHeader ( const eC_Int iFileVersion )

pure virtual

Writes the file header

Parameters

iFileVersion file version

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteString()

virtual void CGUIStreamWriter::WriteString	(	const eC_String &	pkString,
		const eC_Char *const	pcTag
	)

pure virtual

Writes a string to the set streaming file.

Parameters

pkString	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteTextID()

virtual void CGUIStreamWriter::WriteTextID	(	TextResource_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a text ID to the streaming file. The call is directly forwarded to WriteInt().

Parameters

eID	The text ID to be written.
pcTag	Optional descriptive tag.

◆ WriteTextToFile()

void CGUIStreamWriter::WriteTextToFile ( CGUIText * pText ) const

Writes a text object to the streaming file set by WriteDialogToFile().

Parameters

pText Pointer to the text which should be written.

◆ WriteUByte()

virtual void CGUIStreamWriter::WriteUByte	(	const eC_UByte	ubByte,
		const eC_Char *const	pcTag
	)

pure virtual

Writes an unsigned byte to the streaming file.

Parameters

ubByte	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteUInt()

virtual void CGUIStreamWriter::WriteUInt	(	const eC_UInt	uiInt,
		const eC_Char *const	pcTag
	)

pure virtual

Writes an unsigned integer to the streaming file.

Parameters

uiInt	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteUShort()

virtual void CGUIStreamWriter::WriteUShort	(	const eC_UShort	usShort,
		const eC_Char *const	pcTag
	)

pure virtual

Writes an unsigned short to the streaming file.

Parameters

usShort	Value which should be written.
pcTag	Optional descriptive tag.

Implemented in CGUIStreamWriterBinary, CGUIStreamWriterJSON, and CGUIStreamWriterXML.

◆ WriteUUID()

virtual void CGUIStreamWriter::WriteUUID	(	UUID_t	eID,
		const eC_Char *const	pcTag
	)

inlinevirtual

Writes a UUID to the streaming file.

Parameters

eID	the UUID to be written
pcTag	Optional descriptive tag.

The documentation for this class was generated from the following file:

GUIStreamWriter.h

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ CGUIStreamWriter()

Member Function Documentation

◆ CreateInstance()

◆ DeleteInstance()

◆ GetFileAlignment()

◆ GetFileEndianess()

◆ GetFileSuffix()

◆ GetFileType()

◆ GetInstance()

◆ SetFileAlignment()

◆ SetFileEndianess()

◆ SetStreamingFile()

◆ WriteAnimationChainID()

◆ WriteAnimationToFile()

◆ WriteBehaviourToFile()

◆ WriteBinary()

◆ WriteBool()

◆ WriteByte()

◆ WriteColor()

◆ WriteCommandToFile()

◆ WriteCommentTag() [1/2]

◆ WriteCommentTag() [2/2]

◆ WriteDataPoolID()

◆ WriteFloat()

◆ WriteFontID()

◆ WriteGeneralResourceID()

◆ WriteHex()

◆ WriteImageID()

◆ WriteInt()

◆ WriteLayouterToFile()

◆ WriteObjectID()

◆ WritePropertyID()

◆ WriteShort()

◆ WriteSoundID()

◆ WriteStreamingFileHeader()

◆ WriteString()

◆ WriteTextID()

◆ WriteTextToFile()

◆ WriteUByte()

◆ WriteUInt()

◆ WriteUShort()

◆ WriteUUID()
