An AnimationChain is a combination of several independent animations. More...

#include <GUIAnimationChain.h>

Inheritance diagram for CGUIAnimationChain:

[legend]

Classes
struct	AnimationInfo_t
	Holds the animation id and the offset for each animation. More...

Public Types
enum	AnimationChain_t { PARALLEL_ANIMATION , CHAINED_ANIMATION }
	Defines the chain type. More...

typedef eC_TListDoubleLinked< AnimationInfo_t >	AnimationList_t
	The animation list is a double-linked list of animation info structs.

Public Member Functions
	CGUIAnimationChain ()

	CGUIAnimationChain (const AnimationChain_t eType, const eC_Bool bCyclic=false)

virtual	~CGUIAnimationChain ()
	Destructor.

void	AddAnimation (CGUIAnimation *pkAnimation, eC_UInt uiTimeOffset=0)

void	ContinueAnimation ()

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

const CGUIAnimation *	GetAnimation (eC_UInt uiID)

const AnimationList_t *	GetAnimations ()

AnimationChain_t	GetChainType ()

eC_Bool	GetCyclicAnimation () const

eC_UInt	GetID ()

virtual eC_Bool	IsAnimating () const

eC_Bool	IsPaused () const

void	OnStatusChanged (CGUIAnimation::AnimationStatus_t eStatus, CGUIAnimation *pAnimation)

void	PauseAnimation ()

void	ReadFromStream ()

void	RemoveAllAnimations ()

void	RemoveAnimation (CGUIAnimation *pkAnimation)

void	SetCyclicAnimation (const eC_Bool bCyclicAnimation)

void	StartAnimation ()

void	StopAnimation ()

void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Public Member Functions inherited from CGUIAnimationObserver
virtual	~CGUIAnimationObserver ()

virtual void	OnStatusChanged (CGUIAnimation::AnimationStatus_t eStatus, CGUIAnimation *pAnimation)=0

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_UInt	ANIMATION_CHAIN_CLASS_VERSION
	The class version of the animation chain class.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Friends
class	CGUIAnimationHandler

Additional Inherited Members
Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Detailed Description

An AnimationChain is a combination of several independent animations.

The animations can be started one after the other, or in parallel. For each animation which is added an optional time offset can be defined.

For an AnimationChain which allows parallel animations (AnimationChain_t::PARALLEL_ANIMATION), this offset is relative to the start time of the AnimationChain. For an AnimationChain which does not allow parallel execution(AnimationChain_t::CHAINED_ANIMATION), the time offset is relative to the end of the previous animation.

Each animation which is added to the animation chain will be added to the CGUIAnimationHandler.

Example:

CGUIAnimation* pAnimation;
CGUIAnimationChain* pChain;

pChain = new CGUIAnimationChain(CGUIAnimationChain::CHAINED_ANIMATION);

pAnimation = new CGUIAnimationMove(pkMessageBox, CGUIEasing::EASE_IN_OUT_SINE, CGUIEasing::EASE_IN_OUT_SINE,
GETGUI.GetHalfWidth() - pkMessageBox->GetHalfWidth(),
GETGUI.GetHalfHeight() - pkMessageBox->GetHalfHeight(),
eC_FromInt(0),
eC_FromInt(0), 1000);

pChain->AddAnimation(pAnimation,0);

pAnimation = new CGUIAnimationMove(pkMessageBox, CGUIEasing::EASE_IN_OUT_SINE, CGUIEasing::EASE_NONE,
eC_FromInt(0),
eC_FromInt(0),
GETGUI.GetWidth() - pkMessageBox->GetWidth(),
eC_FromInt(0), 1000);

pChain->AddAnimation(pAnimation,2000);

// Start the animation chain.
pChain->StartAnimation();

Member Enumeration Documentation

◆ AnimationChain_t

enum CGUIAnimationChain::AnimationChain_t

Defines the chain type.

Enumerator
PARALLEL_ANIMATION	Each animation is started based on its offset relative to the start of the animation chain.
CHAINED_ANIMATION	The animations are started one after the other. The offset is used as time between the animations.

Constructor & Destructor Documentation

◆ CGUIAnimationChain() [1/2]

CGUIAnimationChain::CGUIAnimationChain	(	const AnimationChain_t	eType,
		const eC_Bool	bCyclic = `false`
	)

Constructor

Parameters

eType	The type of the animation chain.
bCyclic	Defines if the chain starts at the beginning again, when the last animation is finished.

◆ CGUIAnimationChain() [2/2]

CGUIAnimationChain::CGUIAnimationChain ( )

Default constructor used by the factory.

Member Function Documentation

◆ AddAnimation()

void CGUIAnimationChain::AddAnimation	(	CGUIAnimation *	pkAnimation,
		eC_UInt	uiTimeOffset = `0`
	)

Add an animation. The animation is owned and handled by the AnimationChain.

Parameters

pkAnimation	The animation to add.
uiTimeOffset	The offset relative to the previous animation in case of CHAINED_ANIMATION or relative to the animation start in case of PARALLEL_ANIMATION.

◆ ContinueAnimation()

void CGUIAnimationChain::ContinueAnimation ( )

Continue the execution of the animation chain. The timer callback will be restored (installed again).

◆ DoAnimate()

virtual void CGUIAnimationChain::DoAnimate ( const eC_Value & vTimes = eC_FromInt(1) )

virtual

Timer callback for the animation chain which is used to handle the animation offsets.

Parameters

vTimes Ignored by base class, used by implemented animation to compensate for jitter

Reimplemented from CGUIAnimatable.

◆ GetAnimation()

const CGUIAnimation * CGUIAnimationChain::GetAnimation ( eC_UInt uiID )

Parameters

uiID	The animation ID

Returns: The animation with the ID "uiID" if part of the animation chain else NULL

◆ GetAnimations()

const AnimationList_t * CGUIAnimationChain::GetAnimations ( )

inline

Returns: The list of animations which are part of the chain.

◆ GetChainType()

AnimationChain_t CGUIAnimationChain::GetChainType ( )

inline

Returns: The type of the animation chain.

◆ GetCyclicAnimation()

eC_Bool CGUIAnimationChain::GetCyclicAnimation ( ) const

inline

Returns: True if cyclic animation is activated, else False.

◆ GetID()

eC_UInt CGUIAnimationChain::GetID ( )

inline

Returns: The unique id of the animation chain.

◆ IsAnimating()

virtual eC_Bool CGUIAnimationChain::IsAnimating ( ) const

virtual

Checks if the animation chain is currently animating.

Returns: True if an animation callback is registered, otherwise False.

Reimplemented from CGUIAnimatable.

◆ IsPaused()

eC_Bool CGUIAnimationChain::IsPaused ( ) const

Checks if the animation chain is currently paused.

Returns: True if an animation chain is currently paused

◆ OnStatusChanged()

void CGUIAnimationChain::OnStatusChanged	(	CGUIAnimation::AnimationStatus_t	eStatus,
		CGUIAnimation *	pAnimation
	)

virtual

Called by the animations when they are finished or deleted. This is used for chained animations.

Parameters

eStatus	The new status of the animation.
pAnimation	The Animation whose status is updated.

Implements CGUIAnimationObserver.

◆ PauseAnimation()

void CGUIAnimationChain::PauseAnimation ( )

Pause the execution of an animation chain. This includes pausing of the gaps (time offset) between animations. The timer callback will be removed.

◆ ReadFromStream()

void CGUIAnimationChain::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also: CGUIObject::ReadFromStream()

Reimplemented from CGUIStreamableObject.

◆ RemoveAllAnimations()

void CGUIAnimationChain::RemoveAllAnimations ( )

Remove all contained animations. This only clears the internal list. It does NOT delete any animation!

◆ RemoveAnimation()

void CGUIAnimationChain::RemoveAnimation ( CGUIAnimation * pkAnimation )

Remove an animation. This only removes the animation from internal list. It does NOT delete the animation!

Parameters

pkAnimation The animation to remove.

◆ SetCyclicAnimation()

void CGUIAnimationChain::SetCyclicAnimation ( const eC_Bool bCyclicAnimation )

inline

Activate or deactivate cyclic animation. The chain will restart at the beginning after the last animation finished, if cyclic animation is activated.

Parameters

bCyclicAnimation True to activate cyclic animation, false to deactivate.

◆ StartAnimation()

void CGUIAnimationChain::StartAnimation ( )

virtual

Start the animation chain. All contained animations will be triggered based on their offsets and on the order in which they were added (only for CHAINED_ANIMATION).

Reimplemented from CGUIAnimatable.

◆ StopAnimation()

void CGUIAnimationChain::StopAnimation ( )

virtual

Stops all animations which are part of this chain.

Reimplemented from CGUIAnimatable.

◆ WriteToStream()

void CGUIAnimationChain::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIStreamableObject.

Friends And Related Function Documentation

◆ CGUIAnimationHandler

friend class CGUIAnimationHandler

friend

The documentation for this class was generated from the following file:

GUIAnimationChain.h
