CGUIAnimationMove Class Reference

This animation translates a CGUIObject from a start position to a target position. More...

#include <GUIAnimationMove.h>

Inheritance diagram for CGUIAnimationMove:

Public Member Functions
	CGUIAnimationMove ()
	CGUIAnimationMove (CGUIObject *pAnimatedObject, CGUIEasing::EasingType_t eEasingX, CGUIEasing::EasingType_t eEasingY, eC_Value vStartX, eC_Value vStartY, eC_Value vTargetX, eC_Value vTargetY, eC_UInt uiDuration, eC_Bool bUseCurrentPosition=false, eC_UInt uiStepTime=25)
void	ApplyAnimation (eC_UInt uiElapsedTime)
void	InitAttributes ()
void	ReadFromStream ()
void	SetStartPos (const eC_Value vStartX, const eC_Value vStartY)
void	SetTargetPos (const eC_Value vTargetX, const eC_Value vTargetY)
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimation
virtual	~CGUIAnimation ()
void	AddAnimationObserver (CGUIAnimationObserver *pkObserver)
virtual void	ApplyAnimation (eC_UInt uiElapsedTime)=0
void	ContinueAnimation ()
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	GetAnimatedAttributes ()
CGUIObject *	GetAnimatedObject () const
ObjectHandle_t	GetAnimatedObjectID () const
eC_UInt	GetDuration () const
eC_UInt	GetID () const
eC_UInt	GetStepTime () const
virtual void	InitAttributes ()
eC_Bool	IsDeletedAfterFinish () const
eC_Bool	IsPaused () const
void	PauseAnimation ()
void	ReadFromStream ()
void	RemoveAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetAnimatedObject (CGUIObject *pkObject)
void	SetAnimatedObjectID (const ObjectHandle_t &eObject)
void	SetAnimationObserver (CGUIAnimationObserver *pkObserver)
void	SetDeletedAfterFinish (const eC_Bool bDeletedAfterFinish)
void	SetDuration (eC_UInt uiDuration)
void	StartAnimation ()
void	StopAnimation ()
void	UpdateAnimatedObjectPointer ()
void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))
virtual eC_Bool	IsAnimating () const
virtual void	StartAnimation ()
virtual void	StopAnimation ()
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes
static const eC_UInt	MOVE_ANIMATION_CLASS_MIN_VERSION
	The minimal class version allowed.
static const eC_UInt	MOVE_ANIMATION_CLASS_VERSION
	The class version of the implementation.
Static Public Attributes inherited from CGUIAnimation
static const eC_Char	XMLTAG_ANIMATIONCLASSID []
	XML tag to be used when writing a animation class ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONENDTAG []
	XML tag to be used when finish writing CGUIAnimation information into the stream.
static const eC_Char	XMLTAG_ANIMATIONID []
	XML tag to be used when writing a animation ID into a stream.
static const eC_Char	XMLTAG_ANIMATIONSTARTTAG []
	XML tag to be used when start writing CGUIAnimation information into the stream.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Additional Inherited Members
Public Types inherited from CGUIAnimation
enum	AnimationStatus_t {   ANIMATION_RUNNING , ANIMATION_PAUSED , ANIMATION_STOPPED , ANIMATION_FINISHED ,   ANIMATION_DELETED }
Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()
Protected Member Functions inherited from CGUIAnimation
	CGUIAnimation ()
	CGUIAnimation (CGUIObject *pkAnimatedObject, eC_UInt uiDuration, eC_UInt uiStepTime=25, eC_Bool bDeletedAfterFinish=false)
void	AddAnimatedAttribute (CGUIAnimatedAttribute kAnimatedAttribute)
CGUIAnimatedAttribute &	GetAnimatedAttribute (const eC_UInt &uiAttributeIndex) const
virtual void	OnStatusChanged (AnimationStatus_t eStatus)
void	RemoveAnimatedAttributes ()
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const
Protected Attributes inherited from CGUIAnimation
eC_TListDoubleLinked< CGUIAnimatedAttribute > *	m_pkAnimatedAttributes
	available animated attributes

Detailed Description

This animation translates a CGUIObject from a start position to a target position.

The duration for the animation determines the animation's speed.

The animation is achieved by interpolating between the start position and the target position. For the interpolation CGUIEasing functions are used. The CGUIEasing functions are passed in the constructor.

Example:

// The animation shall be done in 5 seconds.
const eC_Value vStartX = eC_FromInt(100);
const eC_Value vStartY = eC_FromInt(100);
const eC_Value vTargetX = eC_FromInt(200);
const eC_Value vTargetY = eC_FromInt(200);
const eC_UInt uiDuration = 5000;

// Now create the instance of the animation.
CGUIAnimationMove* pAnimation = new CGUIAnimationMove(
    pkAnimatedObject, CGUIEasing::EASE_LINEAR, CGUIEasing::EASE_LINEAR,
    vStartX, vStartY, vTargetX, vTargetY, uiDuration);

// To start the animation call the StartAnimation() method of the animation.
pAnimation->StartAnimation();

//If the instance of the animation is not available directly use the AnimationHandler.
eC_UInt uiMyAnimationID = pAnimation->GetID();

GETANIMATIONHDL.GetAnimation(uiMyAnimationID);

Constructor & Destructor Documentation

CGUIAnimationMove() [1/2]

CGUIAnimationMove::CGUIAnimationMove	(	CGUIObject *	pAnimatedObject,
		CGUIEasing::EasingType_t	eEasingX,
		CGUIEasing::EasingType_t	eEasingY,
		eC_Value	vStartX,
		eC_Value	vStartY,
		eC_Value	vTargetX,
		eC_Value	vTargetY,
		eC_UInt	uiDuration,
		eC_Bool	bUseCurrentPosition = false,
		eC_UInt	uiStepTime = 25
	)

Constructor

Parameters

pAnimatedObject	The Object that shall be moved.
eEasingX	The easing type that is used for the XPos of the object.
eEasingY	The easing type that is used for the YPos of the object.
vStartX	X-position at start of animation.
vStartY	Y-position at start of animation.
vTargetX	Target X-position of animation.
vTargetY	Target Y-position of animation.
uiDuration	The duration for the complete animation in ms.
bUseCurrentPosition	If set to true the start position of the animation will be set to the current position of the animated object.
uiStepTime	The time between two animation steps in ms.

CGUIAnimationMove() [2/2]

CGUIAnimationMove::CGUIAnimationMove

(

)

Default constructor for streaming.

Member Function Documentation

ApplyAnimation()

void CGUIAnimationMove::ApplyAnimation ( eC_UInt  uiElapsedTime )

virtual

This function contains the animation logic. It typically accesses the animation's CGUIEasing functions to get the current values and sets these values in the animated object. This function is called by DoAnimate()

Parameters

uiElapsedTime

Time elapsed (in ms) since start of animation.

Implements CGUIAnimation.

InitAttributes()

void CGUIAnimationMove::InitAttributes ( )

virtual

Sets the animated object to the start position.

Reimplemented from CGUIAnimation.

ReadFromStream()

void CGUIAnimationMove::ReadFromStream ( )

virtual

Reads attributes from the streaming file. Only for use with GUIFactoryManager.

See also

CGUIObject::ReadFromStream()

Reimplemented from CGUIAnimation.

SetStartPos()

void CGUIAnimationMove::SetStartPos	(	const eC_Value	vStartX,
		const eC_Value	vStartY
	)

Set the start position of the move animation.

Parameters

vStartX	X coordinate of the starting point of the animation.
vStartY	Y coordinate of the starting point of the animation.

SetTargetPos()

void CGUIAnimationMove::SetTargetPos	(	const eC_Value	vTargetX,
		const eC_Value	vTargetY
	)

Set the target position of the move animation.

Parameters

vTargetX	X coordinate of the target point of the animation.
vTargetY	Y coordinate of the target point of the animation.

WriteToStream()

void CGUIAnimationMove::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes attributes to the streaming file. A CGUIStreamWriter has to be initialized.

Parameters

bWriteClassID

This flag is used to switch writing of the class ID, leading and trailing tags. When implementing a new streamable object, check this flag. If it is true, first write the class ID, then continue with this object's attributes, and finally call the base class implementation with this flag set to false (this is the default).

Reimplemented from CGUIAnimation.

---

The documentation for this class was generated from the following file:

• GUIAnimationMove.h
