Base class for stream readers. More...

#include <GUIStreamReader.h>

Inheritance diagram for CGUIStreamReader:

Public Member Functions
virtual	~CGUIStreamReader ()

virtual CGUIStreamReader *	Clone () const =0

virtual void	DeleteCommentTag (const eC_Char *pcTag=NULL)=0

virtual void	DeleteCommentTag (const eC_String &kTag)=0

eC_UInt	GetCurLine () const

FileAlignment_t	GetFileAlignment () const

FileEndianess_t	GetFileEndianess () const

virtual const eC_String &	GetFileSuffix () const

FileType_t	GetFileType () const

eC_String	GetLastReadTag () const

virtual AnimationHandle_t	ReadAnimationChainID (const eC_Char *pcTag=NULL)

virtual void	ReadBinary (eC_TArray< eC_UByte > &aData, const eC_Char *pcTag=NULL)=0

virtual eC_Bool	ReadBool (const eC_Char *pcTag=NULL)=0

virtual eC_Byte	ReadByte (const eC_Char *pcTag=NULL)=0

virtual ColorValue_t	ReadColor (const eC_Char *pcTag=NULL)=0

virtual DataPoolResource_t	ReadDataPoolID (const eC_Char *pcTag=NULL)

virtual eC_Float	ReadFloat (const eC_Char *pcTag=NULL)=0

virtual FontResource_t	ReadFontID (const eC_Char *pcTag=NULL)

virtual GeneralResource_t	ReadGeneralResourceID (const eC_Char *pcTag=NULL)

virtual eC_UInt	ReadHex (const eC_Char *pcTag=NULL)=0

virtual ImageResource_t	ReadImageID (const eC_Char *pcTag=NULL)

virtual eC_Int	ReadInt (const eC_Char *pcTag=NULL)=0

virtual ObjectHandle_t	ReadObjectID (const eC_Char *pcTag=NULL)

virtual GlobalProperty_t	ReadPropertyID (const eC_Char *pcTag=NULL)

virtual eC_Short	ReadShort (const eC_Char *pcTag=NULL)=0

virtual SoundResource_t	ReadSoundID (const eC_Char *pcTag=NULL)

virtual eC_Int	ReadStreamingFileHeader ()=0

virtual eC_String	ReadString (const eC_Char *pcTag=NULL)=0

virtual TextResource_t	ReadTextID (const eC_Char *pcTag=NULL)

virtual eC_UByte	ReadUByte (const eC_Char *pcTag=NULL)=0

virtual eC_UInt	ReadUInt (const eC_Char *pcTag=NULL)=0

virtual eC_UShort	ReadUShort (const eC_Char *pcTag=NULL)=0

void	ResetStreamingFile ()

void	SetStreamingFile (eC_File *pkStreamingFile)

Static Public Member Functions
static void	CreateInstance ()

static void	DeleteInstance ()

static CGUIStreamReader &	GetInstance ()

Protected Member Functions
	CGUIStreamReader (FileType_t eFileType, FileEndianess_t eFileEndianess, FileAlignment_t eFileAlignment)

void	ResizeReadBuffer (eC_Bool bReset)

Protected Attributes
eC_TArray< eC_Char >	m_aReadBuffer
	Dynamic array to hold currently read tag content.

FileAlignment_t	m_eFileAlignment
	Alignment of the file.

FileEndianess_t	m_eFileEndianess
	Endianess of the file.

FileType_t	m_eFileType
	File Type.

eC_String	m_kLastReadTag
	Last tag which was read, used to skip to the end of an corrupted object.

eC_File *	m_pkCurrentInputFile
	Pointer to the current streaming file. All reading operations will be performed on this file.

eC_UInt	m_uiCurLine
	Line number in current streaming file.

Detailed Description

Base class for stream readers.

Stream readers are used to read GUI definitions from files. This abstract base class defines the interfaces for handling streaming files and reading values from them.

Each instance of a stream reader operates on one file at a time. A file can be set by calling SetStreamingFile().

Note: CGUIStreamReader is NOT responsible for destruction of the streaming file, this should be done by the file creator. Call ResetStreamingFile() after destruction of it, to avoid streaming operations on a non valid file pointer.

After setting a file, the various read methods can be called. Each of them expects a 'tag' which can be a descriptive text string or something else. Implementations can use these tags in whatever way they want, for instance for error checking. They may also choose to ignore the tags. However, a CGUIStreamReader implementation in general is expected to be able to read what its counterpart CGUIStreamWriter implementation wrote. Each of the methods returns the value read from the file.

The stream reader offers the method GetCurLine() which returns an internal line number. Implementations are expected to increase the counter in a meaningful way that allows for printing debug messages that point users to errors in their streaming files.

Additionally the StreamReader can return the last read tag which can be used to e.g. check for corrupted elements and skip until the end of these.

For each of the Read... methods declared in this class there is an additional macro, for instance READ_INT for the method ReadInt(). Streaming code should use these macros instead of direct method calls.

See also: Streaming

Constructor & Destructor Documentation

◆ ~CGUIStreamReader()

virtual CGUIStreamReader::~CGUIStreamReader ( )

virtual

Destructor.

Removes this object from stream reader stack.

◆ CGUIStreamReader()

CGUIStreamReader::CGUIStreamReader	(	FileType_t	eFileType,
		FileEndianess_t	eFileEndianess,
		FileAlignment_t	eFileAlignment
	)

protected

Constructs a stream reader. Initially, no file is set. The line number is initialized to 1. This reader will be pushed on top of the reader stack.

Parameters

eFileType	initial file type
eFileEndianess	initial file endianess
eFileAlignment	initial file alignment

Member Function Documentation

◆ Clone()

virtual CGUIStreamReader * CGUIStreamReader::Clone ( ) const

pure virtual

Returns: Clone this StreamReader. Caller is responsible for deleting the allocated instance.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ CreateInstance()

static void CGUIStreamReader::CreateInstance ( )

static

Create Instance

◆ DeleteCommentTag() [1/2]

virtual void CGUIStreamReader::DeleteCommentTag ( const eC_Char * pcTag = NULL )

pure virtual

Reads over (removes) a tag from the current streaming file without reading a value.

Parameters

pcTag Optional descriptive tag.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ DeleteCommentTag() [2/2]

virtual void CGUIStreamReader::DeleteCommentTag ( const eC_String & kTag )

pure virtual

Reads over (removes) a tag from the current streaming file without reading a value.

Parameters

kTag	descriptive tag.

Implemented in CGUIStreamReaderXML, and CGUIStreamReaderBinary.

◆ DeleteInstance()

static void CGUIStreamReader::DeleteInstance ( )

static

Delete Instance

◆ GetCurLine()

eC_UInt CGUIStreamReader::GetCurLine ( ) const

inline

Returns the current line in the streaming file.

Returns: The line number in the current streaming file.

◆ GetFileAlignment()

FileAlignment_t CGUIStreamReader::GetFileAlignment ( ) const

inline

Gets the alignment of the file

Returns: alignment of the file

◆ GetFileEndianess()

FileEndianess_t CGUIStreamReader::GetFileEndianess ( ) const

inline

Gets the endianess of the file

Returns: Endianess of the file

◆ GetFileSuffix()

virtual const eC_String & CGUIStreamReader::GetFileSuffix ( ) const

virtual

Returns the file suffix which is associated with this reader's file format. This can be an empty string, if e.g. the reader works with formats which are unrelated to files.

Returns: String with the associated file suffix (e.g. ".xml")

Reimplemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ GetFileType()

FileType_t CGUIStreamReader::GetFileType ( ) const

inline

Gets the type of the file

Returns: type of the file

◆ GetInstance()

static CGUIStreamReader & CGUIStreamReader::GetInstance ( )

static

Returns: Returns instance of current stream stack's top.

◆ GetLastReadTag()

eC_String CGUIStreamReader::GetLastReadTag ( ) const

inline

Gets the last read Tag

Returns: last read tag

◆ ReadAnimationChainID()

virtual AnimationHandle_t CGUIStreamReader::ReadAnimationChainID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads an animation chain handle from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The object handle read from the file.

◆ ReadBinary()

virtual void CGUIStreamReader::ReadBinary	(	eC_TArray< eC_UByte > &	aData,
		const eC_Char *	pcTag = `NULL`
	)

pure virtual

Reads binary stream. Array will be retrieved from stream in raw mode.

Parameters

	pcTag	Optional descriptive tag.
[out]	aData	Array the read data will be set to.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadBool()

virtual eC_Bool CGUIStreamReader::ReadBool ( const eC_Char * pcTag = NULL )

pure virtual

Reads a boolean value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadByte()

virtual eC_Byte CGUIStreamReader::ReadByte ( const eC_Char * pcTag = NULL )

pure virtual

Reads a signed byte value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadColor()

virtual ColorValue_t CGUIStreamReader::ReadColor ( const eC_Char * pcTag = NULL )

pure virtual

Reads a color from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadDataPoolID()

virtual DataPoolResource_t CGUIStreamReader::ReadDataPoolID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a DataPool ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The DataPool ID read from the file.

◆ ReadFloat()

virtual eC_Float CGUIStreamReader::ReadFloat ( const eC_Char * pcTag = NULL )

pure virtual

Reads a float value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadFontID()

virtual FontResource_t CGUIStreamReader::ReadFontID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a font ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The font ID read from the file.

◆ ReadGeneralResourceID()

virtual GeneralResource_t CGUIStreamReader::ReadGeneralResourceID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a general resource ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The general resource ID read from the file.

◆ ReadHex()

virtual eC_UInt CGUIStreamReader::ReadHex ( const eC_Char * pcTag = NULL )

pure virtual

Reads a hexadecimal integer value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadImageID()

virtual ImageResource_t CGUIStreamReader::ReadImageID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads an image ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The image ID read from the file.

◆ ReadInt()

virtual eC_Int CGUIStreamReader::ReadInt ( const eC_Char * pcTag = NULL )

pure virtual

Reads a signed integer value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadObjectID()

virtual ObjectHandle_t CGUIStreamReader::ReadObjectID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads an object handle from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The object handle read from the file.

◆ ReadPropertyID()

virtual GlobalProperty_t CGUIStreamReader::ReadPropertyID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a Property ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The Property ID read from the file.

◆ ReadShort()

virtual eC_Short CGUIStreamReader::ReadShort ( const eC_Char * pcTag = NULL )

pure virtual

Reads a short value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadSoundID()

virtual SoundResource_t CGUIStreamReader::ReadSoundID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a sound ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The sound ID read from the file.

◆ ReadStreamingFileHeader()

virtual eC_Int CGUIStreamReader::ReadStreamingFileHeader ( )

pure virtual

Reads the file header of a streaming file

Returns: version of the file

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadString()

virtual eC_String CGUIStreamReader::ReadString ( const eC_Char * pcTag = NULL )

pure virtual

Reads a string from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The string that has been read.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadTextID()

virtual TextResource_t CGUIStreamReader::ReadTextID ( const eC_Char * pcTag = NULL )

inlinevirtual

Reads a text ID from the current streaming file. The call is directly forwarded to ReadInt().

Parameters

pcTag Optional descriptive tag.

Returns: The text ID read from the file.

◆ ReadUByte()

virtual eC_UByte CGUIStreamReader::ReadUByte ( const eC_Char * pcTag = NULL )

pure virtual

Reads an unsigned byte value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadUInt()

virtual eC_UInt CGUIStreamReader::ReadUInt ( const eC_Char * pcTag = NULL )

pure virtual

Reads an unsigned integer value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ReadUShort()

virtual eC_UShort CGUIStreamReader::ReadUShort ( const eC_Char * pcTag = NULL )

pure virtual

Reads an unsigned short value from the current streaming file.

Parameters

pcTag Optional descriptive tag.

Returns: The value read from the file.

Implemented in CGUIStreamReaderBinary, and CGUIStreamReaderXML.

◆ ResetStreamingFile()

void CGUIStreamReader::ResetStreamingFile ( )

Removes the streaming file. This method must be called whenever a file is no longer used and is closed by another instance. This method resets the line number and the internal pointer, ensuring that further read operations do not use invalid file pointers.

◆ ResizeReadBuffer()

void CGUIStreamReader::ResizeReadBuffer ( eC_Bool bReset )

protected

The local read buffer will be resized by power-of-2 or reset to initial size of 128 Bytes.

Parameters

bReset Set this flag true initializes a new, empty buffer with initial size. False increments the current array size and preserves content.

◆ SetStreamingFile()

void CGUIStreamReader::SetStreamingFile ( eC_File * pkStreamingFile )

Sets the file to read from. When the file is no longer needed, call ResetStreamingFile(). Always sets the streaming file mode to eC_File::FS_BIGENDIAN.

Parameters

pkStreamingFile The streaming file. Subsequent read method calls operate on this file.

The documentation for this class was generated from the following file:

GUIStreamReader.h

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ ~CGUIStreamReader()

◆ CGUIStreamReader()

Member Function Documentation

◆ Clone()

◆ CreateInstance()

◆ DeleteCommentTag() [1/2]

◆ DeleteCommentTag() [2/2]

◆ DeleteInstance()

◆ GetCurLine()

◆ GetFileAlignment()

◆ GetFileEndianess()

◆ GetFileSuffix()

◆ GetFileType()

◆ GetInstance()

◆ GetLastReadTag()

◆ ReadAnimationChainID()

◆ ReadBinary()

◆ ReadBool()

◆ ReadByte()

◆ ReadColor()

◆ ReadDataPoolID()

◆ ReadFloat()

◆ ReadFontID()

◆ ReadGeneralResourceID()

◆ ReadHex()

◆ ReadImageID()

◆ ReadInt()

◆ ReadObjectID()

◆ ReadPropertyID()

◆ ReadShort()

◆ ReadSoundID()

◆ ReadStreamingFileHeader()

◆ ReadString()

◆ ReadTextID()

◆ ReadUByte()

◆ ReadUInt()

◆ ReadUShort()

◆ ResetStreamingFile()

◆ ResizeReadBuffer()

◆ SetStreamingFile()
