#include <GUICmdBehaviour.h>

Inheritance diagram for CGUICmdBehaviour:

[legend]

Protected Member Functions
	CGUICmdBehaviour ()

virtual	~CGUICmdBehaviour ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyID, const eC_UInt &uiModifiers)

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX, const eC_Value &vDeltaY, const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyID, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyID, const eC_UInt &uiModifiers)

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual void	ExecuteCommand (const BehaviourType_t &eFromBehaviour)=0
	Executes the command for the given behaviour, if it is equal to the stored one. More...

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual void	GetFocus ()

virtual eC_Bool	Increase ()

virtual void	LoseFocus ()

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

Protected Member Functions inherited from CGUIBehaviourDecorator
	CGUIBehaviourDecorator (CGUIObject *const pkObject=NULL)

	CGUIBehaviourDecorator (const CGUIBehaviourDecorator &kSource)

virtual void	AssociatedObjectChanges (CGUIObject *const pkNewAssociatedObject)

CGUIObject *	GetAssociatedObject () const

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Additional Inherited Members
Public Member Functions inherited from CGUIBehaviourDecorator
virtual	~CGUIBehaviourDecorator ()

virtual CGUIBehaviourDecorator *	Clone () const

virtual eC_Bool	IsCompositeBehaviour () const

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

Base class which Associates a command with one event slot. The event will be forwarded to the associated object.

See also: CGUICmdBehaviour, CGUIMultiCmdBehaviour

Constructor & Destructor Documentation

◆ CGUICmdBehaviour()

CGUICmdBehaviour::CGUICmdBehaviour ( )

inlineprotected

Constructor.

◆ ~CGUICmdBehaviour()

virtual CGUICmdBehaviour::~CGUICmdBehaviour ( )

inlineprotectedvirtual

Destructor.

Member Function Documentation

◆ Decrease()

virtual eC_Bool CGUICmdBehaviour::Decrease ( )

protectedvirtual

Called when the object receives a standard GK_PAGEDOWN event. For a simple object there is nothing to do but to indicate that the event has not been handled. For a standardized event handling mechanism, this method must exist.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoButtonDown()

virtual eC_Bool CGUICmdBehaviour::DoButtonDown	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse button or finger is pressed down over an object.

Note: DoButtonDown() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the object was pressed relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoButtonUp()

virtual eC_Bool CGUICmdBehaviour::DoButtonUp	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse button or finger is released. The object under the mouse at the time of releasing will receive this event.

Note: DoButtonUp() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the button was released relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the mouse was released.
vAbsY	Y-position in screen coordinates where the mouse was released.

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoChar()

virtual eC_Bool CGUICmdBehaviour::DoChar	(	const eC_UInt &	uiKey,
		const GUIKeyIdentifier_t &	eKeyIdentifier,
		const eC_UInt &	uiModifiers
	)

protectedvirtual

Called in reaction to a ET_CHAR event, which means in general that a character key was pressed. In this slot you will get the character with the Guiliani key identifier and modifiers. In most cases the Guiliani key identifier will be GK_NONE. But there are some special cases (e.g. Smartphones) for which it makes sense to send a Guiliani-Key identifier (GK_INTERMIT) even if a character key was pressed.

Parameters

uiKey	Character of the pressed key.
eKeyIdentifier	The Guiliani key identifier.
uiModifiers	The key modifiers bitfield.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoClick()

virtual eC_Bool CGUICmdBehaviour::DoClick	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

protectedvirtual

Called when the object receives a click event. A click can e.g., be the result of a mouse click, a finger press/release sequence on touchscreens, or be triggered by a GK_ACTION keyboard event.

Note: DoClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and released at the same position for in a certain time span, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoDoubleClick()

virtual eC_Bool CGUICmdBehaviour::DoDoubleClick	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

protectedvirtual

Called when an object is clicked twice within a given time span.

See also: CGUIEventHandler::SetDoubleClickTime()

Note: DoDoubleClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the two clicks were done relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoDrag()

virtual eC_Bool CGUICmdBehaviour::DoDrag	(	const eC_Value &	vDeltaX,
		const eC_Value &	vDeltaY,
		const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the object receives a Drag event. Drags are typically created if the mouse is being used while a mouse-button is being pressed, or if the user moves his finger over a touchscreen.

Parameters

vDeltaX	relative movement in x-direction since the last call of DoDrag/ButtonDown
vDeltaY	relative movement in y-direction since the last call of DoDrag/ButtonDown
vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoDragEnd()

virtual eC_Bool CGUICmdBehaviour::DoDragEnd	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called on the dragged object (=the object on which the initial ButtonDown-event occurred) when the mouse button is released after a drag event.

Parameters

vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoKeyDown()

virtual eC_Bool CGUICmdBehaviour::DoKeyDown	(	const GUIKeyIdentifier_t &	eKeyIdentifier,
		const eC_UInt &	uiModifiers
	)

protectedvirtual

Called in reaction to a ET_KEYDOWN event, which means in general that a non-character key was pressed. For that reason you will only get the Guiliani-Key identifier (possibly with modifiers) in this slot and not the character of the pressed key.

Parameters

eKeyIdentifier	The Guiliani key identifier.
uiModifiers	The key modifiers bitfield.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoKeyUp()

virtual eC_Bool CGUICmdBehaviour::DoKeyUp	(	const GUIKeyIdentifier_t &	eKeyIdentifier,
		const eC_UInt &	uiModifiers
	)

protectedvirtual

Called in reaction to a ET_KEYUP event, which means in general that a non-character key was released. For that reason you will only get the Guiliani key identifier (possibly with modifiers) in this slot and not the character of the released key.

Parameters

eKeyIdentifier	The Guiliani key identifier.
uiModifiers	The key modifiers bitfield.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoLongClick()

virtual eC_Bool CGUICmdBehaviour::DoLongClick	(	const eC_Value &	vAbsX = `eC_FromInt(-1)`,
		const eC_Value &	vAbsY = `eC_FromInt(-1)`
	)

protectedvirtual

Called when an object is pressed for a longer period of time.

See also: CGUIEventHandler::SetLongClickTime()

Note: DoLongClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and held down at the same position for a certain amount of time, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoMouseEnter()

virtual eC_Bool CGUICmdBehaviour::DoMouseEnter	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse enters the area which is covered by an object. If several objects cover the same region, the topmost one receives the event. Objects will not receive DoMouseEnter events if they are not highlightable.

See also: CGUIObject::IsHighlightable()

Parameters

vAbsX	X-position in screen coordinates where the mouse entered the object
vAbsY	Y-position in screen coordinates where the mouse entered the object

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoMouseLeave()

virtual eC_Bool CGUICmdBehaviour::DoMouseLeave	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse leaves the area which is covered by an object. Objects will not receive DoMouseLeave events if they are not highlightable.

See also: CGUIObject::IsHighlightable()

Parameters

vAbsX	X-position of the mouse in screen coordinates after it left the object
vAbsY	Y-position of the mouse in screen coordinates after it left the object

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoScrollDown()

virtual eC_Bool CGUICmdBehaviour::DoScrollDown	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse wheel was scrolled in downward direction.

Parameters

vAbsX	X-position of the mouse in screen coordinates
vAbsY	Y-position of the mouse in screen coordinates

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoScrollLeft()

virtual eC_Bool CGUICmdBehaviour::DoScrollLeft	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse wheel was scrolled in upward direction while the scroll direction modifier was pressed.

Parameters

vAbsX	X-position of the mouse in screen coordinates
vAbsY	Y-position of the mouse in screen coordinates

See also: CGUIEventHandler::SetScrollModifiers()

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoScrollRight()

virtual eC_Bool CGUICmdBehaviour::DoScrollRight	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse wheel was scrolled in downward direction while the scroll direction modifier was pressed.

Parameters

vAbsX	X-position of the mouse in screen coordinates
vAbsY	Y-position of the mouse in screen coordinates

See also: CGUIEventHandler::SetScrollModifiers()

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoScrollUp()

virtual eC_Bool CGUICmdBehaviour::DoScrollUp	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse wheel was scrolled in upward direction.

Parameters

vAbsX	X-position of the mouse in screen coordinates
vAbsY	Y-position of the mouse in screen coordinates

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ ExecuteCommand()

virtual void CGUICmdBehaviour::ExecuteCommand ( const BehaviourType_t & eFromBehaviour )

protectedpure virtual

Executes the command for the given behaviour, if it is equal to the stored one.

Parameters

eFromBehaviour Behaviour slot from which this method was called.

Implemented in CGUIConditionalBehaviour, CGUIMultiCmdBehaviour, and CGUISingleCmdBehaviour.

◆ FocusNext()

virtual eC_Bool CGUICmdBehaviour::FocusNext	(	CGUIObject *const	pRefObj = `NULL`,
		const eC_Bool &	bSubTreeOfRefObjDone = `false`
	)

protectedvirtual

Called when the object is requested to focus the "next" object. Called when the object receives a standard GK_DOWN event or by request from Source-Code. For a simple object there is nothing to do but to indicate that the event has not been handled. For a standardized event handling mechanism, this method must exist.

Parameters

pRefObj	usually is a child of this object which indicates the current position in the child list.
bSubTreeOfRefObjDone	indicates if the subtree that is under pRefObj has already been asked to take focus, or if not.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ FocusPrevious()

virtual eC_Bool CGUICmdBehaviour::FocusPrevious	(	CGUIObject *const	pRefObj = `NULL`,
		const eC_Bool &	bSubTreeOfRefObjDone = `false`
	)

protectedvirtual

Called when the object is requested to focus the "previous" object. Typically, this happens in reaction to a standard GK_UP event or by request from Source-Code. For a simple object there is nothing to do but to indicate that the event has not been handled. For a standardized event handling mechanism, this method must exist.

Parameters

pRefObj	usually is a child of this object which indicates the current position in the child list.
bSubTreeOfRefObjDone	indicates if the subtree that is under pRefObj has already been asked to take focus, or if not.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ GetFocus()

virtual void CGUICmdBehaviour::GetFocus ( )

protectedvirtual

Called when the object, or one of its children, received the focus. If this control is a composite object then the following applies: Whether this control or a child control got the focus can be determined by checking if this control is the currently focused object in the event handler.

See also: LoseFocus, CGUIEventHandler::GetFocussedObject()

Reimplemented from CGUIBehaviour.

◆ Increase()

virtual eC_Bool CGUICmdBehaviour::Increase ( )

protectedvirtual

Called when the object receives a standard GK_PAGEUP event. For a simple object there is nothing to do but to indicate that the event has not been handled. For a standardized event handling mechanism, this method must exist.

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ LoseFocus()

virtual void CGUICmdBehaviour::LoseFocus ( )

protectedvirtual

Called when an object has lost the focus. In this method the focused object is already set to the object that newly received the focus.

See also: GetFocus

Reimplemented from CGUIBehaviour.

◆ OnCreate()

virtual void CGUICmdBehaviour::OnCreate ( )

protectedvirtual

Slot for handling creation of object. Will be called after the object was created and all attributes have been set.

Reimplemented from CGUIBehaviour.

◆ OnDelete()

virtual void CGUICmdBehaviour::OnDelete ( )

protectedvirtual

Slot for handling deletion of object. Will be called within the destructor, so do not throw any exceptions.

Reimplemented from CGUIBehaviour.

◆ OnHide()

virtual void CGUICmdBehaviour::OnHide ( )

protectedvirtual

Slot for handling change to invisible.

Reimplemented from CGUIBehaviour.

◆ OnShow()

virtual void CGUICmdBehaviour::OnShow ( )

protectedvirtual

Slot for handling change to visible.

Reimplemented from CGUIBehaviour.

The documentation for this class was generated from the following file:

GUICmdBehaviour.h

Protected Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ CGUICmdBehaviour()

◆ ~CGUICmdBehaviour()

Member Function Documentation

◆ Decrease()

◆ DoButtonDown()

◆ DoButtonUp()

◆ DoChar()

◆ DoClick()

◆ DoDoubleClick()

◆ DoDrag()

◆ DoDragEnd()

◆ DoKeyDown()

◆ DoKeyUp()

◆ DoLongClick()

◆ DoMouseEnter()

◆ DoMouseLeave()

◆ DoScrollDown()

◆ DoScrollLeft()

◆ DoScrollRight()

◆ DoScrollUp()

◆ ExecuteCommand()

◆ FocusNext()

◆ FocusPrevious()

◆ GetFocus()

◆ Increase()

◆ LoseFocus()

◆ OnCreate()

◆ OnDelete()

◆ OnHide()

◆ OnShow()
