This control can be used to visualize multiple data-sources in line- or bar-charts. More...

#include <GUIChart.h>

Inheritance diagram for CGUIChart:

[legend]

Classes
struct	Data_t

Public Types
enum	AxisRepresentation_t { NONE , LINE , LINE_AND_SCALING , LINE_SCALING_AND_TEXT }
	enum how the axis are displayed More...

enum	DataRepresentation_t { POINTS , POINTS_AND_LINES , LINES , BARS , PIE , RING , STACKED_LINES , STACKED_BARS }
	enum how to disply values More...

Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Public Member Functions
	CGUIChart ()

	CGUIChart (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIChart (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, eC_Int iScalingXAxis, eC_Int iScalingYAxis, eC_Value vMaxShownNumberY, eC_Value vMinShownNumberY, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIChart (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, eC_UInt iAxisColor, eC_UInt TextLabelColor, eC_UInt DrawLineColor, eC_UInt DrawPointColor, eC_UInt BarColor, eC_Value AxisLineWidth, eC_Value DrawLineWidth, eC_Value vScaleLength, eC_Value vPointSize, eC_UInt uiScalingXAxis, eC_UInt uiScalingYAxis, eC_Value vMaxShownNumberY, eC_Value vMinShownNumberY, eC_Value vZoomFactorY, eC_UInt uiZoomFactorX, const ObjectHandle_t &eID=NO_HANDLE)

virtual	~CGUIChart ()

void	AddData (eC_Value vDataValue, eC_UInt uiDimension=0)

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoClick (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX, const eC_Value &vDeltaY, const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDraw ()

eC_UInt	GetAxisColor () const

eC_Value	GetAxisLineWidth () const

eC_UInt	GetBarColor (const eC_UInt &uiIndex) const

DataRepresentation_t	GetDataRepresentation () const

eC_Value	GetDrawLineWidth () const

CGUIRect	GetFocusArea () const

CGUICommonEnums::AxisAlignment_t	GetHelperLineRepresentation () const

eC_UInt	GetHorizontalHelperLineColor () const

eC_UInt	GetLineColor (const eC_UInt &uiIndex) const

eC_UInt	GetPointColor (const eC_UInt &uiIndex) const

eC_Value	GetPointSize () const

void	GetRangeX (eC_Int &iMinNumber, eC_Int &iMaxNumber) const

void	GetRangeY (eC_Value &vMinValue, eC_Value &vMaxValue) const

AxisRepresentation_t	GetRepresentationXAxis () const

AxisRepresentation_t	GetRepresentationYAxis () const

eC_Value	GetScaleLength () const

eC_UInt	GetScalingXAxis () const

eC_UInt	GetScalingYAxis () const

eC_UInt	GetSelectionColor () const

eC_Bool	GetShowBarData () const

eC_Int	GetStartLabelValue () const

eC_UInt	GetTextLabelColor () const

eC_UInt	GetVerticalHelperLineColor () const

eC_Value	GetZoomFactorX () const

eC_Value	GetZoomFactorY () const

virtual eC_Bool	IsHighlightable () const

void	JumpToDataPoint (const eC_Int &iMinShownData)

void	JumpToTheEnd ()

void	KeepLastXElemenets (const eC_UInt &uiDataAmountToKepp)

virtual void	ReadFromStream ()

void	SetAxisColor (const eC_UInt &uiAxisColor)

void	SetAxisColor (const GlobalProperty_t &eAxisColor)

void	SetAxisLineWidth (const eC_Value &vAxisLineWidth)

void	SetBarColor (const eC_UInt &uiIndex, const eC_UInt &uiBarColor)

void	SetBarColor (const eC_UInt &uiIndex, const GlobalProperty_t &eBarColor)

void	SetDataRepresentation (const DataRepresentation_t &eDataRepresentation)

void	SetDrawLineWidth (const eC_Value &vDrawLineWidth)

void	SetFont (const FontResource_t &eFontId)

virtual void	SetHeight (const eC_Value &vY)

void	SetHelperLineRepresentation (const CGUICommonEnums::AxisAlignment_t &eRepresentation)

void	SetHorizontalHelperLineColor (const eC_UInt &uiColor)

void	SetHorizontalHelperLineColor (const GlobalProperty_t &eColor)

void	SetImages (const ImageResource_t &eImageBG)

void	SetLineColor (const eC_UInt &uiIndex, const eC_UInt &uiLineColor)

void	SetLineColor (const eC_UInt &uiIndex, const GlobalProperty_t &eLineColor)

void	SetMaxValueY (const eC_Value &vMaxNumber)

void	SetMinValueY (const eC_Value &vMinNumber)

void	SetPointColor (const eC_UInt &uiIndex, const eC_UInt &uiPointColor)

void	SetPointColor (const eC_UInt &uiIndex, const GlobalProperty_t &ePointColor)

void	SetPointSize (const eC_Value &vPointSize)

void	SetRangeX (const eC_Int &iMinNumber, const eC_Int &iMaxNumber)

void	SetRangeY (const eC_Value &vMinValue, const eC_Value &vMaxValue)

void	SetRepresentationXAxis (const AxisRepresentation_t &eXAxis)

void	SetRepresentationYAxis (const AxisRepresentation_t &eYAxis)

void	SetScaleLength (const eC_Value &vScaleLength)

void	SetScalingXAxis (const eC_UInt &uiScalingXAxis)

void	SetScalingYAxis (const eC_UInt &uiScalingYAxis)

void	SetSelectionColor (const eC_UInt &uiSelectionColor)

void	SetSelectionColor (const GlobalProperty_t &eSelectionColor)

void	SetShowBarData (const eC_Bool &bShowBarData)

void	SetStandardImages ()

void	SetStartLabelValue (const eC_Int &iStartValue)

void	SetTextLabelColor (const eC_UInt &uiTextLabelColor)

void	SetTextLabelColor (const GlobalProperty_t &eTextLabelColor)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

void	SetVerticalHelperLineColor (const eC_UInt &uiColor)

void	SetVerticalHelperLineColor (const GlobalProperty_t &eColor)

virtual void	SetWidth (const eC_Value &vX)

void	SetZoomFactorX (const eC_Value &vZoomFactorX)

void	SetZoomFactorY (const eC_Value &vZoomFactorY)

void	WipeAllData ()

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

void	ZoomInX ()

void	ZoomInY ()

void	ZoomOutX ()

void	ZoomOutY ()

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Additional Inherited Members
Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Detailed Description

This control can be used to visualize multiple data-sources in line- or bar-charts.

Member Enumeration Documentation

◆ AxisRepresentation_t

enum CGUIChart::AxisRepresentation_t

enum how the axis are displayed

Enumerator
NONE	do not show axis
LINE	show only line of axis
LINE_AND_SCALING	Dots of data connected with 1 line.
LINE_SCALING_AND_TEXT	Bars Raising out of x-axis.

◆ DataRepresentation_t

enum CGUIChart::DataRepresentation_t

enum how to disply values

Enumerator
POINTS	only points
LINES	points and lines Dots of data connected with 1 line
BARS	Bars Raising out of x-axis.
PIE	pie-chart (only one dataset)
RING	ring-chart (stacked datasets)
STACKED_LINES	stacked lines on top of each other
STACKED_BARS	stacked bars on top of each other

Constructor & Destructor Documentation

◆ CGUIChart() [1/4]

CGUIChart::CGUIChart	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		eC_UInt	iAxisColor,
		eC_UInt	TextLabelColor,
		eC_UInt	DrawLineColor,
		eC_UInt	DrawPointColor,
		eC_UInt	BarColor,
		eC_Value	AxisLineWidth,
		eC_Value	DrawLineWidth,
		eC_Value	vScaleLength,
		eC_Value	vPointSize,
		eC_UInt	uiScalingXAxis,
		eC_UInt	uiScalingYAxis,
		eC_Value	vMaxShownNumberY,
		eC_Value	vMinShownNumberY,
		eC_Value	vZoomFactorY,
		eC_UInt	uiZoomFactorX,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructor Please use the SetImages method to set the correct images.

Parameters

pkParent	Pointer to the designated parent object
vX	X-position relative to its parent object
vY	Y-position relative to its parent object
vWidth	Width of the geometry object
vHeight	Height of the geometry object
iAxisColor	Color of the axis Ex(0xff000000)
TextLabelColor	Color of the Text Lables Ex(0xff000000)
DrawLineColor	Color of the Line that connects data points Ex(0xff000000)
DrawPointColor	Color of the Data Points Ex(0xff123456)
BarColor	Color of the Bars Ex(0xff000000)
AxisLineWidth	Witdh of axis lines
DrawLineWidth	Witdh of lines that connect Data Points
vScaleLength	Length of the lines that go thru X and Y axis
vPointSize	Size of the point to be drawn
uiScalingXAxis	Number of parts in X axis (lines that cross X axis)
uiScalingYAxis	Number of parts in Y axis (lines that cross Y axis)
vMaxShownNumberY	Maximum lable number on Y axis (is not a constant AND changes dinamically depending on user interaction)
vMinShownNumberY	Minimum lable number on Y axis (is not a constant AND changes dinamically depending on user interaction)
vZoomFactorY	How much zoom will enlarge Y axis (best choice 2)
uiZoomFactorX	How much zoom will enlarge X axis (best choice 2)
eID	Object identifier of this object (choose NO_HANDLE if none is required)

◆ CGUIChart() [2/4]

CGUIChart::CGUIChart	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructor Please use the SetImages method to set the correct images.

Parameters

pkParent	Pointer to the designated parent object
vX	X-position relative to its parent object
vY	Y-position relative to its parent object
vWidth	Width of the geometry object
vHeight	Height of the geometry object
eID	Object-ID Parameters that will set up automatically: (iAxisColor, TextLabelColor, DrawLineColor, DrawPointColor, BarColor, AxisLineWidth, DrawLineWidth, vScaleLength, vPointSize uiScalingXAxis, uiScalingYAxis, vMaxShownNumberY, vMinShownNumberY, vZoomFactorY, uiZoomFactorX)

◆ CGUIChart() [3/4]

CGUIChart::CGUIChart	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		eC_Int	iScalingXAxis,
		eC_Int	iScalingYAxis,
		eC_Value	vMaxShownNumberY,
		eC_Value	vMinShownNumberY,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructor Please use the SetImages method to set the correct images.

Parameters

pkParent	Pointer to the designated parent object
vX	X-position relative to its parent object
vY	Y-position relative to its parent object
vWidth	Width of the geometry object
vHeight	Height of the geometry object
iScalingXAxis	initial scaling of x-axis
iScalingYAxis	initial scaling of y-axis
vMaxShownNumberY	Maximum lable number on Y axis (is not a constant AND changes dinamically depending on user interaction)
vMinShownNumberY	Minimum lable number on Y axis (is not a constant AND changes dinamically depending on user interaction)
eID	Object-ID Parameters that will set up automatically: (iAxisColor, TextLabelColor, DrawLineColor, DrawPointColor, BarColor, AxisLineWidth, DrawLineWidth, vScaleLength, vPointSize uiScalingXAxis, uiScalingYAxis, vZoomFactorY, uiZoomFactorX)

◆ ~CGUIChart()

virtual CGUIChart::~CGUIChart ( )

virtual

Destructor

◆ CGUIChart() [4/4]

CGUIChart::CGUIChart ( )

Standard constructor. Only to be called by factory. No user code should call this constructor, not even in streaming mode (that is, when GUILIANI_STREAM_GUI is defined)!

See also: CGUIChart()

Member Function Documentation

◆ AddData()

void CGUIChart::AddData	(	eC_Value	vDataValue,
		eC_UInt	uiDimension = `0`
	)

AddData Adds data to the array. Note that the dimension starts at 0. For example if only one line of data is displayed then its dimension is 0. If user wish to display two lines of data, then the user needs to append second dimension (1) and so on.

Parameters

vDataValue	eC_Value
uiDimension	eC_UInt

◆ DoButtonDown()

virtual eC_Bool CGUIChart::DoButtonDown	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called when the mouse button or finger is pressed down over an object.

Note: DoButtonDown() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the object was pressed relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoClick()

virtual eC_Bool CGUIChart::DoClick	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called when the object receives a click event. A click can e.g., be the result of a mouse click, a finger press/release sequence on touchscreens, or be triggered by a GK_ACTION keyboard event.

Note: DoClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and released at the same position for in a certain time span, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoDrag()

virtual eC_Bool CGUIChart::DoDrag	(	const eC_Value &	vDeltaX,
		const eC_Value &	vDeltaY,
		const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called when the object receives a Drag event. Drags are typically created if the mouse is being used while a mouse-button is being pressed, or if the user moves his finger over a touchscreen.

Parameters

vDeltaX	relative movement in x-direction since the last call of DoDrag/ButtonDown
vDeltaY	relative movement in y-direction since the last call of DoDrag/ButtonDown
vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoDragEnd()

virtual eC_Bool CGUIChart::DoDragEnd	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called on the dragged object (=the object on which the initial ButtonDown-event occurred) when the mouse button is released after a drag event.

Parameters

vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoDraw()

virtual eC_Bool CGUIChart::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns: True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

◆ GetAxisColor()

eC_UInt CGUIChart::GetAxisColor ( ) const

GetAxisColor This method returns the color of the x- and y-axis (scaling color is also included).

Returns: Axis-color

◆ GetAxisLineWidth()

eC_Value CGUIChart::GetAxisLineWidth ( ) const

GetAxisLineWidth This method returns the visual width of the axis lines (scaling lines are also included)

Returns: m_vAxisLineWidth eC_Value

◆ GetBarColor()

eC_UInt CGUIChart::GetBarColor ( const eC_UInt & uiIndex ) const

GetBarColor This method returns the color of the bar (bar-chart representation) depending on the dymensions. Default is 0 (first data array)

Parameters

uiIndex eC_UInt

Returns: bar-color of index

◆ GetDataRepresentation()

DataRepresentation_t CGUIChart::GetDataRepresentation ( ) const

This method returns the currently set representation of data points. It can be points, points and lines, lines or bars.

Returns: data representation

◆ GetDrawLineWidth()

eC_Value CGUIChart::GetDrawLineWidth ( ) const

GetDrawLineWidth This method returns the visual width of the draw lines (line-chart representation)

Returns: m_vDrawLineWidth eC_Value

◆ GetFocusArea()

CGUIRect CGUIChart::GetFocusArea ( ) const

Get the currently focussed area of data

Returns: focus-area

◆ GetHelperLineRepresentation()

CGUICommonEnums::AxisAlignment_t CGUIChart::GetHelperLineRepresentation ( ) const

This method returns the representation type of the helper lines

Returns: representation type of the helper lines

◆ GetHorizontalHelperLineColor()

eC_UInt CGUIChart::GetHorizontalHelperLineColor ( ) const

This method returns the color of the horizontal helper lines

Returns: color

◆ GetLineColor()

eC_UInt CGUIChart::GetLineColor ( const eC_UInt & uiIndex ) const

GetLineColor This method returns the color of the line (line-chart representation) depending on the dymensions. Default is 0 (first data array)

Parameters

uiIndex

Returns: line-color of index

◆ GetPointColor()

eC_UInt CGUIChart::GetPointColor ( const eC_UInt & uiIndex ) const

GetPointColor This method returns the color of the point (point-chart representation) depending on the dymensions. Default is 0 (first data array)

Parameters

uiIndex eC_UInt

Returns: point-color of index

◆ GetPointSize()

eC_Value CGUIChart::GetPointSize ( ) const

GetPointSize This method returns the visual size of the datapoints

Returns: m_vPointSize eC_Value

◆ GetRangeX()

void CGUIChart::GetRangeX	(	eC_Int &	iMinNumber,
		eC_Int &	iMaxNumber
	)		const

Get the range for shown datapoints

Parameters

iMinNumber	is the data point to be shown first
iMaxNumber	is the data point to be shown last

◆ GetRangeY()

void CGUIChart::GetRangeY	(	eC_Value &	vMinValue,
		eC_Value &	vMaxValue
	)		const

Get the range for y-axis

Parameters

vMinValue	minimum value
vMaxValue	maximum value

◆ GetRepresentationXAxis()

AxisRepresentation_t CGUIChart::GetRepresentationXAxis ( ) const

This method return the currently set representation of x-axis. (invisible, only-axis, axis and scaling, axis scaling and labels)

Returns: horizontal axis-representation

◆ GetRepresentationYAxis()

AxisRepresentation_t CGUIChart::GetRepresentationYAxis ( ) const

This method return the currently set representation of y-axis. (invisible, only-axis, axis and scaling, axis scaling and labels)

Returns: vertical axis-representation

◆ GetScaleLength()

eC_Value CGUIChart::GetScaleLength ( ) const

GetScaleLength This method returns the visual lenght of the scales (x- and y-axis scaling)

Returns: m_vScaleLength eC_Value

◆ GetScalingXAxis()

eC_UInt CGUIChart::GetScalingXAxis ( ) const

GetScalingXAxis This method returns the scaling of X-axis.

Returns: m_uiScalingXAxis eC_UInt

◆ GetScalingYAxis()

eC_UInt CGUIChart::GetScalingYAxis ( ) const

GetScalingYAxis This method returns the scaling of Y-axis.

Returns: m_uiScalingYAxis eC_UInt

◆ GetSelectionColor()

eC_UInt CGUIChart::GetSelectionColor ( ) const

GetBarColor This method returns the color of the selection Default is 0 (first data array)

Returns: Selection-color

◆ GetShowBarData()

eC_Bool CGUIChart::GetShowBarData ( ) const

Return if bar-data is currently shown

Returns: true if active

◆ GetStartLabelValue()

eC_Int CGUIChart::GetStartLabelValue ( ) const

Get the starting value for x-axis

Returns: starting-value

◆ GetTextLabelColor()

eC_UInt CGUIChart::GetTextLabelColor ( ) const

GetDrawLineColor This method returns the color of the text that is used to draw all labels.

Returns: Color of text-label

◆ GetVerticalHelperLineColor()

eC_UInt CGUIChart::GetVerticalHelperLineColor ( ) const

This method returns the color of the horizontal helper lines

Returns: color

◆ GetZoomFactorX()

eC_Value CGUIChart::GetZoomFactorX ( ) const

GetZoomFactorX This method returns the zoom factor of X-axis.

Returns: m_uiZoomFactorX eC_Value

◆ GetZoomFactorY()

eC_Value CGUIChart::GetZoomFactorY ( ) const

GetZoomFactorY This method returns the zoom factor of Y-axis.

Returns: m_vZoomFactorY eC_Value

◆ IsHighlightable()

virtual eC_Bool CGUIChart::IsHighlightable ( ) const

inlinevirtual

This method checks if an object is highlightable. This refers to whether it can be highlighted via the event handler. If true the event handler may mark this object as the currently highlighted one. Thus, there is no special flag in CGUIObject that determines if an object is highlightable. The default determination is that the control is in none of the following states:

invisible
grayed-out
disabled if so the return value will be true. NOTE: when an object is not highlightable, it will never receive DoMouseEnter and DoMouseLeave-events
Returns
True if highlightable, False otherwise

Reimplemented from CGUIObject.

◆ JumpToDataPoint()

void CGUIChart::JumpToDataPoint ( const eC_Int & iMinShownData )

Sets the minimum data point as first datapoint of the x axis For example - 100 data points and scaling of x axis is 10 SetMinShownData(20) will make it so that the x axis will display 20th data point first and 29th data point last

Parameters

iMinShownData is the data point to be shown first

◆ JumpToTheEnd()

void CGUIChart::JumpToTheEnd ( )

JumpToTheEnd Whenever this method will be called the data-point view will jump to the end. That means that only the last datapoints will be displayed.

◆ KeepLastXElemenets()

void CGUIChart::KeepLastXElemenets ( const eC_UInt & uiDataAmountToKepp )

KeepLastXElemenets This method keeps x amount of data points that are saved in this class. Note, if you are using DataPool then when the DataPool will notify this class again, all data points will come back.

Parameters

uiDataAmountToKepp eC_UInt

◆ ReadFromStream()

virtual void CGUIChart::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. Only for use with GUIFactory. GUIStreamingFileReader has to be set in CGUI::Init().

See also: CGUIFactory

Reimplemented from CGUIObject.

◆ SetAxisColor() [1/2]

void CGUIChart::SetAxisColor ( const eC_UInt & uiAxisColor )

SetAxisColor

Parameters

uiAxisColor

◆ SetAxisColor() [2/2]

void CGUIChart::SetAxisColor ( const GlobalProperty_t & eAxisColor )

SetAxisColor

Parameters

eAxisColor

◆ SetAxisLineWidth()

void CGUIChart::SetAxisLineWidth ( const eC_Value & vAxisLineWidth )

SetAxisLineWidth This method sets the with of axis lines (that also includes the width of scaling lines)

Parameters

vAxisLineWidth eC_Value

◆ SetBarColor() [1/2]

void CGUIChart::SetBarColor	(	const eC_UInt &	uiIndex,
		const eC_UInt &	uiBarColor
	)

SetBarColor

Parameters

uiIndex	is the indes of the array of colors (starts from 0)
uiBarColor

◆ SetBarColor() [2/2]

void CGUIChart::SetBarColor	(	const eC_UInt &	uiIndex,
		const GlobalProperty_t &	eBarColor
	)

SetBarColor

Parameters

uiIndex	is the indes of the array of colors (starts from 0)
eBarColor

◆ SetDataRepresentation()

void CGUIChart::SetDataRepresentation ( const DataRepresentation_t & eDataRepresentation )

This method changes the representation of data points. It can be points, points and lines, lines or bars.

Parameters

eDataRepresentation data representation

◆ SetDrawLineWidth()

void CGUIChart::SetDrawLineWidth ( const eC_Value & vDrawLineWidth )

SetDrawLineWidth This method sets the with of lines that are used to connect data points

Parameters

vDrawLineWidth eC_Value

◆ SetFont()

void CGUIChart::SetFont ( const FontResource_t & eFontId )

Sets the font used for the axis

Parameters

eFontId FontID

◆ SetHeight()

virtual void CGUIChart::SetHeight ( const eC_Value & vY )

virtual

Sets this object's height to a new value.

Parameters

vY	the new height

Reimplemented from CGUIObject.

◆ SetHelperLineRepresentation()

void CGUIChart::SetHelperLineRepresentation ( const CGUICommonEnums::AxisAlignment_t & eRepresentation )

This method sets display of helper-lines (none, hor, ver or both)

Parameters

eRepresentation type of helper-lines

◆ SetHorizontalHelperLineColor() [1/2]

void CGUIChart::SetHorizontalHelperLineColor ( const eC_UInt & uiColor )

This method sets the color of the horizontal helper lines.

Parameters

uiColor color

◆ SetHorizontalHelperLineColor() [2/2]

void CGUIChart::SetHorizontalHelperLineColor ( const GlobalProperty_t & eColor )

This method sets the color of the horizontal helper lines.

Parameters

eColor color

◆ SetImages()

void CGUIChart::SetImages ( const ImageResource_t & eImageBG )

SetImages Method to change the images used for the chart background. If the chart size varies from the supplied image's size, the image will automatically split into three portions. These are either a left/middle/right part for horizontal, or a top/middle/bottom part for vertical sliders. The left/top images will be constructed from the left/top half of the original image. Analogue, The right/bottom images will be constructor from the right/bottom half of the original image. The pixel row/column in the middle of the original image will be stretched to fill up the space, if the chart is to be displayed bigger than the original image.

Parameters

eImageBG ID of background image

◆ SetLineColor() [1/2]

void CGUIChart::SetLineColor	(	const eC_UInt &	uiIndex,
		const eC_UInt &	uiLineColor
	)

SetLineColor

Parameters

uiIndex	eC_Uint is the indes of the array of colors (starts from 0)
uiLineColor

◆ SetLineColor() [2/2]

void CGUIChart::SetLineColor	(	const eC_UInt &	uiIndex,
		const GlobalProperty_t &	eLineColor
	)

SetLineColor

Parameters

uiIndex	eC_Uint is the indes of the array of colors (starts from 0)
eLineColor

◆ SetMaxValueY()

void CGUIChart::SetMaxValueY ( const eC_Value & vMaxNumber )

Sets the maximum number of Y axis scaling

Parameters

vMaxNumber is the maximum number

◆ SetMinValueY()

void CGUIChart::SetMinValueY ( const eC_Value & vMinNumber )

Sets the minimum number of Y axis scaling

Parameters

vMinNumber is the minimum number

◆ SetPointColor() [1/2]

void CGUIChart::SetPointColor	(	const eC_UInt &	uiIndex,
		const eC_UInt &	uiPointColor
	)

SetPointColor

Parameters

uiIndex	eC_Uint is the indes of the array of colors (starts from 0)
uiPointColor

◆ SetPointColor() [2/2]

void CGUIChart::SetPointColor	(	const eC_UInt &	uiIndex,
		const GlobalProperty_t &	ePointColor
	)

SetPointColor

Parameters

uiIndex	eC_Uint is the indes of the array of colors (starts from 0)
ePointColor

◆ SetPointSize()

void CGUIChart::SetPointSize ( const eC_Value & vPointSize )

SetPointSize This method sets the size of points that are used to draw data on the screen

Parameters

vPointSize eC_Value

◆ SetRangeX()

void CGUIChart::SetRangeX	(	const eC_Int &	iMinNumber,
		const eC_Int &	iMaxNumber
	)

Sets the range for shown data points It will start always from the first parameter, but if the last parameter will exceed normal scaling of x axis then the chart will display more datapoints than the input suggests.

Parameters

iMinNumber	is the data point to be shown first
iMaxNumber	is the data point to be shown last

◆ SetRangeY()

void CGUIChart::SetRangeY	(	const eC_Value &	vMinValue,
		const eC_Value &	vMaxValue
	)

Sets minimum and maximum value for y-axis

Parameters

vMinValue	minimum value
vMaxValue	maximum value

◆ SetRepresentationXAxis()

void CGUIChart::SetRepresentationXAxis ( const AxisRepresentation_t & eXAxis )

This method changes the representation of x-axis. (invisible, only-axis, axis and scaling, axis scaling and labels)

Parameters

eXAxis

◆ SetRepresentationYAxis()

void CGUIChart::SetRepresentationYAxis ( const AxisRepresentation_t & eYAxis )

This method changes the representation of y-axis. (invisible, only-axis, axis and scaling, axis scaling and labels)

Parameters

eYAxis

◆ SetScaleLength()

void CGUIChart::SetScaleLength ( const eC_Value & vScaleLength )

SetScaleLength This method sets the lenght of scale lines (both x- and y-axis)

Parameters

vScaleLength eC_Value

◆ SetScalingXAxis()

void CGUIChart::SetScalingXAxis ( const eC_UInt & uiScalingXAxis )

SetScalingXAxis This method sets the scaling of x-axis (amount of partitions - in how many parts will be x-axis divided) This dictetes how many datapoints (if datapoints > scaling) will be displayed in one chart frame

Parameters

uiScalingXAxis eC_UInt

◆ SetScalingYAxis()

void CGUIChart::SetScalingYAxis ( const eC_UInt & uiScalingYAxis )

SetScalingYAxis This method sets the scaling of y-axis (amount of partitions - in how many parts will be y-axis divided) This dictetes how many labels will be on y-axis (not including the origin label)

Parameters

uiScalingYAxis eC_UInt

◆ SetSelectionColor() [1/2]

void CGUIChart::SetSelectionColor ( const eC_UInt & uiSelectionColor )

SetSelectionColor

Parameters

uiSelectionColor

◆ SetSelectionColor() [2/2]

void CGUIChart::SetSelectionColor ( const GlobalProperty_t & eSelectionColor )

SetSelectionColor

Parameters

eSelectionColor

◆ SetShowBarData()

void CGUIChart::SetShowBarData ( const eC_Bool & bShowBarData )

This method turns on and off the value feedback method. ONLY works in bar-chart representation. Value feedback method shows the data value of the bar that is clicked by the user.

Parameters

bShowBarData

◆ SetStandardImages()

void CGUIChart::SetStandardImages ( )

SetStandardImages Sets standard images.

◆ SetStartLabelValue()

void CGUIChart::SetStartLabelValue ( const eC_Int & iStartValue )

SetStartLabelValue This method sets the value label at which x-axis starts

Parameters

iStartValue eC_Int

◆ SetTextLabelColor() [1/2]

void CGUIChart::SetTextLabelColor ( const eC_UInt & uiTextLabelColor )

SetTextLabelColor

Parameters

uiTextLabelColor

◆ SetTextLabelColor() [2/2]

void CGUIChart::SetTextLabelColor ( const GlobalProperty_t & eTextLabelColor )

SetTextLabelColor

Parameters

eTextLabelColor

◆ SetValue()

virtual eC_Bool CGUIChart::SetValue ( CDataPoolEntry & rkValue )

virtual

Generic interface used by the DataPool for setting values in GUIObjects. By default, this maps directly onto the SetValue() API dealing with a single CGUIValue.

Parameters

rkValue Reference to the DataPoolEntry used for retrieving the value(s)

Returns: The return value of the called API (Usually True if OK and False in case of error).

Reimplemented from CGUIObject.

◆ SetVerticalHelperLineColor() [1/2]

void CGUIChart::SetVerticalHelperLineColor ( const eC_UInt & uiColor )

This method sets the color of the horizontal helper lines

Parameters

uiColor color

◆ SetVerticalHelperLineColor() [2/2]

void CGUIChart::SetVerticalHelperLineColor ( const GlobalProperty_t & eColor )

This method sets the color of the horizontal helper lines

Parameters

eColor color

◆ SetWidth()

virtual void CGUIChart::SetWidth ( const eC_Value & vX )

virtual

Sets this object's width to a new value.

Parameters

vX	the new width

Reimplemented from CGUIObject.

◆ SetZoomFactorX()

void CGUIChart::SetZoomFactorX ( const eC_Value & vZoomFactorX )

SetZoomFactorX This method sets the zoom factor of x-axis. That means that each time when the user zooms out the x-axis the ignore factor (data displayed per scale (default is 1)) will be multiplied by this number

Parameters

vZoomFactorX for x-axis

◆ SetZoomFactorY()

void CGUIChart::SetZoomFactorY ( const eC_Value & vZoomFactorY )

SetZoomFactorY This method sets the zoom factor of y-axis. That means that each time when the user zooms out the y-axis the min and max numbers will be multiplied by this number.

Parameters

vZoomFactorY for y-axis

◆ WipeAllData()

void CGUIChart::WipeAllData ( )

WipeAllData This method deletes all data points that are saved in this class. Note, if you are using DataPool then when the DataPool will notify this class again, all data points will come back.

◆ WriteToStream()

virtual void CGUIChart::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all object attributes to the streaming file. StreamWriter has to be initialized. Only for use with GUIStreamWriter.

Parameters

bWriteClassID This flag is used to select if writing of ControlID, leading and trailing tags is performed. Only GUIStreamWriter and GUICompositeObject have to set this flag true.

See also: CGUIStreamWriter

Reimplemented from CGUIObject.

◆ ZoomInX()

void CGUIChart::ZoomInX ( )

ZoomInX This method zooms in of x-axis (which means that less data points will be drawn in a single chart frame)

◆ ZoomInY()

void CGUIChart::ZoomInY ( )

ZoomInY This method zooms out in y-axis (which means that the range between min and max is smaller)

◆ ZoomOutX()

void CGUIChart::ZoomOutX ( )

ZoomOutX This method zooms out of x-axis (which means that more data points will be drawn in a single chart frame)

◆ ZoomOutY()

void CGUIChart::ZoomOutY ( )

ZoomOutY This method zooms out of y-axis (which means that the range between min and max is bigger)

The documentation for this class was generated from the following file:

GUIChart.h

Classes

Public Types

Public Member Functions

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ AxisRepresentation_t

◆ DataRepresentation_t

Constructor & Destructor Documentation

◆ CGUIChart() [1/4]

◆ CGUIChart() [2/4]

◆ CGUIChart() [3/4]

◆ ~CGUIChart()

◆ CGUIChart() [4/4]

Member Function Documentation

◆ AddData()

◆ DoButtonDown()

◆ DoClick()

◆ DoDrag()

◆ DoDragEnd()

◆ DoDraw()

◆ GetAxisColor()

◆ GetAxisLineWidth()

◆ GetBarColor()

◆ GetDataRepresentation()

◆ GetDrawLineWidth()

◆ GetFocusArea()

◆ GetHelperLineRepresentation()

◆ GetHorizontalHelperLineColor()

◆ GetLineColor()

◆ GetPointColor()

◆ GetPointSize()

◆ GetRangeX()

◆ GetRangeY()

◆ GetRepresentationXAxis()

◆ GetRepresentationYAxis()

◆ GetScaleLength()

◆ GetScalingXAxis()

◆ GetScalingYAxis()

◆ GetSelectionColor()

◆ GetShowBarData()

◆ GetStartLabelValue()

◆ GetTextLabelColor()

◆ GetVerticalHelperLineColor()

◆ GetZoomFactorX()

◆ GetZoomFactorY()

◆ IsHighlightable()

◆ JumpToDataPoint()

◆ JumpToTheEnd()

◆ KeepLastXElemenets()

◆ ReadFromStream()

◆ SetAxisColor() [1/2]

◆ SetAxisColor() [2/2]

◆ SetAxisLineWidth()

◆ SetBarColor() [1/2]

◆ SetBarColor() [2/2]

◆ SetDataRepresentation()

◆ SetDrawLineWidth()

◆ SetFont()

◆ SetHeight()

◆ SetHelperLineRepresentation()

◆ SetHorizontalHelperLineColor() [1/2]

◆ SetHorizontalHelperLineColor() [2/2]

◆ SetImages()

◆ SetLineColor() [1/2]

◆ SetLineColor() [2/2]

◆ SetMaxValueY()

◆ SetMinValueY()

◆ SetPointColor() [1/2]

◆ SetPointColor() [2/2]

◆ SetPointSize()

◆ SetRangeX()

◆ SetRangeY()

◆ SetRepresentationXAxis()

◆ SetRepresentationYAxis()

◆ SetScaleLength()

◆ SetScalingXAxis()

◆ SetScalingYAxis()

◆ SetSelectionColor() [1/2]

◆ SetSelectionColor() [2/2]
