Displays a static image in the GUI. More...

#include <GUIImage.h>

Inheritance diagram for CGUIImage:

[legend]

Public Types
enum	BlitType_t { IBT_CENTER , IBT_STRETCH , IBT_TILED }
	enum for blitting-type More...

Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Public Member Functions
	CGUIImage ()

	CGUIImage (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ImageResource_t &eImageID, const eC_Bool &bStretchBlit=true, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIImage (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ImageResource_t &eImageID, const eC_Bool &bStretchBlit=true, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIImage (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const ImageResource_t &eImageID, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIImage (const CGUIImage &kSource)

virtual eC_Bool	DoDraw ()

BlitType_t	GetBlitType () const

ImageResource_t	GetImageID () const

CGUINinePatch &	GetNinePatch ()

eC_Bool	GetStretchBlit () const

virtual eC_Bool	IsHighlightable () const

CGUIImage &	operator= (const CGUIImage &kSource)

virtual void	ReadFromStream ()

void	SetBlitType (const BlitType_t &eBlitType)

void	SetImage (const ImageResource_t &eImage, const eC_Bool &bFitToImage=false)

void	SetStretchBlit (eC_Bool bStretchBlit)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

UUID_t	GetUUID () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

void	SetUUID (const UUID_t &kUUID)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoScale (const eC_Value &vDelta)

virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDataPool (const DataPoolResource_t &eID)

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX=eC_FromInt(-1), const eC_Value &vDeltaY=eC_FromInt(-1), const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScroll (const eC_Value &vAbsX, const eC_Value &vAbsY, const eC_Value &vDelta, const eC_Bool &bModifierActive)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Additional Inherited Members
Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()

Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_UUID []
	XML tag to be used when writing a UUID into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

static const eC_Char	XMLTAG_BEHAVIOURCOUNT []
	XML tag for count.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes inherited from CGUIObject
UUID_t	m_kUUID
	UUID of object.

Detailed Description

Displays a static image in the GUI.

The "image" control is used to display a static image. The position and dimension of the image can be set freely. The scaling of the images is arbitrary in x and y dimension - so the aspect ratio can be changed. The "image" control is typically used to display e.g., a background image or brand icons (Class: CGUIImage).

This control displays an image. The image can be stretched if the control size does not match the image size.

Example:

// Create an image.
CGUIImage* pkImage = new CGUIImage(this,
                            eC_FromInt(0), eC_FromInt(0),
                            eC_FromInt(30), eC_FromInt(30),
                            IMG_IMAGE1,
                            true,
                            OBJ_IMAGE);

// Set image.
// Before calling this method, please add image id to UserImageResource.h.
// After that call GETRESMANAGER.RegisterImageResource() to register an image for image id.
pkImage->SetImage(IMG_IMAGE2,true);

// Sets the alpha (transparency) value of the image
pkImage->SetAlpha(12);

Member Enumeration Documentation

◆ BlitType_t

enum CGUIImage::BlitType_t

enum for blitting-type

Enumerator

IBT_STRETCH

blit image in center

IBT_TILED

stretch image to fit

tile image to fit

Constructor & Destructor Documentation

◆ CGUIImage() [1/5]

CGUIImage::CGUIImage	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const ImageResource_t &	eImageID,
		const eC_Bool &	bStretchBlit = `true`,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a CGUIImage object. Note that if the given width and height do not match the actual size of the image it will be stretched when drawing it, resulting in a potential performance loss.

Parameters

pkParent	Pointer to the parent object of this image.
vX	The x coordinate of the upper left corner of this image.
vY	The y coordinate of the upper left corner of this image.
vWidth	The width of this image.
vHeight	The height of this image.
eImageID	The ID of the image represented by this object.
eID	This image's object ID.
bStretchBlit	If true image will be stretched to the size of the object, if false image will be centered.

◆ CGUIImage() [2/5]

CGUIImage::CGUIImage	(	CGUICompositeObject *const	pkParent,
		const CGUIRect &	kRect,
		const ImageResource_t &	eImageID,
		const eC_Bool &	bStretchBlit = `true`,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a CGUIImage object. Note that if the given width and height do not match the actual size of the image it will be stretched when drawing it, resulting in a potential performance loss.

Parameters

pkParent	Pointer to the parent object of this image.
kRect	The bounding rectangle, relative to parent.
eImageID	The ID of the image represented by this object.
eID	This image's object ID.
bStretchBlit	If true image will be stretched to the size of the object, if false image will be centered.

◆ CGUIImage() [3/5]

CGUIImage::CGUIImage	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const ImageResource_t &	eImageID,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructs a CGUIImage object and determines its size by the image.

Parameters

pkParent	Pointer to the parent object of this image.
vX	The x coordinate of the upper left corner of this image.
vY	The y coordinate of the upper left corner of this image.
eImageID	The ID of the image represented by this object. The size of this object is initialized with the dimensions of the image.
eID	This image's object ID.

◆ CGUIImage() [4/5]

CGUIImage::CGUIImage ( const CGUIImage & kSource )

Copy-constructor of the CGUIImage class.

Parameters

kSource Source object to be copied.

◆ CGUIImage() [5/5]

CGUIImage::CGUIImage ( )

Standard constructor.

See also: CGUIObject().

Member Function Documentation

◆ DoDraw()

virtual eC_Bool CGUIImage::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns: True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

Reimplemented in CGUIAnimatedImage, and CGUIImageStack.

◆ GetBlitType()

BlitType_t CGUIImage::GetBlitType ( ) const

Get currently used blitting-type

Returns: blitting-type

◆ GetImageID()

ImageResource_t CGUIImage::GetImageID ( ) const

Get the ImageID.

Returns: ImageID

◆ GetNinePatch()

CGUINinePatch & CGUIImage::GetNinePatch ( )

Returns the nine-patch for direct modification

Returns: nine-patch

◆ GetStretchBlit()

eC_Bool CGUIImage::GetStretchBlit ( ) const

Sets the stretch blit attribute of the image

Returns: True if image will be stretched

◆ IsHighlightable()

virtual eC_Bool CGUIImage::IsHighlightable ( ) const

inlinevirtual

This method checks if an object is highlightable. This refers to whether it can be highlighted via the event handler. If true the event handler may mark this object as the currently highlighted one. Thus, there is no special flag in CGUIObject that determines if an object is highlightable. The default determination is that the control is in none of the following states:

invisible
grayed-out
disabled if so the return value will be true. NOTE: when an object is not highlightable, it will never receive DoMouseEnter and DoMouseLeave-events
Returns
True if highlightable, False otherwise

Reimplemented from CGUIObject.

◆ operator=()

CGUIImage & CGUIImage::operator= ( const CGUIImage & kSource )

Operator= method of the CGUIImage class.

Parameters

kSource Source object to be copied.

Returns: Copied object.

◆ ReadFromStream()

virtual void CGUIImage::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. Only for use with GUIFactory. GUIStreamingFileReader has to be set in CGUI::Init().

See also: CGUIFactory

Reimplemented from CGUIObject.

Reimplemented in CGUIAnimatedImage, and CGUIImageStack.

◆ SetBlitType()

void CGUIImage::SetBlitType ( const BlitType_t & eBlitType )

Sets the type of blitting for the image

Parameters

eBlitType tpye of blitting

◆ SetImage()

void CGUIImage::SetImage	(	const ImageResource_t &	eImage,
		const eC_Bool &	bFitToImage = `false`
	)

Sets the ID of the image that will be drawn by this control.

Parameters

eImage	An image ID. If it is the same ID as the current one, this method does nothing.
bFitToImage	Specifies whether the CGUIImage object shall be automatically resized to match the given image's dimensions.

◆ SetStretchBlit()

void CGUIImage::SetStretchBlit ( eC_Bool bStretchBlit )

Sets the stretch blit attribute of the image

Parameters

bStretchBlit Specifies whether the CGUIImage object shall be automatically resized to match the given image's dimensions.

◆ WriteToStream()

virtual void CGUIImage::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all object attributes to the streaming file. StreamWriter has to be initialized. Only for use with GUIStreamWriter.

Parameters

bWriteClassID This flag is used to select if writing of ControlID, leading and trailing tags is performed. Only GUIStreamWriter and GUICompositeObject have to set this flag true.

See also: CGUIStreamWriter

Reimplemented from CGUIObject.

Reimplemented in CGUIAnimatedImage, and CGUIImageStack.

The documentation for this class was generated from the following file:

GUIImage.h

Public Types

Public Member Functions

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ BlitType_t

Constructor & Destructor Documentation

◆ CGUIImage() [1/5]

◆ CGUIImage() [2/5]

◆ CGUIImage() [3/5]

◆ CGUIImage() [4/5]

◆ CGUIImage() [5/5]

Member Function Documentation

◆ DoDraw()

◆ GetBlitType()

◆ GetImageID()

◆ GetNinePatch()

◆ GetStretchBlit()

◆ IsHighlightable()

◆ operator=()

◆ ReadFromStream()

◆ SetBlitType()

◆ SetImage()

◆ SetStretchBlit()

◆ WriteToStream()
