This control can be used to draw multiple function-graphs. Attributes for both axis and the visualization of data can be set. More...

#include <GUIGraph.h>

Inheritance diagram for CGUIGraph:

[legend]

Public Member Functions
	CGUIGraph ()
	Default constructor.

	CGUIGraph (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIGraph (const CGUIGraph &kToBeCopied)

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX, const eC_Value &vDeltaY, const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDraw ()

eC_UInt	GetAxisColor () const

eC_Value	GetAxisLineWidth () const

void	GetAxisStyle (CGUICommonEnums::AxisStyle_t &eAxisStyleX, CGUICommonEnums::AxisStyle_t &eAxisStyleY) const

FontResource_t	GetFontID () const

CGUICommonEnums::AxisAlignment_t	GetHelperLines () const

eC_UInt	GetHelperLinesColor () const

eC_Value	GetHelperLineWidth () const

eC_Bool	GetInteractive () const

void	GetLabelSpacing (eC_UInt &uiLabelSpacingX, eC_UInt &uiLabelSpacingY) const

eC_UInt	GetLineColor (const eC_UInt &uiIndex) const

eC_Value	GetLineWidth () const

void	GetLogBase (eC_UInt &uiLogBaseX, eC_UInt &uiLogBaseY)

void	GetOffset (eC_Value &vOffsetX, eC_Value &vOffsetY) const

void	GetScaling (eC_Value &vScalingX, eC_Value &vScalingY) const

eC_UInt	GetValueSpacing () const

virtual eC_Bool	IsHighlightable () const

CGUIGraph &	operator= (const CGUIGraph &kSource)

virtual void	ReadFromStream ()

void	SetAxisColor (const eC_UInt &uiAxisColor)

void	SetAxisColor (const GlobalProperty_t &eAxisColor)

void	SetAxisLineWidth (const eC_Value &vAxisLineWidth)

void	SetAxisStyle (const CGUICommonEnums::AxisStyle_t &eAxisStyleX, const CGUICommonEnums::AxisStyle_t &eAxisStyleY)

void	SetFontID (const FontResource_t &eFontID)

void	SetFunction (const eC_UInt &uiIndex, CGUIGraphFunction *pkFunction)

void	SetHelperLines (const CGUICommonEnums::AxisAlignment_t &eHelperLines)

void	SetHelperLinesColor (const eC_UInt &uiHelperLinesColor)

void	SetHelperLinesColor (const GlobalProperty_t &eHelperLinesColor)

void	SetHelperLineWidth (const eC_Value &vHelperLineWidth)

void	SetInteractive (const eC_Bool &bInteractive)

void	SetLabelSpacing (const eC_UInt &uiLabelSpacingX, const eC_UInt &uiLabelSpacingY)

void	SetLineColor (const eC_UInt &uiIndex, const eC_UInt &uiLineColor)

void	SetLineColor (const eC_UInt &uiIndex, const GlobalProperty_t &eLineColor)

void	SetLineWidth (const eC_Value &vLineWidth)

void	SetLogBase (const eC_UInt &uiLogBaseX, const eC_UInt &uiLogBaseY)

void	SetOffset (const eC_Value &vOffsetX, const eC_Value &vOffsetY)

void	SetScaling (const eC_Value &vScalingX, const eC_Value &vScalingY)

void	SetValueSpacing (const eC_UInt &uiValueSpacing)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

UUID_t	GetUUID () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

void	SetUUID (const UUID_t &kUUID)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoScale (const eC_Value &vDelta)

virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDataPool (const DataPoolResource_t &eID)

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScroll (const eC_Value &vAbsX, const eC_Value &vAbsY, const eC_Value &vDelta, const eC_Bool &bModifierActive)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Public Member Functions inherited from CGUIColorPropertyObserver
	CGUIColorPropertyObserver ()
	default-constructor

	~CGUIColorPropertyObserver ()
	destructor

eC_UInt	AddColorProperty (const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

void	AddColorProperty (const eC_UInt &uiIndex, const eC_Bool &bColorIsProperty, const eC_UInt &uiColorValue, const GlobalProperty_t &eColorProperty)

ColorValue_t	GetColorProperty (const eC_UInt &uiIndex) const

eC_UInt	GetColorValue (const eC_UInt &uiIndex) const

virtual void	OnColorPropertyChange ()

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

void	RemoveColorProperty (const eC_UInt &uiIndex)

void	SetColorProperty (const eC_UInt &uiIndex, const ColorValue_t &kColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const eC_UInt &uiColorValue)

void	SetColorProperty (const eC_UInt &uiIndex, const GlobalProperty_t &eColorProperty)

Public Member Functions inherited from CGUIObserver
	CGUIObserver ()
	Default constructor.

virtual	~CGUIObserver ()
	Default destructor. Notifies all subjects of destruction.

const eC_TListDoubleLinked< CGUISubject * > &	GetSubjectList () const

virtual void	OnNotification ()
	Called by CGUISubject whenever an observed object triggers an update. More...

virtual void	OnNotification (const CGUIObject *const pkUpdatedObject)

virtual void	OnNotification (const CGUIValue &kObservedValue, const CGUIObject *const pkUpdatedObject, const eC_UInt uiX=0, const eC_UInt uiY=0)

virtual void	OnNotification (const eC_String &kMessage)

void	SetAutoDelete (const eC_Bool bAutoDelete)

Additional Inherited Members
Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()

Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_UUID []
	XML tag to be used when writing a UUID into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

static const eC_Char	XMLTAG_BEHAVIOURCOUNT []
	XML tag for count.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Member Functions inherited from CGUIObserver
virtual void	AddSubject (CGUISubject *pSubjectToAdd)

virtual void	RemoveSubject (CGUISubject *pSubjectToRemove)

Protected Attributes inherited from CGUIObject
UUID_t	m_kUUID
	UUID of object.

Detailed Description

This control can be used to draw multiple function-graphs. Attributes for both axis and the visualization of data can be set.

With SetFunction() the corresponding functions can be set which will be called when redrawing the graphs.

The functions must implement CGUIGraphFunction.

Constructor & Destructor Documentation

◆ CGUIGraph() [1/2]

CGUIGraph::CGUIGraph	(	CGUICompositeObject *const	pkParent,
		const eC_Value &	vX,
		const eC_Value &	vY,
		const eC_Value &	vWidth,
		const eC_Value &	vHeight,
		const ObjectHandle_t &	eID = `NO_HANDLE`
	)

Constructor.

Parameters

pkParent	Pointer to the designated parent object.
vX	X-position relative to its parent object, i.e. the x-offset from the left border of the parent object
vY	Y-position relative to its parent object, i.e. the y-offset from the upper border of the parent object
vWidth	Width of the object
vHeight	Height of the object
eID	Object identifier of this object (choose NO_HANDLE if none is required).

◆ CGUIGraph() [2/2]

CGUIGraph::CGUIGraph ( const CGUIGraph & kToBeCopied )

Copy constructor

Parameters

kToBeCopied

Member Function Documentation

◆ DoDoubleClick()

virtual eC_Bool CGUIGraph::DoDoubleClick	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called when an object is clicked twice within a given time span.

See also: CGUIEventHandler::SetDoubleClickTime()

Note: DoDoubleClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the two clicks were done relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoDrag()

virtual eC_Bool CGUIGraph::DoDrag	(	const eC_Value &	vDeltaX,
		const eC_Value &	vDeltaY,
		const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

virtual

Called when the object receives a Drag event. Drags are typically created if the mouse is being used while a mouse-button is being pressed, or if the user moves his finger over a touchscreen.

Parameters

vDeltaX	relative movement in x-direction since the last call of DoDrag/ButtonDown
vDeltaY	relative movement in y-direction since the last call of DoDrag/ButtonDown
vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoDraw()

virtual eC_Bool CGUIGraph::DoDraw ( )

virtual

Visualizes the object. It is forbidden to call SetRelXPos, SetRelYPos, SetWidth or SetHeight in DoDraw, i.e., it is not allowed to change the layout.

Returns: True if anything was drawn, False otherwise

Reimplemented from CGUIObject.

◆ GetAxisColor()

eC_UInt CGUIGraph::GetAxisColor ( ) const

Return the color for the axis as a value

Returns: color of axis

◆ GetAxisLineWidth()

eC_Value CGUIGraph::GetAxisLineWidth ( ) const

Return the line-width for the axis

Returns: line-width

◆ GetAxisStyle()

void CGUIGraph::GetAxisStyle	(	CGUICommonEnums::AxisStyle_t &	eAxisStyleX,
		CGUICommonEnums::AxisStyle_t &	eAxisStyleY
	)		const

Get the axis-style of the y-axis

Parameters

eAxisStyleX
eAxisStyleY

◆ GetFontID()

FontResource_t CGUIGraph::GetFontID ( ) const

Return the font used for the labels

Returns: font-id

◆ GetHelperLines()

CGUICommonEnums::AxisAlignment_t CGUIGraph::GetHelperLines ( ) const

Return alignment of helper-lines

Returns: alignment

◆ GetHelperLinesColor()

eC_UInt CGUIGraph::GetHelperLinesColor ( ) const

Return the color for the helper-lines as a value

Returns: color of helper-lines

◆ GetHelperLineWidth()

eC_Value CGUIGraph::GetHelperLineWidth ( ) const

Return the line-width for the helper-lines

Returns: line-width

◆ GetInteractive()

eC_Bool CGUIGraph::GetInteractive ( ) const

Get interactive-mode

Returns: true if interactive-mode is set, else false

◆ GetLabelSpacing()

void CGUIGraph::GetLabelSpacing	(	eC_UInt &	uiLabelSpacingX,
		eC_UInt &	uiLabelSpacingY
	)		const

Return current spacing for y-axis

Parameters

uiLabelSpacingX	spacing for x-axis in pixels
uiLabelSpacingY	spacing for y-axis in pixels

◆ GetLineColor()

eC_UInt CGUIGraph::GetLineColor ( const eC_UInt & uiIndex ) const

Return the color for graph at specified index

Parameters

uiIndex index of graph

Returns: color as value

◆ GetLineWidth()

eC_Value CGUIGraph::GetLineWidth ( ) const

Return the line-width for the plotted graph

Returns: line-width

◆ GetLogBase()

void CGUIGraph::GetLogBase	(	eC_UInt &	uiLogBaseX,
		eC_UInt &	uiLogBaseY
	)

Return base for logarithmic scale

Parameters

uiLogBaseX	base for x-axis
uiLogBaseY	base for y-axis

◆ GetOffset()

void CGUIGraph::GetOffset	(	eC_Value &	vOffsetX,
		eC_Value &	vOffsetY
	)		const

Return the offset for Y-axis

Parameters

vOffsetX	offset in pixels for x-axis
vOffsetY	offset in pixels for y-axis

◆ GetScaling()

void CGUIGraph::GetScaling	(	eC_Value &	vScalingX,
		eC_Value &	vScalingY
	)		const

Return the currently active scaling

Parameters

vScalingX
vScalingY

◆ GetValueSpacing()

eC_UInt CGUIGraph::GetValueSpacing ( ) const

Return current value-spacing for y-axis

Returns: uiValueSpacingX value-spacing in pixels

◆ IsHighlightable()

virtual eC_Bool CGUIGraph::IsHighlightable ( ) const

inlinevirtual

This method checks if an object is highlightable. This refers to whether it can be highlighted via the event handler. If true the event handler may mark this object as the currently highlighted one. Thus, there is no special flag in CGUIObject that determines if an object is highlightable. The default determination is that the control is in none of the following states:

invisible
grayed-out
disabled if so the return value will be true. NOTE: when an object is not highlightable, it will never receive DoMouseEnter and DoMouseLeave-events
Returns
True if highlightable, False otherwise

Reimplemented from CGUIObject.

◆ operator=()

CGUIGraph & CGUIGraph::operator= ( const CGUIGraph & kSource )

Assignment constructor

Parameters

kSource

Returns: copy

◆ ReadFromStream()

virtual void CGUIGraph::ReadFromStream ( )

virtual

Reads all object attributes from streaming file. This method is called by CGUIFactoryManager after one of the registered factories has created an instance of this class.

Reimplemented from CGUIObject.

◆ SetAxisColor() [1/2]

void CGUIGraph::SetAxisColor ( const eC_UInt & uiAxisColor )

Set the color for the axis as a value

Parameters

uiAxisColor

◆ SetAxisColor() [2/2]

void CGUIGraph::SetAxisColor ( const GlobalProperty_t & eAxisColor )

Set the color for the axis as a property

Parameters

eAxisColor

◆ SetAxisLineWidth()

void CGUIGraph::SetAxisLineWidth ( const eC_Value & vAxisLineWidth )

Set the width for the axis-lines

Parameters

vAxisLineWidth line-width

◆ SetAxisStyle()

void CGUIGraph::SetAxisStyle	(	const CGUICommonEnums::AxisStyle_t &	eAxisStyleX,
		const CGUICommonEnums::AxisStyle_t &	eAxisStyleY
	)

Set the axis-style for the y-axis

Parameters

eAxisStyleX
eAxisStyleY

◆ SetFontID()

void CGUIGraph::SetFontID ( const FontResource_t & eFontID )

Set the font used for labeling the axis

Parameters

eFontID

◆ SetFunction()

void CGUIGraph::SetFunction	(	const eC_UInt &	uiIndex,
		CGUIGraphFunction *	pkFunction
	)

Set function for graph at specified index

Parameters

uiIndex	index of graph
pkFunction	function for graph

◆ SetHelperLines()

void CGUIGraph::SetHelperLines ( const CGUICommonEnums::AxisAlignment_t & eHelperLines )

Set visibility of helper-lines

Parameters

eHelperLines

◆ SetHelperLinesColor() [1/2]

void CGUIGraph::SetHelperLinesColor ( const eC_UInt & uiHelperLinesColor )

Set the color for the helper-lines as a value

Parameters

uiHelperLinesColor

◆ SetHelperLinesColor() [2/2]

void CGUIGraph::SetHelperLinesColor ( const GlobalProperty_t & eHelperLinesColor )

Set the color for the helper-lines as a property

Parameters

eHelperLinesColor

◆ SetHelperLineWidth()

void CGUIGraph::SetHelperLineWidth ( const eC_Value & vHelperLineWidth )

Set the width for the helper-lines

Parameters

vHelperLineWidth line-width

◆ SetInteractive()

void CGUIGraph::SetInteractive ( const eC_Bool & bInteractive )

Set interactive-mode. If true it will be possible to move the area of the control currently displayed by dragging the mouse. a double-click will reset to the center of the view.

Parameters

bInteractive

◆ SetLabelSpacing()

void CGUIGraph::SetLabelSpacing	(	const eC_UInt &	uiLabelSpacingX,
		const eC_UInt &	uiLabelSpacingY
	)

Set spacing for the labels in pixels

Parameters

uiLabelSpacingX	spacing for x-axis in pixels
uiLabelSpacingY	spacing for y-axis in pixels

◆ SetLineColor() [1/2]

void CGUIGraph::SetLineColor	(	const eC_UInt &	uiIndex,
		const eC_UInt &	uiLineColor
	)

Set the color for graph at specified index to color

Parameters

uiIndex	index of graph
uiLineColor	color as value

◆ SetLineColor() [2/2]

void CGUIGraph::SetLineColor	(	const eC_UInt &	uiIndex,
		const GlobalProperty_t &	eLineColor
	)

Set the color for graph at specified index to color

Parameters

uiIndex	index of graph
eLineColor	color as property

◆ SetLineWidth()

void CGUIGraph::SetLineWidth ( const eC_Value & vLineWidth )

Set the width for the plotted graph

Parameters

vLineWidth line-width

◆ SetLogBase()

void CGUIGraph::SetLogBase	(	const eC_UInt &	uiLogBaseX,
		const eC_UInt &	uiLogBaseY
	)

Set base for logarithmic scale

Parameters

uiLogBaseX	base for x-axis
uiLogBaseY	base for y-axis

◆ SetOffset()

void CGUIGraph::SetOffset	(	const eC_Value &	vOffsetX,
		const eC_Value &	vOffsetY
	)

Set offset for Y-axis This is the number of pixels the center is moved in horizontal/vertical direction.

Parameters

vOffsetX	offset in pixels for x-axis
vOffsetY	offset in pixels for y-axis

◆ SetScaling()

void CGUIGraph::SetScaling	(	const eC_Value &	vScalingX,
		const eC_Value &	vScalingY
	)

Set the scaling for the axis in pixels per value A setting of 10.0 will plot a value every 10 pixels. A setting below 1.0 for the x-axis is not accepted. The scaling for the x-axis is also used to display the scale

Parameters

vScalingX	scaling for x-axis
vScalingY	scaling for y-axis

◆ SetValueSpacing()

void CGUIGraph::SetValueSpacing ( const eC_UInt & uiValueSpacing )

Set spacing for the values in pixels The spacing will be used avoid calculating every value for the function. Instead the calculation will only be done in intervals of this value in pixels

Parameters

uiValueSpacing value spacing in pixels

◆ WriteToStream()

virtual void CGUIGraph::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all object attributes to the streaming file. A CGUIStreamWriter has to be initialized first.

Parameters

bWriteClassID This flag is used to select if writing of ControlID, leading and trailing tags is performed.

Reimplemented from CGUIObject.

The documentation for this class was generated from the following file:

GUIGraph.h

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ CGUIGraph() [1/2]

◆ CGUIGraph() [2/2]

Member Function Documentation

◆ DoDoubleClick()

◆ DoDrag()

◆ DoDraw()

◆ GetAxisColor()

◆ GetAxisLineWidth()

◆ GetAxisStyle()

◆ GetFontID()

◆ GetHelperLines()

◆ GetHelperLinesColor()

◆ GetHelperLineWidth()

◆ GetInteractive()

◆ GetLabelSpacing()

◆ GetLineColor()

◆ GetLineWidth()

◆ GetLogBase()

◆ GetOffset()

◆ GetScaling()

◆ GetValueSpacing()

◆ IsHighlightable()

◆ operator=()

◆ ReadFromStream()

◆ SetAxisColor() [1/2]

◆ SetAxisColor() [2/2]

◆ SetAxisLineWidth()

◆ SetAxisStyle()

◆ SetFontID()

◆ SetFunction()

◆ SetHelperLines()

◆ SetHelperLinesColor() [1/2]

◆ SetHelperLinesColor() [2/2]

◆ SetHelperLineWidth()

◆ SetInteractive()

◆ SetLabelSpacing()

◆ SetLineColor() [1/2]

◆ SetLineColor() [2/2]

◆ SetLineWidth()

◆ SetLogBase()

◆ SetOffset()

◆ SetScaling()

◆ SetValueSpacing()

◆ WriteToStream()
