CGfxWrapGL Class Reference

OpenGL graphic wrapper base class. This is the base class for all OpenGL related graphic wrappers (OpenGL and OpenGL-ES). More...

#include <GfxWrapGL.h>

Inheritance diagram for CGfxWrapGL:

Public Member Functions
virtual void	Arc (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)
void	BindBuffer (const eC_UInt &eType, const eC_UInt &uiBuffer)
void	BindTexture (const eC_UInt &eType, const eC_UInt &uiTextureID)
void	CreateScreen (const eC_UInt &uiWidth, const eC_UInt &uiHeight)
eC_UInt	CreateTexture ()
void	DeleteTexture (const eC_UInt &uiTextureID)
void	DisableBlending ()
	disable blending
virtual eC_Bool	DrawToBitmap (GUIBitmapPlaneID_t uiBitmapID)
virtual eC_Bool	DrawToScreen ()
virtual void	Ellipse (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Bool &bFilled)
void	EnableBlending ()
	enable blending
virtual void	FilledRect (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2)
CGUIImageDataGL *	GetImageData (const ImageResource_t &eImageID)
virtual eC_UInt	GetPhysicalScreenHeight ()
virtual eC_UInt	GetPhysicalScreenWidth ()
const eC_UInt	GetTextureID (const ImageResource_t &eImageID)
eC_UInt	GetVBO () const
virtual eC_UInt	GetVirtualScreenHeight ()
virtual eC_UInt	GetVirtualScreenWidth ()
virtual eC_Bool	ImageExists (const ImageResource_t eID) const
void	InitGLProcs ()
virtual eC_Bool	InitView ()
eC_Bool	IsFBOSupported () const
virtual void	Line (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2)
virtual void	Polygon (eC_Value *pvPoints, const eC_UInt &uiCount, const eC_Bool &bFilled)
virtual void	ReadTextureData (const eC_UInt &uiTexID, const eC_UInt &uiXPos, const eC_UInt &uiYPos, const eC_UInt &uiWidth, const eC_UInt &uiHeight, void *pkData)=0
virtual void	Rect (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2)
virtual void	RestoreWrapperState ()
virtual void	Ring (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Value &vRingWidth, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)
void	Set2DView ()
void	Set2DView (const eC_UInt uiWidth, const eC_UInt uiHeight)
void	SetClientStates (const eC_Bool &bVertexEnabled, const eC_Bool &bTextureCoordsEnabled)
virtual void	SetCliprect (const CGUIRect &rkNewClipRect)
virtual void	SetForegroundColorImpl (const eC_UByte &ubRed, const eC_UByte &ubGreen, const eC_UByte &ubBlue, const eC_UByte &ubAlpha=255)
virtual eC_Value	SetLineWidth (const eC_Value &vWidth)
void	SetMixTextureWithColor (const eC_Bool &bMixWithColor)
void	SetPerspectiveProjection (const eC_Value &vFovy, const eC_Value &vAspect, const eC_Value &vNear, const eC_Value &vFar)
virtual void	SetScreenSize (const eC_UInt &uiWidth, const eC_UInt &uiHeight)
void	SetTexturingActive (const eC_Bool &bTexturingActive)
virtual void	StoreWrapperState ()
Public Member Functions inherited from CGfxWrap
void	ForceRefresh ()
eC_Bool	GetDoubleBufferingEnforcesFlipping ()
eC_Bool	GetFilteredBlit () const
virtual eC_UInt	GetNOFImages ()
eC_Bool	GetOptimizedBlit () const
virtual eC_UInt	GetPhysicalScreenHeight ()=0
virtual eC_UInt	GetPhysicalScreenWidth ()=0
CGUICommonEnums::ImageType_t	GetScreenFormat () const
virtual eC_UInt	GetScreenHorizontalPPI () const
virtual eC_UInt	GetScreenVerticalPPI () const
virtual eC_UInt	GetVirtualScreenHeight ()=0
virtual eC_UInt	GetVirtualScreenWidth ()=0
eC_String	GetWrapperName () const
virtual eC_Bool	ImageExists (const ImageResource_t eID) const =0
virtual void	RestoreWrapperState ()
void	SetDoubleBufferingEnforcesFlipping (const eC_Bool bDoubleBufferingEnforcesFlipping)
virtual void	SetFilteredBlit (const eC_Bool &bFilteredBlit)
void	SetGfxEnv (CGfxEnv *pkGfxEnv)
virtual void	SetOptimizedBlit (const eC_Bool &bOptimizedBlit)
void	SetScreenFormat (const CGUICommonEnums::ImageType_t &uiScreenFormat)
virtual void	SetScreenSize (const eC_UInt &uiWidth, const eC_UInt &uiHeight)
virtual void	SetWindowCaption (const eC_String &kText)
virtual void	StoreWrapperState ()
void	SetForegroundColor (const eC_UByte &ubRed, const eC_UByte &ubGreen, const eC_UByte &ubBlue, const eC_UByte &ubAlpha=255)
void	SetForegroundColor (const eC_UInt &uiCol)
void	UpdateGlobalAlpha (const eC_UByte &ubAlpha)
void	SetGlobalAlpha (const eC_UByte &ubAlpha)
eC_UInt	GetForegroundColor () const
eC_UByte	GetGlobalAlpha () const
eC_UByte	ApplyGlobalAlpha (const eC_UByte ubAlpha) const
void	Line (const CGUIRect &kAbsRect)
void	Rect (const CGUIRect &kAbsRect)
void	FilledRect (const CGUIRect &kAbsRect)
void	Ellipse (const CGUIRect &kAbsRect, const eC_Bool &bFilled)
void	Arc (const CGUIRect &kAbsRect, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)
void	Ring (const CGUIRect &kAbsRect, const eC_Value &vRingWidth, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)
void	Polygon (CGUIPoint *pkPoints, const eC_UInt &uiCount, const eC_Bool &bFilled)
void	Text (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_String *const lpString)
virtual void	RedrawGUI ()
virtual void	ResetCliprect ()
	Resets the clipping rectangle.
virtual void	GetCliprect (CGUIRect &AbsClipRect) const
void	InvalidateRect (const CGUIRect &kInvalidRect)
void	InvalidateRect (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2)
const CGUIRect &	GetInvalidatedRect () const
virtual void	ClearInvalidRect ()
void	BlitImg (const ImageResource_t &eID, const eC_Value &vAbsDestX, const eC_Value &vAbsDestY)
void	BlitImg (const CGUIImageData &kImageData, const eC_Value &vAbsDestX, const eC_Value &vAbsDestY)
void	BlitImgExt (const ImageResource_t &eID, const eC_Value &vAbsDestX, const eC_Value &vAbsDestY, const eC_Value &vWidth, const eC_Value &vHeight, const eC_Bool &bStretch=true, const eC_UByte &ubAlpha=255)
void	BlitImgNinePatch (const ImageResource_t &eID, const CGUIRect &kAbsRect, const CGUINinePatch &kNinePatch, const eC_UByte &ubAlpha=255)
void	BlitImgExt (const ImageResource_t &eID, const CGUIRect &kAbsRect, const eC_Bool &bStretch=true, const eC_UByte &ubAlpha=255)
void	BlitImgExt (const ImageResource_t &eID, const CGUIRect &kSrcAbsRect, const CGUIRect &kDstAbsRect, const eC_UByte &ubAlpha=255)
void	BlitImgExt (const ImageResource_t &eID, const eC_UInt &uiAbsSrcX, const eC_UInt &uiAbsSrcY, const eC_UInt &uiSrcWidth, const eC_UInt &uiSrcHeight, const eC_Value &vAbsDestX, const eC_Value &vAbsDestY, const eC_Value &vDestWidth, const eC_Value &vDestHeight, const eC_UByte &ubAlpha=255, const eC_Value &vAngle=eC_FromFloat(0), const eC_Value &vRotCenterX=eC_FromFloat(0.5), const eC_Value &vRotCenterY=eC_FromFloat(0.5))
eC_UInt	GetImgWidth (const ImageResource_t &eID) const
eC_UInt	GetImgHeight (const ImageResource_t &eID) const
CGUIRect	GetImgOriginRect (const ImageResource_t &eID) const
void	SetFont (const FontResource_t &eID)
void	SetFontSpacing (const eC_Float &fSpacing)
void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)
void	FittingNumChars (const eC_String *const pkText, eC_Value vWidthMax, eC_UInt &uiNumChars, const eC_Bool &bStartAtEnd=false)
eC_Int	GetAscender () const
eC_Int	GetDescender () const
eC_Int	GetInternalLeading () const
void	GetGlyphMetrics (const eC_Char cChar, CFntWrap::GlyphMetrics_t &kMetrics)
eC_Value	GetTextXPosAdjustment (const CGUIText::HorAligned_t eHorAlignment)
eC_Value	GetTextYPosAdjustment (const CGUIText::VerAligned_t eVerAlignment)
eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)
eC_UInt	GetNOFFonts ()
void	ChangeFont (const FontResource_t &eFontID, const eC_Char *const pcPath, const eC_UInt &uiFontSize, const CFntWrap::GUIFont_t &eFontStyle)
void	LoadFont (const FontResource_t &eFontID)
void	UnloadFont (const FontResource_t &eFontID)
virtual eC_Bool	SupportCompressedFonts () const
virtual void	LoadGlyphData (CGUIImageData *pkImageData, const eC_UInt &uiGlyphWidth, const eC_UInt &uiGlyphHeight, eC_UByte *pkGlyphBitmap)
virtual void	UnloadGlyphData (CGUIImageData *pkImageData)
virtual eC_TArray< eC_UByte > *	GetBitmapPlaneData (const GUIBitmapPlaneID_t &eBitmapPlaneID)
virtual void	SetTargetLayer (const eC_UInt &uiLayerID)
virtual void	SetRenderingOffset (const eC_Value &vOffsetX, const eC_Value &vOffsetY)
void	GetRenderingOffset (eC_Value &vOffsetX, eC_Value &vOffsetY)
virtual GUIBitmapPlaneID_t	CreateBitmapPlane (const CGUIObject &rkParentObject, const eC_Value &vWidth, const eC_Value &vHeight)
void	DeleteBitmapPlane (const GUIBitmapPlaneID_t uiBitmapID)
void	DeleteBitmapPlanes (const CGUIObject *pkObject)
CGUIBitmapPlane &	GetBitmapPlane (const GUIBitmapPlaneID_t uiBitmapID)
GUIBitmapPlaneID_t	GetUsedBitmapPlaneID () const

Static Public Member Functions
static eC_Bool	CheckGLError (const eC_String &kCallingMethod, const eC_String &kFunction="")
Static Public Member Functions inherited from CGfxWrap
static void	DeleteInstance ()
	Delete the graphics wrapper instance.
static eC_UInt	GetNextPowerOf2 (const eC_Value &vValue)

Static Public Attributes
static const eC_Value	cvPixelCenterOffset

Protected Member Functions
	CGfxWrapGL (void)
	Constructor.
virtual	~CGfxWrapGL (void)
	Destructor.
virtual void	BlitImgExtImpl (const CGUIImageData &kImageData, const eC_Value &vAbsDestX, const eC_Value &vAbsDestY)
virtual void	BlitImgExtImpl (const ImageResource_t &eID, const eC_UInt &uiSrcX, const eC_UInt &uiSrcY, const eC_UInt &uiSrcWidth, const eC_UInt &uiSrcHeight, const eC_Value &vDestX, const eC_Value &vDestY, const eC_Value &vDestWidth, const eC_Value &vDestHeight, const eC_UByte &ubAlpha=255, const eC_Value &vAngle=eC_FromFloat(0), const eC_Value &vRotCenterX=eC_FromFloat(0.5), const eC_Value &vRotCenterY=eC_FromFloat(0.5))
virtual void	BlitImgNinePatch (const ImageResource_t &eID, const CGUIRect &kAbsRect, const eC_UInt uiTopBorder, const eC_UInt uiBottomBorder, const eC_UInt uiLeftBorder, const eC_UInt uiRightBorder, const eC_UByte &ubAlpha)
void	BlitNinePatchExt ()
	helper for blitting ninepatch
virtual CGUIBitmapPlane *	CreateGfxDependentBitmap (GUIBitmapPlaneID_t uiNewBitmapID, const CGUIObject &rkParentObject, const eC_Value &vWidth, const eC_Value &vHeight)
void	DeInit (void)
void	DrawRect (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Bool bFilled)
void	GenerateTexture (const ImageResource_t &eImageID)
virtual eC_UInt	GetImageSize (const ImageResource_t &eID) const
virtual eC_UInt	GetImgHeightImpl (const ImageResource_t &eID) const
virtual eC_UInt	GetImgWidthImpl (const ImageResource_t &eID) const
eC_Value	GetZCorrection ()
void	IncreaseZCorrection ()
void	Init (void)
virtual void	LoadImgImpl (const eC_String &psPath, const ImageResource_t &eID)
virtual void	LoadImgImpl (void *pkMemory, const eC_UInt &uiWidth, const eC_UInt &uiHeight, const eC_UInt &eImageType, const ImageResource_t &eID)
virtual void	RestoreBackBuffer (const eC_Value vWidth, const eC_Value vHeight)
void	SetCliprect (const CGUIRect &rkNewClipRect, const eC_Bool &bRotate)
eC_Bool	SetNOFImagesImpl (const eC_UInt uiNOFImages)
void	SetScissor (const eC_Bool &bEnabled, const eC_Int &iX=0, const eC_Int &iY=0, const eC_Int &iWidth=0, const eC_Int &iHeight=0)
virtual void	UnloadImg (const ImageResource_t &eID)
Protected Member Functions inherited from CGfxWrap
	CGfxWrap ()
	Constructor.
virtual	~CGfxWrap (void)
	Destructor.
virtual void	Arc (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)=0
void	DeInit ()
	Deinitialization.
virtual void	Ellipse (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2, const eC_Bool &bFilled)=0
virtual void	FilledRect (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2)=0
void *	GetWorkingMemory (const eC_UInt &uiSize)
virtual void	Line (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2)=0
	the following methods are protected to prevent calling them directly More...
virtual void	Polygon (eC_Value *pvPoints, const eC_UInt &uiCount, const eC_Bool &bFilled)=0
virtual void	Rect (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2)=0
void	ReleaseWorkingMemory ()
virtual void	Ring (const eC_Value &vX1, const eC_Value &vY1, const eC_Value &vX2, const eC_Value &vY2, const eC_Value &vRingWidth, const eC_Value &vStartAngle, const eC_Value &vEndAngle, const eC_Value &vRotationAngle, const eC_Bool &bFilled)=0
virtual void	SetForegroundColorImpl (const eC_UByte &ubRed, const eC_UByte &ubGreen, const eC_UByte &ubBlue, const eC_UByte &ubAlpha=255)=0
virtual eC_Bool	Refresh (const RefreshCall_t eRefreshCallType)=0
virtual void	StartHandleDraw (const CGUIRect &crkClipRect)
virtual void	StartRedrawGUI ()
virtual void	EndRedrawGUI ()
	Callback which is called at the end of RedrawGUI() after all Invalidated areas were drawn and refreshed.
virtual void	DestroyScreen ()
	Method to clean and release the screen which was created via the CreateScreen Method. More...
eC_Bool	SetNOFImages (const eC_UInt uiNOFImages)
void	LoadImg (const eC_String &kPath, const ImageResource_t &eID)
void	LoadImg (void *pkMemory, const eC_UInt &uiWidth, const eC_UInt &uiHeight, const eC_UInt &eImageType, const ImageResource_t &eID)
virtual void	RefreshImage (const ImageResource_t &eID, void *pkMemory)
void	SetInvalidatedRect (const eC_Value &vAbsX1, const eC_Value &vAbsY1, const eC_Value &vAbsX2, const eC_Value &vAbsY2)
void	SetInvalidatedRect (const CGUIRect &NewAbsRect)
void	ResetInvalidatedRect ()
	Resets the invalidated rectangle.
CGUIBitmapPlane &	GetDummyBitmap ()
virtual eC_Bool	FinishDrawToBitmap ()

Protected Attributes
eC_TArray< CGUIImageDataGL * >	m_apTextures
	used textures
Matrix3D_t	m_avTransMat
	transition matrix
eC_Bool	m_bFBOSupported
	< Indicates if FrameBufferObjects are supported on this machine
eC_UInt	m_uiVertexVBO
	vertex buffer object
eC_Value	m_vAlpha
	alpha
eC_Value	m_vAspect
	aspect-ratio
eC_Value	m_vBlue
	blue
eC_Value	m_vDepthCorrection
	depth-corretion
eC_Value	m_vFar
	far-plane
eC_Value	m_vFovy
	fov
eC_Value	m_vGreen
	green
eC_Value	m_vNear
	near-plane
eC_Value	m_vRed
	red
Protected Attributes inherited from CGfxWrap
eC_Bool	m_bDoubleBufferingEnforcesFlipping
eC_Bool	m_bFilteredBlit
	if filtered blit is active
eC_Bool	m_bInvalidationInLastFrame
eC_Bool	m_bOptimizedBlit
	if optimized blit is active
CGUIRect	m_kClippingRect
eC_Semaphore	m_kGfxWrapSemaphore
	Semaphore to lock access to methods used in a multi thread context.
CGUIRect	m_kInvalidatedRect
eC_TListDoubleLinked< CGUIRect >	m_kInvalidatedRectList
	This is the list of invalidated rectangular regions within the GUI.
eC_TListDoubleLinked< CGUIRect >	m_kLastFrameInvalidatedRectList
	This is the list of regions which have been invalidated during the LAST frame.
eC_String	m_kWrapperName
	name of the wrapper
CGfxEnv *	m_pkGfxEnv
	pointer to the graphics-environment
WorkingMemory *	m_pkWorkingMemory
	working memory
eC_UByte	m_ubAlpha
	Currently set global alpha value.
eC_UInt	m_uiColor
	Currently set foreground color.
eC_UInt	m_uiNOFImages
	total number of image-objects
eC_UInt	m_uiScreenHeight
	Screen height.
eC_UInt	m_uiScreenWidth
	Screen width.
eC_Value	m_vGlobalAlphaFactor
eC_Value	m_vLineWidth
	Line width in pixels.
eC_Value	m_vRenderingOffsetX
	offset in x-direction
eC_Value	m_vRenderingOffsetY
	offset in y-direction

Friends
class	CGUIBitmapPlane_GL

Additional Inherited Members
Public Types inherited from CGfxWrap
enum	RefreshCall_t {   SINGLE_REFRESH , FIRST_REFRESH_OF_FRAME , INTERMEDIATE_REFRESH , LAST_REFRESH_OF_FRAME ,   FORCED_REFRESH }
Static Protected Attributes inherited from CGfxWrap
static const eC_Value	cvTwoPi
	constant for 2 PI

Detailed Description

OpenGL graphic wrapper base class. This is the base class for all OpenGL related graphic wrappers (OpenGL and OpenGL-ES).

To understand how Guiliani is handling coordinatesystems under OpenGL please

See also

cvPixelCenterOffset.

Member Function Documentation

Arc()

virtual void CGfxWrapGL::Arc ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2, const eC_Value &  vStartAngle, const eC_Value &  vEndAngle, const eC_Value &  vRotationAngle, const eC_Bool &  bFilled  )

virtual

Draws an arc which is completly inside the rectangle described through the rectangle the top left edge at (vAbsX1, vAbsY1) and bottom right edge at (vAbsX2, vAbsY2). The arc will be filled out if the last parameter is true

Parameters

vX1	X-coordinate of bounding rectangle's top left corner
vY1	Y-Coordinate of bounding rectangle's top left corner
vX2	X-coordinate of bounding rectangle's bottom right corner
vY2	Y-Coordinate of bounding rectangle's bottom right corner
vStartAngle	start-angle
vEndAngle	end-angle
vRotationAngle	rotation-angle
bFilled	Specifies whether the arc will be drawn outlined (false) or filled (true)

Implements CGfxWrap.

BindBuffer()

void CGfxWrapGL::BindBuffer	(	const eC_UInt &	eType,
		const eC_UInt &	uiBuffer
	)

Bind buffer

Parameters

eType
uiBuffer

BindTexture()

void CGfxWrapGL::BindTexture	(	const eC_UInt &	eType,
		const eC_UInt &	uiTextureID
	)

Bind texture

Parameters

eType
uiTextureID

BlitImgExtImpl() [1/2]

virtual void CGfxWrapGL::BlitImgExtImpl ( const CGUIImageData &  kImageData, const eC_Value &  vAbsDestX, const eC_Value &  vAbsDestY  )

inlineprotectedvirtual

Blits an image. This MUST be implemented by all graphics wrappers. It is ensured that the supplied image ID is in the valid range and is not DUMMY_IMAGE. For detailed explanations, please refer to CGfxWrap::BlitImgExt

Parameters

kImageData	ImageData
vAbsDestX	Destination X position in absolute coordinates
vAbsDestY	Destination Y position in absolute coordinates

Implements CGfxWrap.

BlitImgExtImpl() [2/2]

virtual void CGfxWrapGL::BlitImgExtImpl ( const ImageResource_t &  eID, const eC_UInt &  uiAbsSrcX, const eC_UInt &  uiAbsSrcY, const eC_UInt &  uiSrcWidth, const eC_UInt &  uiSrcHeight, const eC_Value &  vAbsDestX, const eC_Value &  vAbsDestY, const eC_Value &  vDestWidth, const eC_Value &  vDestHeight, const eC_UByte &  ubAlpha = 255, const eC_Value &  vAngle = eC_FromFloat(0), const eC_Value &  vRotCenterX = eC_FromFloat(0.5), const eC_Value &  vRotCenterY = eC_FromFloat(0.5)  )

protectedvirtual

Blits an image. This MUST be implemented by all graphics wrappers. It is ensured that the supplied image ID is in the valid range and is not DUMMY_IMAGE. For detailed explanations, please refer to CGfxWrap::BlitImgExt

Parameters

eID	Identifier of the image to be blitted.
uiAbsSrcX	X coordinate of upper left corner of the relevant area within the source image
uiAbsSrcY	Y coordinate of upper left corner of the relevant area within the source image
uiSrcWidth	Width of the relevant area within the source image
uiSrcHeight	Height of the relevant area within the source image
vAbsDestX	Destination X position in absolute coordinates
vAbsDestY	Destination Y position in absolute coordinates
vDestWidth	Destination width
vDestHeight	Destination height
ubAlpha	Degree of transparency. 0=transparent 255=opaque Default is opaque.
vAngle	Angle in degrees by which the image will be rotated
vRotCenterX	Rotation center X. In range of 0 to 1 (like U/V coordinates)
vRotCenterY	Rotation center Y. In range of 0 to 1 (like U/V coordinates)

Implements CGfxWrap.

BlitImgNinePatch()

virtual void CGfxWrapGL::BlitImgNinePatch ( const ImageResource_t &  eID, const CGUIRect &  kAbsRect, const eC_UInt  uiTopBorder, const eC_UInt  uiBottomBorder, const eC_UInt  uiLeftBorder, const eC_UInt  uiRightBorder, const eC_UByte &  ubAlpha  )

protectedvirtual

Nine-Patch blit of an image. Performs an intelligent 9-patch stretch blit of the image associated with the supplied Image Identifier. The image will be blitted to the position given by the upper left corner of the supplied rectangle and stretched to the desired width and height. To reduce visual artifacts during stretching, the image will automatically be split up into 9 parts. The four corners will be left unscaled, the four edges are each scaled in one axis, and the middle part is stretched in both axes. The two parameters uiXBorder and uiYBorder specify the width/height of the sections in pixels.

See also

CGUINinePatch

Parameters

eID	Identifier of the image to be blitted.
kAbsRect	Rectangle describing the destination position and size of the image on the screen
uiTopBorder	Height of the topmost three sections of the Nine-patch in pixels
uiBottomBorder	Height of the lowermost three sections of the Nine-patch in pixels
uiLeftBorder	Width of the leftmost three sections of the Nine-patch in pixels
uiRightBorder	Width of the rightmost three sections of the Nine-patch in pixels
ubAlpha	Degree of transparency. 0=transparent 255=opaque. Default is opaque.

Reimplemented from CGfxWrap.

CheckGLError()

static eC_Bool CGfxWrapGL::CheckGLError ( const eC_String &  kCallingMethod, const eC_String &  kFunction = ""  )

static

Checks for occurency of OpenGL Erros. All OpenGL errors (error code and text) since the last call of this function (or glGetError) are log in the Guiliani Log.

Parameters

kCallingMethod	String which will be added to the Log entry.
kFunction	name of function

Returns

True if successful, False otherwise

CreateGfxDependentBitmap()

virtual CGUIBitmapPlane * CGfxWrapGL::CreateGfxDependentBitmap ( GUIBitmapPlaneID_t  uiNewBitmapID, const CGUIObject &  rkParentObject, const eC_Value &  vWidth, const eC_Value &  vHeight  )

protectedvirtual

Method which will be called by CreateBitmap to instantiate a new Bitmap-Object. This Method needs to be implemented by every derived GfxWrapper. If a GfxWrapper does not support Bitmap-Handling, he may create an CGUIBaseBitmap

See also

Bitmap planes

Parameters

uiNewBitmapID	ID of the new BitmapPlane
rkParentObject	reference to the GUIObject which will be the parent of the bitmap
vWidth	width of the new bitmap
vHeight	height of the new bitmap

Returns

pointer to the new created BitmapObject

Reimplemented from CGfxWrap.

Reimplemented in CGfxWrapOGL, CGfxWrapOGLES1_1, and CGfxWrapOGLES2.

CreateScreen()

void CGfxWrapGL::CreateScreen	(	const eC_UInt &	uiWidth,
		const eC_UInt &	uiHeight
	)

create screen

Parameters

uiWidth
uiHeight

CreateTexture()

eC_UInt CGfxWrapGL::CreateTexture

(

)

Create texture

Returns

texture-id

DeInit()

void CGfxWrapGL::DeInit ( void  )

protected

Method to give the graphic library the opportunity to clean up

DeleteTexture()

void CGfxWrapGL::DeleteTexture

(

const eC_UInt &

uiTextureID

)

delete texture

Parameters

uiTextureID

DrawRect()

void CGfxWrapGL::DrawRect ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2, const eC_Bool  bFilled  )

protected

Draws a rectangle

Parameters

vX1	X position of corner 1
vY1	Y position of corner 1
vX2	X position of corner 2
vY2	Y position of corner 2
bFilled	Whether to draw a filled rectangle

DrawToBitmap()

virtual eC_Bool CGfxWrapGL::DrawToBitmap ( GUIBitmapPlaneID_t  uiBitmapID )

virtual

Changes the RenderTarget to the BitmapPlane with the given ID. All successive GfxWrap draw commands will be done in the bitmap of this plane instead of within the framebuffer

Parameters

uiBitmapID

ID of the BitmapPlane in which will be drawn.

Returns

True if the BitmapPlane with given ID exists, otherwise False

Reimplemented from CGfxWrap.

DrawToScreen()

virtual eC_Bool CGfxWrapGL::DrawToScreen ( )

virtual

Activates the Screen as active RenderTarget again

Returns

True if the changing was successful, otherwise False

Reimplemented from CGfxWrap.

Ellipse()

virtual void CGfxWrapGL::Ellipse ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2, const eC_Bool &  bFilled  )

virtual

Draws an ellipse which is complete inside the rectangle described through the rectangle the top left edge at (vX1, vY1) and bottom right edge at (vX2, vY2). The ellipse will be filled out if the last parameter is true

Parameters

vX1	X-Coordinate of bounding rectangle's top left corner
vY1	Y-Coordinate of bounding rectangle's top left corner
vX2	X-Coordinate of bounding rectangle's bottom right corner
vY2	Y-Coordinate of bounding rectangle's bottom right corner
bFilled	Specifies whether the ellipse will be drawn outlined (false) or filled (true)

Implements CGfxWrap.

FilledRect()

virtual void CGfxWrapGL::FilledRect ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2  )

virtual

Draws a filled rectangle with the top left edge at (vX1, vY1) and bottom right edge at (vX2, vY2)

Parameters

vX1	X-Coordinate of top left corner
vY1	Y-Coordinate of top left corner
vX2	X-Coordinate of bottom right corner
vY2	Y-Coordinate of bottom right corner

Implements CGfxWrap.

GenerateTexture()

void CGfxWrapGL::GenerateTexture ( const ImageResource_t &  eImageID )

protected

Generates a texture of matching (power of 2) size for the given image ID and copies the image into it

Parameters

eImageID

ImageID for which the texture should be created.

GetImageData()

CGUIImageDataGL * CGfxWrapGL::GetImageData

(

const ImageResource_t &

eImageID

)

Gets pointer to an image data object.

Parameters

eImageID

Image data object to be returned.

Returns

Pointer to image data object.

GetImageSize()

virtual eC_UInt CGfxWrapGL::GetImageSize ( const ImageResource_t &  eID ) const

protectedvirtual

Returns the amount of memory taken up by an image.

Parameters

eID	ID of the image to be measured.

Returns

Size of the image in byte.

Implements CGfxWrap.

GetImgHeightImpl()

virtual eC_UInt CGfxWrapGL::GetImgHeightImpl ( const ImageResource_t &  eID ) const

protectedvirtual

Gets the height of an image.

Parameters

eID	Identifier of the image.

Returns

The height of the image in pixels.

Implements CGfxWrap.

GetImgWidthImpl()

virtual eC_UInt CGfxWrapGL::GetImgWidthImpl ( const ImageResource_t &  eID ) const

protectedvirtual

Gets the width of an image.

Parameters

eID	Identifier of the image.

Returns

The width of the image in pixels.

Implements CGfxWrap.

GetPhysicalScreenHeight()

virtual eC_UInt CGfxWrapGL::GetPhysicalScreenHeight ( )

virtual

Returns the screen height. Will always return the physical screen height with which the GfxWrap was originally initialized. Regardless of whether the virtual screen size has been modified e.g. while drawing into a CGUIBitmapPlane.

Returns

Physical screen height

Implements CGfxWrap.

GetPhysicalScreenWidth()

virtual eC_UInt CGfxWrapGL::GetPhysicalScreenWidth ( )

virtual

Returns the screen width. Will always return the physical screen width with which the GfxWrap was originally initialized. Regardless of whether the virtual screen size has been modified e.g. while drawing into a CGUIBitmapPlane.

Returns

Physical screen width

Implements CGfxWrap.

GetTextureID()

const eC_UInt CGfxWrapGL::GetTextureID

(

const ImageResource_t &

eImageID

)

Returns the TextureID and generates the texture if needed

Parameters

eImageID

The image ID

Returns

The texture ID

GetVBO()

eC_UInt CGfxWrapGL::GetVBO ( ) const

inline

Returns the currently used vertex buffer object.

Returns

Vertex buffer object.

GetVirtualScreenHeight()

virtual eC_UInt CGfxWrapGL::GetVirtualScreenHeight ( )

virtual

Returns the screen height in pixels, may vary if DrawToBitmap is active. It will then return the active BitmapPlane's height instead.

See also

GetPhysicalScreenHeight()

Returns

eC_UInt The screen height

Implements CGfxWrap.

GetVirtualScreenWidth()

virtual eC_UInt CGfxWrapGL::GetVirtualScreenWidth ( )

virtual

Returns the screen width in pixels, may vary if DrawToBitmap is active. It will then return the active BitmapPlane's width instead.

See also

GetPhysicalScreenWidth()

Returns

eC_UInt The screen width

Implements CGfxWrap.

GetZCorrection()

eC_Value CGfxWrapGL::GetZCorrection ( )

protected

Accessing the Z-Correction for current render target. Render targets may be the screen or any BitmapPlane.

Returns

returns the current z-correction for the active render target.

ImageExists()

virtual eC_Bool CGfxWrapGL::ImageExists ( const ImageResource_t  eID ) const

virtual

Returns whether the image with the given ID currently is loaded within the Graphics Wrapper. This interface must be implemented by derived graphics wrappers.

Parameters

eID	The ID to check

Returns

True if the image with the given ID is currently loaded, False otherwise.

Implements CGfxWrap.

IncreaseZCorrection()

void CGfxWrapGL::IncreaseZCorrection ( )

protected

Increases the Z-Correction for the current render target. The render target may be the screen or any BitmapPlane.

Init()

void CGfxWrapGL::Init ( void  )

protected

Method to initialize the graphic library

InitGLProcs()

void CGfxWrapGL::InitGLProcs

(

)

Initialize function pointers to gl-functions

InitView()

virtual eC_Bool CGfxWrapGL::InitView ( )

virtual

Helper for initialization

Returns

IsFBOSupported()

eC_Bool CGfxWrapGL::IsFBOSupported ( ) const

inline

Check if FBO is supported

Returns

Line()

virtual void CGfxWrapGL::Line ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2  )

virtual

Draws a line from (vX1, vY1) to (vX2, vY2)

Parameters

vX1	X-Coordinate of starting point
vY1	Y-Coordinate of starting point
vX2	X-Coordinate of ending point
vY2	Y-Coordinate of ending point

Implements CGfxWrap.

LoadImgImpl() [1/2]

virtual void CGfxWrapGL::LoadImgImpl ( const eC_String &  psPath, const ImageResource_t &  eID  )

protectedvirtual

Loads an image. This loads an image from the given path and associates it with an Image-Identifier.

Parameters

psPath	Complete path and filename of the image to be loaded.
eID	ID by which the image will later be accessible.

Implements CGfxWrap.

LoadImgImpl() [2/2]

virtual void CGfxWrapGL::LoadImgImpl ( void *  pkMemory, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight, const eC_UInt &  eImageType, const ImageResource_t &  eID  )

protectedvirtual

Loads an image file from disk. Internally called by ResourceManager.

Parameters

pkMemory	memory-location
uiWidth
uiHeight
eImageType
eID	image-id which will be set

Implements CGfxWrap.

Polygon()

virtual void CGfxWrapGL::Polygon ( eC_Value *  pvPoints, const eC_UInt &  uiCount, const eC_Bool &  bFilled  )

virtual

Draws a polygon

Parameters

pvPoints	polygon points
uiCount	number of points
bFilled	if true the polygon is filled

Implements CGfxWrap.

ReadTextureData()

virtual void CGfxWrapGL::ReadTextureData ( const eC_UInt &  uiTexID, const eC_UInt &  uiXPos, const eC_UInt &  uiYPos, const eC_UInt &  uiWidth, const eC_UInt &  uiHeight, void *  pkData  )

pure virtual

Read data from texture

Parameters

uiTexID
uiXPos
uiYPos
uiWidth
uiHeight
pkData

Implemented in CGfxWrapOGL, CGfxWrapOGLES1_1, and CGfxWrapOGLES2.

Rect()

virtual void CGfxWrapGL::Rect ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2  )

virtual

Draws a rectangle with the top left edge at (vX1, vY1) and bottom right edge at (vX2, vY2)

Parameters

vX1	X-Coordinate of top left corner
vY1	Y-Coordinate of top left corner
vX2	X-Coordinate of bottom right corner
vY2	Y-Coordinate of bottom right corner

Implements CGfxWrap.

RestoreBackBuffer()

virtual void CGfxWrapGL::RestoreBackBuffer ( const eC_Value  vWidth, const eC_Value  vHeight  )

protectedvirtual

Restores the Backbuffer of the display after it has been used for texture rendering Always begins in LOWER LEFT of screen!

Parameters

vWidth	of the area to restore.
vHeight	of the area to restore.

RestoreWrapperState()

virtual void CGfxWrapGL::RestoreWrapperState ( )

virtual

Restores a previously saved state for the Graphics-Wrapper. Any change in the underlying API will be purged.

Reimplemented from CGfxWrap.

Ring()

virtual void CGfxWrapGL::Ring ( const eC_Value &  vX1, const eC_Value &  vY1, const eC_Value &  vX2, const eC_Value &  vY2, const eC_Value &  vRingWidth, const eC_Value &  vStartAngle, const eC_Value &  vEndAngle, const eC_Value &  vRotationAngle, const eC_Bool &  bFilled  )

virtual

Draws a ring which is completly inside the rectangle described through the rectangle the top left edge at (vAbsX1, vAbsY1) and bottom right edge at (vAbsX2, vAbsY2). The ring will be filled out if the last parameter is true 0-degrees is at the mathematically correct position on the unit-circle angles are increasing in counter-clockwise direction. rotation-angle is increasing in clockwise direction, i.e. rotating by 90 degrees will result in the 0-degress being at the bottom-center

Parameters

vX1	X-coordinate of bounding rectangle's top left corner
vY1	Y-Coordinate of bounding rectangle's top left corner
vX2	X-coordinate of bounding rectangle's bottom right corner
vY2	Y-Coordinate of bounding rectangle's bottom right corner
vRingWidth	width of the ring
vStartAngle	start-angle
vEndAngle	end-angle
vRotationAngle	rotation-angle
bFilled	Specifies whether the ring will be drawn outlined (false) or filled (true)

Implements CGfxWrap.

Set2DView() [1/2]

void CGfxWrapGL::Set2DView

(

)

Sets the default 2D view used by the gfx wrapper for 2D drawing operations. This method uses the dimensions returned by GetVirtualScreenWidth() and GetVirtualScreenHeight().

Set2DView() [2/2]

void CGfxWrapGL::Set2DView	(	const eC_UInt	uiWidth,
		const eC_UInt	uiHeight
	)

Sets the default 2D view used by the gfx wrapper for 2D drawing operations.

Parameters

uiWidth	Width of Viewport
uiHeight	Height of Viewport

SetClientStates()

void CGfxWrapGL::SetClientStates	(	const eC_Bool &	bVertexEnabled,
		const eC_Bool &	bTextureCoordsEnabled
	)

set client-sates

Parameters

bVertexEnabled
bTextureCoordsEnabled

SetCliprect() [1/2]

virtual void CGfxWrapGL::SetCliprect ( const CGUIRect &  rkNewClipRect )

virtual

Sets a clipping rectangle. All drawing operations will be limited to the region within the clipping rectangle. This is very useful for advanded features such as soft-scrolling. Note that the clipping rectangle is not allowed to exceed the invalidated rectangle, since this would lead to visual artifacts.

Parameters

rkNewClipRect

A normalised rectangle that includes all pixels that could be drawn by the functions of the graphics wrapper. The rectangle includes the border. All pixels outside will be left untouched.

Implements CGfxWrap.

SetCliprect() [2/2]

void CGfxWrapGL::SetCliprect ( const CGUIRect &  rkNewClipRect, const eC_Bool &  bRotate  )

protected

This SetCliprect version is used for an anti-clockwise rotation of the GUI. E.g. in GfxWrapEAGL implementation, if the iOS device is rotated.

Parameters

rkNewClipRect	A normalised rectangle that includes all pixels that could be drawn by the functions of the graphics wrapper. The rectangle includes the border. All pixels outside will be left untouched.
bRotate	Set this true to set glScissor rotated anti-clockwise.

SetForegroundColorImpl()

virtual void CGfxWrapGL::SetForegroundColorImpl ( const eC_UByte &  ubRed, const eC_UByte &  ubGreen, const eC_UByte &  ubBlue, const eC_UByte &  ubAlpha = 255  )

virtual

Sets the foreground color via r, g and b values and an alpha value

Parameters

ubRed	Red intensity within a range of 0 - 255
ubGreen	Green intensity within a range of 0 - 255
ubBlue	Blue intensity within a range of 0 - 255
ubAlpha	alpha value

Implements CGfxWrap.

SetLineWidth()

virtual eC_Value CGfxWrapGL::SetLineWidth ( const eC_Value &  vWidth )

virtual

Sets the line width in pixels

Parameters

vWidth

width of lines

Returns

The previous line width.

Reimplemented from CGfxWrap.

SetMixTextureWithColor()

void CGfxWrapGL::SetMixTextureWithColor

(

const eC_Bool &

bMixWithColor

)

Set color-mixing

Parameters

bMixWithColor

SetNOFImagesImpl()

eC_Bool CGfxWrapGL::SetNOFImagesImpl ( const eC_UInt  uiNOFImages )

protectedvirtual

Sets the total number of images. This is called internally by the ResourceManager when dynamically allocated image resources require the total number of images to be raised. Derived classes will have to override this method and resize their internal image-storage structures according to the new number of images which will have to be stored.

Parameters

uiNOFImages

The number of images

Returns

True if internal storage has been successfully adapted to support the requested number of images. False otherwise.

Reimplemented from CGfxWrap.

SetPerspectiveProjection()

void CGfxWrapGL::SetPerspectiveProjection	(	const eC_Value &	vFovy,
		const eC_Value &	vAspect,
		const eC_Value &	vNear,
		const eC_Value &	vFar
	)

Applies a perspective projection matrix to current GL_PROJECTION. Old projection matrix will be overwritten. Projection matrices are used to project 3D space coordinates to a 2D screen.

OpenGL and OpenGL-ES provides projection matrix creation for parallel projection mode (glOrtho), but for perspective projection invokation of the GLU library is needed. To avoid this dependency, this implementation provides this.

The matrix is calculated the following way:

(1/w) (0) ( 0 ) ( 0 ) M = (0) (1/h) ( 0 ) ( 0 ) (0) (0) (-(near+far)/d) (-2*near*far/d) (0) (0) ( -1 ) ( 0 )

where:

h = tan(fovy/2) w = aspectRatio * h d = far - near

Parameters

vFovy	Field of view in the vertical direction in DEG [0; 90].
vAspect	Aspect ratio of the viewport, which is width divided by height.
vNear	Distance to front clipping plane.
vFar	Distance to back clipping plane.

SetScissor()

void CGfxWrapGL::SetScissor ( const eC_Bool &  bEnabled, const eC_Int &  iX = 0, const eC_Int &  iY = 0, const eC_Int &  iWidth = 0, const eC_Int &  iHeight = 0  )

protected

Set scissor-area

Parameters

bEnabled
iX
iY
iWidth
iHeight

SetScreenSize()

virtual void CGfxWrapGL::SetScreenSize ( const eC_UInt &  uiWidth, const eC_UInt &  uiHeight  )

virtual

Sets the new physical screen size.

Parameters

uiWidth	New screen width.
uiHeight	New screen height.

Reimplemented from CGfxWrap.

SetTexturingActive()

void CGfxWrapGL::SetTexturingActive

(

const eC_Bool &

bTexturingActive

)

Set texturing active

Parameters

bTexturingActive

StoreWrapperState()

virtual void CGfxWrapGL::StoreWrapperState ( )

virtual

Saves the current active state of the Graphics-Wrapper. This might be used to manipulate the underlying API (e.g. OpenGL) without interfering with Guiliani-internal state.

Reimplemented from CGfxWrap.

UnloadImg()

virtual void CGfxWrapGL::UnloadImg ( const ImageResource_t &  eID )

protectedvirtual

Unloads an image. Unloads the image associated with the supplied Image-identifier and frees the memory formerly occupied by this image.

Parameters

eID	Identifier of the image to be unloaded.

Reimplemented from CGfxWrap.

Friends And Related Function Documentation

CGUIBitmapPlane_GL

friend class CGUIBitmapPlane_GL

friend

Member Data Documentation

cvPixelCenterOffset

const eC_Value CGfxWrapGL::cvPixelCenterOffset

static

Offset to get from OpenGL's coordinates to the pixel center. Note: OpenGL Pixel Coordinates do not refer to the "center" of the pixel, but to the edges between them. This means 0/0 would not point to the center of the top/left pixel, but instead to the top/left corner of this pixel Therefore, we move the coordinates to the center of the pixel by adding 0.375 pixels because of better compatibility to more graphic cards.

---

The documentation for this class was generated from the following file:

• GfxWrapGL.h
