Abstract base class to transit from a source dialog to a destination dialog. More...

#include <GUITransitionBase.h>

Inheritance diagram for CGUITransitionBase:

[legend]

Public Member Functions
	CGUITransitionBase (eC_UInt uiTransitionTime, eC_Bool bAutoDelete=true)
	Constructs a Transition. More...

eC_UInt	GetTransitionTime () const
	Gets the transition time in ms. More...

bool	IsActive ()

void	SetTransitionTime (eC_UInt uiTransitionTime)
	Sets the transition time in ms. More...

void	StartTransition (CGUIObject pkSource, CGUIObject pkDest, eC_Bool bDeleteSrc=true)
	Starts a Transition. More...

Public Member Functions inherited from CGUIObject
	CGUIObject ()

	CGUIObject (CGUICompositeObject *const pkParent, const CGUIRect &kRect, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (CGUICompositeObject *const pkParent, const eC_Value &vX, const eC_Value &vY, const eC_Value &vWidth, const eC_Value &vHeight, const ObjectHandle_t &eID=NO_HANDLE)

	CGUIObject (const CGUIObject &kSource)

virtual	~CGUIObject ()

void	AddValueObserver (CGUIObserver *pkObserver)

eC_Bool	CalculateInvalidatedRect (CGUIRect &rRect) const

virtual eC_Bool	ClaimFocus ()

virtual void	CreateSnapshot (eC_UInt uiBackColor=0x00)

eC_Bool	DataPoolConnectorExists () const

void	DeleteSnapshot ()

virtual void	DisableSnapshotDrawing (eC_Bool bDeleteSnapshot=true)

virtual eC_Bool	DoDraw ()

virtual eC_Bool	DoDrawSnapshot ()

virtual void	EnableSnapshotDrawing ()

virtual CGUIObject *	FindObject (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	FocusAny ()

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

CGUIRect	GetAbsRect () const

eC_Value	GetAbsXPos () const

eC_Value	GetAbsXPosCenter () const

eC_Value	GetAbsXPosREdge () const

eC_Value	GetAbsYPos () const

eC_Value	GetAbsYPosBEdge () const

eC_Value	GetAbsYPosCenter () const

eC_UByte	GetAlpha () const

CGUIBehaviourDecorator *	GetBehaviour ()

const CGUIBehaviourDecorator *	GetBehaviour () const

GUIBitmapPlaneID_t	GetBitmapID () const

CGUIBitmapPlane &	GetBitmapPlane () const

CGUIRect	GetCurrentAbsRect () const

eC_Value	GetCurrentAbsXPos () const

eC_Value	GetCurrentAbsXPosCenter () const

eC_Value	GetCurrentAbsXPosREdge () const

eC_Value	GetCurrentAbsYPos () const

eC_Value	GetCurrentAbsYPosBEdge () const

eC_Value	GetCurrentAbsYPosCenter () const

CDataPoolConnector &	GetDataPoolConnector ()

eC_Value	GetDistanceBottom () const

eC_Value	GetDistanceRight () const

eC_Value	GetHalfHeight () const

eC_Value	GetHalfWidth () const

eC_Value	GetHeight () const

ObjectHandle_t	GetID () const

CGUILayouter *	GetLayouter ()

const CGUILayouter *	GetLayouter () const

ObjectHandle_t	GetNeighborBottomID () const

ObjectHandle_t	GetNeighborLeftID () const

ObjectHandle_t	GetNeighborRightID () const

ObjectHandle_t	GetNeighborTopID () const

CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false)

const CGUIObject *	GetObjectByID (const ObjectHandle_t &eID, const eC_Bool &bOnlyVisible=false) const

CGUIRect	GetOriginRect () const

CGUICompositeObject *	GetParent ()

const CGUICompositeObject *	GetParent () const

CGUIRect	GetRelRect () const

eC_Value	GetRelXPos () const

eC_Value	GetRelXPosCenter () const

eC_Value	GetRelXPosREdge () const

eC_Value	GetRelYPos () const

eC_Value	GetRelYPosBEdge () const

eC_Value	GetRelYPosCenter () const

UUID_t	GetUUID () const

eC_Value	GetWidth () const

void	InvalidateArea ()

eC_Bool	IsClickable () const

eC_Bool	IsClickThrough () const

virtual eC_Bool	IsCompositeObject () const

eC_Bool	IsDescendantOf (const CGUIObject *const pAncestor) const

eC_Bool	IsDisabled () const

eC_Bool	IsDragable () const

eC_Bool	IsDragged () const

eC_Bool	IsDrawingSnapshot () const

eC_Bool	IsFocussable () const

eC_Bool	IsFocussed () const

eC_Bool	IsGrayedOut () const

virtual eC_Bool	IsHighlightable () const

eC_Bool	IsHighlighted () const

eC_Bool	IsInvisible () const

eC_Bool	IsPressed () const

eC_Bool	IsStopFocus () const

void	NotifyValueObservers (const CGUIValue &kValue, const eC_UInt uiX=0, const eC_UInt uiY=0)

CGUIObject &	operator= (const CGUIObject &kSource)

virtual void	ReadFromStream ()

virtual void	RefreshLayout (CGUILayouter::eMovedEdges_t eMovedEdges) const

void	RemoveValueObserver (CGUIObserver *pkObserver)

void	RenderToBitmap (eC_UInt uiBitmapID, eC_Value vXOffset=eC_FromInt(0), eC_Value vYOffset=eC_FromInt(0))

eC_Bool	RequestFocus ()

void	SetAlpha (eC_UByte ubAlpha)

void	SetBehaviour (CGUIBehaviourDecorator *pkBehaviour)

void	SetClickThrough (const eC_Bool &bClickThrough)

virtual void	SetDisabled (const eC_Bool &bDisabled)

virtual void	SetFocussable (const eC_Bool &bFocussable)

virtual void	SetGrayedOut (const eC_Bool &bGrayOut)

virtual void	SetHeight (const eC_Value &vY)

void	SetID (const ObjectHandle_t &eID)

virtual void	SetInvisible (const eC_Bool &bInvisible)

void	SetLayouter (CGUILayouter *pLayouter)

void	SetNeighborBottomID (const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborIDs (const ObjectHandle_t eNewNeighborLeftID, const ObjectHandle_t eNewNeighborRightID, const ObjectHandle_t eNewNeighborTopID, const ObjectHandle_t eNewNeighborBottomID)

void	SetNeighborLeftID (const ObjectHandle_t eNewNeighborLeftID)

void	SetNeighborRightID (const ObjectHandle_t eNewNeighborRightID)

void	SetNeighborTopID (const ObjectHandle_t eNewNeighborTopID)

virtual void	SetParent (CGUICompositeObject *const pkParent)

void	SetRelRect (const CGUIRect &kNewRect)

virtual void	SetRelXPos (const eC_Value &vX)

void	SetRelXPosCenter (const eC_Value &vXCenter)

void	SetRelXPosREdge (const eC_Value &vX)

virtual void	SetRelYPos (const eC_Value &vY)

void	SetRelYPosBEdge (const eC_Value &vY)

void	SetRelYPosCenter (const eC_Value &vYCenter)

void	SetStopFocus (const eC_Bool &bDontFocusToParent)

void	SetUUID (const UUID_t &kUUID)

virtual eC_Bool	SetValue (CDataPoolEntry &rkValue)

virtual eC_Bool	SetValue (const CGUIValue &rkValue)

virtual void	SetWidth (const eC_Value &vX)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoScale (const eC_Value &vDelta)

virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDataPool (const DataPoolResource_t &eID)

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX=eC_FromInt(-1), const eC_Value &vDeltaY=eC_FromInt(-1), const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScroll (const eC_Value &vAbsX, const eC_Value &vAbsY, const eC_Value &vDelta, const eC_Bool &bModifierActive)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Protected Member Functions
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual void	EndTransition ()=0
	Cleans up a Transition. More...

virtual void	InitTransition ()=0
	Initializes a Transition. More...

virtual void	UpdateTransition (eC_Value vProgress)=0
	Initializes a Transition. More...

Protected Member Functions inherited from CGUIObject
virtual eC_Bool	CreateBitmapPlane ()

virtual eC_Bool	FourWayNext (FourWayFocus_t eFocusDirection)

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
CGUIObject *	m_pkDest
	Pointer to the destination object.

CGUICompositeObject *	m_pkParent
	Pointer to the parent composite object.

CGUIObject *	m_pkSource
	Pointer to the source object.

eC_UInt	m_uiFrameRate
	Frame rate.

Protected Attributes inherited from CGUIObject
UUID_t	m_kUUID
	UUID of object.

Additional Inherited Members
Public Types inherited from CGUIObject
enum	FourWayFocus_t { FOCUS_LEFT , FOCUS_RIGHT , FOCUS_UP , FOCUS_DOWN }

Static Public Member Functions inherited from CGUIStreamableObject
static UUID_t	GenerateUUID ()

Static Public Attributes inherited from CGUIObject
static const eC_Char	XMLTAG_ALPHA []
	XML tag to be used writing alpha-value into a stream.

static const eC_Char	XMLTAG_CLICKTHROUGH []
	XML tag to be used writing clickthrough-state into a stream.

static const eC_Char	XMLTAG_CONTROLCLASSID []
	XML tag to be used when writing a control class ID into a stream.

static const eC_Char	XMLTAG_DISABLED []
	XML tag to be used writing disabled-state into a stream.

static const eC_Char	XMLTAG_FOCUSSABLE []
	XML tag to be used writing focussable-state into a stream.

static const eC_Char	XMLTAG_GRAYEDOUT []
	XML tag to be used writing grayedout-state into a stream.

static const eC_Char	XMLTAG_HEIGHT []
	XML tag to be used writing height into a stream.

static const eC_Char	XMLTAG_INVISIBLE []
	XML tag to be used writing invisible-state into a stream.

static const eC_Char	XMLTAG_OBJECTID []
	XML tag to be used writing object id into a stream.

static const eC_Char	XMLTAG_OVERRIDDENNEIGHBORS []
	XML tag to be used writing overridden neighbors into a stream.

static const eC_Char	XMLTAG_UUID []
	XML tag to be used when writing a UUID into a stream.

static const eC_Char	XMLTAG_WIDTH []
	XML tag to be used writing width into a stream.

static const eC_Char	XMLTAG_XPOS []
	XML tag to be used writing x-position into a stream.

static const eC_Char	XMLTAG_YPOS []
	XML tag to be used writing y-position into a stream.

Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

static const eC_Char	XMLTAG_BEHAVIOURCOUNT []
	XML tag for count.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

Abstract base class to transit from a source dialog to a destination dialog.

The "dialog transitions" uses transitions to change from one dialog to another. Guiliani provides the following transitions (Class: CGUITransitionBase):

Blend: fading out a source dialog while a destination dialog will be faded in
Dissolve: dissolving the source-screen by splitting it up into a number of rectangular tiles, and overblending it with the destination-screen tile by tile.
Push: moving out a source dialog while a destination dialog is moved in
Rotation: rotating out a source dialog while a destination dialog is rotated in.

This class serves as base class for all dialog transitions. Inherited classes must override: InitTransition EndTransition and UpdateTransition

To compute a transition StartTransition must be called. The source dialog needs to have a parent container. The destination dialog should have a parent which normally should be the parent of the source. The source dialog is set to be invisible when the transition has finished and if specified by bDeleteSrc parameter the source dialog is deleted.

A GUIObject can only be part of one transition at the same time. If an object is already part of a transition all further calls to StartTransition are ignored.

Constructor & Destructor Documentation

◆ CGUITransitionBase()

CGUITransitionBase::CGUITransitionBase	(	eC_UInt	uiTransitionTime,
		eC_Bool	bAutoDelete = `true`
	)

Constructs a Transition.

Parameters

uiTransitionTime	Transition time in ms.
bAutoDelete	The transition instance is deleted by default after transition has finished

Member Function Documentation

◆ DoAnimate()

virtual void CGUITransitionBase::DoAnimate ( const eC_Value & vTimes = eC_FromInt(1) )

protectedvirtual

animation callback

Parameters

vTimes

Reimplemented from CGUIAnimatable.

◆ EndTransition()

virtual void CGUITransitionBase::EndTransition ( )

protectedpure virtual

Cleans up a Transition.

Implemented in CGUITransitionBlend, CGUITransitionDissolve, CGUITransitionEnterLeave, CGUITransitionPush, and CGUITransitionRotation.

◆ GetTransitionTime()

eC_UInt CGUITransitionBase::GetTransitionTime ( ) const

inline

Gets the transition time in ms.

Returns: Transition time in ms.

◆ InitTransition()

virtual void CGUITransitionBase::InitTransition ( )

protectedpure virtual

Initializes a Transition.

Implemented in CGUITransitionBlend, CGUITransitionDissolve, CGUITransitionEnterLeave, CGUITransitionPush, and CGUITransitionRotation.

◆ IsActive()

bool CGUITransitionBase::IsActive ( )

Returns if the transition is still in progress.

Returns: True if the transition is still in progress otherwise False

◆ SetTransitionTime()

void CGUITransitionBase::SetTransitionTime ( eC_UInt uiTransitionTime )

Sets the transition time in ms.

Parameters

uiTransitionTime Transition time in ms.

◆ StartTransition()

void CGUITransitionBase::StartTransition	(	CGUIObject *	pkSource,
		CGUIObject *	pkDest,
		eC_Bool	bDeleteSrc = `true`
	)

Starts a Transition.

Parameters

pkSource	The dialog that is already visible and where transition starts. The GUIObject must have a valid parent
pkDest	The dialog that is not visible at transition start but after transition has finished. This object is not allowed to have a parent at transition start. It will be put to source's parent by the transition class.
bDeleteSrc	If true the source object will be deleted after transition has finished. Otherwise it will be set to be invisible.

◆ UpdateTransition()

virtual void CGUITransitionBase::UpdateTransition ( eC_Value vProgress )

protectedpure virtual

Initializes a Transition.

Parameters

vProgress The current transition progress (0..1)

Implemented in CGUITransitionBlend, CGUITransitionDissolve, CGUITransitionEnterLeave, CGUITransitionPush, and CGUITransitionRotation.

The documentation for this class was generated from the following file:

GUITransitionBase.h

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ CGUITransitionBase()

Member Function Documentation

◆ DoAnimate()

◆ EndTransition()

◆ GetTransitionTime()

◆ InitTransition()

◆ IsActive()

◆ SetTransitionTime()

◆ StartTransition()

◆ UpdateTransition()
