GlyphLib (uGuiliani font) implementation of the Font Wrapper. More...

#include <FntWrapGlyphLib.h>

Inheritance diagram for CFntWrapGlyphLib:

[legend]

Classes
struct	FontEntry_s
	entry for font More...

Public Member Functions
void	LoadFont (const FontResource_t &eFontID)

void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)

void	SetFont (const FontResource_t &eID)

void	UnloadFont (const FontResource_t &eFontID)

Public Member Functions inherited from CFntWrap
void	ChangeFont (const FontResource_t &eFontID, const eC_String &pcPath, const eC_UInt uiFontSize, const GUIFont_t &eFontStyle)

virtual void	FittingNumChars (const eC_String *const pkText, eC_Value vWidthMax, eC_UInt &uiNumChars, const eC_Bool &bStartAtEnd=false)

virtual eC_Int	GetAscender () const

virtual eC_Int	GetDescender () const

virtual void	GetGlyphMetrics (const eC_Char cChar, GlyphMetrics_t &kMetrics)

virtual eC_Int	GetInternalLeading () const

virtual eC_UInt	GetNOFFonts ()

CGUICommonEnums::Rotation_t	GetRotation () const

virtual eC_Value	GetTextXPosAdjustment (const CGUIText::HorAligned_t eHorAlignment)

virtual eC_Value	GetTextYPosAdjustment (const CGUIText::VerAligned_t eVerAlignment)

virtual void	LoadFont (const FontResource_t &eFontID)

virtual void	RequiredSpace (const eC_String *const pkText, eC_Value &vWidth, eC_Value &vHeight)=0

virtual void	SetFont (const FontResource_t &eID)

virtual void	SetFontSpacing (const eC_Float &fSpacing)

virtual eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)

void	SetRotation (const CGUICommonEnums::Rotation_t &eRotation)

virtual void	Text (const eC_Value &vX1, const eC_Value &vY1, const eC_String *const lpString)=0

virtual void	UnloadFont (const FontResource_t &eFontID)

Static Public Member Functions
static eC_Bool	CreateInstance ()

Static Public Member Functions inherited from CFntWrap
static void	DeleteInstance ()

Protected Member Functions
virtual eC_Int	GetAscender () const

virtual eC_Int	GetDescender () const

virtual void	GetGlyphMetrics (const eC_Char cChar, GlyphMetrics_t &kMetrics)

virtual eC_Int	GetInternalLeading () const

virtual void	RenderGlyphToScreen (const eC_Value &vX1, const eC_Value &vY1, CGUIImageData &kGlyphImage)

virtual void	RenderTextInternal (const eC_String *lpString, const TextOperation_t &eOperation, const eC_Value &vX1, const eC_Value &vY1, eC_Value &vWidth, eC_Value &vHeight, eC_Value vWidthMax, eC_UInt &uiNumFittingChars)

eC_Bool	SetNOFFonts (const eC_UInt uiNOFFonts)

void	Text (const eC_Value &vX1, const eC_Value &vY1, const eC_String *const lpString)

Protected Member Functions inherited from CFntWrap
	CFntWrap ()
	Constructor.

virtual	~CFntWrap ()
	Destructor.

void *	GetWorkingMemory (const eC_UInt &uiSize)

void	ReleaseWorkingMemory ()
	release working memory

Protected Attributes
eC_TArray< FontEntry_s >	m_kFontsHandles
	handles of all loaded fonts

eC_UInt	m_uiCurrentFontIndex
	the currently used font-index

Protected Attributes inherited from CFntWrap
FontResource_t	m_eCurFont
	Current font id.

CGUICommonEnums::Rotation_t	m_eRotation
	Rotation.

eC_UInt	m_uiNOFFonts
	Total number of fonts.

eC_Value	m_vSpacing
	Font spacing, i.e the space between letters.

Additional Inherited Members
Public Types inherited from CFntWrap
enum	GUIFont_t { FNT_NORMAL = 0 , FNT_ITALIC = 1 , FNT_UNDERLINED = 2 , FNT_BOLD = 4 }

enum	TextOperation_t { RENDER_TEXT , GET_REQUIRED_SPACE }

Detailed Description

GlyphLib (uGuiliani font) implementation of the Font Wrapper.

Platform Specific Limitations

As the CFntWrapGlyphLib uses a pre-compiled ROMFS to store the glyph bitmaps, it is not possible to change the number of used fonts via SetNOFFonts()

See CFntWrapGlyphLib Platform Specific Limitations This class is used to wrap the funtionality of the GlyphLib

Member Function Documentation

◆ CreateInstance()

static eC_Bool CFntWrapGlyphLib::CreateInstance ( )

static

Create the instance

Returns: true if successful

◆ GetAscender()

virtual eC_Int CFntWrapGlyphLib::GetAscender ( ) const

protectedvirtual

Returns the currently set font's ascender-metric. If the ascender is not supported by a given Font-Wrapper, this returns 0.

Returns: ascender in pixels

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibDAVE, and CFntWrapGlyphLibGL.

◆ GetDescender()

virtual eC_Int CFntWrapGlyphLib::GetDescender ( ) const

protectedvirtual

Returns the currently set font's descender-metric. If the descender is not supported by a given Font-Wrapper, this returns 0.

Returns: descender in pixels

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibDAVE, and CFntWrapGlyphLibGL.

◆ GetGlyphMetrics()

virtual void CFntWrapGlyphLib::GetGlyphMetrics	(	const eC_Char	cChar,
		GlyphMetrics_t &	kMetrics
	)

protectedvirtual

Get the metrics of a glyph for a specific character

Parameters

cChar	character
kMetrics	metrics of glyph

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibDAVE, and CFntWrapGlyphLibGL.

◆ GetInternalLeading()

virtual eC_Int CFntWrapGlyphLib::GetInternalLeading ( ) const

protectedvirtual

Returns the currently set font's internal leading. If the internal leading is not supported by a given Font-Wrapper, this returns 0.

Returns: internal leading in pixels

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibDAVE, and CFntWrapGlyphLibGL.

◆ LoadFont()

void CFntWrapGlyphLib::LoadFont ( const FontResource_t & eFontID )

virtual

Loads a font identified by eFontID into an array of fonts at position eFontID. If the font already exists, it's not loaded again. Should only be called by a FntWrapper.

Parameters

eFontID id (and hence index) of the font. False else.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibGL.

◆ RenderGlyphToScreen()

virtual void CFntWrapGlyphLib::RenderGlyphToScreen	(	const eC_Value &	vX1,
		const eC_Value &	vY1,
		CGUIImageData &	kGlyphImage
	)

protectedvirtual

Renders a glyph to the screen. This function takes the 8 bit alpha image provided by freetype adds color and blits it to the screen.

Parameters

vX1	The x coordinate where the glyph image is rendered.
vY1	The y coordinate where the glyph image is rendered.
kGlyphImage	The glyph image containing a 8 bit alpha image of the glyph.

Reimplemented in CFntWrapGlyphLibDAVE.

◆ RenderTextInternal()

virtual void CFntWrapGlyphLib::RenderTextInternal	(	const eC_String *	lpString,
		const TextOperation_t &	eOperation,
		const eC_Value &	vX1,
		const eC_Value &	vY1,
		eC_Value &	vWidth,
		eC_Value &	vHeight,
		eC_Value	vWidthMax,
		eC_UInt &	uiNumFittingChars
	)

protectedvirtual

Render a text

Parameters

lpString	text
eOperation	Use RENDER_TEXT to render the text or GET_REQUIRED_SPACE to calculate the required space.
vX1	x-position
vY1	y-position
vWidth	the width needed for the text
vHeight	the height needed for the text
vWidthMax	the maximum width available
uiNumFittingChars	maximum number of characters which will fit

◆ RequiredSpace()

void CFntWrapGlyphLib::RequiredSpace	(	const eC_String *const	pkText,
		eC_Value &	vWidth,
		eC_Value &	vHeight
	)

virtual

Calculates the required space in x- and y-direction of a given text with the currently active font.

Parameters

pkText	The text.
vWidth	Reference to width of the font in pixels.
vHeight	Reference to height of the font in pixels.

Implements CFntWrap.

◆ SetFont()

void CFntWrapGlyphLib::SetFont ( const FontResource_t & eID )

virtual

Sets a new font for the application.

Parameters

eID	id (and hence index) of the font.

Reimplemented from CFntWrap.

◆ SetNOFFonts()

eC_Bool CFntWrapGlyphLib::SetNOFFonts ( const eC_UInt uiNOFFonts )

protectedvirtual

Sets the total number of fonts. This is called internally by the ResourceManager when dynamically allocated font resources require the total number of fonts to be raised. Derived classes will have to override this method and resize their internal font-storage structures according to the new number of fonts which will have to be stored.

Parameters

uiNOFFonts The number of fonts

Returns: True if internal storage has been successfully adapted to support the requested number of fonts. False otherwise.

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibGL.

◆ Text()

void CFntWrapGlyphLib::Text	(	const eC_Value &	vX1,
		const eC_Value &	vY1,
		const eC_String *const	lpString
	)

protectedvirtual

Print the text to screen.

Parameters

vX1	Absolute x position of the top-left corner of the bounding rectangle.
vY1	Absolute y position of the top-left corner of the bounding rectangle.
lpString	The string to be printed.

Implements CFntWrap.

◆ UnloadFont()

void CFntWrapGlyphLib::UnloadFont ( const FontResource_t & eFontID )

virtual

Unloading is not supported by GlyphLib

Parameters

eFontID FontID to unload

Reimplemented from CFntWrap.

Reimplemented in CFntWrapGlyphLibGL.

The documentation for this class was generated from the following file:

FntWrapGlyphLib.h
