This is the Sound-Wrapper base class. More...

#include <SndWrap.h>

Inheritance diagram for CSndWrap:

[legend]

Public Member Functions
virtual eC_UInt	GetNOFSounds ()

virtual eC_UByte	GetVolume ()=0

virtual eC_Bool	PauseSnd (const SoundResource_t &eID)=0

virtual eC_Bool	PlaySnd (const SoundResource_t &eID, eC_UInt uiFlags=2)=0

virtual eC_Bool	ResumeSnd (const SoundResource_t &eID)=0

virtual eC_Bool	SetVolume (eC_UByte ubVolume)=0

virtual eC_Bool	StopSnd (const SoundResource_t &eID)=0

Static Public Member Functions
static void	DeleteInstance ()
	Deletes the Sound-Wrapper instance.

Protected Member Functions
	CSndWrap ()
	Constructor.

	CSndWrap (const CSndWrap &kSource)

virtual	~CSndWrap ()
	Destructor.

virtual void	LoadSnd (const eC_String &kPath, const SoundResource_t &eID, eC_UInt uiDeviceID=0)=0

CSndWrap &	operator= (const CSndWrap &kSource)

virtual eC_Bool	SetNOFSounds (eC_UInt uiNOFSounds)

virtual void	UnloadSnd (const SoundResource_t &eID)=0

Protected Attributes
eC_UInt	m_uiNOFSounds
	total number of sound-objects.

Friends
class	CGUIComponentManager

class	CGUIResourceManager

Detailed Description

This is the Sound-Wrapper base class.

Guiliani is designed independently of a certain underlying sound library, in order to allow its porting to any desired platform. Abstraction of sound functionality is guaranteed through the use of sound-wrappers. This is the base-class, from which all wrappers customized for a specific sound library, have to be derived.

The methods declared in this base-class will be used by Guiliani standard-sounds to output themselves. You may leave implementations of certain methods empty for your specific derivation, if you know that you will not need them. For example you may decide not to implement sound-loading functionality for your specific sound-wrapper. You are also free to add completely new methods to your own wrapper-classes and use these within your custom-made controls.

warning! this code has been only tested for specific application and is not in a final state! operating without mistakes in any case can not be guaranteed!

Constructor & Destructor Documentation

◆ CSndWrap()

CSndWrap::CSndWrap ( const CSndWrap & kSource )

protected

Copy-constructor. Dummy implementation to avoid unintended use of compiler-generated default.

Parameters

kSource The source to be copied

Member Function Documentation

◆ GetNOFSounds()

virtual eC_UInt CSndWrap::GetNOFSounds ( )

inlinevirtual

Gets the number of sounds.

Returns: Number of sounds.

◆ GetVolume()

virtual eC_UByte CSndWrap::GetVolume ( )

pure virtual

Method to get the volume of an output device. The volume has to be implemented in percent. The range is from 0 till 100.

Returns: The currently set volume in percent.

Implemented in CSndWrapNull, CSndWrapALSA, CSndWrapOSS, CSndWrapSDL, CSndWrapWin, and CSndWrapWAVBase.

◆ LoadSnd()

virtual void CSndWrap::LoadSnd	(	const eC_String &	kPath,
		const SoundResource_t &	eID,
		eC_UInt	uiDeviceID = `0`
	)

protectedpure virtual

Method to load a sound file.

Parameters

kPath	Path to the sound file.
eID	ID of the sound.
uiDeviceID	TBD

Implemented in CSndWrapNull, CSndWrapWAVBase, CSndWrapSDL, and CSndWrapWin.

◆ operator=()

CSndWrap & CSndWrap::operator= ( const CSndWrap & kSource )

protected

Operator= method. Dummy implementation to avoid unintended use of compiler-generated default.

Parameters

kSource The source to be assigned from

Returns: The assignment destination

◆ PauseSnd()

virtual eC_Bool CSndWrap::PauseSnd ( const SoundResource_t & eID )

pure virtual

Method to break playback on a specified sound.

Parameters

eID	ID of the sound you want to pause.

Returns: False on error.

Implemented in CSndWrapNull, CSndWrapWAVBase, CSndWrapSDL, and CSndWrapWin.

◆ PlaySnd()

virtual eC_Bool CSndWrap::PlaySnd	(	const SoundResource_t &	eID,
		eC_UInt	uiFlags = `2`
	)

pure virtual

Method to send data to the specified output device.

Parameters

eID ID of the sound you want to play.

uiFlags Flags to set for playing. possible flags: PLAY_SYNC - wait until playback has finished before returning PLAY_ASYNC - return immediately to calling function PLAY_WAIT - if a sound is currently playing, wait for the playing sound to end, then play the new sound PLAY_DISCARD - if a sound is currently playing, return without playing the new sound PLAY_IMMEDIATELY - if a sound is currently playing, immediately stop playback and play the new sound

Returns: False on error.

Implemented in CSndWrapWAVBase, CSndWrapSDL, CSndWrapWin, and CSndWrapNull.

◆ ResumeSnd()

virtual eC_Bool CSndWrap::ResumeSnd ( const SoundResource_t & eID )

pure virtual

Method for continuing the playback of a specified sound.

Parameters

eID	ID of the sound you want to resume.

Returns: False on error.

Implemented in CSndWrapNull, CSndWrapWAVBase, CSndWrapSDL, and CSndWrapWin.

◆ SetNOFSounds()

virtual eC_Bool CSndWrap::SetNOFSounds ( eC_UInt uiNOFSounds )

protectedvirtual

Sets the total number of sounds. This is called internally by the ResourceManager when dynamically allocated sound resources require the total number of sounds to be raised.

Parameters

uiNOFSounds Number of sounds to set.

Returns: True if successfully set, False otherwise

Reimplemented in CSndWrapNull.

◆ SetVolume()

virtual eC_Bool CSndWrap::SetVolume ( eC_UByte ubVolume )

pure virtual

Method to set the volume of an output device. The volume has to be implemented in percent. The range is from 0 till 100.

Parameters

ubVolume to set in percent.

Returns: False on error.

Implemented in CSndWrapNull, CSndWrapSDL, CSndWrapWin, CSndWrapALSA, CSndWrapOSS, and CSndWrapWAVBase.

◆ StopSnd()

virtual eC_Bool CSndWrap::StopSnd ( const SoundResource_t & eID )

pure virtual

Method to stop playback of a specified sound.

Parameters

eID	ID of the sound you want to stop.

Returns: False on error.

Implemented in CSndWrapNull, CSndWrapWAVBase, CSndWrapSDL, and CSndWrapWin.

◆ UnloadSnd()

virtual void CSndWrap::UnloadSnd ( const SoundResource_t & eID )

protectedpure virtual

Method to unload a sound file.

Parameters

eID	ID of the sound to unload.

Implemented in CSndWrapNull, CSndWrapOSS, CSndWrapWAVBase, CSndWrapSDL, and CSndWrapWin.

Friends And Related Function Documentation

◆ CGUIComponentManager

friend class CGUIComponentManager

friend

◆ CGUIResourceManager

friend class CGUIResourceManager

friend

The documentation for this class was generated from the following file:

SndWrap.h
