CGUISetObjectVisualsCmd Class Reference

An example for a custom command that changes the object visuals of an GUIObject. More...

#include <GUISetObjectVisualsCmd.h>

Inheritance diagram for CGUISetObjectVisualsCmd:

Public Member Functions
	CGUISetObjectVisualsCmd ()
	Default constructor to be used by a factory.
	CGUISetObjectVisualsCmd (ObjectHandle_t eTargetObject, eC_Bool bChangePosition, eC_Value vTargetX, eC_Value vTargetY, eC_Bool bAnimatePosition, eC_UInt uiPositionDuration, CGUIEasing::EasingType_t ePositionEasing, eC_Bool bChangeSize, eC_Value vTargetWidth, eC_Value vTargetHeight, eC_Bool bAnimateSize, eC_UInt uiSizeDuration, CGUIEasing::EasingType_t eSizeEasing, eC_Bool bChangeAlpha, eC_UByte ubTargetAlpha, eC_Bool bAnimateAlpha, eC_UInt uiAlphaDuration, CGUIEasing::EasingType_t eAlphaEasing)
virtual void	ReadFromStream ()
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUICommand
void	AddAdditionalCmd (CGUICommandPtr pkCmd, eC_Bool bOneTime=false)
CGUICommandPtr	GetAdditionalCmd (const eC_UInt &uiIndex) const
eC_UInt	GetNumberOfAdditionalCmds () const
eC_UInt	GetPriority () const
eC_UInt	GetTimeUntilNextExecution () const
eC_Bool	IsFinished () const
virtual void	ReadFromStream ()
void	RemoveAdditionalCmd (CGUICommandPtr pkCmd)
void	RemoveAllAdditionalCmds ()
	Removes all additional commands from this command's list.
void	SetPriority (eC_UInt uiPriority)
void	SetTimeUntilNextExecution (eC_UInt uiTime)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from NSmartPtr::RefCounted
	RefCounted ()
	Create RefCounted object. The reference count is initialized to 0.
virtual	~RefCounted ()
	Destroy reference counted object.
void	AddRef ()
	Increase reference count.
eC_Int	RefCount () const
void	Release ()
bool	Unique () const

Protected Member Functions
void	Do ()
	Implements the actual command functionality. More...
Protected Member Functions inherited from CGUICommand
	CGUICommand (const eC_UInt uiPriority=0, const eC_UInt uiTimeUntilFirstExecution=0, const eC_Bool bFinished=true)
virtual	~CGUICommand ()
	Destructor.
virtual void	Do ()=0
void	SetToBeFinished (eC_Bool bIsFinished)
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
eC_Bool	m_bAnimateAlpha
	animate alpha
eC_Bool	m_bAnimatePosition
	animate position
eC_Bool	m_bAnimateSize
	animate size
eC_Bool	m_bChangeAlpha
	change alpha
eC_Bool	m_bChangePosition
	change position
eC_Bool	m_bChangeSize
	change size
CGUIEasing::EasingType_t	m_eAlphaEasing
	animation-easing
CGUIEasing::EasingType_t	m_ePositionEasing
	animation-easing
CGUIEasing::EasingType_t	m_eSizeEasing
	animation-easing
ObjectHandle_t	m_eTargetObject
	Target object ID.
eC_UByte	m_ubTargetAlpha
	target alpha-value
eC_UInt	m_uiAlphaDuration
	animation duration
eC_UInt	m_uiPositionDuration
	animation duration
eC_UInt	m_uiSizeDuration
	animation duration
eC_Value	m_vTargetHeight
	target height
eC_Value	m_vTargetWidth
	target width
eC_Value	m_vTargetX
	target x-position
eC_Value	m_vTargetY
	target y-position

Additional Inherited Members
Static Public Attributes inherited from CGUICommand
static const eC_Char	XMLTAG_ADDITIONALCMDCOUNT []
	XML tag to be used when writing the additional command count into a stream.
static const eC_Char	XMLTAG_COMMANDCLASSID []
	XML tag to be used when writing the command class ID into a stream.
static const eC_Char	XMLTAG_REMOVE_AFTER_EXECUTION []
	XML tag to be used when writing the remove after execution flag.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

An example for a custom command that changes the object visuals of an GUIObject.

The target object is referenced by an object ID that has to be passed to the constructor. When this command is executed, it tries to find the specified object. If no object is found, this command does nothing. If the object is found, the object visuals are changed according the given values.

Constructor & Destructor Documentation

CGUISetObjectVisualsCmd()

CGUISetObjectVisualsCmd::CGUISetObjectVisualsCmd	(	ObjectHandle_t	eTargetObject,
		eC_Bool	bChangePosition,
		eC_Value	vTargetX,
		eC_Value	vTargetY,
		eC_Bool	bAnimatePosition,
		eC_UInt	uiPositionDuration,
		CGUIEasing::EasingType_t	ePositionEasing,
		eC_Bool	bChangeSize,
		eC_Value	vTargetWidth,
		eC_Value	vTargetHeight,
		eC_Bool	bAnimateSize,
		eC_UInt	uiSizeDuration,
		CGUIEasing::EasingType_t	eSizeEasing,
		eC_Bool	bChangeAlpha,
		eC_UByte	ubTargetAlpha,
		eC_Bool	bAnimateAlpha,
		eC_UInt	uiAlphaDuration,
		CGUIEasing::EasingType_t	eAlphaEasing
	)

Constructor.

Parameters

eTargetObject	The ID of the object to be modified by this command.
bChangePosition	If true, the position will be changed
vTargetX	Target value of the x-position
vTargetY	Target value of the y-position
bAnimatePosition	If true the object will be animated to the new position
uiPositionDuration	Duration of the animation to change the position
ePositionEasing	Easing which is used for animating the position
bChangeSize	If true, the size will be changed
vTargetWidth	Target value of the width
vTargetHeight	Target value of the height
bAnimateSize	If true the object will be animated to the new size
uiSizeDuration	Duration of the animation to the change the size
eSizeEasing	Easing which is used for animating the size
bChangeAlpha	If true, the alpha-value will be changed
ubTargetAlpha	Target value of the alpha
bAnimateAlpha	If true the object will be animated to the new alpha-value
uiAlphaDuration	Duration of the animation to change the alpha-value
eAlphaEasing	Easing which is used for animating the alpha-value

Member Function Documentation

Do()

void CGUISetObjectVisualsCmd::Do ( )

protectedvirtual

Implements the actual command functionality.

Implements CGUICommand.

ReadFromStream()

virtual void CGUISetObjectVisualsCmd::ReadFromStream ( )

virtual

Reads all attributes from streaming file. This method is called by CGUIFactoryManager after one of the registered factories has created an instance of this class.

Reimplemented from CGUICommand.

WriteToStream()

virtual void CGUISetObjectVisualsCmd::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes all attributes to the streaming file. A CGUIStreamWriter has to be initialized first.

Parameters

bWriteClassID

This flag is used to select if writing of command class ID, leading and trailing tags is performed.

Reimplemented from CGUICommand.

---

The documentation for this class was generated from the following file:

• GUISetObjectVisualsCmd.h
