CGUISetObjectStateCmd Class Reference

An example for a custom command that changes the object states of an GUIObject. More...

#include <GUISetObjectStateCmd.h>

Inheritance diagram for CGUISetObjectStateCmd:

Public Member Functions
	CGUISetObjectStateCmd ()
	Default constructor to be used by a factory.
	CGUISetObjectStateCmd (ObjectHandle_t eTargetObject, eC_Bool bToggle, eC_Bool bFocusable, eC_Bool bInvisible, eC_Bool bGrayedOut, eC_Bool bDisabled)
virtual void	ReadFromStream ()
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUICommand
void	AddAdditionalCmd (CGUICommandPtr pkCmd, eC_Bool bOneTime=false)
CGUICommandPtr	GetAdditionalCmd (const eC_UInt &uiIndex) const
eC_UInt	GetNumberOfAdditionalCmds () const
eC_UInt	GetPriority () const
eC_UInt	GetTimeUntilNextExecution () const
eC_Bool	IsFinished () const
virtual void	ReadFromStream ()
void	RemoveAdditionalCmd (CGUICommandPtr pkCmd)
void	RemoveAllAdditionalCmds ()
	Removes all additional commands from this command's list.
void	SetPriority (eC_UInt uiPriority)
void	SetTimeUntilNextExecution (eC_UInt uiTime)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const
virtual void	ReadFromStream ()
void	SetXMLTag (const eC_String &kXMLTag)
virtual void	WriteToStream (const eC_Bool bWriteClassID=false)
Public Member Functions inherited from NSmartPtr::RefCounted
	RefCounted ()
	Create RefCounted object. The reference count is initialized to 0.
virtual	~RefCounted ()
	Destroy reference counted object.
void	AddRef ()
	Increase reference count.
eC_Int	RefCount () const
void	Release ()
bool	Unique () const

Protected Member Functions
void	Do ()
	Implements the actual command functionality. More...
Protected Member Functions inherited from CGUICommand
	CGUICommand (const eC_UInt uiPriority=0, const eC_UInt uiTimeUntilFirstExecution=0, const eC_Bool bFinished=true)
virtual	~CGUICommand ()
	Destructor.
virtual void	Do ()=0
void	SetToBeFinished (eC_Bool bIsFinished)
Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const
void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const
void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Protected Attributes
eC_Bool	m_bDisabled
	Changeable state: Disabled.
eC_Bool	m_bFocussable
	Changeable state: focusable.
eC_Bool	m_bGrayedOut
	Changeable state: Grayed out.
eC_Bool	m_bInvisible
	Changeable state: Invisible.
eC_Bool	m_bToggle
	Specifies whether the states shall be toggled on/off, or if they will be set exactly as given.
ObjectHandle_t	m_eTargetObject
	Target object ID.

Additional Inherited Members
Static Public Attributes inherited from CGUICommand
static const eC_Char	XMLTAG_ADDITIONALCMDCOUNT []
	XML tag to be used when writing the additional command count into a stream.
static const eC_Char	XMLTAG_COMMANDCLASSID []
	XML tag to be used when writing the command class ID into a stream.
static const eC_Char	XMLTAG_REMOVE_AFTER_EXECUTION []
	XML tag to be used when writing the remove after execution flag.
Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

An example for a custom command that changes the object states of an GUIObject.

The target object is referenced by an object ID that has to be passed to the constructor. When this command is executed, it tries to find the specified object. If no object is found, this command does nothing. If the object is found, the object states are changed according the given values.

Constructor & Destructor Documentation

CGUISetObjectStateCmd()

CGUISetObjectStateCmd::CGUISetObjectStateCmd	(	ObjectHandle_t	eTargetObject,
		eC_Bool	bToggle,
		eC_Bool	bFocusable,
		eC_Bool	bInvisible,
		eC_Bool	bGrayedOut,
		eC_Bool	bDisabled
	)

Constructor.

Parameters

eTargetObject	The ID of the object to be modified by this command.
bToggle	If true, all states marked as "True" will be toggled. Otherwise all states will be set to True/False exactly as given.
bFocusable	New value of the focusable object state.
bInvisible	New value of the invisible object state.
bGrayedOut	New value of the grayed out object state.
bDisabled	New value of the disabled object state.

Member Function Documentation

Do()

void CGUISetObjectStateCmd::Do ( )

protectedvirtual

Implements the actual command functionality.

Implements CGUICommand.

ReadFromStream()

virtual void CGUISetObjectStateCmd::ReadFromStream ( )

virtual

Reads all attributes from streaming file. This method is called by CGUIFactoryManager after one of the registered factories has created an instance of this class.

Reimplemented from CGUICommand.

WriteToStream()

virtual void CGUISetObjectStateCmd::WriteToStream ( const eC_Bool  bWriteClassID = false )

virtual

Writes all attributes to the streaming file. A CGUIStreamWriter has to be initialized first.

Parameters

bWriteClassID

This flag is used to select if writing of command class ID, leading and trailing tags is performed.

Reimplemented from CGUICommand.

---

The documentation for this class was generated from the following file:

• GUISetObjectStateCmd.h
