CGUIImageCacheReplacementPolicy Class Reference

Abstract replacement policy for use with the Guiliani image cache. More...

#include <GUIImageCacheReplacementPolicy.h>

Inheritance diagram for CGUIImageCacheReplacementPolicy:

Public Member Functions
virtual	~CGUIImageCacheReplacementPolicy ()
	Destructor.
virtual eC_Bool	Add (const ImageResource_t &eImageID, eC_UInt uiSize)=0
virtual eC_Bool	Bump (const ImageResource_t &eImageID)
CGUIImageCacheReplacementManager *	GetImageCacheReplacementManager (void)
virtual ReplacementPolicyType_t	GetPolicyType () const =0
virtual ImageResource_t	Remove ()=0

Static Public Member Functions
static CGUIImageCacheReplacementPolicy *	CreateReplacementPolicyForType (const ReplacementPolicyType_t &eType, CGUIImageCacheReplacementManager *pManager)

Protected Attributes
CGUIImageCacheReplacementManager *	m_pCacheManager
	The replacement manager (bridge implementation)

Detailed Description

Abstract replacement policy for use with the Guiliani image cache.

Member Function Documentation

Add()

virtual eC_Bool CGUIImageCacheReplacementPolicy::Add ( const ImageResource_t &  eImageID, eC_UInt  uiSize  )

pure virtual

Adds an image to the pool of replaceable images The image has to be added in the appropriate way for the implemented replacement policy

Parameters

eImageID	the image's ID
uiSize	the image's size

Returns

True if the image was successfully added

Implemented in CGUIImageCacheReplacementDummy, CGUIImageCacheReplacementFifo, CGUIImageCacheReplacementGreedy, and CGUIImageCacheReplacementLru.

Bump()

virtual eC_Bool CGUIImageCacheReplacementPolicy::Bump ( const ImageResource_t &  eImageID )

virtual

Marks an image as recently used, if supported by the replacement policy (Only valid for LRU replacement)

Parameters

eImageID

the image's ID

Returns

True if any action was performed

Reimplemented in CGUIImageCacheReplacementLru.

CreateReplacementPolicyForType()

static CGUIImageCacheReplacementPolicy * CGUIImageCacheReplacementPolicy::CreateReplacementPolicyForType ( const ReplacementPolicyType_t &  eType, CGUIImageCacheReplacementManager *  pManager  )

static

Creates a replacement policy object for a specific policy type

Parameters

eType	the type of replacement policy
pManager	the replacement manager object to be used with the new policy

Returns

the newly created replacement policy

GetImageCacheReplacementManager()

CGUIImageCacheReplacementManager * CGUIImageCacheReplacementPolicy::GetImageCacheReplacementManager

(

void

)

Get the image cache replacement manager of the policy

Returns

A pointer to the image cache manager

GetPolicyType()

virtual ReplacementPolicyType_t CGUIImageCacheReplacementPolicy::GetPolicyType ( ) const

pure virtual

Returns the type of this replacement policy

Returns

the policy type

Implemented in CGUIImageCacheReplacementDummy, CGUIImageCacheReplacementFifo, CGUIImageCacheReplacementGreedy, and CGUIImageCacheReplacementLru.

Remove()

virtual ImageResource_t CGUIImageCacheReplacementPolicy::Remove ( )

pure virtual

Removes an image from the pool of replaceable images The image to be removed is selected in accordance to the replacement policy

Returns

the removed image's ID

Implemented in CGUIImageCacheReplacementDummy, CGUIImageCacheReplacementFifo, CGUIImageCacheReplacementGreedy, and CGUIImageCacheReplacementLru.

---

The documentation for this class was generated from the following file:

• GUIImageCacheReplacementPolicy.h
