The CGUIFileSysWrap class provides an abstract way of accessing directories and files. More...

#include <GUIFileSysWrap.h>

Inheritance diagram for CGUIFileSysWrap:

[legend]

Public Member Functions
	CGUIFileSysWrap ()

virtual	~CGUIFileSysWrap ()
	Destructor, frees the drives list.

virtual eC_Bool	CheckIfDirectoryExists (const eC_String &kPath) const =0

virtual eC_Bool	CheckIfFileExists (const eC_String &kPath) const =0

virtual eC_Bool	CheckIfFileOrDirectoryExists (const eC_String &kPath) const =0

virtual eC_Bool	CpFile (eC_String kSource, eC_String kDest, eC_Bool bOverwrite=false, eC_Bool bCopyEvenIfIdentical=true)=0

virtual eC_Bool	CreateRelativePath (const eC_String &kFromPath, const eC_String &kToPath, eC_String &kResultPath) const

void	DeInit ()

virtual CGUIDirectory *	DirAlloc (const eC_String &kPath, const CGUIDirectory::StringList_t &kNameFilter, eC_UInt uiFilter=CGUIDirectory::ALL, CGUIDirectory::SortFlag_t eSort=CGUIDirectory::NAME, eC_Bool bCaseInsensitive=true) const =0

virtual CGUIDirectory *	DirAlloc (const eC_String &kPath="", const eC_String &kNameFilter="") const =0

eC_String	GetCurrentPath () const

virtual const eC_String &	GetDirSeparator () const =0

virtual const CGUIDirInfo::DirInfoPtrList_t &	GetDrives ()=0

virtual eC_String	GetExecutablePath ()=0

eC_String	GetFileBaseName (const eC_String &rkFileName) const
	Extracts the base name of a file from a name that includes a path. More...

virtual time_t	GetFileDateTime (const eC_String &kPath) const

eC_String	GetFileName (const eC_String &rkFileName) const
	Extracts the file name from a file name that includes a path. More...

virtual long	GetFileSize (const eC_String &kPath) const

eC_String	GetFileSuffix (const eC_String &rkFileName) const
	Extracts the extension of a file name. More...

virtual eC_String	GetHomePath () const =0

eC_String	GetPath (const eC_String &rkFileName) const
	Extracts the path from a file name that includes a path. More...

const eC_String &	GetPOSIXDirSeparator () const

virtual const eC_String &	GetRootPath () const =0

const eC_String &	GetWinDirSeparator () const

virtual eC_Bool	IsDrive (const eC_String &kDirStr) const =0

virtual eC_Bool	IsStrAbsolute (const eC_String &kStr) const =0

eC_Bool	MakeAbsolutePath (const eC_String &kRelPath, eC_String &kAbsPath) const

virtual eC_String	MakeDirectoryPath (const eC_String &kPath) const

virtual eC_Bool	MakeNormalizedPlatformPath (const eC_String &kOrgPath, eC_String &kResultPath) const

virtual eC_String	MakePlatformPath (const eC_String &kOrgPath) const =0

virtual eC_File *	OpenPlatformFile (const eC_String &kPath, eC_Flag uiMode=eC_File::FS_WRITEACCESS\|eC_File::FS_READACCESS) const

virtual eC_Bool	RemoveFile (const eC_String &kPath) const =0

void	SeparateString (const eC_String &kOrgStr, eC_String &kLeftStr, eC_String &kRightStr, const eC_String &kSeparator, eC_Bool bFromLeft) const

virtual eC_Bool	SetCurrentPath (const eC_String &kPath)=0

Static Public Member Functions
static CGUIFileSysWrap &	GetInstance ()

Static Public Attributes
static const eC_String	ms_DirSepPOSIX
	Directory seperator used for *NIX file system.

static const eC_String	ms_DirSepWin
	Directory separator used for windows file system.

Protected Attributes
eC_String	m_kCurrentPath

CGUIDirInfo::DirInfoPtrList_t	m_kDrivesList

Detailed Description

The CGUIFileSysWrap class provides an abstract way of accessing directories and files.

It is an abstract class. There are implementations for different operating systems. Use the GetInstance() static member function to obtain the platform-specific instance.

A starting point for working with directories is the method DirAlloc() which creates a CGUIDirectory instance. From this instance it is possible to access the contents of a directory. The instance must be deleted if it is not used anymore.

This class provides the possibility to get the general paths of the application and operating system. The GetCurrentPath() method gets the working directory of the current process. The home path is obtained by calling GetHomePath(). It is possible to get a list of drives of the operating system by calling the GetDrives() method. A method called IsDrive checks whether the given string stands for a drive or not.

Since the directory separators can differ between various operating systems, you can call GetDirSeparator() to get the directory separator for the operating system that Guiliani is currently running on. All paths used in the CGUIDirectory, CGUIDirInfo, CGUIFileSysWrap and their derived classes can be adapted to conform to the current operating system by calling the MakePlatformPath() method of this class.

There is a helper function called SeparateString() to split a string into two parts at a given separator. This method is used in separating the path and file name, or base name and suffix.

Constructor & Destructor Documentation

◆ CGUIFileSysWrap()

CGUIFileSysWrap::CGUIFileSysWrap ( )

inline

Constructor.

Member Function Documentation

◆ CheckIfDirectoryExists()

virtual eC_Bool CGUIFileSysWrap::CheckIfDirectoryExists ( const eC_String & kPath ) const

pure virtual

Checks if a directory at given path exists.

Parameters

kPath Path to directory for which the existence should be checked.

Returns: True If the directory specified via the path exists or False if its not a directory (for example file).

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ CheckIfFileExists()

virtual eC_Bool CGUIFileSysWrap::CheckIfFileExists ( const eC_String & kPath ) const

pure virtual

Checks if a file at a given path exists.

Parameters

kPath Path to a file for which the existence should be checked.

Returns: True If the file specified via the path exists or False if it is not a file (for example a directory) or a symlink.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ CheckIfFileOrDirectoryExists()

virtual eC_Bool CGUIFileSysWrap::CheckIfFileOrDirectoryExists ( const eC_String & kPath ) const

pure virtual

Checks if a given path exists. The object specified might be a file or directory.

Parameters

kPath Path to a file or directory for which the existence should be checked.

Returns: True If the object specified via the path exists otherwise False.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ CpFile()

virtual eC_Bool CGUIFileSysWrap::CpFile	(	eC_String	kSource,
		eC_String	kDest,
		eC_Bool	bOverwrite = `false`,
		eC_Bool	bCopyEvenIfIdentical = `true`
	)

pure virtual

Copy a file. All file data and file meta information are copied from the source file to the destination file.

If the given destination is a directory that differs from the source directory, the source file is copied to the destination. If the source and destination directories are the same, this method does nothing and returns False.

If the given destination is a file and it is the same file as the source file, this method does nothing and returns False. Otherwise, it checks whether the destination file exists. If the destination file does not exist, a new file is created. Otherwise it checks whether the destination file can be overwritten. If that is the case, the destination file is overwritten if specified.

Parameters

kSource	The source file name including path. If it is a relative path, the current working directory of the file system wrapper is used to complete the path.
kDest	The destination directory or file. If it is a relative path the current working directory of the file system wrapper is used to complete the path.
bOverwrite	Pass true to overwrite the destination file if it already exists.
bCopyEvenIfIdentical	True if we want to copy the files even if they already exist and are identical (modification date, modification time and size). False if we want to skip copying the files which already exists and have the same date,time of modification and size.

Returns: True if successful, otherwise False.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ CreateRelativePath()

virtual eC_Bool CGUIFileSysWrap::CreateRelativePath	(	const eC_String &	kFromPath,
		const eC_String &	kToPath,
		eC_String &	kResultPath
	)		const

virtual

Create a relative path from one directory to another directory. Example: From: "C:\projects\GSE\my_streamruntime\bin" To: "C:\projects\TestPlatform\testdata" Result: "..\..\..\TestPlatform\testdata" The returned path does not contain a trailing directory separator.

Parameters

kFromPath	The directory the result path will be relative to.
kToPath	The destination directory.
kResultPath	The resulting path.

Returns: True if successful, False otherwise (i.e. if "From" and "To" path are on different drives).

◆ DeInit()

void CGUIFileSysWrap::DeInit ( )

Frees all internally allocated resources. Do not call this method from user code, it is called by Guiliani when shutting down.

◆ DirAlloc() [1/2]

virtual CGUIDirectory * CGUIFileSysWrap::DirAlloc	(	const eC_String &	kPath,
		const CGUIDirectory::StringList_t &	kNameFilter,
		eC_UInt	uiFilter = `CGUIDirectory::ALL`,
		CGUIDirectory::SortFlag_t	eSort = `CGUIDirectory::NAME`,
		eC_Bool	bCaseInsensitive = `true`
	)		const

pure virtual

Allocate a CGUIDirectory instance by giving the path. The instance should be deleted after the user finishes using it.

Parameters

kPath	The kPath for the directory that is passed as a parameter of the CGUIDirectory constructor.
kNameFilter	The name filters to filter the directory that is passed as a parameter of the CGUIDirectory constructor.
uiFilter	The filter attribute to filter the directory that is passed as a parameter of the CGUIDirectory constructor.
eSort	The sort kind to sort the directory that is passed as a parameter of the CGUIDirectory constructor.
bCaseInsensitive	The bool value to indicate whether sort the elements in the directory case-insensitive or not. This is also a parameter of the CGUIDirectory constructor.

Returns: Pointer to the allocated CGUIDirectory instance.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ DirAlloc() [2/2]

virtual CGUIDirectory * CGUIFileSysWrap::DirAlloc	(	const eC_String &	kPath = `""`,
		const eC_String &	kNameFilter = `""`
	)		const

pure virtual

Allocate a CGUIDirectory instance using the given path. The instance should be deleted after the user finishes using it.

Parameters

kPath	The directory path; directly passed to the CGUIDirectory constructor.
kNameFilter	The filter string; directly passed to the CGUIDirectory constructor.

Returns: Pointer to the allocated CGUIDirectory instance.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetCurrentPath()

eC_String CGUIFileSysWrap::GetCurrentPath ( ) const

inline

Returns the absolute path name of the current working directory.

Note: Under Windows CE there is no concept of a "current working directory". Only the directory where the application was started from can be returned.

Returns: The absolute path of the application's current directory.

◆ GetDirSeparator()

virtual const eC_String & CGUIFileSysWrap::GetDirSeparator ( ) const

pure virtual

Gets the directory separator.

Returns: The directory separator.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetDrives()

virtual const CGUIDirInfo::DirInfoPtrList_t & CGUIFileSysWrap::GetDrives ( )

pure virtual

Gets a list of the root directories on this system.

Returns: The list of the drives.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetExecutablePath()

virtual eC_String CGUIFileSysWrap::GetExecutablePath ( )

pure virtual

Returns the absolute path to the current executable

Returns: executable path

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetFileBaseName()

eC_String CGUIFileSysWrap::GetFileBaseName ( const eC_String & rkFileName ) const

Extracts the base name of a file from a name that includes a path.

Example: path/subpath/filename.ext will become filename

Parameters

rkFileName The full file name to be examined.

Returns: The file's base name without path and extension (extension begins after the filename's last dot)

Remarks: This method only performs string operations. It does not check for existence of paths or files.

◆ GetFileDateTime()

virtual time_t CGUIFileSysWrap::GetFileDateTime ( const eC_String & kPath ) const

virtual

Get the last time of modification of the file

Parameters

kPath Full filename (including path) of the file which is getting the last modification

Returns: time and date of the last modification

Reimplemented in CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetFileName()

eC_String CGUIFileSysWrap::GetFileName ( const eC_String & rkFileName ) const

Extracts the file name from a file name that includes a path.

Example: path/subpath/filename.ext will become filename.ext

Parameters

rkFileName The full file name to be examined.

Returns: The file name without the path.

Remarks: This method only performs string operations. It does not check for existence of paths or files.

◆ GetFileSize()

virtual long CGUIFileSysWrap::GetFileSize ( const eC_String & kPath ) const

virtual

Get the size of the file

Parameters

kPath Full filename (including path) of the file which is getting the size

Returns: size of the file

Reimplemented in CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetFileSuffix()

eC_String CGUIFileSysWrap::GetFileSuffix ( const eC_String & rkFileName ) const

Extracts the extension of a file name.

Example: path/subpath/filename.ext.ext2 will become ext2

Parameters

rkFileName The full file name to be examined.

Returns: The extension without path and file name.

Remarks: This method only performs string operations. It does not check for existence of paths or files.

◆ GetHomePath()

virtual eC_String CGUIFileSysWrap::GetHomePath ( ) const

pure virtual

Get the current user's home path.

Returns: User's home path.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetInstance()

CGUIFileSysWrap & CGUIFileSysWrap::GetInstance ( )

static

return instance

Returns: instance

◆ GetPath()

eC_String CGUIFileSysWrap::GetPath ( const eC_String & rkFileName ) const

Extracts the path from a file name that includes a path.

Parameters

rkFileName The full file name to be examined.

Returns: The path without the file name.

Remarks: This method only performs string operations. It does not check for existence of paths or files.

◆ GetPOSIXDirSeparator()

const eC_String & CGUIFileSysWrap::GetPOSIXDirSeparator ( ) const

inline

Returns the *NIX directory separator.

Returns: An eC_String containing a slash.

◆ GetRootPath()

virtual const eC_String & CGUIFileSysWrap::GetRootPath ( ) const

pure virtual

Gets the absolute path for the root directory.

Returns: The absolute path for the root directory.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ GetWinDirSeparator()

const eC_String & CGUIFileSysWrap::GetWinDirSeparator ( ) const

inline

Returns the windows directory separator.

Returns: An eC_String containing a backslash.

◆ IsDrive()

virtual eC_Bool CGUIFileSysWrap::IsDrive ( const eC_String & kDirStr ) const

pure virtual

Check whether the given directory string represents a drive or not.

Parameters

kDirStr The directory string to be checked.

Returns: True if the directory name represents a drive; otherwise False.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ IsStrAbsolute()

virtual eC_Bool CGUIFileSysWrap::IsStrAbsolute ( const eC_String & kStr ) const

pure virtual

Help function to check whether the given path string is an absolute path or not.

Parameters

kStr	The given path.

Returns: True, if it is an absolute path; False otherwise.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ MakeAbsolutePath()

eC_Bool CGUIFileSysWrap::MakeAbsolutePath	(	const eC_String &	kRelPath,
		eC_String &	kAbsPath
	)		const

Converts a relative path to an absolute path using the current directory.

Parameters

kRelPath	relative path
kAbsPath	absolute path as return value

Returns: true, if successful, false otherwise

◆ MakeDirectoryPath()

virtual eC_String CGUIFileSysWrap::MakeDirectoryPath ( const eC_String & kPath ) const

virtual

Adds a dir separator at the end of the given path, if there isn't already one.

Parameters

kPath Path to adjust.

Returns: The resulting string

◆ MakeNormalizedPlatformPath()

virtual eC_Bool CGUIFileSysWrap::MakeNormalizedPlatformPath	(	const eC_String &	kOrgPath,
		eC_String &	kResultPath
	)		const

virtual

Adjust the path with the correct path separator according to the operating system and remove all occurrences of "..". (i.e. "C:\projects\x\..\y\project" becomes "C:\projects\y\project"). After the path is adjusted, the returned path does not contain a trailing directory separator except when it is a root path (i.e. "/" or "C:\").

Parameters

kOrgPath	The original path to be adjusted.
kResultPath	The resulting path.

Returns: True if successful, False otherwise.

◆ MakePlatformPath()

virtual eC_String CGUIFileSysWrap::MakePlatformPath ( const eC_String & kOrgPath ) const

pure virtual

Adjust the path with the correct path separator according to the operating system. After the path is adjusted, the returned path does not contain a trailing directory separator except when it is a root path (i.e. "/" or "C:\").

Parameters

kOrgPath The original path to be adjusted.

Returns: The resulting platform-conforming path.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ OpenPlatformFile()

virtual eC_File * CGUIFileSysWrap::OpenPlatformFile	(	const eC_String &	kPath,
		eC_Flag	uiMode = `eC_File::FS_WRITEACCESS\|eC_File::FS_READACCESS`
	)		const

virtual

Opens the given file from the platform's filesystem. This method is useful for getting write-access to the filesystem. If you are looking for plain read-access and you wish to support Guiliani's Resource-File and Resource-Header feature, you should use the CGUIResourceFileHander and it's Open()-Interface instead.

Parameters

kPath	Full filename (including path) of the file which shall be opened
uiMode	Requested access mode (see eC_File for details)

Returns: Pointer to newly allocated and opened file. Note that it is in the caller's responsibility to close and free this file! You should check the returned file for errors using eC_File's interfaces.

Reimplemented in CGUIFileSysWrapWin.

◆ RemoveFile()

virtual eC_Bool CGUIFileSysWrap::RemoveFile ( const eC_String & kPath ) const

pure virtual

Removes the file specified with the given absolute path name

Parameters

kPath Name of the file to be deleted

Returns: True if successful; otherwise False.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

◆ SeparateString()

void CGUIFileSysWrap::SeparateString	(	const eC_String &	kOrgStr,
		eC_String &	kLeftStr,
		eC_String &	kRightStr,
		const eC_String &	kSeparator,
		eC_Bool	bFromLeft
	)		const

Help function used to split a string at a given separator. The result strings do not contain the separator. If the bFromLeft is true, it checks the first appearance of the separator from the beginning (left) of the string. If it is false, it checks the first appearance of the separator from end (right) of the string. If the separator character is not found, the kLeftStr result string takes the original one, and kRightStr is left empty.

Parameters

kOrgStr	The original string that needs to be analyzed.
kLeftStr	The left part of the result string.
kRightStr	The right part of the result string.
kSeparator	The separator character stored as a string.
bFromLeft	Indicate whether the first appearance of the separator is searched from left or right (beginning or end) of kOrgStr.

◆ SetCurrentPath()

virtual eC_Bool CGUIFileSysWrap::SetCurrentPath ( const eC_String & kPath )

pure virtual

Sets the application's current working directory to path. If the path is not an absolute path, it does not change the current working directory and returns False.

Parameters

kPath The path to set

Returns: True if the directory was successfully changed; otherwise False.

Implemented in CGUIFileSysWrapDummy, CGUIFileSysWrapPOSIX, and CGUIFileSysWrapWin.

Member Data Documentation

◆ m_kCurrentPath

eC_String CGUIFileSysWrap::m_kCurrentPath

protected

The current application path.

◆ m_kDrivesList

CGUIDirInfo::DirInfoPtrList_t CGUIFileSysWrap::m_kDrivesList

protected

The list of drives in the system. It is initialized every time the user calls GetDrives.

The documentation for this class was generated from the following files:

GUIFileSysWrap.h
GUIFileSysWrapDummy.cpp

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ CGUIFileSysWrap()

Member Function Documentation

◆ CheckIfDirectoryExists()

◆ CheckIfFileExists()

◆ CheckIfFileOrDirectoryExists()

◆ CpFile()

◆ CreateRelativePath()

◆ DeInit()

◆ DirAlloc() [1/2]

◆ DirAlloc() [2/2]

◆ GetCurrentPath()

◆ GetDirSeparator()

◆ GetDrives()

◆ GetExecutablePath()

◆ GetFileBaseName()

◆ GetFileDateTime()

◆ GetFileName()

◆ GetFileSize()

◆ GetFileSuffix()

◆ GetHomePath()

◆ GetInstance()

◆ GetPath()

◆ GetPOSIXDirSeparator()

◆ GetRootPath()

◆ GetWinDirSeparator()

◆ IsDrive()

◆ IsStrAbsolute()

◆ MakeAbsolutePath()

◆ MakeDirectoryPath()

◆ MakeNormalizedPlatformPath()

◆ MakePlatformPath()

◆ OpenPlatformFile()

◆ RemoveFile()

◆ SeparateString()

◆ SetCurrentPath()

Member Data Documentation

◆ m_kCurrentPath

◆ m_kDrivesList
