Behaviour for repeating clicks on object Additional phases can be defined where the start-time of the phase is measured from the beginning of the previous phase. More...

#include <GUIAutoRepeatBehaviour.h>

Inheritance diagram for CGUIAutoRepeatBehaviour:

[legend]

Public Member Functions
	CGUIAutoRepeatBehaviour ()
	Default constructor.

	CGUIAutoRepeatBehaviour (const eC_Bool &bUseLongClick, const eC_UInt &uiInitialDelay, const eC_UInt &uiInterval)

void	AddAdditionalPhase (const eC_UInt &uiStartTime, const eC_UInt &uiInterval)

eC_UInt	GetNumberOfAdditionalPhases () const

virtual void	ReadFromStream ()

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIBehaviourDecorator
virtual	~CGUIBehaviourDecorator ()

virtual CGUIBehaviourDecorator *	Clone () const

virtual eC_Bool	IsCompositeBehaviour () const

Public Member Functions inherited from CGUIBehaviour
virtual eC_Bool	DoUserEvent (CGUIEvent *const pEvent)

virtual void	OnCreate ()

virtual void	OnDelete ()

virtual void	OnHide ()

virtual void	OnShow ()

virtual eC_Bool	DoDoubleClick (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoDrag (const eC_Value &vDeltaX=eC_FromInt(-1), const eC_Value &vDeltaY=eC_FromInt(-1), const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseEnter (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseLeave (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	DoMouseMove (const eC_Value &vAbsX=eC_FromInt(-1), const eC_Value &vAbsY=eC_FromInt(-1))

virtual eC_Bool	FocusPrevious (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual eC_Bool	FocusNext (CGUIObject *const pRefObj=NULL, const eC_Bool &bSubTreeOfRefObjDone=false)

virtual void	GetFocus ()

virtual void	LoseFocus ()

virtual eC_Bool	Decrease ()

virtual eC_Bool	Increase ()

virtual eC_Bool	DoKeyDown (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoKeyUp (const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoChar (const eC_UInt &uiKey, const GUIKeyIdentifier_t &eKeyIdentifier, const eC_UInt &uiModifiers)

virtual eC_Bool	DoScrollUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollLeft (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoScrollRight (const eC_Value &vAbsX, const eC_Value &vAbsY)

Public Member Functions inherited from CGUIStreamableObject
const eC_String &	GetXMLTag () const

virtual void	ReadFromStream ()

void	SetXMLTag (const eC_String &kXMLTag)

virtual void	WriteToStream (const eC_Bool bWriteClassID=false)

Public Member Functions inherited from CGUIAnimatable
virtual	~CGUIAnimatable ()
	Destructor. Removes all existing animation callbacks.

virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	IsAnimating () const

virtual void	StartAnimation ()

virtual void	StopAnimation ()

Protected Member Functions
virtual void	DoAnimate (const eC_Value &vTimes=eC_FromInt(1))

virtual eC_Bool	DoButtonDown (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoButtonUp (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoClick (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoDragEnd (const eC_Value &vAbsX, const eC_Value &vAbsY)

virtual eC_Bool	DoLongClick (const eC_Value &vAbsX, const eC_Value &vAbsY)

Protected Member Functions inherited from CGUIBehaviourDecorator
	CGUIBehaviourDecorator (CGUIObject *const pkObject=NULL)

	CGUIBehaviourDecorator (const CGUIBehaviourDecorator &kSource)

virtual void	AssociatedObjectChanges (CGUIObject *const pkNewAssociatedObject)

CGUIObject *	GetAssociatedObject () const

Protected Member Functions inherited from CGUIStreamableObject
eC_UInt	ReadStreamingHeader (const eC_UInt &uiClassVersion, const eC_UInt &uiClassMinVersion=0) const

void	WriteStreamingFooter (const eC_Bool &bWriteClassID) const

void	WriteStreamingHeader (const eC_Bool &bWriteClassID, const eC_Char *const pkClassIDTag, const eC_Int &iClassID, const eC_UInt &uiClassVersion) const

Additional Inherited Members
Static Public Attributes inherited from CGUIBehaviour
static const eC_Char	XMLTAG_BEHAVIOURCLASSID []
	XML tag to be used when writing a behaviour class ID into a stream.

Static Public Attributes inherited from CGUIStreamableObject
static const eC_Char	XMLTAG_CLASSVERSION []

Detailed Description

Behaviour for repeating clicks on object Additional phases can be defined where the start-time of the phase is measured from the beginning of the previous phase.

Constructor & Destructor Documentation

◆ CGUIAutoRepeatBehaviour()

CGUIAutoRepeatBehaviour::CGUIAutoRepeatBehaviour	(	const eC_Bool &	bUseLongClick,
		const eC_UInt &	uiInitialDelay,
		const eC_UInt &	uiInterval
	)

Constructor

Parameters

bUseLongClick
uiInitialDelay
uiInterval

Member Function Documentation

◆ AddAdditionalPhase()

void CGUIAutoRepeatBehaviour::AddAdditionalPhase	(	const eC_UInt &	uiStartTime,
		const eC_UInt &	uiInterval
	)

Add an additional autorepeat-phase

Parameters

uiStartTime	the start-time of the new phase calculated from the beginning of the previous phase
uiInterval	the interval of the new phase

◆ DoAnimate()

virtual void CGUIAutoRepeatBehaviour::DoAnimate ( const eC_Value & vTimes = eC_FromInt(1) )

protectedvirtual

Called when the timer of an animation callback belonging to this animatable has expired.

Parameters

vTimes The factor of the registered callback time in relation to the actually elapsed time. For example, the elapsed time is 80ms, and the standard time is 50ms, then vTimes is 1.6. If the given time in GETTIMER.AddAnimationCallback is 0, It will be set to -1.

Reimplemented from CGUIAnimatable.

◆ DoButtonDown()

virtual eC_Bool CGUIAutoRepeatBehaviour::DoButtonDown	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse button or finger is pressed down over an object.

Note: DoButtonDown() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on the object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the object was pressed relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoButtonUp()

virtual eC_Bool CGUIAutoRepeatBehaviour::DoButtonUp	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the mouse button or finger is released. The object under the mouse at the time of releasing will receive this event.

Note: DoButtonUp() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see in this state. Thus, to calculate the relative position (where the button was released relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the mouse was released.
vAbsY	Y-position in screen coordinates where the mouse was released.

Returns: True The event has been handled.
False The event has not been handled. In this base implementation always returns False.

Reimplemented from CGUIBehaviour.

◆ DoClick()

virtual eC_Bool CGUIAutoRepeatBehaviour::DoClick	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when the object receives a click event. A click can e.g., be the result of a mouse click, a finger press/release sequence on touchscreens, or be triggered by a GK_ACTION keyboard event.

Note: DoClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and released at the same position for in a certain time span, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ DoDragEnd()

virtual eC_Bool CGUIAutoRepeatBehaviour::DoDragEnd	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called on the dragged object (=the object on which the initial ButtonDown-event occurred) when the mouse button is released after a drag event.

Parameters

vAbsX	current X-position in screen coordinates of the mouse
vAbsY	current Y-position in screen coordinates of the mouse

Returns: True If the event has been handled.
false Else.

Reimplemented from CGUIBehaviour.

◆ DoLongClick()

virtual eC_Bool CGUIAutoRepeatBehaviour::DoLongClick	(	const eC_Value &	vAbsX,
		const eC_Value &	vAbsY
	)

protectedvirtual

Called when an object is pressed for a longer period of time.

See also: CGUIEventHandler::SetLongClickTime()

Note: DoLongClick() should work on the absolute positions of this object, that were set at the time of the passed redraw, as the user expects to click on what he sees and not to click on an object in a newer and probably intermediate state that he currently does not see. Thus, to calculate the relative position (where the mouse button was pressed and held down at the same position for a certain amount of time, relative to the origin of this object) from the vAbsY argument you must do it like this: vMyRelYPos = vAbsY - GetAbsYPos().

Parameters

vAbsX	X-position in screen coordinates where the click occurred
vAbsY	Y-position in screen coordinates where the click occurred

Returns: True The event has been handled.
False The event has not been handled. In this base implementation it always returns False.

Reimplemented from CGUIBehaviour.

◆ GetNumberOfAdditionalPhases()

eC_UInt CGUIAutoRepeatBehaviour::GetNumberOfAdditionalPhases ( ) const

Get number of defined additional phases

Returns: number of additional phases

◆ ReadFromStream()

virtual void CGUIAutoRepeatBehaviour::ReadFromStream ( )

virtual

Reads all attributes from streaming file. This method is called by CGUIFactoryManager after one of the registered factories has created an instance of this class.

Reimplemented from CGUIStreamableObject.

◆ WriteToStream()

virtual void CGUIAutoRepeatBehaviour::WriteToStream ( const eC_Bool bWriteClassID = false )

virtual

Writes all attributes to the streaming file. A CGUIStreamWriter has to be initialized first.

Parameters

bWriteClassID This flag is used to select if writing of command class ID, leading and trailing tags is performed.

Reimplemented from CGUIStreamableObject.

The documentation for this class was generated from the following file:

GUIAutoRepeatBehaviour.h
