CFontCache Class Reference

FontCache is the base-class for glyph-cache. More...

#include <FontCache.h>

Inheritance diagram for CFontCache:

Classes
struct	CachedChar_t
	struct for holding the unicode and a pointer to the related info-block More...
struct	CachedCharInfo_t

Public Member Functions
	CFontCache (const FontResource_t &eFontID, const eC_UInt &uiInitialCacheSize, const eC_Bool &bAutoResize, const eC_UInt &uiResizeBy)
virtual	~CFontCache ()
eC_Int	GetAscender () const
CachedChar_t	GetChar (const eC_UInt &uiUnicode)
eC_Int	GetDescender () const
void *	GetFace ()
eC_Int	GetHeight () const
eC_Int	GetInternalLeading () const

Protected Member Functions
	CFontCache (const CFontCache &kSource)
virtual CachedChar_t	AddChar (const eC_UInt &uiUnicode, const eC_UInt &uiPos)=0
eC_Int	FindChar (const eC_UInt &uiUnicode)
eC_UInt	FindLowestTimestampPos ()
CFontCache &	operator= (const CFontCache &kSource)
virtual void	RemoveChar (const eC_UInt &uiPos)
void	Sort ()
void	Swap (CachedChar_t *pPosA, CachedChar_t *pPosB)

Protected Attributes
eC_TArray< CachedChar_t >	m_asCache
	The dynamic cache array.
eC_Bool	m_bArrayNeedsSorting
	sorting needed after modification
eC_Bool	m_bAutoResize
	auto-resize
eC_Bool	m_bUseTimeStamp
	timestamp
FontResource_t	m_eFontID
	loaded font
eC_Int	m_iAscender
	ascender
eC_Int	m_iDescender
	descender
eC_Int	m_iHeight
	height of font
eC_Int	m_iInternalLeading
	internal leading
void *	m_pkFace
	face of font
eC_UInt	m_uiNextGlyphIndex
	index of next glyph
eC_UInt	m_uiResizeBy
	resize by amount
eC_UInt	m_uiTimer
	current timer

Detailed Description

FontCache is the base-class for glyph-cache.

It stores the cache information for one Font.

Constructor & Destructor Documentation

CFontCache() [1/2]

CFontCache::CFontCache	(	const FontResource_t &	eFontID,
		const eC_UInt &	uiInitialCacheSize,
		const eC_Bool &	bAutoResize,
		const eC_UInt &	uiResizeBy
	)

Constructor

Parameters

eFontID	ID of selected font.
uiInitialCacheSize	initial number of simultaneously cached characters. If parameter equals zero the cache will automatically be resized to be large enough to contain all required characters.
bAutoResize	if true the cache gets resized if not big enough to hold new entries
uiResizeBy	number of elements which are added on resize

~CFontCache()

virtual CFontCache::~CFontCache ( )

virtual

Destructor

CFontCache() [2/2]

CFontCache::CFontCache ( const CFontCache &  kSource )

protected

Copy-constructor. Dummy implementation to avoid unintended use of compiler-generated default

Parameters

kSource

Member Function Documentation

AddChar()

virtual CachedChar_t CFontCache::AddChar ( const eC_UInt &  uiUnicode, const eC_UInt &  uiPos  )

protectedpure virtual

Adds a character to the cache array and sorts array afterwards.

Parameters

uiUnicode	Unicode to add to array.
uiPos	Position in array where the character should be added.

Returns

Struct of added character.

Implemented in CFontCacheFreeType, and CFontCacheGlyphLib.

FindChar()

eC_Int CFontCache::FindChar ( const eC_UInt &  uiUnicode )

protected

Searches for a character inside the cache array by using divide and conquer.

Parameters

uiUnicode

Character to search for.

Returns

Position in array of -1 if not found.

FindLowestTimestampPos()

eC_UInt CFontCache::FindLowestTimestampPos ( )

protected

Searches the list for the lowest timestamp and return that position.

Returns

Lowest timestamp position in array.

GetAscender()

eC_Int CFontCache::GetAscender ( ) const

inline

Returns the ascender of the current font.

Returns

Font's ascender.

GetChar()

CachedChar_t CFontCache::GetChar

(

const eC_UInt &

uiUnicode

)

This method returns a struct with the wanted character's information. It adds a character to the cache array if it does not exist.

Parameters

uiUnicode

Unicode of wanted character.

Returns

Struct of wanted character.

GetDescender()

eC_Int CFontCache::GetDescender ( ) const

inline

Returns the descender of the current font.

Returns

Font's descender.

GetFace()

void * CFontCache::GetFace ( )

inline

get internal face from font

Returns

face

GetHeight()

eC_Int CFontCache::GetHeight ( ) const

inline

Returns the height of current font.

Returns

Font's height.

GetInternalLeading()

eC_Int CFontCache::GetInternalLeading ( ) const

inline

Returns the internal leading of the current font.

Returns

Font's internal leading.

operator=()

CFontCache & CFontCache::operator= ( const CFontCache &  kSource )

protected

Operator= method. Dummy implementation to avoid unintended use of compiler-generated default

Parameters

kSource

Returns

RemoveChar()

virtual void CFontCache::RemoveChar ( const eC_UInt &  uiPos )

protectedvirtual

Removes a character from array.

Parameters

uiPos

Position of the character to remove.

Sort()

void CFontCache::Sort ( )

protected

Sorts the cache list by unicode in ascending order using bubble sort algorithm.

Swap()

void CFontCache::Swap ( CachedChar_t *  pPosA, CachedChar_t *  pPosB  )

protected

Swaps two given values.

Parameters

pPosA	Pointer of the first value.
pPosB	Pointer of the second value.

---

The documentation for this class was generated from the following file:

• FontCache.h
