CFntWrapGLFontAtlas Class Reference

#include <FntWrapGLFontAtlas.h>

Inheritance diagram for CFntWrapGLFontAtlas:

Classes
struct	FontAtlasRecord_t
	Struct representing one character inside the cache array. More...

Public Member Functions
	CFntWrapGLFontAtlas (const FontResource_t &reFontID, const eC_UInt &uiNumberOfRows)
virtual	~CFntWrapGLFontAtlas ()
eC_Int	GetAscender () const
FontAtlasRecord_t	GetChar (const eC_UInt &uiUnicode)
eC_Int	GetDescender () const
virtual void *	GetFace ()=0
eC_Int	GetHeight () const
eC_Int	GetInternalLeading () const
eC_UInt	GetTextureHeight () const
eC_UInt	GetTextureID () const
eC_UInt	GetTextureWidth () const

Protected Member Functions
virtual FontAtlasRecord_t	AddGlyph (const eC_UInt &uiUnicode)=0
eC_UInt	CreateTexture (const eC_Int &iTextureWidth, const eC_Int &iTextureHeight, const eC_UInt &uiLastTextureID=0)
void	DeleteTexture (const eC_UInt &uiTextureID)
eC_UInt	InsertGlyphInformation (const eC_UInt &uiUnicode, const eC_UInt &uiWidth, const eC_Int &iGlyphXPos, const eC_Int &iGlyphYPos, const eC_Int &iGlyphWidth, const eC_Int &iGlyphHeight, const eC_UInt &uiXPos, const eC_UInt &uiYPos)

Protected Attributes
eC_TArray< FontAtlasRecord_t >	m_asGlyphCache
	The dynamic cache array.
eC_Bool	m_bArrayNeedsSorting
	Flag indicating that the internal array of stored characters needs to be sorted.
FontResource_t	m_eFontID
	id of loaded font
eC_Int	m_iAscender
	ascender
eC_Int	m_iDescender
	descender
eC_Int	m_iFontHeight
	height of font
eC_Int	m_iFontWidth
	width of font
eC_Int	m_iInternalLeading
	internal leading
eC_UInt	m_uiCurrentFillRow
	current row for new characters
eC_UInt	m_uiNumberOfCachedGlyphs
	number of cached glyphs
eC_UInt	m_uiRemainingSpace
	remaining pixels of storage for current row
eC_UInt	m_uiTextureHeight
	height of generated texture
eC_UInt	m_uiTextureID
	texture-id for the atlas
eC_UInt	m_uiTextureWidth
	width of generated texture
eC_UInt	m_uiTotalNumberOfRows
	number of rows which can be used for storage

Detailed Description

This class is used by FntWrapFreeTypeGL. It stores the texture-atlas information for one Font.

Constructor & Destructor Documentation

CFntWrapGLFontAtlas()

CFntWrapGLFontAtlas::CFntWrapGLFontAtlas	(	const FontResource_t &	reFontID,
		const eC_UInt &	uiNumberOfRows
	)

Constructor

Parameters

reFontID	ID of selected font.
uiNumberOfRows	Initial number of rows for the texture atlas.

~CFntWrapGLFontAtlas()

virtual CFntWrapGLFontAtlas::~CFntWrapGLFontAtlas ( )

virtual

Destructor

Member Function Documentation

AddGlyph()

virtual FontAtlasRecord_t CFntWrapGLFontAtlas::AddGlyph ( const eC_UInt &  uiUnicode )

protectedpure virtual

Adds a character to the cache array and sorts array afterwards.

Parameters

uiUnicode

Unicode to add to array.

Returns

Struct of just added character.

Implemented in CFntWrapFreeTypeGLFontAtlas, and CFntWrapGlyphLibGLFontAtlas.

CreateTexture()

eC_UInt CFntWrapGLFontAtlas::CreateTexture ( const eC_Int &  iTextureWidth, const eC_Int &  iTextureHeight, const eC_UInt &  uiLastTextureID = 0  )

protected

create a texture with the given dimensions

Parameters

iTextureWidth	width
iTextureHeight	height
uiLastTextureID	ID of last generated texture for font

Returns

id of the new texture

DeleteTexture()

void CFntWrapGLFontAtlas::DeleteTexture ( const eC_UInt &  uiTextureID )

protected

delete the texture

Parameters

uiTextureID

GetAscender()

eC_Int CFntWrapGLFontAtlas::GetAscender ( ) const

inline

Returns the ascender of the current font.

Returns

Font's ascender.

GetChar()

FontAtlasRecord_t CFntWrapGLFontAtlas::GetChar

(

const eC_UInt &

uiUnicode

)

This method returns a struct with the wanted character's information. It adds a character to the cache array if it does not exist.

Parameters

uiUnicode

Unicode of wanted character.

Returns

Struct of wanted character.

GetDescender()

eC_Int CFntWrapGLFontAtlas::GetDescender ( ) const

inline

Returns the descender of the current font.

Returns

Font's descender.

GetFace()

virtual void * CFntWrapGLFontAtlas::GetFace ( )

pure virtual

return the current face

Returns

face

Implemented in CFntWrapFreeTypeGLFontAtlas, and CFntWrapGlyphLibGLFontAtlas.

GetHeight()

eC_Int CFntWrapGLFontAtlas::GetHeight ( ) const

inline

Returns the height of current font.

Returns

Font's height.

GetInternalLeading()

eC_Int CFntWrapGLFontAtlas::GetInternalLeading ( ) const

inline

Returns the internal leading of the current font.

Returns

Font's internal leading.

GetTextureHeight()

eC_UInt CFntWrapGLFontAtlas::GetTextureHeight ( ) const

inline

Return the height of the used texture

Returns

height of texture

GetTextureID()

eC_UInt CFntWrapGLFontAtlas::GetTextureID ( ) const

inline

Returns the internal ID for the used texture

Returns

texture-id

GetTextureWidth()

eC_UInt CFntWrapGLFontAtlas::GetTextureWidth ( ) const

inline

Return the width of the used texture

Returns

width of texture

InsertGlyphInformation()

eC_UInt CFntWrapGLFontAtlas::InsertGlyphInformation ( const eC_UInt &  uiUnicode, const eC_UInt &  uiWidth, const eC_Int &  iGlyphXPos, const eC_Int &  iGlyphYPos, const eC_Int &  iGlyphWidth, const eC_Int &  iGlyphHeight, const eC_UInt &  uiXPos, const eC_UInt &  uiYPos  )

protected

add the information for a new glyph

Parameters

uiUnicode	code-point
uiWidth	width of glyph
iGlyphXPos	x-position
iGlyphYPos	y-position
iGlyphWidth	width
iGlyphHeight	height
uiXPos	x-position inside texture
uiYPos	y-position inside texture

Returns

index of the new glyph

---

The documentation for this class was generated from the following file:

• FntWrapGLFontAtlas.h
